MTD 450 Series User manual

PRINTED IN U.S.A. MTD Products Ltd., P. O. Box 1386, KITCHENER, ONTARIO N2G 4J1
OPERATOR’S MANUAL
IMPORTANT:
READ SAFETY RULES AND INSTRUCTIONS
CAREFULLY BEFORE OPERATING EQUIPMENT.
Safety • Setup • Operation • Maintenance • Troubleshooting • Parts Lists • Warranty
6 / 24 /11
772C0505J
Chipper Shredder — Model Series 450 and 460
Model 464 Shown.

2
Table of Contents
This Operator’s Manual is an important part of your new equipment. It will help you assemble,
prepare and maintain the unit for best performance. Please read and understand what it says.
Customer Support.............................................. 2
Safety Symbols................................................... 3
Safe Operation Practices................................... 4
Setting Up Your Chipper-Shredder.................... 6
Operating Your Chipper-Shredder..................... 9
Maintaining Your Chipper-Shredder ............... 12
Trouble Shooting .............................................. 14
Warranty ............................................................ 15
Illustrated Parts Lists ....................................... 18
Finding and Recording Model Number
BEFORE YOU START ASSEMBLING
YOUR NEW EQUIPMENT,
please locate the model plate on the equipment and copy the
model number and the serial number to the sample model
plate provided to the right. You can locate the model plate by
standing at the operating position and looking down at the rear
of the machine.
Please do
NOT return the unit to the retailer from which it was purchased,
without rst contacting Customer Support.
Customer Support
If you have difficulty assembling this product or have any questions regarding the controls, operation or maintenance of this unit,
you can seek help from the experts. Choose from the options below:
1. Visit www.mtdcanada.ca for many useful suggestions, click on Customer Support button.
2. Call a Customer Support Representative at 1-800-668-1238.
3. The engine manufacturer is responsible for all engine-related issues in terms of performance, power-rating, specifications,
warranty, and service. Depending on the engine manufacturer, more information is included in this publication or packed
separately with this product.
Please have your unit’s model number and serial number ready when you call. See previous section to locate this information.
You will be asked to enter the serial number in order to process your call.
Mo d e l Nu M b e r
Se r i a l Nu M b e r

3
Symbol Description
READ THE OPERATOR’S MANUAL(S)
Read, understand, and follow all instructions in the manual(s) before
attempting to assemble and operate.
WARNING— ROTATING BLADES
Keep hands out of inlet and discharge openings while machine is running.
There are rotating blades inside.
BYSTANDERS
Keep bystanders, pets, and children at least 75 feet from the machine while
it is in operation. Stop machine if anyone enters the area.
WARNING— THROWN DEBRIS
Never operate without the chute deflector properly attached to the
machine.
EYE PROTECTION
Always wear safety glasses or safety goggles when operating this
machine.
1
Safety
Symbols
This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
WARNING
This symbol points
out important safety
instructions which,
if not followed, could
endanger the per-
sonal safety and/or
property of yourself
and others. Read and
follow all instructions
in this manual before
attempting to operate
this machine. Failure
to comply with these
instructions may
result in personal
injury. When you see
this symbol, HEED
ITS WARNING!
Your Responsibility
Restrict the use
of this power machine
to persons who read,
understand
and follow the warnings
and instructions
in this manual
and on the machine.

4
2
Safe
Operation
Practices
Training
Read, understand, and follow all instructions on the1.
machine and in the manual(s) before attempting to
assemble and operate. Keep this manual in a safe
place for future and regular reference and for ordering
replacement parts.
Be familiar with all controls and their proper operation.2.
Know how to stop the machine and disengage them
quickly.
Never allow children under 16 years of age to operate3.
this machine. Children 16 and over should read and
understand the instructions and safe operation practices
in this manual and on the machine and be trained and
supervised by an adult.
Never allow adults to operate this machine without proper4.
instruction.
Keep bystanders, helpers, pets, and children at least5.
75 feet from the machine while it is in operation. Stop
machine if anyone enters the area.
Never run an engine indoors or in a poorly ventilated area.6.
Engine exhaust contains carbon monoxide, an odorless
and deadly gas.
Do not put hands and feet near rotating parts or in the7.
feeding chambers and discharge opening. Contact with
the rotating impeller can amputate fingers, hands, and
feet.
Never attempt to unclog either the feed intake or8.
discharge opening, remove or empty bag, or inspect and
repair the machine while the engine is running. Shut the
engine off and wait until all moving parts have come to a
complete stop. Disconnect the spark plug wire and ground
it against the engine.
Preparation
Thoroughly inspect the area where the equipment is to1.
be used. Remove all rocks, bottles, cans, or other foreign
objects which could be picked up or thrown and cause
personal injury or damage to the machine.
Always wear safety glasses or safety goggles during2.
operation and while performing an adjustment or repair,
to protect your eyes. Thrown objects which ricochet can
cause serious injury to the eyes.
Wear sturdy, rough-soled work shoes and close-fitting3.
slacks and shirts. Loose fitting clothes or jewelry can be
caught in movable parts. Never operate this machine
in bare feet or sandals. Wear leather work gloves when
feeding material in the chipper chute.
Before starting, check all bolts and screws for proper4.
tightness to be sure the machine is in safe working
condition. Also, visually inspect machine for any damage
at frequent intervals.
Maintain or replace safety and instructions labels, as5.
necessary.
Safe Handling of Gasoline:
To avoid personal injury or property damage use extreme care
in handling gasoline. Gasoline is extremely flammable and the
vapors are explosive. Serious personal injury can occur when
gasoline is spilled on yourself or your clothes which can ignite.
Wash your skin and change clothes immediately.
Use only an approved gasoline container.a.
Never fill containers inside a vehicle or on a truck orb.
trailer bed with a plastic liner. Always place containers
on the ground away from your vehicle before filling.
When practical, remove gas-powered equipment fromc.
the truck or trailer and refuel it on the ground. If this is
not possible, then refuel such equipment on a trailer
with a portable container, rather than from a gasoline
dispenser nozzle.
Keep the nozzle in contact with the rim of the fueld.
tank or container opening at all times until fueling is
complete. Do not use a nozzle lock-open device.
Extinguish all cigarettes, cigars, pipes and othere.
sources of ignition.
Never fuel machine indoors.f.
Never remove gas cap or add fuel while the engine isg.
hot or running. Allow engine to cool at least two minutes
before refueling.
Never over fill fuel tank. Fill tank to no more than ½h.
inch below bottom of filler neck to allow space for fuel
expansion.
Replace gasoline cap and tighten securely.i.
If gasoline is spilled, wipe it off the engine andj.
equipment. Move unit to another area. Wait 5 minutes
before starting the engine.
To reduce fire hazards, keep machine free of grass,k.
leaves, or other debris build-up. Clean up oil or fuel
spillage and remove any fuel soaked debris.
Never store the machine or fuel container inside wherel.
there is an open flame, spark or pilot light as on a water
heater, space heater, furnace, clothes dryer or other
gas appliances.
Operation
Do not put hands and feet near rotating parts or in the1.
feeding chambers and discharge opening. Contact with the
rotating impeller can amputate fingers, hands, and feet.
Before starting the machine, make sure the chipper chute,2.
feed intake, and cutting chamber are empty and free of all
debris.
WARNING: Engine Exhaust, some of its constituents, and certain vehicle components contain or
emit chemicals known to State of California to cause cancer and birth defects or other reproduc-
tive harm.
WARNING
This symbol points
out important safety
instructions which, if
not followed, could
endanger the personal
safety and/or property
of yourself and others.
Read and follow all
instructions in this
manual before at-
tempting to operate
this machine. Failure
to comply with these
instructions may result
in personal injury. When
you see this symbol,
HEED ITS WARNING!
Your Responsibility
Restrict the use
of this power machine
to persons who read,
understand
and follow the warnings
and instructions
in this manual
and on the machine.
DANGER: This machine was built to be operated according to the rules for safe operation in this manual. As with
any type of power equipment, carelessness or error on the part of the operator can result in serious injury. This
machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety
instructions could result in serious injury or death.

