The MS6382 MICRO ATX mainboard is a high performance compu-
er mainboard based on KT266/VT8366 and VT8233 chipse . The KT266
chipse is ideal for high quali y and high in egra ion desk op and no ebook
AGP/PCI/LPC compu er sys ems based on Socke A processors.
The VT8366 Hos sys em con roller provides superior perfromance
be ween CPU, DRAM, AGP bus, and V-Link bus wi h pipelined, burs , and
concurren opera ion. The VT8233 V-Link Clien con roller is a highly
in egra ed PCI/LPC con roller. I suppor s five PCI slo s of arbi ra ion and
decoding for all in egra ed func ions and LPC bus.
For sophis ica ed power managemen , he Apollo KT266 chipse
provides independen clock s op con rol for he CPU/SDRAM, PCI, and
AGP buses and Dynamic CKE con rol for powering down of he SDRAM. A
sepera e suspend-well plane is implemen ed for he SDRAM con rol signals
for he Suspend- o-DRAM opera ion.
Chap er 1 con ains he following opics:

Mainboard Specifica ions 1-2
Mainboard Layou 1-4
Quick Componen s Guide 1-5
Key Fea ures 1-6
MSI Special Fea ures 1-6
Introduction
All manuals and user guides at all-guides.com
all-guides.com

Chapter 1
1-2
CPU
!Socke A for AMD® DuronTM/A hlonTM processor.
!Suppor 600MHz up o 1.5GHz processor
Chipset
! VIA® VT8366 chipse . (552 BGA)
- FSB @200/266MHz
- AGP 4x and high bandwid h Vlink hos con roller
- Advanced memory con roller suppor PC200/266 DDR echnology
!VIA® VT8233 chipse . (376 BGA)
- High bandwid h Vlink clien con roller
- In egra ed fas er E herne con roller
- Direc sound ready AC97 digi al audio con roller
- Ul ra DMA 33/66/100 mas er mode EIDE con roller
- Suppor bo h ACPI and legacy APM power managemen
Clock Generator
!100MHz/133MHz clocks are suppor ed.
Main Memory
!Suppor four memory banks using wo 184-pin DDR DIMM
!Suppor a maximum memory size of 2GB
Slots
!One (Accelera ed Graphics Por ) AGP slo .
- AGP specifica ion complian
- Suppor AGP 2.0 1x/2x/4x
!One CNR (Communica ion Ne work Riser) slo .
!Three 32-bi Mas er PCI Bus slo s
!Suppor s 3.3v/5v PCI bus In erface.
n-Board IDE
!Dual Channel mas er mode IDE con roller on he VIA® VT8233 Chipse
provides IDE HDD/CD-ROM wi h PIO, Bus Mas er and Ul ra DMA 33/66/
100 opera ion modes.
!Can connec up o four IDE devices.
Mainboard Specifications
All manuals and user guides at all-guides.com

Introduction
1-3
Audio
!Chip In egra ed
- Direc Sound AC97 Audio
!CT5880 Hardware Audio (Op ion)
n-Board Peripherals
!On-Board Peripherals include:
- 1 floppy por suppor s 2 FDD wi h 360K, 720K, 1.2M, 1.44M and 2.
88Mby es.
- 2 serial por s (COMA + COM B)
- 1 parallel por suppor s SPP/EPP/ECP mode
- 6 USB por s (2 Rear Connec ors/ 2 USB Fron Pin Headers - 4 por s)
- 1 IrDA connec or for SIR/ASKIR/HPSIR.
- 1 Audio/Game por
BI S
!The mainboard BIOS provides Plug & Play BIOS which de ec s he
peripheral devices and expansion cards of he board au oma ically.
!The mainboard provides a Desk op Managemen In erface (DMI) func-
ion which records your mainboard specifica ions.
Dimension
!ATX Form Fac or: 24.3cm x 23.4cm
Mounting
!6 moun ing holes.
All manuals and user guides at all-guides.com

Chapter 1
1-4
Mainboard Layout
MS-6382 MICRO ATX Mainboard
SOCKET 462
Top : mous e
Bottom: ke
y
board
USB
Top : port 1
Bottom: port 2
CD_IN
MODEM_IN
AGP Slot
BATT
+
BIOS
86& !!
86&!$$
,,4
,,4
1,-
1,- .,,
PC I Slot
PC I Slot
PC I Slot
CNR JMDM1 JUSB2 JUSB1
SW1
J3
J2
J1
CPU FAN
ATX
Power Suppy
JFP1
SFAN1
J10JGL1
JBAT1
JGS1
To p :
Midi / Game port
Bottom:
Line- ut
Line-In
Mic
To p : L PT
Bottom:
C M A
C M B
JAU1
+6#&&
CD_IN
AUX_IN
All manuals and user guides at all-guides.com

