MSI G41M series User manual

i
G41Mseries
MS-7563(v1.X)Mainboard
G52-75631X1
7563v1.1-0 Preface.p65 2008/11/11, 午 05:361

ii
CopyrightNotice
The materialinthisdocumentistheintellectual propertyof MICRO-STAR
INTERNATIONAL.Wetakeeverycareinthe preparationof thisdocument, butno
guaranteeisgivenastothecorrectnessofitscontents.Ourproductsareunder
continualimprovementand wereservetherighttomakechangeswithoutnotice.
Trademarks
Alltrademarksarethepropertiesoftheirrespectiveowners.
NVIDIA,theNVIDIAlogo,DualNet, and nForceareregisteredtrademarksortrade-
marksofNVIDIACorporationin theUnitedStatesand/orothercountries.
AMD,Athlon ,Athlon XP,Thoroughbred ,andDuron areregisteredtrade-
marksofAMDCorporation.
Intel®andPentium®areregisteredtrademarksofIntelCorporation.
PS/2and OS®/2areregisteredtrademarksofInternationalBusiness Machines
Corporation.
Windows®95/98/2000/NT/XP/Vistaareregisteredtrademarks ofMicrosoft
Corporation.
Netware®isaregisteredtrademarkofNovell,Inc.
Award®isaregisteredtrademarkofPhoenixTechnologiesLtd.
AMI®isaregisteredtrademarkofAmericanMegatrendsInc.
RevisionHistory
Revision RevisionHistory Date
V1.0 Firstrelease November2008
TechnicalSupport
Ifaproblemariseswithyoursystemandnosolutioncanbeobtainedfromtheuser’s
manual,pleasecontactyourplaceofpurchaseorlocaldistributor.Alternatively,
pleasetrythefollowing helpresourcesforfurtherguidance.
Visit theMSI websiteforFAQ,technical guide,BIOSupdates,driverupdates,
andotherinformation: http://global.msi.com.tw/index.php?
func=service
Contactourtechnicalstaff at: http://ocss.msi.com.tw
7563v1.1-0 Preface.p65 2008/11/11, 午 05:362

iii
SafetyInstructions
CAUTION: Dangerofexplosionifbatteryisincorrectlyreplaced.
Replaceonlywiththe sameorequivalenttype recommendedbythe
manufacturer.
1. Alwaysread thesafetyinstructionscarefully.
2. KeepthisUser’sManualforfuturereference.
3. Keepthisequipmentawayfromhumidity.
4. Laythisequipmentonareliableflatsurfacebeforesetting itup.
5. Theopeningsontheenclosureareforairconvectionhenceprotectstheequip-
ment fromoverheating.DONOTCOVERTHEOPENINGS.
6. Makesurethevoltageofthe powersourceandadjustproperly110/220Vbe-
foreconnectingtheequipmenttothepowerinlet.
7. Placethe powercordsuchawaythatpeoplecannotstepon it. Donotplace
anythingoverthepowercord.
8. AlwaysUnplug thePowerCordbeforeinsertinganyadd-oncardormodule.
9. All cautionsand warningsontheequipmentshouldbenoted.
10. Neverpouranyliquidintotheopeningthatcoulddamage orcauseelectrical
shock.
11. If anyof thefollowing situationsarises, gettheequipmentcheckedbyaservice
personnel:
†Thepowercordorplugisdamaged.
†Liquid haspenetratedintotheequipment.
†Theequipmenthasbeen exposedtomoisture.
†Theequipmenthasnotworkwelloryoucannotgetitworkaccording to
User’sManual.
†Theequipmenthasdroppedand damaged.
†Theequipmenthasobvioussign of breakage.
12.DONOTLEAVETHISEQUIPMENTINANENVIRONMENTUNCONDITIONED,STOR-
AGETEMPERATUREABOVE600 C(1400F),IT MAYDAMAGETHEEQUIPMENT.
7563v1.1-0 Preface.p65 2008/11/11, 午 05:363