5
Thoroughly inspect all material to be shredded and remove3.
any metal, rocks, bottles, cans, or other foreign objects
which could cause personal injury or damage to the
machine.
If it becomes necessary to push material through the4.
shredder hopper, use a small diameter stick. Do not use
your hands or feet.
If the impeller strikes a foreign object or if your machine5.
should start making an unusual noise or vibration,
immediately shut the engine off. Allow the impeller to come
to a complete stop. Disconnect the spark plug wire, ground
it against the engine and perform the following steps:
Inspect for damage.a.
Repair or replace any damaged parts.b.
Check for any loose parts and tighten to assurec.
continued safe operation.
Do not allow an accumulation of processed material to build6.
up in the discharge area. This can prevent proper discharge
and result in kickback of material through the feed opening.
Do not attempt to shred or chip material larger than7.
specified on the machine or in this manual. Personal injury
or machine damage could result.
Never attempt to unclog either the feed intake or discharge8.
opening while the engine is running. Shut the engine off,
wait until all moving parts have stopped, disconnect the
spark plug wire and ground it against the engine before
clearing debris.
Never operate without the shredder hopper, chipper chute,9.
or chute deflector properly attached to the machine. Never
empty or change discharge bag while the engine is running.
Keep all guards, deflectors and safety devices in place and10.
operating properly.
Keep your face and body back and to the side of the chipper11.
chute while feeding material into the machine to avoid
accidental kickback injuries.
Never operate this machine without good visibility or light.12.
Do not operate this machine on a paved, gravel or non-level13.
surface.
Do not operate this machine while under the influence of14.
alcohol or drugs.
Muffler and engine become hot and can cause a burn. Do15.
not touch.
Never pick up or carry machine while the engine is running.16.
If situations occur which are not covered in this manual, use17.
care and good judgement. Contact Customer Support for
assistance and the name of the nearest service dealer.
Maintenance & Storage
Never tamper with safety devices. Check their proper1.
operation regularly.
Check bolts and screws for proper tightness at frequent2.
intervals to keep the machine in safe working condition.
Also, visually inspect machine for any damage and repair,
if needed.
Before cleaning, repairing, or inspecting, stop the engine3.
and make certain the impeller and all moving parts have
stopped. Disconnect the spark plug wire and ground it
against the engine to prevent unintended starting.
Do not change the engine governor settings or overspeed4.
the engine. The governor controls the maximum safe
operating speed of the engine.
Maintain or replace safety and instruction labels, as5.
necessary.
Follow this manual for safe loading, unloading,6.
transporting, and storage of this machine.
Never store the machine or fuel container inside where7.
there is an open flame, spark or pilot light such as a water
heater, furnace, clothes dryer, etc.
Always refer to the operator’s manual for proper8.
instructions on off-season storage.
If the fuel tank has to be drained, do this outdoors.9.
Observe proper disposal laws and regulations for gas, oil,10.
etc. to protect the environment.
Do not modify engine
To avoid serious injury or death, do not modify engine in
any way. Tampering with the governor setting can lead to a
runaway engine and cause it to operate at unsafe speeds.
Never tamper with factory setting of engine governor.
Notice Regarding Emissions
Engines which are certified to comply with California and
federal EPA emission regulations for SORE (Small Off Road
Equipment) are certified to operate on regular unleaded
gasoline, and may include the following emission control
systems: Engine Modification (EM) and Three Way Catalyst
(TWC) if so equipped.
Average Useful Life
According to the Consumer Products Safety Commission
(CPSC) and the U.S. Environmental Protection Agency (EPA),
this product has an Average Useful Life of seven (7) years, or
60 hours of operation. At the end of the Average Useful Life,
buy a new machine or have the machine inspected annually
by an authorized service dealer to ensure that all mechani-
cal and safety systems are working properly and not worn
excessively. Failure to do so can result in accidents, injuries
or death.
2
Safe
Operation
Practices
WARNING
This symbol points
out important safety
instructions which, if
not followed, could
endanger the personal
safety and/or property
of yourself and others.
Read and follow all
instructions in this
manual before at-
tempting to operate
this machine. Failure
to comply with these
instructions may result
in personal injury. When
you see this symbol,
HEED ITS WARNING!
Your Responsibility
Restrict the use
of this power machine
to persons who read,
understand
and follow the warnings
and instructions
in this manual
and on the machine.

