MSI S1102-01 User manual

S1102-01
MS-S336
Server System
User Guide

2Contents
Revision
V1.1, 2023/07
Contents
Regulatory Notices....................................................................................................... 4
Safety Information ......................................................................................................... 6
System Specifications .................................................................................................. 7
System Overview .......................................................................................................... 8
System LED Indicators............................................................................................... 11
Motherboard Overview............................................................................................... 12
Motherboard Connectors .......................................................................................... 13
Storage Connectors.............................................................................................. 13
SATA1~8: SATA 3.0 6Gb/s Ports ................................................................... 13
M2_1, M2_2: M.2 Slots (M Key, PCIe 4.0, 22110/ 2280)................................. 14
Expansion Slots .................................................................................................... 15
PCIE_1~2: PCIe Expansion Slots .................................................................. 15
Power Connectors ................................................................................................ 16
SATAPWR1: SATA Power Connector............................................................ 16
JPWR1: 12V Power Connector ...................................................................... 16
JPWR2: Main Power Connector .................................................................... 17
JSDOMPWR1: SATA DOM Power Connector................................................. 17
Cooling Connectors .............................................................................................. 18
FAN1 ~ 8, PUMP1: Fan Power Connectors ................................................... 18
Other Connectors ................................................................................................. 19
JFP1: Front Panel Connector........................................................................ 19
JTPM1: SPI TPM Module Box Header ........................................................... 20
JGPIO1: GPIO Header .................................................................................... 21
JPMBUS1: PMBUS Box Header .................................................................... 21
JCHASSIS: Chassis Intrusion Header ........................................................... 22
JIPMB1: IPMB Box Header........................................................................... 22
JUSB1: USB 3.2 Port Box Header ................................................................. 23
JUSB2: USB 2.0 Type-A Connector ............................................................... 23

3
Contents
FP_I2C_1, RBP_I2C_1, RBP_I2C_2: I2C Box Header................................... 24
JCOM1: COM Port Box Header...................................................................... 24
Motherboard Jumpers............................................................................................... 25
Getting Started............................................................................................................ 26
Necessary Tools ................................................................................................... 26
Safety Precautions................................................................................................ 26
System Setup.............................................................................................................. 27
Drive Bay ..................................................................................................................... 27
Installing 3.5"/2.5" Storage Drive......................................................................... 27
System Cover.............................................................................................................. 28
Removing System Cover....................................................................................... 28
CPU & Heatsink.......................................................................................................... 29
Installing CPU & Heatsink.................................................................................... 30
Memory ....................................................................................................................... 31
Recommended Memory Population..................................................................... 31
Installing Memory Modules.................................................................................. 32
M.2 M Key.................................................................................................................... 33
Installing M.2 M Key ............................................................................................. 33
Slide Rail ..................................................................................................................... 34
Disassembling Slide Rail...................................................................................... 34
Installing Inner Rail to System............................................................................. 35
Retracting Outer Rail Bracket.............................................................................. 36
Attaching Outer Rail Bracket to Rack Frame ...................................................... 36
Installing System into Rack.................................................................................. 37
Detaching Outer Rail Bracket from Rack Frame................................................. 38
Detaching Inner Rail from System....................................................................... 38

4Regulatory Notices
Regulatory Notices
WEEE Statement
Under the European Union (“EU”) Directive on Waste Electrical and
Electronic Equipment, Directive 2012/19/EU, products of “electrical and
electronic equipment” cannot be discarded as municipal waste anymore
and manufacturers of covered electronic equipment will be obligated to
take back such products at the end of their useful life.
Chemical Substances Information
In compliance with chemical substances regulations, such as the EU REACH
Regulation (Regulation EC No. 1907/2006 of the European Parliament and the
Council), MSI provides the information of chemical substances in products at:
https://csr.msi.com/global/index
CE Conformity
Hereby, Micro-Star International CO., LTD declares that this device is in
compliance with the essential safety requirements and other relevant
provisions set out in the European Directive.
FCC-A Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case
the user will be required to correct the interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Notice 2
Shielded interface cables and AC power cord, if any, must be used in order to comply
with the emission limits.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
∙This device may not cause harmful interference, and
∙This device must accept any interference received, including interference that may
cause undesired operation.