iv
FCC-BRadio Frequency Interference Statement
Thisequipmenthasbeen
tested and found tocomply
withthe limitsforaClassB
digitaldevice,pursuanttoPart
15of the FCCRules.Theselimitsaredesignedtoprovidereasonable protection
againstharmful interferenceinaresidentialinstallation.Thisequipmentgenerates,
usesand canradiateradiofrequencyenergyand,ifnotinstalledand used in accor-
dancewiththeinstructions,maycauseharmful interferencetoradiocommunications.
However,thereisno guarantee thatinterferencewill notoccurin aparticular
installation.Ifthisequipmentdoescauseharmful interferencetoradioortelevision
reception,whichcanbedeterminedbyturning theequipmentoff and on,the useris
encouragedtotrytocorrecttheinterferencebyone ormoreof themeasureslisted
below.
†Reorientorrelocatethereceiving antenna.
†Increasetheseparationbetweentheequipmentand receiver.
†Connecttheequipmentintoanoutleton acircuitdifferentfromthatto
whichthereceiverisconnected.
†Consultthedealeroranexperiencedradio/televisiontechnicianforhelp.
Notice1
Thechangesormodificationsnotexpresslyapprovedbythepartyresponsible for
compliancecould void theuser’sauthoritytooperatetheequipment.
Notice2
Shieldedinterfacecablesand A.C.powercord,ifany,mustbeusedinorderto
complywiththeemissionlimits.
VOIRLANOTICED ’INSTALLATIONAVANTDERACCORDERAURESEAU.
Micro-StarInternational
MS-7563
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe
followingtwoconditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustaccept anyinterferencereceived,includinginterferencethat
maycauseundesiredoperation.
7563v1.1-0 Preface.p65 2008/11/11, 午 05:364

v
WEEE (WasteElectricaland ElectronicEquipment) Statement
7563v1.1-0 Preface.p65 2008/11/11, 午 05:365

vi
7563v1.1-0 Preface.p65 2008/11/11, 午 05:366

vii
7563v1.1-0 Preface.p65 2008/11/11, 午 05:367

viii
CONTENTS
CopyrightNotice..............................................................................................................ii
Trademarks.......................................................................................................................ii
RevisionHistory..............................................................................................................ii
Technical Support...........................................................................................................ii
SafetyInstructions.........................................................................................................iii
FCC-B RadioFrequencyInterferenceStatement........................................................iv
WEEE(WasteElectricalandElectronicEquipment)Statement....................................v
Chapter1.GettingStarted....................................................................................1-1
MainboardSpecifications...................................................................................1-2
MainboardLayout................................................................................................1-4
PackingChecklist.................................................................................................1-5
Chapter2.HardwareSetup..................................................................................2-1
Quick ComponentsGuide....................................................................................2-2
CPU(CentralProcessingUnit)............................................................................2-3
Memory.................................................................................................................2-7
PowerSupply......................................................................................................2-9
BackPanel..........................................................................................................2-10
Connectors........................................................................................................2-12
Jumpers..............................................................................................................2-20
Slots...................................................................................................................2-21
Chapter3BIOSSetup.............................................................................................3-1
EnteringSetup.....................................................................................................3-2
TheMainMenu.....................................................................................................3-4
StandardCMOSFeatures...................................................................................3-6
AdvancedBIOSFeatures...................................................................................3-9
IntegratedPeripherals.......................................................................................3-12
PowerManagementSetup...............................................................................3-14
H/WMonitor........................................................................................................3-17
BIOSSetting Password.....................................................................................3-18
Cell Menu............................................................................................................3-19
LoadFail-Safe/Optimized Defaults.................................................................3-23
AppendixARealtekAudio...................................................................................A-1
InstallingtheRealtekHDAudioDriver................................................................A-2
SoftwareConfiguration......................................................................................A-4
HardwareSetup................................................................................................A-19
AppendixBDualCoreCenter..............................................................................B-1
Activating DualCoreCenter...............................................................................B-2
Main......................................................................................................................B-3
7563v1.1-0 Preface.p65 2008/11/11, 午 05:368

ix
DOT (DynamicOverClocking).............................................................................B-5
Clock.....................................................................................................................B-6
Voltage.................................................................................................................B-7
FANSpeed...........................................................................................................B-8
Temperature.........................................................................................................B-9
UserProfile........................................................................................................B-10
7563v1.1-0 Preface.p65 2008/11/11, 午 05:369

1-1
Getting Started
Getting Started
Chapter1
ThankyouforchoosingtheG41MSeries(MS-7563 v1.X)
Micro-ATXmainboard. The G41MSeriesmainboardsare
basedon Intel G41M&ICH7 chipsetsforoptimalsystem
efficiency.Designedtofittheadvanced Intel Core2Duo/
Quad/Pentium/CeleronLGA775 processor,theG41MSe-
riesdeliverahighperformanceandprofessionaldesktop
platformsolution.
7563v1.0-1.p65 2008/11/11, 午 05:361

