OPERATOR’S MANUAL
Wood Splier / Tree Shear
Model WS5X36
Serial Number 12997-
Manual# 96374 JUL 2021 ENGLISH
COPYRIGHT © 2021
MESSER REPAIR AND FABRICATING LLC
SAUK CENTRE, MN
PRINTED IN USA
ALL RIGHTS RESERVED

2
Using This Manual
The term loader is used in this manual to refer to a skid
steer loader.
Your loader operator’s manual contains instructions to
safely operate the loader. Anyone who operates a loader
with this attachment installed must rst read, under-
stand and follow the instructions in the loader operator’s
manual.
This manual contains instructions to safely operate and
service the attachment. Anyone who operates or services
the attachment must rst read, understand and follow the
instructions in this manual.
Additional operating or servicing information for the
attachment may be provided online, in video, or in
other publications. This additional information does not
replace, and is not a substitute for reading and following,
the instructions in this manual.
The safety alert symbol is shown in WARNING state-
ments to alert users to hazards which could cause death
or injury. Carefully read and follow the messages.
IMPORTANT notices alert users to instructions which, if
not followed, could result in damage. Carefully read and
follow the messages.
There may be times when the attachment and loader
shown in this manual may not be your exact model. The
model shown will be close enough to your attachment or
loader to accurately convey the information.
The most current information available is included in
this manual. The publisher may revise this manual at any
time and is not required to notify users of revisions.
Replacement Manuals
Be sure to include this operator’s manual if you sell or
transfer ownership of the attachment.
Contact Messer Repair and Fabricating, LLC for a
printed manual, or nd a downloadable manual on our
website.
Using This Aachment
The attachment is designed to split wood, and shear and
prune trees.
The attachment is designed to be connected to the load-
er’s front auxiliary hydraulic couplers.
The manufacturer reserves the right to make improve-
ments, and to discontinue or change specications,
models or design without notice and without incurring
obligation.
Loader Compability
The attachment is designed for installation on loaders
with a minimum Rated Operating Capacity (ROC) of
1,500 lbs.
Conrm your loader’s Rated Operating Capacity (ROC)
in the loader operator’s manual. Conrm your attach-
ment’s ROC in Specications in this manual.
Do not install the attachment on the loader if the com-
bined weight of the attachment and attachment load will
exceed the loader ROC during operation because this
may cause diculty in controlling the loader or may
cause loader damage.
Do not exceed the attachment’s ROC because this may
damage the attachment.
Product Misuse
Product misuse can cause accidents, injury and death.
The manufacturer of the attachment is not responsible
for any harm or injury resulting from product misuse.
Product misuse includes operating or servicing the at-
tachment without following the instructions in this man-
ual, using the attachment in any way for which it was not
designed, and modifying the attachment.
Modicaons
Do not modify the attachment in any way.
Manufacturer Contact
Call Messer Repair and Fabricating, LLC at (833) 352-
3477, or visit www.messerrepair.com.
Introducon

3
Idencaon Numbers
Record your product information to provide when you
contact the dealer or manufacturer.
Wood Splier / Tree Shear
Model WS5X36
Serial Number 12997-
Serial Number Locaon
Purchase Date
Dealer
Dealer Phone
Model
Serial #
Product Idencaon and Specicaons
Specicaons
Model WS5X36
Overall Length/Depth
(Boom out)
269 cm (106 in.)
Overall Length/Depth
(Sideways)
69 cm (27 in.)
Overall Width x Height
(Boom out)
114 x 58 cm
(45 x 23 in.)
Overall Width x Height
(Sideways)
251 x 58 cm
(99 x 23 in.)
Max. Throat Opening 91 cm (36 in.)
Cylinder Push Force
(@ 3000 psi)
30 Tons
Weight 447 kg (985 lb.)
Rated Operang Capacity 1814 kg (4000 lbs.)

4
Decal Locaons
Locaon Descripon Part Number
A Warning Decal 96117
B Danger Decal 96116
C Caution Decal 96109
D Stand Clear Decal 96138
Safety Decals
• Wear proper hand and eye protecon when search-
ing for leaks. Use wood or cardboard instead of
hands.
• Keep all components in good repair.
DANGER DECAL 96116
DO NOT ATTEMPT TO SHEAR A TREE OVER 8”
IN DIAMETER
CAUTION DECAL 96109
PINCH POINT
STAND CLEAR DECAL 96138
STAND CLEAR WHILE IN OPERATION
WARNING DECAL 96117
HIGH PRESSURE FLUID HAZARD
To prevent serious injury or death:
• Relieve pressure on system before repairing, adjust-
ing or disconnecng.

