VigilLink VL-IPC265-1 User manual

VL-IPC265-1
Video over IP Controller
VER 1.0

Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating, or adjusting this product. Please keep this manual
for future reference.
A surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shocks, lightning strikes, etc. The use of
surgeprotection systems is highly recommended to protect and extend the
life of your equipment.
Table of Contents
1. Introduction..........................................................................................
1
2. Features................................................................................................
1
3. Package Contents...............................................................................
1
4. Specifications. .....................................................................................
2
5. Operation Controls and Functions. ....................................................
2
5.1 Front Panel......................................................................................
2
5.2 Rear Panel. .....................................................................................
3
5.3 IR Pin Definition...............................................................................
4
6. Rack Mounting Instruction. .................................................................
4
6.1 6U Rack Mounting..........................................................................
4
6.2 1U Rack Mounting..........................................................................
6
7. Web GUI User Guide............................................................................
7
7.1 Preparation before Entering the System.......................................
7
7.2 Functions and Operation. .............................................................
11
8. Application Example...........................................................................
26

1/29
1. Introduction
This Video over IP Controller is used to control and manage IP products. It
supports dual 1G network ports, which can realize dual-network isolation of
the Control network and Multicast video distribution network. It supports
Web GUI/TCP/RS-232/IR/GPIO controls, POE function, and IR control
signal passthrough as well. Since the demand for IP products is daily
increased in the current market, the IP Controller will be widely applied in
more and more different scenarios.
2. Features
☆Easy to create projects, control, and manage the system
☆HTTPS, SSH, SFTP security compatible
☆Built-in Web GUI control interface, supporting Drag & Drop operations
☆Support image preview
☆Support video, audio, RS-232, IR, KVM control, and management of the
distributed system
☆Dual network ports (VIDEO LAN port supports POE function) to isolate
Controls and Multicast networks.
☆Support LAN/RS-232 port control and third-party central control
☆Support IR signal receiving (3.5mm audio jack, 12V level)
☆4 channel GPIO control ports (5V/12V optional level)
☆Multiple circuits protection, lightning protection, and ESD design
☆Reliable system design, ensuring 7*24 hours reliable and stable work
3. Package Contents
①1 ⅹVideo over IP Controller
②1 ⅹ20kHz-60kHz 12V IR Receiver Cable (1.5 meters)
③1 ⅹIR Blaster Cable (1.5 meters)
④2 ⅹ3-pin 3.81mm Phoenix Connector (Male)
⑤1 ⅹ6-pin 3.81mm Phoenix Connector (Male)
⑥ 2 ⅹ Mounting Ears
⑦ 4 ⅹ Machine Screws (KM3*6)
⑧1 ⅹ12V/1A Locking Power Adaptor
⑨1 ⅹUser Manual

2/29
4. Specifications
Technical
Network Video
Bandwidth Up to 1G
Transmission
Distance 100m CAT 5E/6/6A/7
Control Ports
2 x 1G LAN [RJ45 connector] [VIDEO LAN support POE]
1 x IR IN [3.5mm audio jack, 12V level]
1 x IR OUT [3.5mm audio jack]
1 x DIGITAL I/O [6-pin 3.81mm phoenix connector]
2 x RS-232 [3-pin 3.81mm phoenix connector]
1x USB Host [Micro USB, 5-pin female]
Dimensions
204mm(W)×98.5mm(D)×21.5mm(H)
Housing
Metal Enclosure
Color
Black
Weight
508g
Power Supply 12V/1A
Power Consumption
8.4W
Operating
Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity
20~90% RH (non-condensing)
5. Operation Controls and Functions
5.1 Front Panel

3/29
No.
Name
Function Description
1RESET Button
Press and hold this button (about 10 seconds) until Status
LED starts flashing, Controller will be reset automatically.
2
POWER LED
The red LED will light on when the Controller is powered on.
3 STATUS LED
The status LED will flash in yellowish-green every 1 second
until the Controller boots up completely and Control LAN is
ready, then it becomes solid.
4 UPDATE
Firmware update port.
Note: Must keep no connection on this port when Controller
works in normal mode.
5.2 Rear Panel
No.
Name
Function Description
1
DC 12V
DC 12V/1A power input port.
2VIDEO LAN
(POE)
1G Video LAN port, supporting POE function.
Note: When POE is enabled, DC 12V/1A power supply is
not required.
3CONTROL
LAN
The TCP/IP control network port.
4
3-pin Phoenix
Connectors Two identical RS-232 serial communication ports.
56-pin Phoenix
Connector
4 channel I/O level outputs, 1 channel grounding,
1 channel power supply (supports up to 12V/0.5A) to the
outside.
6IO LEVEL
DIP Switch
Used to control I/O level output and VOUT voltage.
Switch to left: 5V I/O level output, VOUT is 5V.
Switch to right: 12V I/O level output, VOUT is 12V.
7
IR IN 12V IR signal input port.
8IR OUT IR signal output port. (Reserved for future use.)

