Regent Lighting Solutions Olympia Pro User manual

1
2
www.regentlight.co.za
www.regentlight.co.za
INSTALLATION INSTRUCTIONS
ALL CONNECTIONS TO BE CARRIED OUT BY A QUALIFIED ELECTRICIAN
ALL CONNECTIONS TO BE CARRIED OUT BY A QUALIFIED ELECTRICIAN
1
PLEASE READ CAREFULLY BEFORE STARTING INSTALLATION.
PLEASE READ CAREFULLY BEFORE STARTING INSTALLATION.
Electrical products can cause death, injury, or damage to property.
Installation of this product must be carried out by a qualified electrician, in
compliance with SANS 10142 or corresponding regulations of the country of
installation. On completion of installation, the Certificate of Compliance must
be updated.
Olympia pro
WARNING
Electronic Control Device
Electronic Control Device
WARNING
3 - 13 MAIN REEF SERVICE ROAD, CORNER
SPRINGBOK AND MAIN REEF ROAD, INDUSTRIA,
JOHANNESBURG. SOUTH AFRICA.
TEL : [phone]
www.regentlight.co.za
RE GENT L I GHT ING A D IVIS ION
OF WA HL IND USTR IES.
Save These Instructions for Future Reference
Save These Instructions for Future Reference
ELECTRIC SHOCK
HAZARD
This equipment is to be
serviced by trained
personnel only.
ELECTRIC SHOCK
HAZARD
This equipment is to be
serviced by trained
personnel only.
Surface mounted and Suspended option available
Olympia pro recessed mounted
DO NOT CONNECT THE FITTING LIVE
June 2021
2
3
L Bracket
ŸIf the main supply power (live)
is on, it will cause damage to
the luminaries.
Requirements:
ŸBe sure the electricity to the
system you are working on is
isolated.
1. Fitting as supplied in Regent
Lighting Solutions box.
For non user replaceable light source: The light source contained in this luminaire
shall only be replacedby the manufacturer or his/her service
agent or a similar qualied person
1
DO NOT PLUG
(CONNECT) WHEN
LIVE AS IT WILL CAUSE
DAMAGE TO THE
LUMINAIRE.
2. Hole cut out 365 x 365 mm
on the ceiling
3. Insert Olympia frame and
secure onto soft surface using
L brackets onto frame.
Regent Lighting reserves the right to change specifications modify designs and discontinue items without
incurring obligation and whilst every effort is made to ensure that descriptions, specifications and other
information in this catalogue are correct, no warranty is given in respect thereof and the company shall not be
liable for any error therein.
TURN OFF POWER AT CIRCUIT BREAKER OR FUSE AND TEST THAT THE POWER IS OFF BEFORE WIRING
WARNING: TO AVOID FIRE, SHOCK OR DEATH
ALL LUMINAIRES SUPPLIED AND TO BE INSTALLED ABOVE AND BELOW 5 METERS ARE IN COMPLIANCE WITH SANS
60598 SECTION 3.5.6 ACCORDING TO THE MANUFACTURER GUARANTEE AND WARRANTY
Sensor Version
optional
365
365
Ceiling cut out

www.regentlight.co.za
www.regentlight.co.za
4
8
This product should be installed by a competent person i.e. Qualified electrician.
This product requires a constant stable electrical supply 220V - 240V VAC 50Hz - alternating current.
The product must be regularly maintained, including the replacement of lamps/LED timeously.
This product could be HAZARDOUS if not used correctly, it could cause electric shock, serious bodily harm or death.
This product is not a toy, please keep away from children.
This product may contain small parts that can be swallowed.
Use only the correct light bulbs/LED as stipulated on the carton for the product.
Any modifications of this product after supply will result in the guarantee being void.
Spare parts may become unavailable over time.Items can vary slightly from the picture on the carton
Coastal humidity can affect the longevity of the light fitting over time.
Be sure to follow the steps in the order given.
Read instructions carefully.
Important Safety Instructions
Ensure ceiling is in between
the bracket and frame
4.Align L bracket with
frame and fasten together
using screws.
Ensure recess frame is
secured.
7 . 1 . L o w e r  t t i n g o n t o
mounted frame.
4
5
7
5
6
L bracket
frame
7
Mains to
Luminaire
Earth Loop
Green/Yellow
Switch
Wire Red
Neutral loop
Black or Blue
(L) Brown
(E) Green/Yellow
(N) Blue
5.Connect the Switched
Live (L), Neutral (N) and
Earth (E) cable(s) to the
Male Female connectors.
NB: Ensure power cable is
c o n n e c t e d b e f o r e
mounting tting into frame.
Test power.
8
7.2. Secure the tting onto
the frame using 4 Allen
screws.
8. Switch on power supply.
6.Insert olympia pro tting
d i a g o n a l l y t h r o u g h
mounted frame.
NB : Ensure there is no pinch
or trapped insulation as
tting is placed.
DO NOT PLUG
(CONNECT) WHEN
LIVE AS IT WILL CAUSE
DAMAGE TO THE
LUMINAIRE.
Male/Female
Connector
L Bracket
Botton
head screw
Frame