5
Wear Protecve Equipment
• Wear gloves to protect hands from burns if hydraulic
couplers become hot during operation.
• Never wear sandals or other light footwear when op-
erating or servicing the attachment. Wear protective
footwear when handling blades or heavy parts.
• Do not wear loose tting clothing which may
become entangled when operating or servicing the
attachment.
Parking Safely
1. Follow the instructions in the loader operator’s man-
ual to park the loader safely.
2. Fully lower the attachment to level ground.
3. Stop the loader engine and remove the key from the
switch.
4. Do not leave the loader operator seat until the engine
and all other moving loader and attachment parts
have stopped.
5. Follow the instructions in the loader operator’s man-
ual to exit the loader safely. Use the attachment step
area if one is provided.
Operang Aachments Safely
• Do not allow anyone to operate the attachment
unless they have rst read and understood the loader
and the attachment operator’s manuals.
• Do not allow anyone to operate the attachment
unless they have rst read and understood the safety
and warning decals on the loader and on the attach-
ment.
• The attachment owner is responsible for training oth-
ers to safely operate the attachment, and is responsi-
ble for any injuries or harm which occurs while the
attachment is being operated.
• If an area to step on the attachment has been provid-
ed, be sure to use it when entering and exiting the
loader.
• Before operating, replace any worn or damaged
safety decals.
• Before operating, thoroughly inspect the attachment
to be sure all hardware (bolts, nuts, etc.) is installed
and tightened.
• Before operating, thoroughly inspect the attachment
to be sure it is in working order. If the attachment
is damaged or otherwise not in working order, do
not operate until it has been repaired by a qualied
technician.
• Before raising or lowering the attachment be sure the
area is clear of bystanders.
• Do not operate the loader or the attachment if you
are under the inuence of alcohol, drugs, or medica-
tions which may cause drowsiness.
• Do not allow children to operate the loader or the
attachment.
• Do not allow anyone who has not been trained to
operate the loader or the attachment.
• Never allow riders on the attachment.
• Keep hands, feet or other objects away from under-
neath the attachment while operating.
• Fully lower the attachment to level ground when you
are done operating.
• Never leave the attachment unattended while in a
raised position.
• When transporting the attachment installed on the
loader, travel at a slower speed to maintain control.
Using the Wood Splier / Tree Shear Safely
• Do not hand feed or roll wood into the attachment.
• Operate the attachment from the cab of the loader
only.
• Do not attempt to shear trees which are more than
eight inches in diameter.
• Extend the boom out by raising and tilting the at-
tachment to keep pruned or sheared limbs away from
the loader to prevent falling onto the loader.
Servicing Safely
• Disconnect the attachment hydraulic hoses from the
loader before servicing. Do not service the attach-
ment when the hydraulic hoses are installed on the
loader.
• Remove the attachment from the loader before ser-
vicing when instructed to do so in this manual.
• Do not allow anyone to service the attachment
Safety

6
situations which could result in injury if not avoided.
Read and understand all safety decals before operating
or servicing the attachment.
See the Safety Decal Location illustration in this manual
to conrm where decals are installed on the attachment.
Safety decals which are missing, worn or faded must
be replaced. Replacement safety decal part numbers are
included in this manual. Contact the attachment manu-
facturer for replacement decals.
unless they have rst read and understood the loader
and the attachment operator’s or service manuals.
• Do not allow anyone to service the attachment
unless they have rst read and understood the safety
and warning decals on the loader and on the attach-
ment.
• The attachment owner is responsible for training oth-
ers to safely service the attachment, and is responsi-
ble for any injuries or harm which occurs while the
attachment is being serviced.
• Before inspecting or servicing the attachment, fol-
low the Parking Safely instructions in this manual
and disconnect the attachment hydraulic hoses from
the loader.
• Always securely block the attachment to prevent
accidental release of the lifting mechanism when
inspecting or servicing the attachment.
Hydraulic Fluid Safety
• Read and understand the hydraulic safety informa-
tion in the loader operator’s manual before operating
or servicing the attachment.
• Use cardboard or a board when you check for a leak.
• Fluid in hydraulic hoses is under extreme pressure.
If uid is injected into your skin seek medical treat-
ment immediately.
• Do not handle any hydraulic components until pres-
sure has been relieved from the system.
• Disconnect the attachment hydraulic hoses from the
loader before inspection or service.
• Inspect attachment hydraulic hoses and hose shields
for damage or wear before attaching to the loader.
Safety Decals
Safety decals may be installed on the attachment to warn
users of safety hazards:
• DANGER decals provide warnings about hazardous
situations which will result in death or serious injury
if not avoided.
• WARNING decals provide warnings about hazard-
ous situations which could result in death or serious
injury if not avoided.
• CAUTION decals provide warnings about hazardous
Safety

