Quick Start
Thank you for purchasing a new motherboard from MSI®. This Quick Start section
provides demonstration diagrams about how to install your computer. Some of the
installations also provide video demonstrations. Please link to the URL to watch it
with the web browser on your phone or tablet. You may have even link to the URL by
scanning the QR code.
Preparing Tools and Components
Intel® LGA1700 CPU
LGA1700 CPU Fan
DDR4 Memory
Graphics Card
SATA Hard Disk Drive
Phillips Screwdriver
Chassis
Power Supply Unit
A Package of Screws
Thermal Paste

4
Safety Information
The components included in this package are prone to damage from electrostatic
discharge (ESD). Please adhere to the following instructions to ensure successful
computer assembly.
Ensure that all components are securely connected. Loose connections may cause
the computer to not recognize a component or fail to start.
Hold the motherboard by the edges to avoid touching sensitive components.
It is recommended to wear an electrostatic discharge (ESD) wrist strap when
handling the motherboard to prevent electrostatic damage. If an ESD wrist strap
is not available, discharge yourself of static electricity by touching another metal
object before handling the motherboard.
Store the motherboard in an electrostatic shielding container or on an anti-static
pad whenever the motherboard is not installed.
Before turning on the computer, ensure that there are no loose screws or metal
components on the motherboard or anywhere within the computer case.
Do not boot the computer before installation is completed. This could cause
permanent damage to the components as well as injury to the user.
If you need help during any installation step, please consult a certified computer
technician.
Always turn off the power supply and unplug the power cord from the power outlet
before installing or removing any computer component.
Keep this user guide for future reference.
Keep this motherboard away from humidity.
Make sure that your electrical outlet provides the same voltage as is indicated on
the PSU, before connecting the PSU to the electrical outlet.
Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
All cautions and warnings on the motherboard should be noted.
If any of the following situations arises, get the motherboard checked by service
personnel:
• Liquid has penetrated into the computer.
• The motherboard has been exposed to moisture.
• The motherboard does not work well or you can not get it work according to user
guide.
• The motherboard has been dropped and damaged.
• The motherboard has obvious sign of breakage.
Do not leave this motherboard in an environment above 60°C (140°F), it may damage
the motherboard.

5
Installing a Processor

https://youtu.be/KMf9oIDsGes
11
22
33
66
44
5577
88
99

6
Installing DDR4 memory
http://youtu.be/T03aDrJPyQs

DIMMB1 DIMMA1
DIMMB1

7
HDD LED
RESET SW
Connecting the Front Panel Header
http://youtu.be/DPELIdVNZUI
JFP1
HDD LED HDD LED -
HDD LED +
POWER LED -
POWER LED +
POWER LED
RESET SW
POWER SW
POWER LED+
POWER LED-
HDD LED

1
2 10
9
Power LED
Reserved
Power Switch
JFP1
Reset SwitchHDD LED

8
Installing the Motherboard
11
https://youtu.be/wWI6Qt51Wnc

Torque:
3 kgf·cm*
*3 kgf·cm
= 0.3 N·m
= 2.6 lbf·in
22

9
Connecting the Power Connectors
http://youtu.be/gkDYyR_83I4
ATX_PWR1 CPU_PWR1


10
11
22
33
44
55
Installing SATA Drives
http://youtu.be/RZsMpqxythc


11
Installing a Graphics Card
http://youtu.be/mG0GZpr9w_A

11
22
33
44
55
66

12
Connecting Peripheral Devices

13
Power On
44
33
1122

14
Specifications
CPU
Supports 13th and 12th Gen Intel® Core™ Processors,
Pentium® Gold and Celeron® Processors
Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new
processors are released.
Chipset Intel® B760 Chipset
Memory
2x DDR4 memory slots, supporting up to 64GB*
Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)
Max. overclocking frequency:
1DPC 1R Max speed up to 5333+ MHz
1DPC 2R Max speed up to 4800+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on compatible memory
Expansion Slot 1x PCIe x16 slot (From CPU)
• Supports up to PCIe 5.0 x16
Onboard Graphics
1x HDMI™ 2.1 port with HDR, supports a maximum
resolution of 4K 60Hz*/ **
1x DisplayPort 1.4 port with HBR3, supports a maximum
resolution of 8K 60Hz*/ **
*Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports 4x SATA 6Gb/s ports (From B760 chipset)
M.2 SSD Slots
2x M.2 slots (Key M)
• M2_1 slot (from CPU)
• Supports PCIe 4.0 x4
• Supports 2280 storage devices
• M2_2 slot (from B760 chipset)
• Support PCIe 4.0 x4
• Support SATA 6Gb/s*
• Support 2280 storage devices
* The SATA8 port will be unavailable when installing M.2 SATA SSD into M2_2.
Continued on next column