5
Regulatory Notices
Battery Information
Please take special precautions if this product comes with a battery.
∙Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer.
∙Avoid disposal of a battery into fire or a hot oven, or mechanically crushing or
cutting of a battery, which can result in an explosion.
∙Avoid leaving a battery in an extremely high temperature or extremely low air
pressure environment that can result in an explosion or the leakage of flammable
liquid or gas.
∙Do not ingest battery. If the coin/button cell battery is swallowed, it can cause
severe internal burns and can lead to death. Keep new and used batteries away
from children.
European Union:
Batteries, battery packs, and accumulators should not be disposed of as
unsorted household waste. Please use the public collection system to
return, recycle, or treat them in compliance with the local regulations.
BSMI:
廢電池請回收
For better environmental protection, waste batteries should be collected
separately for recycling or special disposal.
California, USA:
The button cell battery may contain perchlorate material and requires
special handling when recycled or disposed of in California.
For further information please visit:
http://www.dtsc.ca.gov/hazardouswaste/perchlorate/
Copyright and Trademarks Notice
Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is
a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names
mentioned may be trademarks of their respective owners. No warranty as to accuracy
or completeness is expressed or implied. MSI reserves the right to make changes to
this document without prior notice.
Technical Support
If a problem arises with your product and no solution can be obtained from the user’s
manual, please contact your place of purchase or local distributor. Alternatively,
please visit https://www.msi.com/support/ for further guidance.

6Safety Information
Safety Information
∙Always read the safety instructions carefully.
∙Keep this User’s Manual for future reference.
∙Keep this equipment away from humidity.
∙Lay this equipment on a reliable flat surface before setting it up.
∙The openings on the enclosure are for air convection hence protects the equipment
from overheating. Do not cover the openings.
∙Make sure the voltage of the power source and adjust properly before connecting
the equipment to the power inlet.
∙Place the power cord such a way that people can not step on it. Do not place
anything over the power cord.
∙Always unplug the power cord before inserting any add-on card or module.
∙All cautions and warnings on the equipment should be noted.
∙Never pour any liquid into the opening that could damage or cause electrical shock.
∙If any of the following situations arises, get the equipment checked by service
personnel:
∙The power cord or plug is damaged.
∙Liquid has penetrated into the equipment.
∙The equipment has been exposed to moisture.
∙The equipment does not work well or you can not get it work according to User’s
Manual.
∙The equipment has dropped and damaged.
∙The equipment has obvious sign of breakage.
∙Do not leave this equipment in an environment unconditioned, storage
temperature above 60°C (140°F), it may damage the equipment.

7
System Specifications
System Specifications
Model S1102-01
Form Factor 1U
Dimensions 1.71”H (43.5mm) x 17.26”W (438.5mm) x 21.56”D (547.6mm)
Processor ∙1 x AMD® Ryzen™ 7000 series Processors, TDP 105W
-Processor socket AM5
Chipset AMD B-class Chipset
Memory
∙4 x DIMM slots
-Supports DDR5, up to 5200MT/s (2DPC)
-Supports ECC/ non-ECC UDIMM, up to 128GB
Network
∙2 x 1GbE RJ45 ports
-Intel® Ethernet controller I210-AT
-JLANCONN1 (L) support shared NIC*
∙2 x 10GbE RJ45 ports
-Intel® Ethernet controller X710-AT2
-JLAN1 support shared NIC*
* Only one NIC LAN port can be enabled at a time, either JLAN1 or JLANCONN1 (Lower).
Drive Bays ∙4 x 2.5”/ 3.5” SATA hot-swap drive bays (front side)
∙2 x 2.5” SATＡ drive bays (internal)
Internal Storage
∙6 x SATA 3.0 ports (w/ 1 x VCC)
∙2 x M.2 M-Key (PCIe 4.0 x4, 22110/ 2280)
-M2_1*: Choose either M2_1 or PCIE_2 for the desired function.
-M2_2: Supports PCIe 4.0 x4
* The PCIE_2 and M2_1 slots cannot operate simultaneously. You can use the JSEL_M1 jumper
to select which one to enable.
Expansion Slots
∙1x PCIe slot
-PCIE_1*: PCIe 4.0 x16 signal with riser kit, FHHL (111.28mm x 167.65mm)
* The PCIE_1 expansion slot supports PCIe 5.0 x16 signal without a riser kit.
Security ∙TPM 2.0
∙Case intrusion switch
Server
Management
∙Aspeed AST2600 IPMI 2.0 with iKVM
∙1 x GbE RJ45 port (for Mgmt.)
-Chipset: Realtek®RTL8211FD-CG PHY
Cooling ∙1 x Passive CPU heatsink @105W (with air duct)
∙4 x 40mm x 28mm PWM Hot-swap fans
Environmental
∙Operating Temperature: 0°C ~ 40°C
∙Non-operating Temperature: -20°C ~ 70°C
∙Operating Humidity: 0% ~ 85% (non-condensing)
Accessory 1 x Slide Rail Kit (optional)
Power Supply Standard ATX 500W Power Supply
Certications CE, FCC (Class A)

8System Overview
System Overview
1111
4 x 2.5/ 3.5” SATA
Hot-Swap Drive Bays
11
2233
44
11
55
662299
7788
1010