7
Assembly
Boom Out Right Assembly
1. Attach the boom weldment (A) to the
right side of the main frame (B) with
six 3/4 x 2-1/2 bolts, 3/4 lockwashers
and 3/4 nuts.
2. Attach the kicker weldment (C) to
the main frame with four 3/4 x 2-1/2
bolts, 3/4 lockwashers and 3/4 nuts.
3. Attach the kicker weldment to the
boom weldment with four 3/4 x 2
bolts, 3/4 lockwashers and 3/4 nuts.
4. Route the attachment hydraulic hoses-
through four guides (D-G) as shown.
Boom Out Le Assembly
1. Attach the boom weldment (A) to the
left side of the main frame (B) with
six 3/4 x 2-1/2 bolts, 3/4 lockwashers
and 3/4 nuts.
2. Attach the kicker weldment (C) to
the main frame with four 3/4 x 2-1/2
bolts, 3/4 lockwashers and 3/4 nuts.
3. Attach the kicker weldment to the
boom weldment with four 3/4 x 2
bolts, 3/4 lockwashers and 3/4 nuts.
4. Route the attachment hydraulic hoses-
through four guides (D-G) as shown.
Boom Sideways Assembly
1. Attach the boom weldment (A) to
the center of the main frame (B) with
eight 3/4 x 2-1/2 bolts, 3/4 lockwash-
ers and 3/4 nuts.
2. Route the attachment hydraulic hoses
through four guides (C-F) as shown.

8
7. Move the loader attaching plate levers (A) to the
locked (fully down) position either manually or by
using the loader controls.
8. Park the loader. (See Parking Safely in this manual.)
Picture Note: Wedge on right side shown. Check the
wedges or pins on both sides of the attachment.
9. Check to be sure the loader attaching plate pins or
wedges (C) extended into the holes in the bottom
of the attachment mounting frame. If not, move the
loader attaching plate levers to the unlocked (up)
position and repeat installation.
IMPORTANT
AVOID DAMAGE!
The aachment may come o the loader if it is
not secured to the aaching plate. The aaching
plate pins or wedges must be extended into the
aachment with the levers fully down.
Preparing for Installaon
1. Check the loader and attachment hydraulic couplers
to be sure the surfaces are clean before connecting.
2. Inspect the couplers for damage or wear and replace
if needed for proper connection.
Installing the Aachment
1. Follow the instructions in the loader operator’s
manual to install the attachment and exit the operator
station safely.
2. Fully lower the loader lift arms.
3. Move the loader attaching plate levers (A) to the
unlocked (up) position either manually or by using
the loader controls.
4. Tilt the loader attaching plate forward, and drive
the loader forward until the top edge of the loader
attaching plate is under the top ange (B) of the
attachment mounting frame.
5. Raise the loader lift arms slightly until the attaching
plate is fully seated under the top ange.
6. Tilt the attaching plate backward to raise the front of
the attachment.
IMPORTANT
AVOID DAMAGE!
Aaching plate levers may be damaged if they
strike the aachment. Be sure the aaching plate
levers do not hit the aachment during installaon.
Installing and Removing