Introduction
1-5
Component Function Reference
Socke 462 Ins alling CPU p. 2-2
DDR1~2 Ins alling memory module p. 2-4
ATX Power Supply Ins alling power supply p. 2-6
FDD1 Connec ing o floppy disk drive p. 2-11
J2 Inser ing hermis or p. 2-11
IDE1 & IDE2 Connec ing o HDD drive p. 2-12
JFP1 Connec ing o case p. 2-13
JMDM1 Connec ing o modem card p. 2-14
J1 Connec ing o chassis in rusion swi ch p. 2-14
CPUFAN Connec ing o processor fan p. 2-15
SYSFAN Connec ing o sys em fan p. 2-15
JUSB1 & 2 Connec ing o USB devices p. 2-17
JAU1 Connec ing o Fron Panel Audio p. 2-18
JGL1 Connec ing o powering saving LED p. 2-19
JGS1 Connec ing o power saving swi ch P. 2-20
J3 Connec ing o IR module p. 2-20
JBAT1 Se ing clear CMOS P. 2-21
SW1 Se ing CPU FSB P. 2-22
J10 Se ing Beep on Buzzer or Speaker p. 2-22
AGP Inser ing AGP graphics card p. 2-23
PCI Slo Inser ing expansion cards p. 2-23
CNR Inser ing CNR card p. 2-23
Quick Components Guide
All manuals and user guides at all-guides.com

Chapter 1
1-6
!Micro ATX Form Fac or wi h PC99 color connec or
!Suppor Accelera ed Graphic Por (AGP) Add-On Card
!Suppor AMD® PGA Socke A Duron/A hlon processors a 200/
266MHz Sys em Bus Frequencies
!Chip In egra ed Audio (CT5880 hardware op ion)
!PC Aler Sys em Hardware Moni or
!Suppor DMI (Desk op Managemen In erface) hrough BIOS
!LAN Wake Up Func ion
!Modem (In ernal/Ex ernal) Ring Wake Up Func ion
!Suppor PCI 2.2
!Suspend o RAM/Disk
Key Features
MSI Special Features
The MSI special fea ures are designed by MSI R&D which are only
available in MSI mainboards. The 6382 mainboard is equipped wi h PC Aler TM
III.
All manuals and user guides at all-guides.com
all-guides.com

Introduction
1-7
Features:
!Ne work Managemen
- Moni oring & remo e con rol
!Basic Sys em U ili ies
- Scandisk & Defragmen o main ain your HDD
!3D Graphics Design
- Enables a more friendly user in erface
!Sof ware U ili ies
- Sof Cooler Op imized Cooling
- Doc or Y2K diagnoses Y2K problems
- BusRacing func ion adjus s F.S.B under Windows 95/98
- MoSpeed speeds up your modem ransmission
PC Alert III
The PC Aler TM III is a u ili y you can find in he CD-ROM. The u ili y
is jus like your PC doc or ha can de ec he following PC hardware s a us
during real ime opera ion:
* moni or CPU & sys em empera ure
* moni or fan speed
* moni or sys em vol age
* moni or chassis in rusion
If one of he i ems above is abnormal, he program main screen will be imme-
dia ely shown on he screen, wi h he abnormal i em highligh ed in red. This
will con inue o be shown un il user disables warning.
All manuals and user guides at all-guides.com

Hardware Setup
2-1
This chapter provides you with the information about hardware setup
procedures. While doing the installation, be careful in holding the compo-
nents and follow the installation procedures. For some components, if you
install in the wrong orientation, the components will not work properly.
Besides, please use a grounded wrist strap before handling computer
components. Static electricity may damage the components.
.
This chapter contains the following topics
Central Processing Unit (CPU) 2-2
Memory Installation 2-4
Power Supply 2-6
Back Panel 2-7
Connectors 2-11
Jumpers 2-21
Slots 2-24
Hardware Setup
All manuals and user guides at all-guides.com

Chapter 2
2-2
Central Processing Unit: CPU
The mainboard supports AMD® DuronTM / Athlon processors. The
mainboard uses a CPU socket called Socket A for easy CPU installation.
Make sure that the CPU has a Heat Sink and a cooling fan attached to
prevent overheating. If you do not find the Heat Sink and cooling fan,
contact your dealer or purchase them before turning on the computer.
Overheating will seriously damage the CPU and
system. After inserting the Heat Sink and cooling fan
, check if the cooling fan can work properly to protect
the CPU.
!
WARNING!
1. Pull the lever sideways away
from the socket. Then, raise the
lever up to a 90-degree
angle.
2. Look for the cut edge. The
cut edge should point
towards the lever pivot. The
CPU will only fit in the
correct orientation.
3. Hold the CPU down firmly,
and then close the lever to
complete the installation.
CPU Installation Procedures Open Lever
Cut edge
Sliding
Plate
Close
Lever
All manuals and user guides at all-guides.com

Hardware Setup
2-3
OVERCLOCKING
he motherboard are designed to support overclocking.
Make sure your components are able to tolerate such
abnormal setting while doing overclocking. Any attempt to
operate beyond product specifications is not recommended.
We do not guarantee the damages or risks caused by
inadequate operation or beyond product specification.
!
WARNING!
CPU Core Speed Derivation Procedure
The mainboard can not automatically set the CPU Host Bus Frequency
Clock. Please refer to 2-22 SW1 for the manual setting.
If CPU Clock = 100MHz (set by SW1)
Core/Bus ratio = 7
then CPU core speed = Host Clock x Core/Bus ratio
= 100MHz x 7
= 700MHz
All manuals and user guides at all-guides.com