4/29
5.3 IR Pin Definition

5/29
6. Rack Mounting Instruction
6.1 6U Rack Mounting
This Controller can be mounted in a standard 6U rack (Please contact your
supplier for a 6U rack sale). The mounting steps are as follows:
Step 1: Use included screws to fix two mounting ears on the Controller, as
shown in the figure below:
Step 2: Insert the Controller with mounting ears into a 6U rack (up to 10units
can be installed vertically), as shown in the figure below:

6/29
Step 3: Use screws to fix mounting ears on the rack to complete
themounting, as shown in the figure below:
6.2 1U Rack Mounting
This Controller also can be mounted in a standard 1U rack (up to 4 units can
be installed horizontally). The mounting steps are as follows:
Step 1: Stack two Controllers on top of each other, then use included screws
to fix two 1U rack panels on the Controllers, as shown in the figure below:

7/29
Step 2: Fix two 1U rack panels on another two stacked Controllers in the
same way, then use screws to fix two 1U rack panels together, as shown
in the figure below:
Step 3: Fasten screws between two 1U rack panels, so that four Controllers
are mounted in a 1U rack, as shown in the figure below:

8/29
7. Web GUI User Guide
7.1 Preparation before Entering the System
You can use Controller’s Web GUI to control all IP products at the Switch.
The operation method is shown below:
Step 1: Input the Controller’s default IP address (192.168.0.225) or the URL
(http://controller.local) into the Web browser address bar on the PC to enter the
Web GUI login interface.

9/29
Select the initial username (admin) and input the initial password (1234) on
the above login interface. Then, click “Log In” to enter the Web GUI interface.
For the first time, you need to set up the project, as shown in the following
figure:
Step 2: Click the “Close” button to load an existing project on the web page
directly or click the “Next” button to go to the next step.
On this interface, you need to set the IP mode of Video LAN.

10/29
Mode 1: Automatically managed by Controller Box.
Please connect all the devices according to the following diagram.

11/29
Click the “Next” button and wait for the completion to enter the interface as
shown in the figure below.
Select “Automatically add Encoders and Decoders to project”, and click the
“Scan” button to enter the Project page. All the connected devices will be
listed in the Current Devices list.
Then click “Stop Scan & Auto Assign” to stop the search.
Note: Currently only Mode 1 is available, Mode 2 and Mode 3 will be ready
in the short future, and the operation steps will be supplemented.

12/29
7.2 Functions and Operation
■Preview Page
On this page, you can preview the Encoder/Decoder by clicking the drop-
down list on the right side.
■Matrix Control Page
①Encoders: Display all the current Encoders. The text in the figure is the
name of the device.
② Decoders: Display all the current Decoders. The text on the first line is
the name of the Decoder, and the text on the second line refers to the
Encoder where the signal resource is from.

13/29
Operating Instructions:
(1) If an Encoder shows “No Signal”, it means that the Encoder cannot be
dragged.
(2) If there is an image on an Encoder, it means that the Encoder can be
dragged. As shown in the figure above, if an Encoder is dragged to the
place where the red arrow points to, all Decoders will share the same
signal resource from this Encoder; if an Encoder is dragged to the place
where the blue arrow points to, only the indicated Decoder can receive
signals from this Encoder.
■Project Page
①Current Devices: Devices that have been added to the current project.
②Unassigned Devices: Devices not added to the current project.

14/29
Operating Instructions:
(1) Click “Display ID” to display the ID or PATTERN of the Decoders.
(2) Click “Save Project” to save the project file (config_file.json), so that you
can use the saved project next time without scanning devices again.
(3) Click “Load Project” to load the existing project directly.
(4) Click “Clear Project” to clear the current project, then you will need to
set up the project again.
(5) Click “Scan Once” to search devices that do not appear in the current
project.
(6) Click “Start Scan & Auto Assign” to search for new devices
automaticallyand add to the current project.
■Encoders Page
①ID: The ID of the current device. (Note: ID is not duplicated.)
②Name: The name of the current device.
③MAC Address: The MAC Address of the current device.
④IP Address: The IP Address of the current device.
⑤Firmware: The Firmware version No. of the current device.
⑥Status: The status (online or offline) of the current device.
⑦EDID: The EDID of the current device.
⑧L/R Out: The audio selection of the current device.
⑨CEC Command: The CEC Command of the current device.

15/29
Operating Instructions:
(1) Click “Refresh” to refresh the data of the current Encoders.
(2) Click the drop-down list of EDID to set the current Encoder’s EDID.
(3) Click the drop-down list of L/R Out to set the current Encoder’s
audio output.
(4) Click “Command” to set the CEC command for the Encoder.
(5) Click the icon on the left of the ID to check the detailed information
about thecurrent Encoder, as shown below:
On this page, you can set up the current Encoder as required.

16/29
■Decoders Page
①ID: The ID of the current device. (Note: ID is not duplicated.)
②Name: The name of the current device.
③MAC Address: The MAC Address of the current device.
④IP Address: The IP Address of the current device.
⑤Firmware: The Firmware version No. of the current device.
⑥Status: The status (online or offline) of the current device.
⑦Source: The signal source (Encoder) of the current device.
⑧Display Mode: The display mode of the current device.
⑨Scaler Resolution: The resolution of the current device.
⑩Function: The mode (Matrix/Video Wall/Multiview) of the current device.
CEC Command: The CEC Command of the current device.
Operating Instructions:
(1) Click “Refresh” to refresh the data of the current Decoders.
(2) Click the drop-down list of sources to select the current Decoder’s
signalsource.
(3) Click the drop-down list of Display Mode to select the current Decoder’s
display mode.
(4) Click the drop-down list of Scaler Resolution to select the current
Decoder’s resolution.
(5) Click the drop-down list of Functions to select the current Decoder’s mode.
(6) Click “Command” to set the CEC command for the Decoder.
(7) Click the icon on the left of the ID to check detailed tail information

17/29
about thecurrent Decoder, as shown below:
On this page, you can set up the current Decoder as required.

18/29
■Locked Signal Routing Page
On this page, you can independently route the video and audio signals
between Encoder & Decoder devices. You also can set the IR/Serial/USB
signals as required. Please click “Locked Routing Help” for details.
■Video Wall Management Page
On this page, you can create and configure a video wall as required.
Pleasefollow the below steps to create a video wall.