9
11. Connect the attachment hydraulic hoses to the load-
er’s front auxiliary couplers (F).
a. Install the male couplers into the female couplers
and pull or push the sleeves (G) to be sure they are
locked into place.
b. Rotate the coupler sleeves as shown so the ball
(H) is outside the groove (I) to prevent the coupler
disconnecting (Some sleeves may not have this
locking mechanism).
Removing the Aachment
1. Follow the instructions in the loader operator’s man-
ual to remove the attachment and exit the operator
station safely.
2. Fully lower the loader lift arms and the attachment
to level ground.
3. Follow instructions in the loader operator’s manual
to relieve hydraulic pressure in the front auxiliary
hydraulic coupler lines.
4. Stop the loader engine.
WARNING
AVOID INJURY!
Hydraulic couplers may become hot during op-
eraon. Avoid burns by wearing gloves when
disconnecng hydraulic couplers.
10. Check the attachment hose routing to the loader’s
front auxiliary couplers:
• If the attachment is assembled for operation with the
boom out, route the hoses through the guide (D) as
shown.
• If the attachment is assembled for operation with
the boom sideways, route the hoses through the two
guides (E) as shown.
Installing and Removing

10
5. Disconnect the attachment hydraulic hoses from the
loader’s front auxiliary couplers (A).
a. Rotate the coupler sleeves (B) so the ball (C) is
aligned with the groove (D) to allow the coupler
to disconnect (Some sleeves may not have this
locking mechanism).
b. Grasp and push or pull the sleeves to disconnect
the couplers.
6. Install protective caps on the couplers if they are
provided, and insert the couplers in the tube (E).
WARNING
AVOID INJURY!
Loader aaching plate levers which are operated
manually may have spring tensioning. Firmly grasp
the levers and move the levers slowly.
Installing and Removing
7. Move the loader attaching plate levers (F) to the
unlocked (up) position as shown either manually or
by using the loader controls.
8. Tilt the loader attaching plate forward slightly and
drive the loader backward until the top edge of
the attaching plate clears the top ange (G) of the
attachment mounting frame.

11
Operaon
1. Follow the instructions in the Installing and Remov-
ing section to install the attachment.
2. Park the loader. (See Parking Safely in this manual.)
3. Peform the pre-operation inspection.
Spling Wood
1. Use the loader hydraulic controls to fully retract the
attachment cylinder, opening the area between the
slider weldment and the cutting edge.
Picture note: Attachment installed for operation with
the boom out. Optional cross cut blades shown.
Picture note: Attachment installed for operation with
the boom sideways. Optional cross cut blades shown.
WARNING
AVOID INJURY!
Do not aempt to hand feed or roll wood into the
aachment. Keep bystanders beyond a 100 foot
radius around the aachment when operang. Only
operate the aachment from inside the loader cab.
Pre-Operaon Inspecon
Before starting operation, inspect the area you will be
operating in and inspect the attachment.
Inspect the Work Area
1. Conrm the area is clear of bystanders including
animals. Establish a safety zone by keeping bystand-
ers and animals beyond a 100 foot radius around the
attachment when operating.
Inspect the Aachment
1. Inspect the attachment to be sure it is in working or-
der. If the attachment is damaged or not in working
order, do not operate until it has been repaired by a
qualied technician.
Descripon
Operang
Theory of Operaon
The Wood Splitter / Tree Shear hydraulic hoses are con-
nected to the loader front auxiliary hydraulic couplers.
The loader’s hydraulic controls are used to extend and
retract the hydraulic cylinder, which moves the slider
weldment, forcing the wood into the cutting edge or the
cross cut blades. The Wood Splitter / Tree Shear can be
assembled for operation with the boom out or the boom
sideways.
A - Main Frame
B - Step Area
C - Operator Manual Holder
D - Hydraulic Hoses
E - Hydraulic Cylinder Guard
F - Slider Weldment
G - Boom
H - Cung Edge
I - Cross Cut Blades (Opon-
al)
Picture note: Assembled for boom sideways operation.

12
2. Move the loader and tilt the attachment to position
the wood between the slider weldment (A) and the
cutting edge (B) with the wood against the boom
(C).
Picture note: Splitting with optional cross cut blades.
3. Use the loader hydraulic controls to extend the cyl-
inder and force the wood into the cutting edge and
cross cut blades.
4. When the wood has split as desired or the cylinder is
fully extended, use the loader hydraulic controls to
fully retract the cylinder.
5. Repeat to split the wood as needed.
Trimming or Pruning and Shearing Trees
1. Remove the cross cut blades if installed (See OP-
TIONAL ATTACHMENTS.)
IMPORTANT
AVOID DAMAGE!
Do not aempt to shear trees which are more than
8 inches in diameter. Shearing trees which are
more than 8 inches in diameter may damage the
aachment.
Operang
Picture note: Attachment installed for operation with
the boom out. Optional cross cut blades shown.
Picture note: Attachment installed for operation with
the boom sideways. Optional cross cut blades shown.
2. Use the loader hydraulic controls to retract the hy-
draulic cylinder, opening the area between the slider
weldment (A) and the cutting edge (B) far enough to
allow the tree to t between them.
3. Move the loader and tilt the attachment to position
the tree to be sheared or the limbs to be trimmed or
pruned between the cutting edge and the slider weld-
ment with the wood against the boom (C).