MS-7563Mainboard
1-2
MainboardSpecifications
ProcessorSupport
-Intel®Core2Quad/Core2Duo/ /Yorkfield/Wolfdaleprocessorsin
LGA775package
-Supports4pinCPUFanPin-HeaderwithFan Speed Control
(ForthelatestinformationaboutCPU, pleasevisit
http://global.msi.com.tw/index.php?func=cpuform2)
SupportedFSB
-1333/1066/800 MHz
Chipset
-NorthBridge:Intel®G41chipset
-SouthBridge:Intel®ICH7chipset
MemorySupport
-DDR2667/800 SDRAM(8GBMax)
-2DDR2DIMMs(240pin/1.8V)
(Formoreinformation oncompatiblecomponents,pleasevisit
http://global.msi.com.tw/index.php?func=testreport)
LAN
-Supports10/100/1000 FastEthernetbyRealtek8111DL
Audio
-ChipintegratedbyRealtek®ALC888
-Flexible8-channelaudiowithjacksensing
-SupportsVistapremiumcompliance
IDE
-1IDEportbyICH7
-SupportsUltraDMA66/100mode
-SupportsPIO,BusMasteroperationmode
SATA
-4SATAportsbyICH7
-Supportsstorageand datatransfersatup to3Gb/s
Floppy
-1floppyport
-Supports1FDD with360KB, 720KB,1.2MB,1.44MBand 2.88MB
Connectors
Back panel
-1PS/2mouseport
-1PS/2keyboardport
-1VGAport
-1DVI-D port
7563v1.0-1.p65 2008/11/11, 午 05:362

1-3
Getting Started
-1DisplayPortjack
-4USB2.0Ports
-1RJ-45 LANjack
-11394port(optional)
-6flexibleaudiojacks
On-BoardPinheaders/Connectors
-2USB 2.0pinheaders
-1CD-inpinheader
-1SPDIF-Outpinheader
-1IEEE1394pinheader(optional)
-1Front PanelAudiopinheader
-1Serialportpinheader
-1TPM(optional)
-1ChassisIntrusionSwitchpinheader
-1ParallelPortpinheader
Slots
-1PCI Expressx16 slot
-1PCIExpress x1slot
-2PCIslots
-Support 3.3V/ 5VPCIbusInterface
FormFactor
-Micro-ATX(24.4cmX22.8cm)
Mounting
-6mountingholes
7563v1.0-1.p65 2008/11/11, 午 05:363

MS-7563Mainboard
1-4
G41MSeries
(MS-7563 v1.X)Micro-ATXMainboard
MainboardLayout
PCI 2
PCI 1
PCI_E1
PCI_E2
BATT
+
JUAD1
ALC888
CD_IN1
JSPD1 JUSB1
J1394_1(optional)
JUSB2
JCOM1
JBAT1
JPW1
SYSFAN1
S
Y
S
F
A
N
2
SATA1
SATA2
JFP2JFP1
IDE1A
TX1
JTPM1(optional)
JLPT1
DIMM1 DIMM2
F
D
D
1
JCI1
SATA3
SATA4
T:Line-In
M:Line-Out
B:Mic
T:RS-Out
M:CS-Out
B:SS-Out
Top:LANJack
Bottom:USBports
DisplayPortJack
Top:Mouse
Bottom:Keyboard
Top: VGAport
Bottom:DVI-Dport
Intel
G41
Fintek
F71882FG
Realtek
T:1394 port(optional)
B:USB ports
RTM875T-605
Intel
ICH7
7563v1.0-1.p65 2008/11/11, 午 05:364

1-5
Getting Started
PackingChecklist
*The picturesareforreferenceonlyandmayvaryfromthepackingcontentsofthe
productyoupurchased.
PowerCable
SATACable
MSImotherboard MSIDriver/UtilityCD
Back IOShield
StandardCablefor
IDEDevices
User’sGuide
7563v1.0-1.p65 2008/11/11, 午 05:365

2-1
HardwareSetup
HardwareSetup
Chapter2
Thischapterprovidesyou withtheinformation about
hardwaresetupprocedures.Whiledoingthe installation,
becarefulinholdingthecomponentsandfollowthe
installationprocedures.Forsomecomponents,ifyou
install inthewrong orientation,thecomponentswillnot
workproperly.
Useagroundedwrist strapbeforehandlingcomputer
components.Staticelectricitymaydamagethe
components.
7563v1.0CH2Hardware Setup.p65 2008/11/11, 午 05:361

MS-7563Mainboard
2-2
Quick ComponentsGuide
SYSFAN1,
p.2-14
Back Panel,
p.2-10
JPW1,
p.2-9 CPU, p.2-3 CPUFAN1, p.2-14
JCI1,
p.2-14
DDR2,
p.2-7
ATX1,
p.2-9
FDD1,
p.2-12
JLPT1,
p.2-19
JTPM1,
p.2-17
JCOM1,
p.2-18
SYSFAN2,
p.2-14
IDE1,
p.2-12
SATA1~4,
p.2-13
JBAT1,
p.2-20
JFP1/2,
p.2-16
JUSB1/2,
p.2-18
J1394_1,
p.2-15
JSPD1,
p.2-15
CD_IN1,
p.2-16
JAUD1,
p.2-17
PCI,
p.2-21
PCIE,
p.2-21
7563v1.0CH2Hardware Setup.p65 2008/11/11, 午 05:362