6
3
Setting Up
Your Chipper
Shredder
IMPORTANT: This unit is shipped WITHOUT GASOLINE
OR OIL in the engine. Be certain to service engine with
gasoline and oil as instructed in the separate engine
manual before operating your machine.
Loose Parts In Carton
a. Hopper Assembly d. Bag
b. Chute Deflector e. Safety Glasses
c. Chipper Chute f. Engine Oil
Attaching The Hopper
Assembly
1. a. Remove six hex nuts and washers from the weld
studs on the impeller housing. Do not remove the
support plate. See Figure 3-1.
b. Place hopper assembly into position in front of
impeller housing, aligning holes in hopper assembly
collar with weld studs.
c. Slide hopper assembly onto weld studs and replace
washers and hex nuts. Do not tighten completely.
2. a. Lift hopper assembly up to impeller bracket
assembly.
b. Slide the release rod out slightly to hook the hopper
bracket onto the rod. See Figure 3-2.
c. Tighten the six hex nuts that secure hopper
assembly to impeller housing and also tighten the
hex nuts that secure hopper bracket to hopper
assembly.
Attaching The Chute Deector
3. a. Remove the wing knobs from each side of the lower
impeller housing.
b. Remove the hex lock nut, spacers, and hex bolt from
the top of the impeller housing. See Figure 3-3.
4. a. Align the chute deflector in position on the
discharge opening and insert hex bolt with spacer
through hinge on chute deflector (spacers fit inside
of hinges). See Figure 3-4.
b. Place second spacer over hex bolt inside other
hinge and secure with hex lock nut.
c. Secure both sides of chute deflector to impeller
housing using wing knobs previously removed.
Figure 3-3
Figure 3-2
NOTE: All references
in this manual to the
left or right side of
the chipper shredder
is from the operating
position only. Excep-
tions, if any, will be
specified.
Figure 3-1
IMPORTANT
This unit is shipped
WITHOUT GASOLINE
OR OIL in the engine.
Be certain to service
engine with gasoline
and oil as instructed
in the separate engine
manual before operat-
ing your machine.
Figure 3-4
NOTE: This Operators
Manual covers a range
of product specifica-
tions for various
models. Characteristics
and features discussed
and/or illustrated in this
manual may not be ap-
plicable to all models.
MTD reserves the right
to change product
specifications, designs
and equipment without
notice and without
incurring obligation.
A
B
C
A
B
A
A
B
B
A
B
C

7
Fgure 3-5
3
Figure 3-6
Attaching The Chipper Chute
(Model Series 460)
5. a. Remove the three cupped washers and hex nuts
from weld studs around the opening on the side of
the impeller housing. See Figure 3-5.
b. Remove the hex bolts, flat washers, and lock nuts
from the two holes on the upper end of the support
brace.
6. a. Align the chipper chute over the weld studs, so the
slot in the bottom of the chute is facing down.
b. Secure chipper chute with the three cupped
washers (cupped side against the chipper chute)
and hex nuts previously removed. Do not tighten
the nuts at this time. See Figure 3-6.
7. The chipper shredder was shipped with one end of
the support brace already secured to the lower frame.
Loosen but do not remove the bolts securing the brace
to the frame. See Figure 3-7.
a. Align the holes in the chute with the holes in the top
of the brace and attach brace to chipper chute with
hardware previously removed. Tighten securely.
b. Tighten the bolts securing the support brace to the
frame.
c. Tighten the three nuts on the weld studs holding
the chipper chute to the impeller housing.
Setting Up
Your Chipper
Shredder
NOTE: All references
in this manual to the
left or right side of
the chipper shredder
is from the operating
position only. Excep-
tions, if any, will be
specified.
IMPORTANT
This unit is shipped
WITHOUT GASOLINE
OR OIL in the engine.
Be certain to service
engine with gasoline
and oil as instructed
in the separate engine
manual before operat-
ing your machine.
NOTE: This Operators
Manual covers a range
of product specifica-
tions for various
models. Characteristics
and features discussed
and/or illustrated in this
manual may not be ap-
plicable to all models.
MTD reserves the right
to change product
specifications, designs
and equipment without
notice and without
incurring obligation.
A
B
A
B
Figure 3-7
A
B
C

8
3
Setting Up
Your Chipper
Shredder
Figure 3-10
A
BC
Figure 3-9
NOTE: All references
in this manual to the
left or right side of
the chipper shredder
is from the operating
position only. Excep-
tions, if any, will be
specified.
IMPORTANT
This unit is shipped
WITHOUT GASOLINE
OR OIL in the engine.
Be certain to service
engine with gasoline
and oil as instructed
in the separate engine
manual before operat-
ing your machine.
NOTE: This Operators
Manual covers a range
of product specifica-
tions for various
models. Characteristics
and features discussed
and/or illustrated in this
manual may not be ap-
plicable to all models.
MTD reserves the right
to change product
specifications, designs
and equipment without
notice and without
incurring obligation.
Figure 3-8
Attaching The Chipper Chute
(Model Series 450)
8. a. Remove the three cupped washers and hex nuts
from weld studs around the opening on the side of
the impeller housing. See Figure 3-8.
9. a. Align the chipper chute over the weld studs, so
the slot in the bottom of the chute is facing down.
b. Secure chipper chute with the three cupped
washers (cupped side against the chipper chute)
and hex nuts previously removed. Tighten the
nuts at this time. See Figure 3-9.
Attaching The Bag
10.To attach the bag:
a. Place the opening of the bag completely over the
chute deflector.
b. Pull on the drawstring until the bag is tight around
chute deflector opening.
c. Clip drawstring back on itself, tight against chute
deflector to secure into position. See Figure 3-10.