13
Operang
4. Use the loader hydraulic controls to extend the cylin-
der and force the wood into the cutting edge until it
is cut through.
5. Use the loader hydraulic controls to fully retract the
cylinder.
Using the Oponal Tree Catcher for Shear-
ing Trees
1. Install the tree catcher attachment (See OPTIONAL
ATTACHMENTS.)
2. Remove the cross cut blades if installed (See OP-
TIONAL ATTACHMENTS.)
IMPORTANT
AVOID DAMAGE!
Do not aempt to shear trees which are more than
8 inches in diameter. Shearing trees which are
more than 8 inches in diameter may damage the
aachment.
3. Follow shearing instructions (See Trimming or Prun-
ing and Shearing Trees).
4. Catch the tree between the top arms (A) and behind
the bottom arm (B) to transport.
Transporng the Aachment
On the Loader
Check to be sure the attachment is correctly installed on
the loader before hauling the loader on a trailor or truck.
Follow all loader, truck or trailer operator’s manual
instructions to safely haul the loader.
Hauling the Aachment
Follow all truck or trailer operator’s manual instructions
to securely fasten the attachment to the truck or trailer
with straps or chains.

14
Oponal Aachments
Cross Cut Blades
The standard cutting edge on the Wood Splitter / Tree
Shear is used for shearing and pruning, and will split
wood into two parts.
Install the cross cut blades to split wood into four parts.
One set of cross cut blades and hardware with an allen
wrench are shipped with the attachment from the factory.
Installing and Removing Cross Cut Blades
1. Remove the attachment or park the loader. (See
Parking Safely in this manual.)
Picture note: Install cross cut blades as shown with
small notch at bottom.
2. Install the left blade (A) on the left side of the cut-
ting edge as shown with four 3/4 x 2-1/4 at head
allen bolts (B) and install the right blade to the other
side of the cutting edge.
3. Remove the bolts and the blades when using the
Wood Splitter / Tree Shear for shearing, pruning or
trimming.
Tree Catcher
The tree catcher can be used to catch trees no more than
8 inches in diameter after shearing.
Installing the Tree Catcher
1. Remove the attachment or park the loader. (See
Parking Safely in this manual.)
2. Install the tree catcher on the main frame as shown
with eight 3/4 - 10 x 2-1/2 hex cap screws, and 3/4 -
10 hex nuts (A).

15
Greasing the Slide Weldment
1. Apply grease to the boom area (B) as needed to keep
the weldment sliding smoothly.
Replacing the Hydraulic Hoses or Cylinder
Note: If the attachment was assembled for sideways
operation, it may be easier to remove it from the loader
and tip it to position the cylinder guard on top for ser-
vicing.
1. Park the loader. (See Parking Safely in this manual.)
2. Disconnect the attachment hydraulic hoses from the
loader.
Remove the Cylinder Guard
Note: It may be easier to remove the cylinder mounting
pin if you attach a safe lifting device to the guard and
cylinder to take the weight o the pin.
WARNING
AVOID INJURY!
Disconnect the aachment hydraulic hoses from
the loader before servicing.
Service Intervals
Every 8 hours or daily
• Grease the cylinder.
• Grease the slide weldment.
• Inspect the attachment and hoses for damage and
wear. Replace parts as needed.
• Check and tighten all hardware.
Weekly:
• Inspect the cutting edge and optional cross cut
blades for wear. Sharpen as needed. Replace the
cross cut blades as needed.
Lubricaon
Recommended Grease
Standard Lithium
Greasing the Aachment
1. Park the loader. (See Parking Safely in this manual.)
2. Disconnect the attachment hydraulic hoses from the
loader.
Greasing the Hydraulic Cylinder
1. Lubricate the two grease ttings (A) on the ends of
the cylinder.
WARNING
AVOID INJURY!
Disconnect the aachment hydraulic hoses from
the loader before servicing.
Servicing