9
System Overview
11
UID Button
The UID (Unit Identification) button help users identify and locate a system,
especially in high-density rack environments.
22USB 3.2 Gen 1 Port
This connector is provided for USB peripheral devices. (Speed up to 5 Gbps)
33
!
System Status LED
HDD Activity LED
Power LED
1
LAN Activity LED
44System Power Button/ LED
55
COM Port
A COM port, also called a serial port or DB9 connector, is a communication
interface for transferring data between a computer and external devices
such as barcode scanners, printers, and credit card machines. It’s commonly
used for initial system configuration and diagnostics on server boards
and for connecting legacy devices that lack modern interfaces. Users can
connect a specially configured serial cable to establish a serial connection.
66VGA Port
The DB15-pin female connector is provided for monitors.
77
GbE RJ45 Port (for Mgmt.)
The standard RJ45 LAN jack is provided for connection to the Local Area
Network (LAN). You can connect a network cable to it.
LINK/ACT
LED
SPEED
LED
LED Status Description
Link/ Activity
LED
Off No link
Green Linked
Blinking Data activity
Speed LED
Off 10 Mbps
Orange 100 Mbps
Green 1 Gbps

10 System Overview
88
GbE RJ45 Port
The standard RJ45 LAN jack is provided for connection to the Local Area
Network (LAN). You can connect a network cable to it.
JLANCONN1 (L)
JLANCONN1 (U)
LINK/ACT
LED
SPEED
LED
LED Status Description
Link/ Activity
LED
Off No link
Green Linked
Blinking Data activity
Speed LED
Off 10 Mbps
Orange 100 Mbps
Green 1 Gbps
99
10 GbE RJ45 Port
The standard RJ45 LAN jack is provided for connection to the Local Area
Network (LAN). You can connect a network cable to it.
JLAN2 (Right)JLAN1 (Left)
LINK/ACT
LED
SPEED
LED
LED Status Description
Link/ Activity
LED
Off No link
Green Linked
Blinking Data activity
Speed LED
Off 10 Mbps
Orange 1 Gbps
Green 10 Gbps
1010 Power Supply Unit
1111 2.5” SATA Internal Drive Bay

11
System LED Indicators
System LED Indicators
Power LED
UID LED
!
System Status LED
HDD Activity LED
1
LAN Activity LED
LED LED State Description
Power LED
Blue System power is on
System power is on ACPI S0 state
Blinking System is sleeping
Off System power is off
System power is on ACPI S4, S5 state
UID LED Blue Identify active via command or button
Off No identification
!
System Status LED
Red System has failed
Off System power is not present
1
LAN Activity LED
Green LAN link is established
Blinking LAN Activity is occurring
Off LAN link is not established
HDD Activity LED
Yellow HDD present, no activity
Blinking HDD accessing
Off No HDD activity

12 Motherboard Overview
Motherboard Overview
JCHASSIS JIPMB1
JSEL_M1
JSEL_BMC1
M2_2
PCIE_1
PCIE_2
JCOM1
JLAN1 JLAN2
BZ1
M2_1
BAT1
JGPIO1
JFP1
JUSB1
JUSB2
RBP_I2C_2 RBP_I2C_1
SATA1
SATA3_1
SATA4
JTPM1
FAN1 FAN2 FAN3 FAN4 FAN5 FAN6 FAN7
SATAPWR1
JPWR2
JPWR1
DIMMA1 DIMMA2 DIMMB1 DIMMB2
SATA3
JSDOMPWR1
SATA2
FP_I2C_1
FAN8 PUMP1
JPMBUS1 ID_BTN1
JVGA1 (L)
COM1 (U)
JLANCONN1(U)
JLANCONN1(L)
MLAN_USB1
REAR_USB1

13
Motherboard Connectors
Motherboard Connectors
Storage Connectors
SATA1~8: SATA 3.0 6Gb/s Ports
These connectors are SATA 6Gb/s interface ports, it can connect to SATA devices.
⚠
Important
∙ Please do not fold the SATA cable at a 90-degree angle. Data loss may result during
transmission otherwise.
∙ SATA cables have identical plugs on either sides of the cable. However, it is
recommended that the flat connector be connected to the motherboard for space
saving purposes.
SATA1 SATA2
SATA3
SATA4
SATA3-1

14 Motherboard Connectors
M2_1, M2_2: M.2 Slots (M Key, PCIe 4.0, 22110/ 2280)
The M.2 slot supports solid-state drive (SSD). For Installation procedure, please refer
to “System Setup > M.2 M Key”.
M2_1* M2_2
*M2_1: The M2_1 and PCIE_2 slots
cannot operate simultaneously. You
can use the JSEL_M1 jumper to
select which one to enable.

