MSR HUBBA NX User manual

MOUNTAIN S AFETY R ESEARCH®
HUBBA™NX
Assembly Instructions
© 2014 Cascade Designs, Inc.
4000 First Avenue South
Seattle, WA 98134 USA
1-800-531-9531
1-206-505-9500
PACKAGE INCLUDES:
Frame assembly, tent body, rainfly, 1 guy cord, 1 tensioner,
6 MSR®Mini-Groundhog™ Stakes, 1 repair sleeve
80-466-1
PREPARE FOR SETUP ATTACH HUBBED POLES
ATTACH CLIPS ATTACH RAINFLY
1. Attach clips to pole along length of tent and ridge pole.
1. Spread tent out and stake out four corners tightly.
2. Assemble poles.
1. Insert tips of two hubbed poles into grommets at one end of tent
floor, followed by the remaining two at the other.
2. Insert short ridge pole into two grommets at midpoint of tent
ceiling.
1. Lay rainfly over tent, aligning red webbing to red stake loops,
gray webbing to gray stake loops. Attach the rainfly’s midpoint
grommets to ridge pole.
2. Stretch out vestibule until taut and stake down, making sure
seams align with frame.
USE TIPS: All tents require staking; unsecured tents are susceptible to
wind damage. In some conditions, additional stakes and cord may
be required. Readjustment of stakes and rainfly may be necessary
to keep tent tight and weatherproof. A footprint can help keep your
tent clean, dry and protected from abrasion. Following these tips will
prolong the life of your tent. MSR®offers a full line of accessories to
secure, maintain and enhance your tent.
Please follow these instructions to guide you through assembly only.
For complete instructions on the recommended care and use of your tent,
please refer to Owner’s Manual at www.msrgear.com/tents/ownersmanual
For German, French, Spanish, Italian, Dutch and Japanese instructions go to www.msrgear.com/tents/ownersmanual
Watch video setup instructions, including Fast & Light®options,
at www.msrgear.com/Hubba
