MSR Mutha Hubba NX User manual

MOUNTAIN S AFETY R ESEARCH®
MUTHA HUBBA™NX
Assembly Instructions
© 2014 Cascade Designs, Inc.
4000 First Avenue South
Seattle, WA 98134 USA
1-800-531-9531
1-206-505-9500
PACKAGE INCLUDES:
Frame assembly, tent body, rainfly, 2 guy cords, 2 tensioners,
8 MSR®Mini-Groundhog™ Stakes, 1 repair sleeve
81-395
PREPARE FOR SETUP ASSEMBLE TENT FRAME
ATTACH RIDGE POLE ATTACH RAINFLY
1. Insert ridge pole into grommets above doors.
2. Attach clips to ridge pole.
1. Spread tent out and stake out four corners tightly.
2. Assemble poles.
1. Insert tips of long main poles into grommets with color-coded
webbing at the stake loops.
2. Attach clips to frame.
1. Lay rainfly over tent, aligning red webbing to red stake loops, gray
webbing to gray stake loops. Attach the rainfly’s midpoint grom-
mets to ridge pole. Secure rainfly Velcro tabs to main poles.
2. Place rainfly’s adjustable loop grommets under the main pole ends
at all corners, inserting pole tips into grommets.
3. Stretch out vestibules until taut and stake down, making sure seams
align with frame.
USE TIPS: All tents require staking; unsecured tents are susceptible to
wind damage. In some conditions, additional stakes and cord may
be required. Readjustment of stakes and rainfly may be necessary
to keep tent tight and weatherproof. A footprint can help keep your
tent clean, dry and protected from abrasion. Following these tips will
prolong the life of your tent. MSR®offers a full line of accessories to
secure, maintain and enhance your tent.
Please follow these instructions to guide you through assembly only.
For complete instructions on the recommended care and use of your tent,
please refer to Owner’s Manual at www.msrgear.com/tents/ownersmanual.
For German, French, Spanish, Italian, Dutch and Japanese instructions go to www.msrgear.com/tents/ownersmanual
Watch video setup instructions, including Fast & Light®option,
at www.msrgear.com/MuthaHubba
All manuals and user guides at all-guides.com
all-guides.com

Mutha Hubba Footprint-Rainfly Setup
Step-4
Mutha Hubba Footprint-Rainfly Setup
Step-1
Mutha Hubba Footprint-Rainfly Setup
Step-2
MOUNTAIN S AFETY R ESEARCH®
PREPARE FOR SETUP ATTACH POLES
SECURE RAINFLY SECURE TENT
1. Secure rainfly by attaching the rainfly webbing to the pole tips
using the grommets.
2. Insert ridge pole into grommets above vestibule doors on rainfly.
3. Secure any rainfly hook and loop attachments to the poles.
1. Start by staking out the footprint with the MSR logo facing up.
2. Assemble poles.
1. Insert the poles into the footprint’s corner grommets to create the
same pole structure as the standard setup.
1. Stake out the tent’s vestibules and guy out if necessary.
Mutha Hubba Footprint-Rainfly Setup
Step-3
MUTHA HUBBA™NX
Fast & Light®Setup with Rainfly and MSR®Footprint (sold separately).
