MSI Aegis RS 10th User manual

Aegis RS 10th
Gaming Desktop

Preface
iiiii
Contents
Copyright and Trademarks Notice ��������������������������������������������������������������������������iii
Revision ������������������������������������������������������������������������������������������������������������������iii
Upgrade and Warranty��������������������������������������������������������������������������������������������iv
Acquisition of Replaceable Parts ����������������������������������������������������������������������������iv
Technical Support ���������������������������������������������������������������������������������������������������iv
Safety Instructions��������������������������������������������������������������������������������������������������� v
1. Overview ............................................................ 1-1
Packing Contents������������������������������������������������������������������������������������������������� 1-2
System Overview ������������������������������������������������������������������������������������������������� 1-3
2. Getting Started................................................... 2-1
Safety & Comfort Tips������������������������������������������������������������������������������������������ 2-2
Hardware Setup ��������������������������������������������������������������������������������������������������� 2-3
3. System Operations ............................................. 3-1
Power Management��������������������������������������������������������������������������������������������� 3-2
Network Connection (Windows 10)���������������������������������������������������������������������� 3-4
System Recovery (Windows 10)�������������������������������������������������������������������������� 3-7

Preface
iiiii
Copyright and Trademarks Notice
Copyright © Micro-Star Int’l Co�, Ltd� All rights reserved� The MSI logo used is a registered
trademark of Micro-Star Int’l Co�, Ltd� All other marks and names mentioned may be
trademarks of their respective owners� No warranty as to accuracy or completeness is
expressed or implied� MSI reserves the right to make changes to this document without
prior notice�
Revision
Revision Date
V1�0 2020/07
MSI Computer Corp�
901 Canada Court, City of Industry, CA 91748, USA
[phone]
us�msi�com

Preface
viv
Upgrade and Warranty
Please note that certain components preinstalled in the computer may be upgradable or
replaceable by user’s request� To learn more about upgrade limitation, please refer to
the speci󰘰cations in the User’s Manual. For any further information about the computer
users purchased, please contact the local dealer� Do not attempt to upgrade or replace
any component of the computer if you are not an authorized dealer or service center,
since it may cause the warranty void� It is strongly recommended that you contact the
authorized dealer or service center for any upgrade or replace service�
Acquisition of Replaceable Parts
Please be noticed that the acquisition of replaceable parts (or compatible ones) of
the computer users purchased in certain countries or territories may be ful󰘰lled by
the manufacturer within 5 years at most since the computer has been discontinued,
depending on the o󰘲cial regulations declared at the time. Please contact the
manufacturer via https://us�msi�com/support/ for the detailed information about the
acquisition of spare parts�
Technical Support
If a problem arises with your computer and no solution can be obtained from the user’s
manual, please contact your place of purchase or local distributor�
Alternatively, please try the following help resources for further guidance� Visit the
MSI website for technical guide, BIOS updates, driver updates and other information
via https://us�msi�com/support/ or contact MSI technical support at 1-888-447-6564,
Monday to Friday from 5:00 a.m. to 4:00 p.m. Paci󰘰c Standard Time, for more help.

Preface
viv
Safety Instructions
◙Read the safety instructions carefully and thoroughly�
◙All cautions and warnings on the computer or user’s manual should be
noted�
◙Make sure that the power voltage is within its safety range and has been
adjusted properly to the value of 100~240V before connecting the computer
to the power outlet�
◙If the power cord comes with a 3-pin plug, do not disable the protective earth
pin from the plug� The computer must be connected to an earthed mains
socket-outlet�
◙Always unplug the AC power cord before installing any add-on card or
module to the computer�
◙Always disconnect the AC power cord or switch the wall socket o󰘯 if the
computer would be left unused for a certain time to achieve zero energy
consumption�
◙Place the power cord in a way that people are unlikely to step on it� Do not
place anything on the power cord�
Please take special precautions if this computer comes with a battery�
◙Danger of explosion if battery is incorrectly replaced� Replace only with the
same or equivalent type recommended by the manufacturer�
◙Avoid disposal of a battery into 󰘰re or a hot oven, or mechanically crushing
or cutting of a battery, which can result in an explosion�
◙Avoid leaving a battery in an extremely high temperature or extremely low
air pressure environment that can result in an explosion or the leakage of
󰘱ammable liquid or gas.
◙Do not ingest battery� If the coin/button cell battery is swallowed, it can
cause severe internal burns and can lead to death� Keep new and used
batteries away from children�
◙To reduce the possibility of heat-related injuries or of overheating the
computer, do not place the computer on a soft, unsteady surface or obstruct
the computer air ventilators�
◙Use this computer only on a hard, 󰘱at and steady surface.
◙Keep this computer away from humidity and high temperature�
◙Do not leave the computer in an unconditioned environment with a storage
temperature above 60OC or below 0OC, which may damage the computer�
◙The maximum operating temperature is around 35OC�

Preface
PBvi
Never pour any liquid into the opening that could damage or cause electrical
shock�
Always keep the strong magnetic or electrical objects away from the computer�
If any of the following situations arises, get the computer checked by service
personnel:
◙The power cord or plug is damaged�
◙Liquid has penetrated into the computer�
◙The computer has been exposed to moisture�
◙The computer does not work well or you can not get it work according to
user’s manual�
◙The computer has dropped and damaged�
◙The computer has obvious sign of breakage�
Green Product Features
◙Reduced energy consumption during use and stand-by
◙Limited use of substances harmful to the environment and health
◙Easily dismantled and recycled
◙Reduced use of natural resources by encouraging recycling
◙Extended product lifetime through easy upgrades
◙Reduced solid waste production through take-back policy
Environmental Policy
◙The product has been designed to enable proper reuse of parts and
recycling and should not be thrown away at its end of life�
◙Users should contact the local authorized point of collection for recycling
and disposing of their end-of-life products�

1
Overview
Congratulations on purchasing the Aegis RS Gaming Desktop� This system is
your best PC choice� The feature packed platform also gives you an exciting
PC experience�

Overview
1-31-2
Packing Contents
Gaming Desktop Power Cord
User Guide
Keyboard
Mouse
* Please contact us immediately if any of the items is damaged or missing�
* The illustrations are for reference only and your packing contents may slightly vary
depending on the model you purchased�

Overview
1-31-2
System Overview
hTop View
448866
5577
11Power Button
Press the Power button to turn the system on and o󰘯.
22Reset Button
Press the Reset button to restart your PC�
33Power LED
The LED power light that indicates when the computer is on, o󰘯, or in
Standby�
44USB 3.2 Gen 1 Type C
USB 3�2 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed
data transfer for various devices, such as storage devices, hard drives,
video cameras, etc� The slim and sleek USB Type-C connector features
reversible plug orientation�
55USB 3.2 Gen 1
USB 3�2 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed
data transfer for various devices, such as storage devices, hard drives,
video cameras, etc�
112233

Overview
1-51-4
66Microphone Jack
This connector is provided for microphones�
77Headphone Jack
This connector is provided for headphones or speakers�
88MSI LED Button
Unlock all your RGB lighting e󰘯ects.
hRear View
ON
OFF
99
1212
1010
1313
1111
1414
11
22
33
44
55
66
88
77
1515

Overview
1-51-4
11USB 2.0 Port
The USB (Universal Serial Bus) port is for attaching USB devices such
as keyboard, mouse, or other USB-compatible devices� It supports up to
480Mbit/s (Hi-Speed) data transfer rate�
22HDMI-out
The High-De󰘰nition Multimedia Interface (HDMI) is an all-digital audio/
video interface capable of transmitting uncompressed streams� HDMI
supports all TV format, including standard, enhanced, or high-de󰘰nition
video, plus multi-channel digital audio on a single cable�
33DisplayPort out
DisplayPort is a digital display interface standard� This connector is used
to connect a monitor with DisplayPort inputs�
44USB 3.2 Gen 2 Port ( Type C)
USB 3�2 Gen 2, the SuperSpeed USB 10Gbps, delivers high-speed
data transfer for various devices, such as storage devices, hard drives,
video cameras, etc� The slim and sleek USB Type-C connector features
reversible plug orientation�
55USB 3.2 Gen 1 Port
USB 3�2 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed
data transfer for various devices, such as storage devices, hard drives,
video cameras, etc�
66
PS/2 Combo Port
PS/2 Combo Port is provided for keyboard or mouse�
77
USB 3.2 Gen 2 Port
USB 3�2 Gen 2, the SuperSpeed USB 10Gbps, delivers high-speed data
transfer for various devices, such as storage devices, hard drives, video
cameras, etc�

Overview
PB1-6
88
2.5G LAN Port
The standard RJ-45 LAN jack is provided for connection to the Local Area
Network (LAN)� You can connect a network cable to it�
Green/ OrangeYellow
LED Color LED State Condition
Yellow O󰘯 LAN link is not established�
On (steady state) LAN link is established�
On (blinking) The computer is communicating with another computer on
the LAN�
Green O󰘯 10 Mbit/sec data rate is selected�
On 100 Mbit/sec data rate is selected�
Orange On 1000 Mbit/sec data rate is selected�
99
Mic-In
This connector is provided for microphones�
1010
Line-Out
This connector is provided for headphones or speakers�
1111
Line In
This connector is provided for external audio output devices�
1212
SS-Out
Side surround sound line out in 7�1 channel mode�
1313
CS-Out
Center/ Subwoofer Out in 5�1/ 7�1 channel mode�
1414
RS-Out
Rear-Surround Out in 4/ 5�1/ 7�1 channel mode�
1515
Power Jack
Power supplied through this jack supplies power to your system�
NoticeNotice
High-speed devices are recommended for USB 3�2 ports whereas low-speed devices,
such as mouse or keyboard, are suggested to be plugged into the USB 2�0 ports�

2
Getting Started

Getting Started
2-32-2
Safety & Comfort Tips
Choosing a good workspace is important if you have to work with your PC for a long
period of time�
1� Your work area should have enough illumination�
2� Choose the proper desk and chair and adjust their height to 󰘰t your posture when
operating�
3� When sitting on the chair, sit straight and keep a good posture� Adjust the chair’s
back (if available) to support your back comfortably�
4� Place you feet 󰘱at and naturally on the 󰘱oor, so that your knees and elbows have
the proper position (about 90-degree) when operating�
5� Put your hands on the desk naturally to support your wrists�
6� Avoid using your PC in a place where discomfort may occur (such as on the bed)�
7� The Personal Computer System is an electrical device� Please treat it with great
care to avoid personal injury�

Getting Started
2-32-2
USB Type-C
Mini DisplayPort
DVI
HDMI
DisplayPort
Know Your Video Connectors
Step 1
REMOVE THE TEMPERED GLASS SIDE PANEL
Remove the four thumbscrews on the tempered glass side panel. And gently
remove the tempered glass panel away from the case and place it in a safe area.
Step 2 REMOVE THE FOAM PACKAGING
Carefully pull the foam packaging out the system. It should come out easily
without having to apply any force.
Step 3
INSPECT YOUR PC
Make sure all components and cables are seated firmly. Now, you can replace
the tempered glass side panel and secure with thumbscrews.
Step 4 CONNECT YOUR MONITOR
Connect your monitor to either display ports or HDMI ports on the graphics
cards.
Step 5
CONNECT WIFI ANTENNAE, KEYBOARD & MOUSE
Screw the Wi-Fi Antennae to the gold contact points on the rear of the case.
Plug the mouse and the keyboard into any of the USB ports.
Step 6 POWER ON YOUR DESKTOP
Plug the power cable into the power cable socket and plug the other end of
the power cable into a power outlet. Turn the power supply switch on by
having the “I” symbol on the switch pressed down. Press the power button.
Hardware Setup
hPlacing the System
If you have any further questions regarding your new computer, please do not hesitate
to contact us either through the online customer service site https://us�msi�com/support
or by contacting our customer support at 1-626-271-1004, Monday to Friday from 9:00
a.m. to 6:00 p.m. Paci󰘰c Standard Time. You can also contact technical support by
calling 1-888-447-6564, Monday to Friday from 5:00 a.m. to 4:00 a.m. Paci󰘰c Standard
Time� We will reply to you as soon as possible�

3
System Operations
This chapter provides you with essential information on system operations�
ImportantImportant
All information is subject to change without prior notice�

System Operations
3-33-2
Power Management
Power management of personal computers (PCs) and monitors has the potential to
save signi󰘰cant amounts of electricity as well as deliver environmental bene󰘰ts.
To be energy e󰘲cient, turn o󰘯 your display or set your PC to sleep mode after a period
of user inactivity�
hPower Management in Windows 10
■[Power Options] in Windows OS allow you to control the power management
features of your display, hard drive, and battery� Right-click [Start] , select
[Control Panel] from the list and then click [System and Security]�
Select [Power Options] and choose a power plan that suits your personal
needs. You may also 󰘰ne-tune the settings by clicking [Change plan settings].
■The Shut Down Computer menu presents the options of Sleep (S3/S4) & Shut
Down (S5) for rapid and easy management of your system power�
hPower Management through ENERGY STAR
qualied monitors
The power management feature allows the computer to initiate
a low-power or “Sleep” mode after a period of user inactivity�
When used with an external ENERGY STAR quali󰘰ed monitor,
this feature also supports similar power management features of
the monitor� To take advantage of these potential energy savings,
the power management feature has been preset to behave in the
following ways when the system is operating on AC power:
■ Turn o󰘯 the display after 10 minutes
■Initiate Sleep after 30 minutes

System Operations
3-33-2
hWaking the System Up
The computer shall be able to wake up from power saving mode in response to a
command from any of the following:
■the power button,
■the network (Wake On LAN),
■the mouse,
■the keyboard�
Energy Saving Tips:Energy Saving Tips:
■ Turn o󰘯 the monitor by pressing the monitor power button after a period of user
inactivity�
■Tune the settings in Power Options under Windows OS to optimize your PC’s
power management�
■Install power saving software to manage your PC’s energy consumption�
■ Always disconnect the AC power cord or switch the wall socket o󰘯 if your PC
would be left unused for a certain time to achieve zero energy consumption�

System Operations
3-53-4
Network Connection (Windows 10)
hWired Network
1� Right-click [Start] and select [Network Connections] from the list�
2� Select [Ethernet] and then [Network and Sharing Center]�
3� Select [Set up a new connection or network]�

System Operations
3-53-4
4� Choose [Connect to the Internet] and click [Next]�
5� Select [Broadband (PPPoE)] to connect using DSL or cable that requires a user
name and password�
6� Type the information from your Internet Service Provider (ISP) and click [Connect]
to establish your LAN connection�
