MSI Codex R 12th User manual

USB Type-C
Mini DisplayPort
DVI
HDMI
DisplayPort
Know Your Video Connectors
Step 1 REMOVE THE TEMPERED GLASS SIDE PANEL
Remove the four thumbscrews on the tempered glass side panel. And gently
remove the tempered glass panel away from the case and place it in a safe area.
Step 2 REMOVE THE FOAM PACKAGING
Carefully pull the foam packaging out the system. It should come out easily
without having to apply any force.
Step 3 INSPECT YOUR PC
Make sure all components and cables are seated firmly. Now, you can replace
the tempered glass side panel and secure with thumbscrews.
Step 4 CONNECT YOUR MONITOR
Connect your monitor to either display ports or HDMI ports on the graphics
cards.
Step 5 CONNECT WIFI ANTENNAE, KEYBOARD & MOUSE
Screw the Wi-Fi Antennae to the gold contact points on the rear of the case.
Plug the mouse and the keyboard into any of the USB ports.
Step 6 POWER ON YOUR DESKTOP
Plug the power cable into the power cable socket and plug the other end of
the power cable into a power outlet. Turn the power supply switch on by
having the “I” symbol on the switch pressed down. Press the power button.
If you have any further questions regarding your new computer, please do not hesitate to contact us either through the online customer service site
https://us.msi.com/support or by contacting our customer support at 1-626-271-1004, Monday to Friday from 9:00 a.m. to 6:00 p.m. Pacific Standard Time. You can
also contact technical support by calling 1-888-447-6564, Monday to Friday open 24 hours (Weekend and Public Holiday closed). We will reply to you as soon as possible.
IMPORTANT
PLEASE READ BEFORE TURNING ON THE DESKTOP
Scan for setup
video guides
G52-B0Y22X1-LAX

1
<變數 1> Contents
Contents
Safety Information ...........................................................................................3
Specifications ...................................................................................................4
Rear I/O Panel ...............................................................................................10
Overview of Components ..............................................................................11
CPU Socket...............................................................................................................12
DIMM Slots................................................................................................................13
PCI_E1~4: PCIe Expansion Slots..............................................................................14
JFP1, JFP2: Front Panel Connectors.......................................................................15
JAUD1: Front Audio Connector ................................................................................15
SATA5~8, SATA_A1& SATA_B1: SATA 6Gb/s Connectors .......................................16
M2_1~2: M.2 Slot (Key M).........................................................................................16
ATX_PWR1, CPU_PWR1~2: Power Connectors.......................................................17
JUSB1~2: USB 2.0 Connectors.................................................................................18
JUSB3: USB 3.2 Gen 1 Connector ............................................................................18
JUSB4: USB 3.2 Gen 1 Type-C Connector................................................................19
JLPT1: Parallel Port Connector...............................................................................19
CPU_FAN1, PUMP_FAN1, SYS_FAN1~2: Fan Connectors......................................20
JTPM1: TPM Module Connector...............................................................................20
JCI1: Chassis Intrusion Connector...........................................................................21
JDASH1: Tuning controller Connector.....................................................................21
JBAT1: Clear CMOS (Reset BIOS) Jumper...............................................................22
JCOM1: Serial Port Connector.................................................................................22
JRGB1: RGB LED connector.....................................................................................22
JRAINBOW1~2: Addressable RGB LED connectors ................................................23
EZ Debug LED...........................................................................................................23
Installing OS, Drivers & MSI Center ..............................................................24
Installing Windows 10/ Windows 11.........................................................................24
Installing Drivers......................................................................................................24
MSI Center................................................................................................................24
Thank you for purchasing the MSI® &2'(;5'HVNWRS. This
User Guide gives information about board layout,
component overview, BIOS setup and software installation.

2Contents
UEFI BIOS .......................................................................................................25
BIOS Setup................................................................................................................26
Entering BIOS Setup.................................................................................................26
BIOS User Guide.......................................................................................................26
Resetting BIOS..........................................................................................................27
Updating BIOS...........................................................................................................27

3
Contents Safety Information
Safety Information
∙The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
∙Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
∙Hold the motherboard by the edges to avoid touching sensitive components.
∙It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap is
not available, discharge yourself of static electricity by touching another metal object
before handling the motherboard.
∙Store the motherboard in an electrostatic shielding container or on an anti-static
pad whenever the motherboard is not installed.
∙Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
∙Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
∙If you need help during any installation step, please consult a certified computer
technician.
∙Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
∙Keep this user guide for future reference.
∙Keep this motherboard away from humidity.
∙Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
∙Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
∙All cautions and warnings on the motherboard should be noted.
∙If any of the following situations arises, get the motherboard checked by service
personnel:
▪Liquid has penetrated into the computer.
▪The motherboard has been exposed to moisture.
▪The motherboard does not work well or you can not get it work according to
user guide.
▪The motherboard has been dropped and damaged.
▪The motherboard has obvious sign of breakage.
∙Do not leave this motherboard in an environment above 60°C (140°F), it may
damage the motherboard.