9
4
Operating
Your Chipper
Shredder
Chipper Chute
Allows twigs and small branches up to 3” (2” for Model
Series 450) in diameter to be fed into the impeller for
chipping. See Figure 4-1.
Hopper Assembly
Allow leaves and small branches up to 1/2 diameter
to be fed into the impeller for chipping and shredding.
Material can be raked into hopper assembly by lowering
the hopper assembly. See Figure 4-1.
Release Rod
The release rod is located on the impeller bracket
assembly and it is used to release or lock the hopper
when raising or lowering. See Figure 4-1.
Gas and Oil Fill-Up
Service the engine with gasoline and oil as instructed in
the engine manual. See Engine Manual for location of
gas fill.
WARNING: Use extreme care when
handling gasoline. Gasoline is
extremely flammable and the vapors
are explosive. Never fuel the machine
indoors or while the engine is hot or
running. Extinguish cigarettes, cigars,
pipes and other sources of ignition.
WARNING: The operation of any
chipper shredder can result in foreign
objects being thrown into the eyes,
which can damage your eyes se-
verely. Always wear the safety glasses
provided with this unit or eye shields
before chipping or shredding and while
performing any adjustments or repairs.
This Operators Manual covers a range of product
specifications for various models. Characteristics and
features discussed and/or illustrated in this manual may
not be applicable to all models. MTD reserves the right
to change product specifications, designs and equipment
without notice and without incurring obligation.
WARNING
The operation of any
chipper shredder
can result in foreign
objects being thrown
into the eyes, which
can damage your
eyes severely. Always
wear the safety
glasses provided
with this unit or eye
shields before chip-
ping or shredding
and while performing
any adjustments or
repairs.
Use extreme care
when handling
gasoline. Gasoline is
extremely flammable
and the vapors are
explosive. Never fuel
the machine indoors
or while the engine
is hot or running.
Extinguish cigarettes,
cigars, pipes and
other sources of
ignition.
Figure 4-1
Know Your Chipper Shredder
Chipper Chute
Hopper Assembly
Release Rod

10
4
WARNING
Never run the engine
indoors or in a poorly
ventilated area. Engine
exhaust contains
carbon monoxide, an
odorless and deadly
gas.
Operating
Your Chipper
Shredder
NOTE: A noise will be
heard when finding the start
of the compression cycle.
This noise is caused by
the flails and fingers, which
are part of the shredding
mechanism, and it should
be expected until the impel-
ler reaches full speed.
Figure 4-2
Figure 4-3
Starting Engine
WARNING: Never run the engine
indoors or in a poorly ventilated area.
Engine exhaust contains carbon
monoxide, an odorless and deadly
gas.
IMPORTANT: Because this manual covers several
different model units, different starting instructions may
apply to your particular engine. Some engines may
have a fuel petcock, some may not. Some engines may
have On/Off switches, other may not. Some units will
utilize a choke system, while others will require priming.
These factors depend on what make and model engine
comes with your particular unit. For these reasons,
please refer to the engine operator’s manual for the
correct starting procedure.
1. Attach spark plug wire to spark plug. Make certain
the metal cap on the end of the spark plug is
fastened securely over the metal tip on the spark
plug.
2. Open fuel shut-off valve (if equipped) and make sure
the On/Off switch is in the ON position (if equipped).
3. Move choke lever on engine to CHOKE position, if
equipped. If the unit has a primer, prime engine as
instructed in separate engine manual. See Figure
4-2.
NOTE: A warm engine may not require choking.
4. Move engine throttle control lever to FAST or START
position (if equipped). See Figure 4-2.
5. Grasp starter handle and pull rope out slowly until
engine reaches start of compression cycle (rope will
pull slightly harder at this point).
NOTE: A noise will be heard when finding the start
of the compression cycle. This noise is caused by
the flails and fingers, which are part of the shredding
mechanism, and it should be expected until the impeller
reaches full speed.
6. Pull rope with a rapid, continuous, full arm stroke.
Keep a firm grip on starter handle. Let rope rewind
slowly.
7. Repeat the previous steps until engine fires. When
engine starts, move choke control (if equipped)
gradually to RUN position.
Stopping Engine
1. Move throttle control lever to STOP position (if
equipped) or push the rocker switch to OFF. See
Figure 4-3.
NOTE: See your engine manual packed with your unit
for more detailed instructions.

11
4
WARNING
Never run the engine
indoors or in a poorly
ventilated area. Engine
exhaust contains
carbon monoxide, an
odorless and deadly
gas.
Operating
Your Chipper
Shredder
NOTE: A noise will be
heard when finding the start
of the compression cycle.
This noise is caused by
the flails and fingers, which
are part of the shredding
mechanism, and it should
be expected until the impel-
ler reaches full speed.
Shredding
Yard waste such as leaves and pine needles can be
placed in the hopper for shredding. After material has
been processed by the shredder blade and flails, it will be
forced out of the chute deflector, and, if attached, into a
debris collection bag.
Observe the following guidelines when shredding yard
debris:
Never attempt to shred material other than normal•
yard debris (leaves, twigs, pine cones, etc.).
Avoid shredding fibrous plants such as tomato vines•
until they are thoroughly dried out. Fresh vines do
not shred well and tend to wrap themselves around
the impeller and flails.
Place reasonable amounts of debris into the hopper•
at a time. Do not overload the hopper.
Allow the material in the hopper to be drawn into the•
blades and shredded before adding additional debris
to the hopper. Failure to due so may result in a
clogged hopper, clogged chute deflector or a stalled
engine.
Chipping
Branches up to 3” in diameter can be fed into the chipper
chute. Observe the following guidelines when chipping
branches:
Keep both hands firmly on the branch as you feed it•
into the chipper chute.
Never feed more than one branch into the chipper•
chute at a time.
Never feed anything other than branches (or wood)•
into the chipper chute.
Apply intermittent pressure (force, in short pulses)•
while feeding larger (3-inch diameter) branches into
the chipper chute, to avoid bogging or stalling the
engine.
IMPORTANT: Never feed branches with a diameter
greater than three (3) inches into the chipper chute. Do-
ing so can result in serious damage to your unit’s chipper
blades, flails or impeller.
NOTE: For best performance, always operate the
unit with sharp chipper blades. If a noticeable loss in
performance is encountered while chipping branches, the
chipper blades should be replaced.
Lowering The Hopper Assembly
1. With one hand grasp the handle at the top of the
hopper assembly and lift slightly.
2. With the other hand pull out on the release rod
and lower the hopper assembly to the ground. See
Figure 4-1.
To Empty Bag
1. Un-clip drawstring and loosen bag from chute
deflector opening.
2. Empty bag and reattach to the discharge chute
opening. Pull on the drawstring until the bag is tight
around the chute opening and clip the drawstring
tight against the chute deflector.
IMPORTANT: The flail screen is located inside the
housing in the discharge area. If the flail screen
becomes clogged, remove and clean as instructed in
SECTION 5: MAINTAINING YOUR CHIPPER SHRED-
DER. For best performance, it is also important to keep
the chipper blade sharp.

12
5
Maintaining
Your Chipper
Shredder
WARNING
Always stop engine,
disconnect spark
plug, and ground
against engine
before cleaning,
lubricating or
doing any kind of
maintenance on your
machine.
Figure 5-1
Figure 5-2
General Recommendations
1. Always observe safety rules when performing
any maintenance.
2. The warranty on this chipper shredder does not
cover items that have been subjected to operator
abuse or negligence. To receive full value from war-
ranty, operator must maintain the chipper shredder
as instructed here.
3. Changing of engine-governed speed will void
engine warranty.
4. All adjustments should be checked at least once
each season.
5. Periodically check all fasteners and make sure these
are tight.
Lubrication
1. Lubricate the release rod and spring with light oil
once a season. See Figure 5-1.
2. Lubricate the pivot points on the hopper assembly
with light oil once a season. See Figure 5-1.
3. Lubricate the pivot points on the discharge chute with
light oil once a season. See Figure 5-1.
4. Follow the separate engine manual packed with you
unit for lubrication instructions.
Equipment Care
1. Clean the chipper shredder thoroughly after each use.
2. Wash bag periodically with water. Allow to dry thoroughly
in shade.
3. If the discharge area becomes clogged, remove flail
screen and clean as instructed below.
NOTE: Cleaning with a forceful spray of water is not recom-
mended as it could contaminate the fuel system.
Engine Care
Refer to the separate engine manual for all engine
maintenance instructions.
1. Check engine oil level before each use as instructed in
the separate engine manual packed with your unit. Read
and follow instructions carefully.
2. Clean air cleaner every 25 hours under normal condi-
tions or once a season. Clean every few hours under
extremely dusty conditions. To service the air cleaner,
refer to the separate engine manual packed with your
unit.
3. The spark plug should be cleaned and the gap reset
once a season. Check engine manual for correct plug
type and gap specifications.
4. Clean engine regularly with a cloth or brush. Keep the
cooling system (blower housing area) clean to permit
proper air circulation. Remove all grass, dirt and combus-
tible debris from muffler area.
Removing The Flail Screen
If the discharge area becomes clogged, remove the flail
screen and clean area as follows:
1. Stop the engine and make certain the chipper shredder
has come to a complete stop.
2. Disconnect spark plug wire from spark plug and ground
against the engine.
3. a. Remove the bag and two wing knobs on each side of
the chute deflector. See Figure 5-2.
b. Lift the chute deflector up to keep it out of the way.
c. Remove the two hairpin clips from each clevis pin
which extend through the housing and remove pins.
d. Remove the flail screen from inside the housing and
clean the screen by scraping or washing with water.
See Figure 5-2.
4. Reinstall the screen, making certain to reassemble the
flail screen with the curve side down.
5. Reattach the chute deflector with the hardware previ-
ously removed and connect the bag to unit.
Sharpening Or Replacing Chipper
Blades
1. Disconnect the spark plug wire and ground against the
engine.
2. Remove the flail screen as instructed in the previous
section.
*Model 464 Shown
Lubricate these
points before
reassembly.
A
B
C
D
*Model 464 Shown

13
3. Remove the chipper chute by removing three hex nuts
and washers.
4. Remove the chipper chute support brace (Model Series
460) from the frame by removing the hex bolts.
5. Rotate impeller assembly by hand until you locate one of
two chipper blades in the chipper chute opening.
6. Remove the blade by removing the internal hex screws,
lock washers, and hex nuts which secure it to the impel-
ler. Retain the hardware. See Figure 5-3.
NOTE: Use a 3/16” hex key (Allen) wrench on the outside of
the blade and a 1/2” box (or socket) wrench on the inside of
the impeller. Hold the Allen wrench stationary and rotate the
box (or socket) wrench to loosen the nut.
7. Install a replacement blade (Part No. 781-0490) with the
hardware removed earlier or sharpen.
IMPORTANT: When sharpening the blade, protect hands
by using gloves. Follow the original angle of grind and
make sure to remove an equal amount from each blade.
8. To replace the other blade, rotate the impeller to
expose the second blade and repeat the steps above.
NOTE: When reassembling the shredder blade, tighten
center bolt to between 550 and 700 in.-lbs. and the two
out bolts to between 250 and 350 in.-lbs.
WARNING: The impeller’s chipper
blades and shredder blade are sharp.
Wear leather work gloves to protect your
hands.
Sharpening Or Replacing The
Shredder Blade
1. Stop the engine and make certain that all moving parts
have come to a complete stop.
2. Disconnect the spark plug wire and ground against the
engine.
3. Lower the hopper assembly and block up the housing.
4. Remove the six hex lock nuts and flat washers from the
weld studs on the flail housing. Retain the hardware.
5. Carefully separate the hopper assembly from the impel-
ler assembly and remove the support plate.
NOTE: When reassembling the support plate, make
certain the embossed tab faces inward towards the
impeller.
6. Remove the two wing knobs that secure the chute
deflector and raise the chute.
7. Insert a 1/2” or 3/4” diameter pipe through the flail
screen into the impeller to keep it from turning or
remove the flail screen and insert a piece of wood into
the chute opening.
8. a. Remove the two internal hex screws, lock washers,
and hex lock nuts which secure the shredder blade
to the impeller.
b. Remove the hex bolt, lock washer, and flat washer
to completely free shredder blade. See Figure 5-4.
Figure 5-3
5
WARNING
The impeller’s
chipper blades and
shredder blade are
sharp. Wear leather
work gloves to
protect your hands.
Maintaining
Your Chipper
Shredder
IMPORTANT
When reassembling the
shredder blade, tighten
center bolt to between
550 and 700 in.-lbs.
and the two out bolts to
between 250 and 350
in.-lbs.
NOTE: Use a 3/16” hex key (Allen) wrench on the
outside of the shredder blade and a 1/2” box (or socket)
wrench on the inside of the shredder blade. Hold the
Allen wrench stationary and rotate the box (or socket)
wrench to loosen the nut. Use caution when removing
the blade to avoid contacting the weld studs on housing.
IMPORTANT: When sharpening the blade, follow
the original angle of grind as a guide. It is extremely
important that each cutting edge receives an equal
amount of grinding to prevent an unbalanced blade.
An unbalanced blade will cause excessive vibration
when rotating at high speeds and may cause damage
to the unit. The blade can be tested by balancing it on a
screwdriver or nail. Remove metal from the heavy side
until it is balanced evenly.
Storing Your Chipper Shredder
The following steps should be taken to prepare your
chipper shredder for storage.
1. Clean the equipment thoroughly.
2. Wipe equipment with an oiled rag to prevent rust.
3. Refer to engine manual for correct engine storage
instructions.
4. Store unit in a clean, dry area. Do not store next to
corrosive materials such as fertilizer.
Figure 5-4
A
A
B