2-3
HardwareSetup
CPU(CentralProcessingUnit)
Whenyou areinstalling theCPU, makesuretoinstallthecoolertoprevent
overheating. If youdonothavetheCPUcooler, consultyourdealerbeforeturning
onthecomputer.
Forthelatest informationaboutCPU,pleasevisit http://global.msi.com.tw/index.php?
func=cpuform2
Introduction toLGA775 CPU
Thesurfaceof LGA775 CPU.
Remembertoapplysomether-
malpasteon itforbetterheat
dispersion.
Yellowtriangleis the Pin1indicator
Thepin-padsideofLGA775
CPU.
Yellowtriangleis the Pin1indicator
Alignment Key Alignment Key
Important
Overheating
Overheating will seriouslydamage the CPUand system.Always makesure
thecoolingfancanworkproperlytoprotectthe CPUfromoverheating.Make
surethatyouapplyan even layerofthermalpaste(orthermaltape)between
the CPUand the heatsinktoenhanceheatdissipation.
ReplaceingtheCPU
WhilereplacingtheCPU,alwaysturnofftheATXpowersupplyorunplug the
powersupply spowercordfromthegrounded outlet firsttoensurethe safety
ofCPU.
Overclocking
Thismainboardisdesigned tosupportoverclocking.However,pleasemake
sureyourcomponentsareabletotoleratesuchabnormalsetting,while
doing overclocking.Anyattempttooperatebeyond productspecificationsis
notrecommended. Wedonotguaranteethedamages orrisks caused
byinadequateoperation orbeyondproductspecifications.
7563v1.0CH2Hardware Setup.p65 2008/11/11, 午 05:363

MS-7563Mainboard
2-4
Important
1.ConfirmifyourCPUcoolerisfirmlyinstalledbeforeturning on yoursystem.
2.Donottouchthe CPUsocketpinstoavoiddamaging.
3.The availabilityoftheCPUlandside coverdependsonyourCPUpacking.
2.Removethe capfromleverhinge
side(asthe arrowshows).
1.TheCPUsockethasaplasticcapon
ittoprotectthe contactfromdamage.
BeforeyouinstalltheCPU,always
coverittoprotectthesocket pin.
3.Thepinsof socketreveal.
CPU&Cooler Installation
When youareinstalling theCPU, make suretheCPUhasacoolerattached on
thetoptopreventoverheating. Meanwhile, do notforgettoapplysomethermal
pasteonCPUbeforeinstalling theheatsink/coolerfanforbetterheatdispersion.
Followthestepsbelowtoinstall theCPU&coolercorrectly.Wrong installationwill
causethedamageofyourCPU&mainboard.
4.Opentheloadlever.
7563v1.0CH2Hardware Setup.p65 2008/11/11, 午 05:364

2-5
HardwareSetup
6.Afterconfirmingthe CPUdirection
forcorrectmating,putdownthe
CPUin thesockethousing frame.
Besuretograspontheedgeof
theCPUbase.Notethatthe align-
mentkeysarematched.
8.Covertheload plateontothe
package.
5.Lifttheloadleverup andopenthe
loadplate.
7.VisuallyinspectiftheCPUis
seatedwell intothesocket. If not,
takeouttheCPUwithpurevertical
motionand reinstall.
alignment
key
7563v1.0CH2Hardware Setup.p65 2008/11/11, 午 05:365

MS-7563Mainboard
2-6
10. Aligntheholeson themainboard
withtheheatsink.Pushdownthe
cooleruntilitsfourclipsget
wedged intothe holesofthe
mainboard.
12.Turnoverthemainboardtocon-
firmthatthe clip-endsarecorrectly
inserted.
9.Press downtheloadleverlightly
ontothe loadplate,and thense-
curetheleverwiththehookunder
retentiontab.
Important
1.Readthe CPUstatusinBIOS(Chapter3).
2. WheneverCPUisnot installed,always protect yourCPUsocketpinwiththe
plasticcap covered (showninFigure1)toavoiddamaging.
3.Mainboardphotosshowninthissection arefordemonstration oftheCPU/
coolerinstallation only.The appearanceofyourmainboardmayvarydepend-
ingonthemodel you purchase.
11.Pressthefourhooks downtofasten
the cooler.Then rotatethelocking
switch(refertothecorrectdirection
markedonit)tolock thehooks.
locking
switch
Mainboard
Hook
7563v1.0CH2Hardware Setup.p65 2008/11/11, 午 05:366