4Specications
Specifications
CPU
∙Supports 12th Gen Intel® Core™ Processors
∙Processor socket LGA1700
* Please go to www.msi.com to get the newest support
status as new processors are released.
Chipset Intel® B660 chipset
Memory
∙4x DDR5 memory slots, support up to 128GB*
∙Supports 1R 4800 MHz (by JEDEC & POR)
∙Max overclocking frequency:
▪1DPC 1R Max speed up to 6200+ MHz
▪1DPC 2R Max speed up to 5200+ MHz
▪2DPC 1R Max speed up to 4000+ MHz
▪2DPC 2R Max speed up to 4000+ MHz
∙Supports Intel® XMP 3.0 OC
∙Supports Dual Controller Dual-Channel mode
∙Supports non-ECC, un-buffered memory
*Please go to www.msi.com for more information on
compatible memory
Expansion Slots
∙4x PCIe x16 slots
▪PCI_E1 (From CPU)
▫Support PCIe 4.0 x16
▪PCI_E2 ~4 (From B660 chipset)
▫Support PCIe 3.0 x1
Onboard Graphics
∙1x HDMI 2.1 with HDR port, supports a maximum
resolution of 4K 60Hz */**
* Available only on processors featuring integrated
graphics.
** Graphics specifications may vary depending on the
CPU installed.
Audio Realtek® ALC897 Codec
∙7.1-Channel High Definition Audio
LAN 1x Realtek® 8125BG 2.5Gbps LAN controller
Continued on next page

5
Specications Specications
Continued from previous page
Wireless LAN &
Bluetooth®
Intel® Wi-Fi 6
∙The Wireless module is pre-installed in the M.2
(Key-E) slot
∙Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz)
up to 2.4Gbps
∙Supports 802.11 a/ b/ g/ n/ ac/ ax
∙Supports Bluetooth® 5.2
Storage
∙4x SATA 6Gb/s ports (SATA5~8, from B660 Chipset)*
∙2x SATA 6Gb/s ports (SATA_A1 & SATA_B1, from
Asmedia ASM1061)
∙2x M.2 slots (Key M)
▪M2_1 slot (From CPU)
▫Supports PCIe 4.0 x4
▫Supports 2242/ 2260/ 2280 storage devices
▪M2_2 slot (From B660 chipset)*
▫Supports PCIe 4.0x4
▫Supports SATA 6Gb/s
▫Supports 2242/ 2260/ 2280 storage devices
▫Intel® Optane™ Memory Ready for M2_2 slot
∙Support Intel® Smart Response Technology for Intel
Core™ processors
* SATA7 will be unavailable when installing M.2 SATA
SSD in the M2_2 slot.
RAID
∙Supports RAID 0, RAID 1, RAID 5 and RAID 10 for
SATA storage devices*
*SATA_A1 & SATA_B1 do not support RAID function.
USB
∙Intel® B660 Chipset
▪2x USB 3.2 Gen 2 10Gbps (Type-A+Type-C) ports
on the back panel
▪3x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports
and 1 Type-C port available through the internal
USB connectors)
▪6x USB 2.0 ports (2 Type-A ports on the back
panel and 4 ports available through the internal
USB connectors)
∙Asmedia ASM1074
▪4x USB 3.2 Gen 1 5Gbps Type-A ports on the
back panel
Continued on next page