14
For repairs beyond
the minor adjust-
ments listed here,
contact an authorized
service dealer.
6
Trouble
Shooting
CauseProblem Remedy
Engine fails to start 1. Throttle lever not in correct starting
position (if equipped).
2. Spark plug wire disconnected.
3. Choke not in CHOKE position (if
equipped).
4. Fuel tank empty or stale fuel.
5. Engine not primed (if equipped).
6. Faulty spark plug.
7. Blocked fuel line.
8. Engine flooding.
1. Move throttle lever to FAST or START
position.
2. Connect wire to spark plug.
3. Move choke lever to CHOKE position.
4. Fill tank with clean, fresh gasoline.
5. Prime engine as instructed in engine
manual.
6. Clean, adjust gap, or replace.
7. Clean fuel line.
8. Wait a few minutes to restart, but do not
prime.
Engine runs erratic 1. Connect and tighten spark plug wire.
2. Move choke lever to OFF position.
3. Clean fuel line; fill tank with clean, fresh
gasoline.
4. Clear vent.
5. Drain fuel tank and carburetor. Refill with
fresh fuel.
6. Refer to engine manual.
7. See authorized service dealer.
1. Spark plug wire loose.
2. Unit running on CHOKE (if
equipped).
3. Blocked fuel line or stale fuel.
4. Gas cap vent plugged.
5. Water or dirt in fuel system.
6. Dirty air cleaner.
7. Carburetor out of adjustment.
Engine overheats 1. Fill crankcase with proper oil.
2. Refer to the engine manual packed with
your unit.
3. See authorized service dealer.
1. Engine oil level low.
2. Dirty air filter.
3. Carburetor not adjusted properly.
Occasional skip
(hesitates) at high speed
1. Adjust gap to .030”. Refer to engine
manual.
2. See authorized service dealer.
1. Spark plug gap too close.
2. Carburetor idle mixture adjustment
improperly set.
Excessive vibration 1. See authorized service dealer.
1. Loose parts or damaged impeller.
1. Low engine RPM.
2. Chipper blade dull.
Rate of discharge
slows considerably
or composition of
discharged material
changes.
1. Always run engine at full throttle.
2. Replace chipped blade or see your
authorized dealer.
Unit does not discharge 1. Stop engine immediately and disconnect
spark plug wire. Clean flail screen and
inside of discharge opening.
2. Stop engine and disconnect spark plug
wire. Remove lodged object.
3. Always run engine at full throttle
1. Chute deflector clogged.
2. Foreign object lodged in impeller.
3. Low engine RPM.

15
7
Warranty
Failure to comply
with suggested
maintenance
and lubrication
specifications
will void
warranty.
TWO YEAR LIMITED WARRANTY
The limited warranty set forth below is given by MTD Products Limited with respect to new merchandise purchased and
used in Canada and/or its territories and possessions (either entity respectively, “MTD”).
MTD warrants this product (excluding its normal wear parts as described below) against defects in material and
workmanship for a period of two (2) years commencing on the date of original purchase and will, at its option, repair
or replace, free of charge, any part found to be defective in materials or workmanship. This limited warranty shall
only apply if this product has been operated and maintained in accordance with the Operator’s Manual furnished with
the product, and has not been subject to misuse, abuse, commercial use, neglect, accident, improper maintenance,
alteration, vandalism, theft, fire, water, or damage because of other peril or natural disaster. Damage resulting from the
installation or use of any part, accessory or attachment not approved by MTD for use with the product(s) covered by
this manual will void your warranty as to any resulting damage.
Normal wear parts are warranted to be free from defects in material and workmanship for a period of thirty (30) days
from the date of purchase. Normal wear parts include, but are not limited to items such as: batteries, belts, blades,
blade adapters, grass bags, rider deck wheels, seats, snow thrower skid shoes, friction wheels, shave plates, auger
spiral rubber, tires, engine oil, air filters and spark plugs.
HOW TO OBTAIN SERVICE: Warranty service is available, WITH PROOF OF PURCHASE, through your local
authorized service dealer. To locate the dealer in your area contact MTD Products Limited, Kitchener, ON N2G 4J1, or
call 1-800-668-1238 or log on to our Web site at www.mtdcanada.com.
This limited warranty does not provide coverage in the following cases:
a. The engine or component parts thereof. These items may carry a separate manufacturer’s warranty. Refer to
applicable manufacturer’s warranty for terms and conditions. The Powermore engine is not excluded under this
agreement.
b. Log splitter pumps, valves, and cylinders have a separate one-year warranty.
c. Routine maintenance items such as lubricants, filters, blade sharpening, tune-ups, brake adjustments, clutch
adjustments, deck adjustments, and normal deterioration of the exterior finish due to use or exposure.
d. Service completed by someone other than an authorized service dealer.
e. MTD does not extend any warranty for products sold or exported outside of Canada, including possessions and
territories.
f. Replacement parts that are not genuine MTD parts.
g. Transportation charges and service calls.
h. If Products are used commercially. (MTD may separately offer Limited Commercial Warranties on certain select
products. Ask your dealer or retailer for details or contact MTD Service for more information.)
No implied warranty, including any implied warranty of merchantability of fitness for a particular purpose,
applies after the applicable period of express written warranty above as to the parts as identified. No other
express warranty, whether written or oral, except as mentioned above, given by any person or entity, including
a dealer or retailer, with respect to any product, shall bind MTD. During the period of the warranty, the exclu-
sive remedy is repair or replacement of the product as set forth above.
The provisions as set forth in this warranty provide the sole and exclusive remedy arising from the sale. MTD
shall not be liable for incidental or consequential loss or damage including, without limitation, expenses
incurred for substitute or replacement lawn care services or for rental expenses to temporarily replace a
warranted product.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how
long an implied warranty lasts, so the above exclusions or limitations may not apply to you.
In no event shall recovery of any kind be greater than the amount of the purchase price of the product sold. Alteration
of safety features of the product shall void this warranty. You assume the risk and liability for loss, damage, or
injury to you and your property and/or to others and their property arising out of the misuse or inability to use the
product.
This limited warranty shall not extend to anyone other than the original purchaser or to the person for whom it was
purchased as a gift.
HOW LOCAL LAWS RELATE TO THIS WARRANTY: This limited warranty gives you specific legal rights, and you
may also have other rights that vary in different jurisdictions.
IMPORTANT: Owner must present Original Proof of Purchase to obtain warranty coverage.
MTD Products Ltd., P. O. BOX 1386, KITCHENER, ON N2G 4J1; Phone: [phone].06

