MRC VP-17C User manual

PTFE Coated
Chemical Resistant Vacuum Pumps
VP-17/19/34C
PLEASE READ THIS MANUAL CAREFULLYBEFORE OPERATION
3, Hagavish st. Israel 58817 Tel: [phone], Fax: [phone] [email protected]
MRC.8.20
User Manual

This instrument is designed for laboratory usage only. Please read this manual
carefully before installing and operating. The instrument shall not be modified in
any way. Any modification will void the warranty and may result in potential hazard.
We are not responsible for any injury or damage caused by any non-intended
purposes and modifying the instrument without authorization.
1. Check the voltage specified on the name plate and ensure it matches the line
voltage in your location.
2. Install the instrument in a clean, dust-less and ventilated area under 40℃.
3. Never use the pump with any flammable gas or toxic material.
4. The pump is not designed to start against applied vacuum. To prevent
damage, verify that the pump inlet is at atmospheric pressure before each
start. If necessary, the inlet can be vented to atmosphere by partially
unscrewing the vacuum regulator knob.
5. When finish pumping, please do not turn off the pump at once and continue
to run the vacuum pump for at least two minutes in order to draw out the
mist and tiny liquid to prolong the service life of the pump.
6. This pump has a thermal protection device that automatically shuts-off when
it becomes overheated.
7. The temperature of the surface of pump is very high after use or during work,
please don’t touch it to avoid being burnt.
8. Do not use any lubricant, which may damage the pump.
9. If the supply cord is damaged, please contact the manufacturer or your
service agent for replacement to avoid hazard.
* Warning: The PTFE-coated diaphragm and chamber can offer good resistance
to a wide range of chemicals except strong acid and alkali.
Important Notice

When unpacking, notice if the pump is in good situation. If not, please contact
the distributor or contact us by e-mail: [email protected] immediately for
assistance.
Model
Position
Designation
VP-17C
1
On/Off Switch
2
Air Outlet
3
Air Inlet
4
Vacuum Gauge
5
Vacuum Regulator
6
Moisture Trap
VP-17C Main Part Diagram
Unpacking
1
2
4
3
5
6

VP-34C VP-19C
Model
Position
Designation
VP-34C
1
On/Off Switch
2
Air Outlet
3
Air Inlet
4
Vacuum Gauge
5
Vacuum Regulator
6
Moisture Trap
Model
Position
Designation
VP-19C
1
On/Off Switch
2
Air Outlet
3
Air Inlet
4
Vacuum Gauge
5
Vacuum Regulator
6
Moisture Trap
VP-34C/19C Main Part Diagram

Operating procedure
1. Press on/off (1) button to activate the pump after making sure all tubing are
well connected.
2. To setup vacuum by adjusting the regulator (5).
* Warning: When pump is used for aqueous solution filtration, please ensure the
liquid level of flask not exceed safety level. Failure to comply could result in
serious damage to the pump and void the warranty. If it occurs, please contact
the distributor immediately for service.
1. If the moisture trap is full of liquid more than 70%, please stop doing the
experiments immediately and remove the liquid.
2. After finishing the experiment, please remove the liquid in the moisture trap
and pumping the air for at least 2 minutes to withdraw the residual steam.
Maintenance
Operation

189300-11(22)
VP-17C, PTFE Coated Chemical Resistant Vacuum Pump,
AC110V,60Hz (AC 220V,50Hz)
189300-62
VP-17C Repair kit
189400-11(22)
VP-34C, PTFE Coated Chemical Resistant Vacuum Pump,
AC110V,60Hz (AC 220V,50Hz)
189410-11(22)
VP-19C, PTFE Coated Chemical Resistant Vacuum Pump,
AC110V,60Hz (AC 220V,50Hz)
189400-62
VP-34C/VP-19C Repair Kit
189300-06
Moisture Trap / Vacuum Regulator
Ordering Information