6Specications
Continued from previous page
Internal Connectors
∙1x 24-pin ATX main power connector
∙1x 8-pin ATX 12V power connector
∙1x 4-pin ATX 12V power connector
∙6x SATA 6Gb/s connectors
∙2x M.2 slots (M-Key)
∙1x USB 3.2 Gen 1 5Gbps Type-C port
∙1x USB 3.2 Gen 1 5Gbps connectors (supports
additional 2 USB 3.2 Gen 1 5Gbps ports)
∙2x USB 2.0 connectors (supports additional 4 USB
2.0 ports)
∙1x 4-pin CPU fan connector
∙1x 4-pin water-pump fan connector
∙2x 4-pin system fan connectors
∙1x Front panel audio connector
∙2x System panel connectors
∙1x Parallel port connector
∙1x Serial port connector
∙1x Chassis Intrusion connector
∙1x Clear CMOS jumper
∙1x TPM module connector
∙1x Tuning controller connector
LED Features
∙1x 4-pin RGB LED connector
∙2x 3-pin RAINBOW LED connectors
∙4x EZ Debug LED
Back Panel
Connectors
∙1x PS/2 keyboard/ mouse combo port
∙2x USB 2.0 Type-A ports
∙1x HDMI port
∙4x USB 3.2 Gen 1 5Gbps Type-A ports
∙1x LAN (RJ45) port
∙1x USB 3.2 Gen 2 10Gbps Type-A port
∙1x USB 3.2 Gen 2 10Gbps Type-C port
∙2x Wi-Fi Antenna connectors
∙3x audio jacks
Continued on next page

7
Specications Specications
Continued from previous page
I/O Controller NUVOTON NCT6687D Controller Chip
Hardware Monitor
∙CPU/ System/ Chipset temperature detection
∙CPU/ System/ Pump fan speed detection
∙CPU/ System/ Pump fan speed control
Form Factor ∙Micro-ATX Form Factor
∙9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
BIOS Features
∙1x 256 Mb flash
∙UEFI AMI BIOS
∙ACPI 6.4, SMBIOS 3.4
∙Multi-language
Software
∙Drivers
∙MSI Center
∙Intel® Extreme Tuning Utility
∙CPU-Z MSI GAMING
∙Google Chrome™, Google Toolbar, Google Drive
∙Norton™ Internet Security Solution
MSI Center Features
∙LAN Manager
∙Mystic Light
∙Ambient Devices
∙Frozr AI Cooling
∙User Scenario
∙True Color
∙Live Update
∙Hardware Monitoring
∙Super Charger
∙Speed Up
∙Smart Image Finder
∙MSI Companion
Continued on next page

8Specications
Continued from previous page
Special Features
∙Audio
▪Audio Boost
∙Network
▪2.5G LAN
▪LAN Manager
▪Intel WiFi
∙Cooling
▪M.2 Shield Frozr
▪7W/mK MOSFET thermal pad
▪Pump Fan
▪Smart Fan Control
∙LED
▪Mystic Light
▪Mystic Light Extension(RGB)
▪Mystic Light Extension(RAINBOW)
▪Mystic Light Extension
▪Ambient Devices Support
Continued on next page

9
Specications Specications
Continued from previous page
Special Features
∙Performance
▪Lightning Gen 4 PCI-E Slot
▪Lightning Gen 4 M.2
▪Memory Boost
▪Core Boost
▪Game Boost
▪USB 3.2 Gen 2 10G
▪USB with Type A+C
▪Front USB Type-C
▪Dual CPU Power
▪2oz Copper thickened PCB
∙Protection
▪PCI-E Steel Armor
∙Experience
▪MSI Center
▪Click BIOS 5
▪EZ M.2 Clip
▪Forzr AI Cooling
▪CPU Cooler Tuning
▪EZ DEBUG LED
▪App Player
▪Tile

10 Rear I/O Panel
Rear I/O Panel
Link/ Activity LED
Status Description
Off No link
Yellow Linked
Blinking Data activity
Speed LED
Status Description
Off 10 Mbps connection
Green 100/ 1000 Mbps connection
Orange 2.5 Gbps connection
LAN Port LED Status Table
Audio 7.1-channel Configuration
To configure 7.1-channel audio, you have to connect front audio I/O module to JAUD1
connector and follow the below steps.
1. Click on the Realtek HD Audio Manager > Advanced Settings to open the dialog
below.
2. Select Mute the rear output device, when a front headphone plugged in.
3. Plug your speakers to audio jacks on rear and front I/O panel. When you plug into
a device at an audio jack, a dialogue window will pop up asking you which device
is current connected.
USB 3.2 Gen 1
5Gbps Type-A
PS/2 Combo port 2.5 Gbps LAN
USB 2.0 Type-A
Line-in
Mic-in
Line-out
USB 3.2 Gen 2
10Gbps Type-A
USB 3.2 Gen 2
10Gbps Type-C
Wi-Fi Antenna
connectors