16
Servicing
1. Remove the 3/8 - 16 locknut (A) and 3/8 - 16 x 3
hex cap screw securing the cylinder mounting pin.
2. Remove the cylinder mounting pin (B).
3. Slide the guard over and remove it.
Replacing the Hydraulic Hoses
1. Remove the cylinder guard.
2. Remove the tie straps (C) securing the hoses.
3. Disconnect the tting (D) and remove the hydraulic
hose you are replacing.
4. Install the new hose on the cylinder.
5. Install tie straps to secure the hoses.
6. Install the cylinder guard with the mounting pin, bolt
and nut.
Replacing the Hydraulic Cylinder
1. Remove the cylinder guard.
2. Use a safe lifting device to secure the cylinder for
removal.
3. Remove the tie straps (C) securing the hoses.
4. Disconnect the ttings (D) and remove the hydraulic
hoses from the cylinder.
5. Remove the 3/8 - 16 lock nut (A) and 3/8 - 16 x 3
hex cap screw (E).
6. Remove the rod end cylinder mounting pin (F). Re-
move the cylinder.
7. Install the new cylinder with the rod end mounting
pin, bolt and nut.
8. Install the hoses on the new cylinder.
9. Install tie straps to secure the hoses.
10. Install the cylinder guard with the base end mount-
ing pin, bolt and nut.
Sharpening the Cung Edge or Cross Cut
Blades
1. Park the loader. (See Parking Safely in this manual.)
2. Disconnect the attachment hydraulic hoses from the
loader.
3. Sharpen with an angle grinder as needed.
WARNING
AVOID INJURY!
Disconnect the aachment hydraulic hoses from
the loader before servicing.

17
Troubleshoong
Problem Acon
Hydraulic cylinder won’t extend or
retract.
1. Check to be sure the attachment hydraulic couplers are fully connected.
2. Check the attachment for hydraulic uid leaks.
3. See loader operator’s manual to check hydraulic pressure and ow.
4. Contact the attachment manufacturer about possible cylinder replacement.
Troubleshoong

18
Replacement Parts
Contact Messer Repair and Fabricating, LLC for replacement parts.
Part numbers may change without notice.
Item Qty. Part Number Part Descripon
1 1 08952-P Boom Weldment
2 1 08950-P Main Frame Weldment
3 1 06272-P Kicker Weldment
4 1 96128 Operator Manual large Canister 12 x 3.5 in.
5 1 08949 Base End Cylinder Pin
6 1 08948 Rod End Pin
7 1 08946-P Slider Weldment
Replacement Parts

19
Replacement Parts
Item Qty. Part Number Part Descripon
8 1 WCT5X36 Welded Cross Tube - 5 in. Bore x 36 in. Stroke Cylinder
9 1 08839-P Cylinder Guard Weldment
10 1 08175-P Cross Cuts Left Weldment
11 1 08173-P Cross Cuts Right Weldment
12 1 08947 Sliding Blade
13 2 05410 Guide Plate
14 2 07870 .1875 Spacer Plate
15 2 06286 .375 Spacer Plate
16 2 07869 .5 Saddle Spacer Shim
17 10 Bolt, 5/8 - 11 x 3
18 10 Locknut, 5/8 - 11
* 1 1/2 Long Arm SKT HX Key-L
* 16 Bolt, 3/4 - 10 x 2-1/2
* 16 Nut, 3/4 - 10
* 16 Split Lockwasher, 3/4
* 10 Bolt, 5/8 - 11 x 3
* 10 Top Locknut, 5/8 - 11
* 2 Bolt, 3/8 - 16 x 3
* 2 Top Locknut, 3/8 - 16
* 4 Flat Cap Screw, 3/4 -10 x 2-1/4
* 2 Nut, 1/2 - 13
* 1 Coupler Assembly Female, 1/2'' ORB-#8, 3/4"-16 SAE
* 1 Nipple Assembly Male, 1/2'' ORB-#8, 3/4"-16 SAE
* 1 168.5 in. Hose, 1/2
* 1 178.5 in. Hose, 1/2
* 2 90° Screw Fitting
* 2 90° Screw Fitting
* Part not shown.