16
Models 450 and 460/
Modèles 450 et 460
34
38
35
A
A
B
B
20
2
34
42
28
34
35
35
34
8
25 1
23
48
7
7
21
19
9
2
11
14
3
27
5
13
34
13
16
15
11
18
18
11
24
16
30
6
38
40
34
29
41
33
10
10
12
38
38
22
39
26
32
36 31
17
34
38 34

17
8
For parts and/or
accessories refer to
customer support on
page 2.
Adressez-vous au
«Service après-
vente» à la page 2
pour ce qui concerne
les pièces et/ou
accessoires.
Parts List
Pièces
détachées
REF PART
NO.NO.
N° DE N° DE
RÉF PIÈCE DESCRIPTION DESCRIPTION
1736-0217 Lockwasher Heavy 3/8" ID Rondelle frein 3/8 DI
2714-0149B Internal Cotter PinGoupille fendue interne
3 720-0170 Hand Knob Ass’y Bouton à oreilles
4 681-0094A Chute Deflector Ass’y Déflecteur de la goulotte
5 711-0835 Clevis Pin .5" Dia. x 4.62" Lg. Axe de chape 0,50 dia x 4,62 po de lg
6 781-0457 Shredder Screen Tamis à broyeuse
7 726-0211 “U” Nut 5/16-18 Écrou en «U» 5/16-18
8 750-0793 Chute Hinge Spacer 1.66" Lg. Cales d’écartement 1,66 po de lg
9712-3027 Hex L-Flanged Nut 1/4-20 Contre-écrou à embase 1/4-20
10 712-3004A Hex Flange L-Nut 5/16-18 Contre-écrou à embase 5/16-18
11 736-0119 L-Wash 5/16 ID Rondelle frein 5/16 DI
12 681-04116 Flail Housing Ass’y - Inner Boîtier des fleaux - interne
13 710-3025 Screw-Hex Cap Vis à tête hex
14 710-0157 Hex Screw 5/16-24 x .75 Vis à tête hex. 5/16-24 x 0,75
14 710-0117 Hex Screw 5/16-24 x 1.00 Vis à tête hex. 5/16-24 x 1,00
15 742-0544B Chipper Blade Lame
15 781-0490 Chipper Blade Lame
16 710-1054 Flat Hd. Screw 5/16-24 x .75" Lg. Vis à tête plate 5/16-24 x 0,75 po de lg
17 681-04096 Impeller Assembly Turbine
17 681-04095 Impeller Assembly Turbine
18 712-0411 Hex Top L-Nut 5/16-24 Écrou de blocage hex. 5/16-24
19 712-0266 Hex Cent L-Nut 3/8-16 Contre-écrou de blocage 3/8-16
20 719-04308 Flail Blade Lame
21 738-04286 Shoulder Pin .5 x 2.625 Goupille épaulée 0,5 x 2,625
22 710-3008 Hex Bolt 5/16-18 x .75" Lg. Gr. 5 Boulon hex. 5/16-18 x 0,75 po de lg. Qual. 5
23 736-0247 Flat Washer .40 ID x 1.25 OD x .160 Rondelle plate 0,40 DI x 1,25 DE x 0,160
24 742-0571 Chipper Blade Lame
25 710-1254 Hex Patch Bolt 3/8-24 x 2.25" (Grade 8) Boulon hex 3/8-24 x 2,25 po de lg Qual. 8
26 681-0004A Flail Housing Ass’y - Outer Boîtier des fleaux - extérieure
27 710-0825 Hex Bolt 1/4-20 x 3.75" Lg. Boulon hex. 1/4-20 x 3,75 po de lg.
28 781-0515 Front Support Brkt. Support - avant
29 781-0574 Back Up Plate Plaque de renfort
30 681-0104 Bracket Ass’y - R.R. Support - arrière droit
31 732-0306A Compression Spring Ressort de compression
32 736-0117 Flat Washer .385 ID x .62 OD x .033 Rondelle plate 0,385 DI x 0,62 DE x 0,033
33 714-0104 Int. Cotter Pin .072 x 1.13" Lg. Goupille fendue int. 0,072 x 1,13 po de lg.
34 736-0264 Flat Washer .344 ID x .625 OD x .063 Rondelle plate 0,344 DI x 0,625 DE x 0,063
35 710-0376 Hex Scr 5/16 x 1,00 Gr. 5 Vis à tête hex. 5/16 x 1,00 Qual. 5
36 748-0453 Spacer .375 x 2.50 Lg. Entretoise 0,375 x 2,50 po de lg.
38 712-0429 Hex Ins. L-Nut 5/16-18 Contre-écrou de blocage 5/16-18
39 731-1710A Hopper Collar Collier de la trémie
40 681-0123 Bracket Ass’y - Frt. Support - avant
41 711-1128 Lock Rod Tige de blocage
42 731-1707A Hopper Trémie
450-4601
6.24.11
Model 450 only/Modèle 450 seulement.
 Model 460 only/Modèle 460 seulement.