11
Rear I/O Panel Overview of Components
SATA_A
SATA_B
M2_2
JFP2
JTPM1
JRGB1
SATA▼5▲6
SATA▼7▲8
JBAT1
M2_1
SYS_FAN2 JUSB4
JUSB3
JUSB2
JUSB1
JCOM1
JLPT1
CPU_FAN1
PUMP_FAN1
SYS_FAN1
PCI_E1
PCI_E2
PCI_E3
JCI1
PCI_E4
JAUD1
Processor Socket
CPU_PWR1
CPU_PWR2
JRAINBOW1
JDASH1
JRAINBOW2 JFP1
ATX_PWR1
DIMMB1
DIMMB2
DIMMA1
DIMMA2
Overview of Components
* Distance from the center of the CPU to the nearest DIMM slot.
52mm*

12 Overview of Components
CPU Socket
Please install the CPU into the CPU socket as shown below.
⚠
Important
∙
Always unplug the power cord from the power outlet before installing or removing
the CPU.
∙
Please retain the CPU protective cap after installing the processor. MSI will deal
with Return Merchandise Authorization (RMA) requests if only the motherboard
comes with the protective cap on the CPU socket.
∙
When installing a CPU, always remember to install a CPU heatsink. A CPU heatsink
is necessary to prevent overheating and maintain system stability.
∙
Conrm that the CPU heatsink has formed a tight seal with the CPU before booting
your system.
∙
Overheating can seriously damage the CPU and motherboard. Always make sure
the cooling fans work properly to protect the CPU from overheating. Be sure to apply
an even layer of thermal paste (or thermal tape) between the CPU and the heatsink to
enhance heat dissipation.
∙
Whenever the CPU is not installed, always protect the CPU socket pins by covering
the socket with the plastic cap.
∙
If you purchased a separate CPU and heatsink/ cooler, Please refer to the docu-
mentation in the heatsink/ cooler package for more details about installation.
1
4
6
57
8
9
3
2

13
Overview of Components Overview of Components
DIMM Slots
Please install the memory module into the DIMM slot as shown below.
Memory module installation recommendation
DIMMB2
DIMMA2 DIMMA2
DIMMB2
DIMMB1
DIMMA2
DIMMA1
1
2
3
2

14 Overview of Components
⚠
Important
∙
Always insert memory modules in the DIMMA2 slot rst.
∙
To ensure system stability for Dual channel mode, memory modules must be of the
same type, number and density.
∙
Some memory modules may operate at a lower frequency than the marked value
when overclocking due to the memory frequency operates dependent on its Serial
Presence Detect (SPD). Go to BIOS and nd the DRAM Frequency to set the memory
frequency if you want to operate the memory at the marked or at a higher frequency.
∙
It is recommended to use a more ecient memory cooling system for full DIMMs
installation or overclocking.
∙
The stability and compatibility of installed memory module depend on installed
CPU and devices when overclocking.
∙
Please refer www.msi.com for more information on compatible memory.
PCI_E1~4: PCIe Expansion Slots
⚠
Important
∙
When adding or removing expansion cards, always turn o the power supply and
unplug the power supply power cable from the power outlet. Read the expansion
card’s documentation to check for any necessary additional hardware or software
changes.
∙
If you install a large and heavy graphics card, you need to use a tool such as MSI
Gaming Series Graphics Card Bolster to support its weight to prevent deformation
of the slot.
∙
For a single PCIe x16 expansion card installation with optimum performance, using
the PCI_E1 slot is recommended.
PCI_E1: PCIe 4.0 x16 (From CPU)
PCI_E3: PCIe 3.0 x1 (From B660 chipset)
PCI_E4: PCIe 3.0 x1 (From B660 chipset)
PCI_E2: PCIe 3.0 x1 (From B660 chipset)

15
Overview of Components Overview of Components
JFP1, JFP2: Front Panel Connectors
These connectors connect to the switches and LEDs on the front panel.
1
2 10
9
+
+
+- --
-
+
Power LED
HDD LED Reset Switch
Reserved
Power Switch 1 HDD LED + 2 Power LED +
3 HDD LED - 4 Power LED -
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
JFP2 1
+
+-
-
Speaker
Buzzer 1 Speaker - 2 Buzzer +
3 Buzzer - 4 Speaker +
HDD LED
RESET SW
HDD LED HDD LED -
HDD LED +
POWER LED -
POWER LED +
POWER LED
JFP1
JAUD1: Front Audio Connector
This connector allow you to connect audio jacks on the front panel.
1
2 10
9
1 MIC L 2 Ground
3 MIC R 4 NC
5 Head Phone R 6 MIC Detection
7 SENSE_SEND 8 No Pin
9 Head Phone L 10 Head Phone Detection

