MSR HUBBA HUBBA NX User manual

MOUNTAIN S AFETY R ESEARCH®
HUBBA HUBBA™NX
Assembly Instructions
© 2014 Cascade Designs, Inc.
4000 First Avenue South
Seattle, WA 98134 USA
1-800-531-9531
1-206-505-9500
PACKAGE INCLUDES:
Frame assembly, tent body, rainfly, 2 guy cords, 2 tensioners,
6 MSR®Mini-Groundhog™ Stakes, 1 repair sleeve
80-467-1
PREPARE FOR SETUP ATTACH HUBBED POLES
ATTACH CLIPS ATTACH RAINFLY
1. Attach clips to pole along length of tent and ridge pole.
1. Spread tent out and stake out four corners tightly.
2. Assemble poles.
1. Insert tips of two hubbed poles into grommets at one end of tent
floor, followed by the remaining two at the other.
2. Insert short ridge pole into two grommets at midpoint of tent
ceiling.
1. Lay rainfly over tent, aligning red webbing to red stake loops,
gray webbing to gray stake loops. Attach the rainfly’s midpoint
grommets to ridge pole.
2. Stretch out vestibules until taut and stake down, making sure
seams align with frame.
USE TIPS: All tents require staking; unsecured tents are susceptible to
wind damage. In some conditions, additional stakes and cord may
be required. Readjustment of stakes and rainfly may be necessary
to keep tent tight and weatherproof. A footprint can help keep your
tent clean, dry and protected from abrasion. Following these tips will
prolong the life of your tent. MSR®offers a full line of accessories to
secure, maintain and enhance your tent.
Please follow these instructions to guide you through assembly only.
For complete instructions on the recommended care and use of your tent,
please refer to Owner’s Manual at www.msrgear.com/tents/ownersmanual
For German, French, Spanish, Italian, Dutch and Japanese instructions go to www.msrgear.com/tents/ownersmanual
Watch video setup instructions, including Fast & Light®options,
at www.msrgear.com/HubbaHubba

HUBBA HUBBA™NX
Fast & Light®Setup with Rainfly
and MSR®Footprint (sold separately). Fast & Light®Setup with Rainfly only.
PREPARE FOR SETUP
1. Assemble poles
2. Lay rainfly on the ground.
Hubba Rainfly Only Setup
Step-1
PREPARE FOR SETUP, ATTACH POLES
1. Start by staking out the
footprint with the MSR
logo facing up.
2. Insert assembled poles
into the footprint’s
corner grommets to
create the same pole
structure as the
standard setup.
Hubba Hubba Footprint-Rainfly Setup
Step-2
SECURE TENT
1. Stake out the corners and tension
the webbing straps.
2. Stake out the vestibules and guy
out if necessary
Hubba Hubba Rainfly Only Setup
Step-3
ATTACH POLES
1. Insert tips of poles into grommets
at bottom of rainfly on one side.
2. Place the other end of the poles
into grommets at other side
of rainfly, making sure
frame fits properly
under the rainfly.
3. Insert ridge pole
into grommets
above vestibule
doors on rainfly.
Hubba Hubba Rainfly Only Setup
Step-2
MOUNTAIN S AFETY R ESEARCH®
SECURE RAINFLY
1. Secure rainfly by attaching the
rainfly webbing to the pole
tips using the grommets.
2. Insert ridge pole into
grommets above vestibule
doors on rainfly.
Hubba Hubba Footprint-Rainfly Setup
Step-3
SECURE TENT
1. Stake out the tent’s vestibules
and guy out if necessary.
Hubba Hubba Footprint-Rainfly Setup
Step-4