15
Motherboard Connectors
Expansion Slots
PCIE_2*: PCIe 4.0 x 8 slot (Gen 4 x 4 signal from CPU)
PCIE_1: PCIe 5.0 x 16 slot (Gen 5 x 16 signal from CPU)
*PCIE_2: The PCIE_2 and M2_1 slots
cannot operate simultaneously. You can
use the JSEL_M1 jumper to select which
one to enable.
PCIE_1~2: PCIe Expansion Slots
The PCI Express(Peripheral Component Interconnect Express) slots support PCIe
interface expansion cards.
⚠
Important
When adding or removing expansion cards, make sure that you unplug the power
supply first. Meanwhile, read the documentation for the expansion card to configure
any necessary hardware or software settings for the expansion card, such as jumpers,
switches or BIOS configuration.

16 Motherboard Connectors
Power Connectors
JPWR1
JPWR2
SATAPWR1JSDOMPWR1
SATAPWR1: SATA Power Connector
This connector is used to provide power to SATA devices.
SATAPWR1 3
4
21
1 GND 2 GND
3P12V 4P5V
JPWR1: 12V Power Connector
This connector allows you to connect an ATX power supply.
1
48
5
JPWR1
1 GND 2 GND
3 GND 4 GND
5 P12V 6 P12V
7 P12V 8 P12V

17
Motherboard Connectors
JPWR2: Main Power Connector
This connector allows you to connect an ATX power supply.
24
131
12
JPWR2
1 +3.3V 2 +3.3V
3GND 4 +5V
5GND 6 +5V
7GND 8 PWR OK
9 5VSB 10 +12V
11 +12V 12 +3.3V
13 +3.3V 14 -12V
15 GND 16 PS-ON#
17 GND 18 GND
19 GND 20 Res
21 +5V 22 +5V
23 +5V 24 GND
JSDOMPWR1: SATA DOM Power Connector
This connector is used to provide power to SATA DOM devices.
JSDOMPWR1 211 GND 2 P5V
⚠
Important
Make sure that all power connectors are securely connected to the power supply to
ensure stable operation of the motherboard.

18 Motherboard Connectors
Cooling Connectors
FAN1 ~ 8, PUMP1: Fan Power Connectors
The fan power connector supports system cooling fans with +12V. When connecting
the wire to the connectors, always note that the red wire is the positive and should be
connected to the +12V; the black wire is Ground and should be connected to GND.
FAN1~8
4
1
1 GND 3 FAN_TACH
2P12V 4BMC_PWM
PUMP1
4
1
1 GND 3 N/A
2P12V 4BMC_PWM
1
8
9
2 3 4 65 7
FAN1
FAN5
FAN2
FAN4
FAN3
FAN6
FAN7
FAN8
PUMP1
1
2
3
4
6
5
7
8
9

19
Motherboard Connectors
Other Connectors
JFP1: Front Panel Connector
The front panel connector is provided for electrical connection to the front panel
switches and LEDs.
JFP1
12
2324
1PWR_LED+ 2FP_PWR
3N/A 4SYS_ID_LED+
5 PWR_LED- 6 SYS_ID_LED-
7 HDD_ACT_LED+ 8 SYS_FAULT_LED1-
9 HDD_ACT_LED- 10 SYS_FAULT_LED2-
11 PWR_BTN 12 NIC#1_ACT_LED+
13 PWR_BTN_GND 14 NIC#1_ACT_LED-
15 RST_BTN 16 SMB_SDA
17 RST_BTN_GND 18 SMB_SCL
19 SYS_ID_BTN 20 CHASSIS_INTRUSION
21 WIRE_TEMP_SENSOR 22 NIC#2_ACT_LED+
23 NMI_BTN 24 NIC#2_ACT_LED-
JFP1

20 Motherboard Connectors
JTPM1: SPI TPM Module Box Header
This connector connects to a TPM (Trusted Platform Module) (optional). Please refer
to the TPM security platform manual for more details.
JTPM1
2
3
19
20
1N/A 2SPI_LOC_ROM_CS_N
3CPU_RSMEST_L 4N/A
5GND 6PVDD_P1V8_AUX
7 SPI_LOC_ROM_CLK 8 SPI_CPU0_WP_L
9 SPI_CPU0_HOLD_L 10 SPI_LOC_ROM_MISO
11 N/A 12 SPI_LOC_ROM_MOSI
13 CPU_SPI_TPM_CS_N 14 GND
15 PVDD_P1V8_AUX 16 GND
17 CPU_TPM_SPI_IRQ_N 18 PVDD_P1V8_AUX
19 TPM_RESET_N 20 PVDD_P1V8_AUX
JTPM1