16 Overview of Components
SATA5~8, SATA_A1& SATA_B1: SATA 6Gb/s Connectors
These connectors are SATA 6Gb/s interface ports. Each connector can connect to one
SATA device.
SATA5
SATA7
SATA6
SATA_B1
SATA_A1
SATA8
⚠
Important
∙
SATA7 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
∙
Please do not fold the SATA cable at a 90-degree angle. Data loss may result
during transmission otherwise.
∙
SATA cables have identical plugs on either sides of the cable. However, it is
recommended that the at connector be connected to the motherboard for space
saving purposes.
M2_1~2: M.2 Slot (Key M)
Please install the M.2 solid-state drive (SSD) into the M.2 slot as shown below.
30º30º
3
2
1
(Optional)

17
Overview of Components Overview of Components
ATX_PWR1, CPU_PWR1~2: Power Connectors
These connectors allow you to connect an ATX power supply.
⚠
Important
Make sure that all the power cables are securely connected to a proper ATX power
supply to ensure stable operation of the motherboard.
24
131
12
ATX_PWR1
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 Ground 15 Ground
4 +5V 16 PS-ON#
5 Ground 17 Ground
6 +5V 18 Ground
7 Ground 19 Ground
8 PWR OK 20 Res
9 5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 Ground
5
41
8
CPU_PWR1
1 Ground 5 +12V
2 Ground 6 +12V
3 Ground 7 +12V
4 Ground 8 +12V
3
2 1
4CPU_PWR2 1 Ground 3 +12V
2 Ground 4 +12V

18 Overview of Components
JUSB3: USB 3.2 Gen 1 Connector
This connector allows you to connect USB 3.2 Gen 1 5Gbps ports on the front panel.
1
10 11
20
1 Power 11 USB2.0+
2 USB3_RX_DN 12 USB2.0-
3 USB3_RX_DP 13 Ground
4 Ground 14 USB3_TX_C_DP
5 USB3_TX_C_DN 15 USB3_TX_C_DN
6 USB3_TX_C_DP 16 Ground
7 Ground 17 USB3_RX_DP
8 USB2.0- 18 USB3_RX_DN
9 USB2.0+ 19 Power
10 Ground 20 No Pin
⚠
Important
Note that the Power and Ground pins must be connected correctly to avoid possible
damage.
JUSB1~2: USB 2.0 Connectors
These connectors allow you to connect USB 2.0 ports on the front panel.
⚠
Important
∙
Note that the VCC and Ground pins must be connected correctly to avoid possible
damage.
∙
In order to recharge your iPad,iPhone and iPod through USB ports, please install
MSI Center utility.
1
2 10
9
1 VCC 2 VCC
3 USB0- 4 USB1-
5 USB0+ 6 USB1+
7 Ground 8 Ground
9 No Pin 10 NC

19
Overview of Components Overview of Components
JUSB4: USB 3.2 Gen 1 Type-C Connector
This connector allows you to connect USB 3.2 Gen 1 Type-C connector on the front
panel. The connector possesses a foolproof design. When you connect the cable, be
sure to connect it with the corresponding orientation.
JUSB4
USB Type-C Cable
USB Type-C port on the
front panel
1
2 26
25
1 RSTB# 2 AFD# 3 PRND0
4 ERR# 5 PRND1 6 PINIT#
7 PRND2 8 LPT_SLIN# 9 PRND3
10 Ground 11 PRND4 12 Ground
13 PRND5 14 Ground 15 PRND6
16 Ground 17 PRND7 18 Ground
19 ACK# 20 Ground 21 BUSY
22 Ground 23 PE 24 Ground
25 SLCT 26 No Pin
JLPT1: Parallel Port Connector
This connector allows you to connect the optional parallel port with bracket.
This manual suits for next models
1
Table of contents
Other MSI Desktop manuals

MSI
MSI Infinite S B928 User manual

MSI
MSI MPG GUNGNIR 110R User manual

MSI
MSI MS-98E2 User manual

MSI
MSI AP1622E User manual

MSI
MSI 915G COMBO-FR - Motherboard - ATX User manual

MSI
MSI Trident B937 User manual

MSI
MSI Midas 915GM User manual

MSI
MSI PRO 20EX Series User manual

MSI
MSI AE270 Series User manual

MSI
MSI Trident B924 User manual