20
Warranty
MESSER REPAIR & FABRICATING, LLC
Limited Warranty and Terms and Conditions of Sale
The following limited warranty, and terms and conditions of sale (the “Limited Warranty”) apply to all equipment, products,
parts, and goods (any of the foregoing are referred to herein as “Equipment”) sold by Messer Repair & Fabricating, LLC
(“Messer”):
1. Covers All Equipment. Each purchase of Equipment by a purchaser is expressly made conditional on purchaser’s assent to
the terms and conditions in this Limited Warranty.
2. Limited Warranty. Messer warrants that for a period of 24 months from the date of purchase, the Equipment will remain
free from defects in material and workmanship under normal use and proper maintenance. Messer’s obligation under the war-
ranty shall be limited to the repair or replacement (at Messer’s option) of the Equipment. Notwithstanding the foregoing, if the
Equipment is used for commercial purposes or is rented or leased out by the purchaser, then, the foregoing warranty shall only
be for a period of 180 days and not 24 months.
3. No Warranty For Equipment Components From Third Parties. Notwithstanding the limited warranty terms set forth above,
MESSER OFFERS NO WARRANTY WHATSOEVER WITH RESPECT TO ANY COMPONENTS OF THE EQUIPMENT
MADE OR PROVIDED TO MESSER BY OTHER MANUFACTURERS, PRODUCERS, OR SELLERS (the “Purchased
Components”). The sole and exclusive warranty for each the Purchased Components shall be limited to the express written
warranty with respect to the Purchased Component as provided by the manufacturer, producer, or seller of such Purchased
Component. Messer’s responsibility and liability for the Purchased Components shall be limited to the assignment of the
Purchased Components’ express written warranties applicable to the Purchased Components. Purchased Components include,
without limitation, the following: axles, tires and rims; trailer hitch components and jacks; hydraulic pumps, motors, cylinders
and components; and bales spears, pallet tines, and bucket teeth.
4. No Other Warranties. THE FOREGOING REPAIR AND REPLACEMENT OBLIGATIONS IN SECTION 2 ARE IN
LIEU OF ALL OTHER WARRANTIES, LIABILITIES AND OBLIGATIONS, INCLUDING ALL WARRANTIES OF
MERCHANTABILITY, OF FITNESS FOR A PARTICULAR PURPOSE OR OTHERWISE, EXPRESSED OR IMPLIED
IN FACT OR BY LAW, AND STATE MESSER’S ENTIRE AND EXCLUSIVE LIABILITY AND PURCHASER’S EXCLU-
SIVE REMEDY FOR ANY CLAIM IN CONNECTION WITH THE SALE AND PURCHASE OF EQUIPMENT (AND ALL
COMPONENTS THEREOF), THEIR DESIGN, SUITABILITY FOR USE, INSTALLATION OR OPERATIONS.
5. Location of Warranty Repairs. All warranty repairs pursuant to this Limited Warranty shall be made at Messer’s corporate
manufacturing plant, or other location as determined by Messer, at its discretion. Purchaser shall be responsible for and pay for
any transportation expenses necessary for Limited Warranty repairs.
6. Limited Warranty Voidable. The limited warranty herein is void and deemed waived if the purchaser fails to give written
notice to Messer of any alleged defect under the limited warranty herein within 20 days of its discovery; or (a) purchaser or
parties other than Messer or its authorized representatives attempts to remedy or x the alleged Equipment defects; or (b) pur-
chaser has used the Equipment for purposes it was not intended to be used for; or (c) purchaser has not operated the Equipment
in a manner consistent with Messer’s instructions for the Equipment; or (d) the Equipment has been modied, altered, abused,
or misused; or (e) the Equipment has been damaged pursuant to accident, re, ood, or other Act of God.
7. No Consequential Damages. IN NO EVENT SHALL MESSER BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL
OR CONSEQUENTIAL DAMAGES WHATSOEVER, AND MESSER’S LIABILITY, UNDER NO CIRCUMSTANCES,
WILL EXCEED THE PRICE PAID FOR THE EQUIPMENT FOR WHICH LIABILITY IS CLAIMED.
8. Governing Law. This contract shall be governed by the laws of the State of Minnesota.
9. Arbitration. Any controversy or claim arising out of or relating to the limited warranty provided herein, or any alleged
breach thereof, shall be settled exclusively by arbitration in accordance with the Rules of the American Arbitration Association,
and judgment upon the award rendered by the arbitrator may be entered in any court having jurisdiction thereof. The arbitra-
tion shall be conducted in Minneapolis, MN, by one arbitrator selected by Messer and Purchaser, or, if they cannot agree, the
President of the American Arbitration Association.
Rev. 7-20