15
Continued from previous column
RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
Audio Realtek® ALC897 Codec
7.1-Channel High Definition Audio
LAN 1x Realtek 8125B 2.5Gbps LAN controller
Wireless LAN &
Bluetooth®
Intel® Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E)
slot
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz*
(160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth® 5.3**, FIPS, FISMA
* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in
Windows 10 build 21H1 and Windows 11.
** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
Power Connectors 1x 24-pin ATX main power connector
1x 8-pin 12V power connector
Internal USB
Connectors
Intel® B760 Chipset
1x USB 3.2 Gen 2 10Gbps Type-C ports
1x USB 3.2 Gen 1 5Gbps connectors
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
1x USB 2.0 Type-A connectors
• Supports additional 2 USB 2.0 ports
Fan Connectors
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
1x 4-pin system fan connector
System Connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
Jumpers 1x Clear CMOS jumper
Continued on next column

16
Continued from previous column
LED Features
1x 4-pin RGB LED connector
1x 3-pin ARGB V2 LED connector
4x EZ Debug LED
Back Panel
Connectors
4x USB 3.2 Gen 1 5Gbps Type-A ports (From Hub GL3523)
1x DisplayPort
1x HDMI™ port
1x USB 3.2 Gen 2 10Gbps Type-C port (From B760
chipset)
1x USB 3.2 Gen 2 10Gbps Type-A port (From B760
chipset)
2x USB 2.0 Type-A ports (From B760 chipset)
1x 2.5G LAN (RJ45) port
2x Wi-Fi Antenna connectors
3x audio jacks
I/O Controller NUVOTON NCT6687D-M Controller Chip
Hardware Monitor
CPU/ System/ Chipset temperature detection
CPU/ System/ Pump fan speed detection
CPU/ System/ Pump fan speed control
Form Factor Min-ITX Form Factor
6.7 in. x 6.7 in. (17 cm x 17 cm)
BIOS Features
1x 256 Mb flash
UEFI AMI BIOS
ACPI 6.4, SMBIOS 3.5
Multi-language
Software
Drivers
MSI Center
Intel XTU
MSI APP Player (BlueStacks)
CPU-Z MSI GAMING
Norton 360 Deluxe
AIDA64 Extreme - MSI Edition

17
Special Features
MSI Center Features
• Gaming Mode
• Smart Priority
• Game Highlights
• Mystic Light
• Ambient Link
• Frozr AI Cooling
• User Scenario
• True Color
• Live Update
• Hardware Monitoring
• Super Charger
• Devices Speed Up
• Smart Image Finder
• MSI Companion
• System Diagnosis
Thermal Features
• M.2 Shield Frozr
• Extended Heatsink Design
• Pump Fan
• Smart Fan Control
• K7 MOSFET thermal pad
• Extra choke pad
Audio
• Audio Boost
Network
• 2.5G LAN
• Intel WiFi 6E
LED
• Mystic Light Extension (ARGB V2/
RGB)
• Mystic Light Sync
• Ambient Link
• EZ Debug LED
Performance
• Lightning Gen 5 PCI-E Slot
• Lightning Gen 4 M.2
• Core Boost
• USB 3.2 Gen 2
• PCI-E Steel Armor
• Memory Boost
• Front USB Type-C
• Pre-installed I/O Shield
• Server Grade PCB
• 2oz Copper thickened PCB
BIOS
• Click BIOS 5

18
Package Contents
Please check the contents of your motherboard package. It should contain:
Board
• 1x Motherboard
Documentation
• 1x Quick installation guide
• 1x European Union regulatory notice
Cables
• 1x SATA 6Gb/s cable
• 1x JARGB extension cable
Accessories
• 1x Wi-Fi antenna set
• 1x M.2 screw and standoff package (2 sets/pack)
• 1x Cable sticker

Important
 There is an ISO file in the supplied USB drive. Please do not delete it accidentally.
For more information on installing drivers, please refer to Installing OS, Drivers &
MSI Center chapter.
 If any of the above items are damaged or missing, please contact your retailer.