18
Models 450 and 460/
Modèles 450 et 460
7
13
10
16
11
10
26
24
25
22
7
12
9
7
9
6
21
20
20
18
17
19
17
19
23
15
5
2
34
1
69
14
8
11
27
10
18
Model/Modèle 450

19
8
For parts and/or
accessories refer to
customer support on
page 2.
Adressez-vous au
«Service après-
vente» à la page 2
pour ce qui concerne
les pièces et/ou
accessoires.
Parts List
Pièces
détachées
REF PART
NO.NO.
N° DE N° DE
RÉF PIÈCE DESCRIPTION DESCRIPTION
 1 728-0175 Pop Rivet Rivet
 2 731-1899 Chipper Shredder Chute Goulotte de déchiquetage
 3 735-0249A Chipper Flap Rabat de la goulotte
 4 781-0633 Flat Strip Baguette plate
 5 681-04119 Chipper Chute Ass’y Déflecteur de la goulotte
 6 710-0751 Hex Bolt 1/4-20 x .62 Gr. 5 Boulon hexagonale 1/4-20 x 0,62 Qual. 5
 7 712-04064 Hex L-Flanged Nut 1/4-20 Gr. F Contre-écrou à embase 1/4-20 Qual. F
 8 710-0106 Hex Screw 1/4-20 x 1.25 Vis à tête hexagonale 1/4-20 x 1,25
 9 736-0173 Flat Washer .28 ID x .74 DE x .063 Rondelle frein 0,28 DI x 0,74 DE x 0,063
10 736-0242 Cup. Wash. .340 ID x .872 OD x .060 Rondelle creuse 0,340 DI x 0,872 DE x 0,060
11 712-3010 Hex Nut 5/16-18 hd. Gr. 5 Écrou hexagonal 5/16-18 Qual. 5
12 749-1004 Chute Support Support de la goulotte
13 712-3004A Hex Flange L-Nut 5/16-18 Gr. 5 Contre-écrou à embase 5/16-18 Qual. 5
14 710-0805 Hex Bolt 5/16-18 x 1.50" Lg. Gr. 5 Boulon hexagonal 5/16-18 x 1,50 po de lg Qual. 5
(w/205 cc and 250 cc engines) (avec 205 cc et 250 cc moteurs)
 710-0157A Hex Bolt 5/16-18 x 1.75" Lg. Gr. 5 Boulon hexagonal 5/16-18 x 1,75 po de lg Qual. 5
(w/208 cc Powermore engines) (avec 208 cc moteurs Powermore)
15 736-0170 Special L-Wash 5/16" ID x 1.0 Rondelle frein - spéciale 5/16 DI x 1,0
16 710-0809 Hex Wash Hd TT Scr. 1/4-20 x 1.25 Vis taraudée 1/4-20 x 1,25
 17 738-0814 Shredder Axle Essieu de la déchiqueteuse
17 738-0813 Shredder Axle Essieu de la déchiqueteuse
18 750-0786 Spacer .64 ID x 1.24 Entretoise 0,64 DI x 1,24
 19 734-1600 Wheel Ass'y Comp. 10 x 2.5 Ensemble de roue complet 10 x 2,5
19 634-04009 Wheel Ass'y Comp. 10 x 4 x 4 Ensemble de roue complet 10 x 4 x 4
20 726-0214 Push Cap 5/8" Dia Rod Chapeau à enfoncer dia 5/8 po
21 681-0184C Frame (w/205 cc and 250 cc engines) Bâti (avec 205 cc et 250 cc moteurs)
681-0183B Frame (w/305 cc engine) Bâti (avec 305 cc engine)
22 736-0451 Washer .320 ID x .93 OD Rondelle 0,320 DI x 0,93 DE
23 710-0502A Screw 3/8-16 x 1.250 Vis 3/8-16 x 1,250
 24 737-0195 Elbow Fitting Raccord
25 737-0298 Oil Drain Pipe Tuyau de vidange
26 737-0132 Oil Drain End Cap Capuchon
 27 681-04118 Chipper Shredder Chute Goulotte de déchiquetage
 664-04022 Chipper Bag Ass’y (not shown) Sac de déchiqueteuse-broyeuse (non illustré)
 664-04023 Chipper Bag Ass’y (not shown) Sac de déchiqueteuse-broyeuse (non illustré)
 28 781-04292 Engine Plate Plaque de moteur
450-460
6.24.11
Model 450 only/Modèle 450 seulement.
 Model 460 only/Modèle 460 seulement.

17
7
Garantie
Le non-respect des
conseils d’entretien
et de lubrification
annule la garantie.
GARANTIE LIMITÉE DE DEUX ANS
La garantie limitée qui est énoncée ci-dessous est offerte par MTD Products Limited, pour toutes les marchandises
achetées et utilisées au Canada et/ou ses territoires (l’une ou l’autre entité respectivement appelée « MTD »).
« MTD » garantit que ce produit (à l’exception des pièces à usure normale énumérées ci-dessous)est exempt de tout
vice de matière et de fabrication pour une durée de deux (2) ans à compter de la date de l’achat initial et s’engage
à réparer ou à remplacer, gratuitement et à son choix, toute pièce qui s’avère défectueuse en raison d’un vice de
matière ou de fabrication. Cette garantie limitée n’est applicable que si ce produit a été utilisé et entretenu conformé-
ment aux instructions de la notice d’utilisation qui l’accompagne. De plus, le produit ne doit pas avoir fait l’objet d’un
emploi incorrect ou abusif, d’une utilisation à des fins commerciales, d’une négligence, d’un accident, d’un entretien
incorrect, d’une modification, d’un acte de vandalisme, d’un vol, d’un incendie, d’une inondation ou de tout autre
dégât causé par tout incident ou désastre naturel. Les dégâts causés par l’installation ou l’utilisation d’une pièce, d’un
accessoire ou d’un équipement annexe, dont l’emploi avec le produit faisant l’objet de la notice d’utilisation n’est pas
homologué par MTD, rendront la garantie nulle et non avenue.
Les pièces ou composants à usure normale sont garantis exempts de tout vice de matière et de fabrication pour une
période de 30 jours à compter de la date d’achat. Les pièces et composants à usure normale comprennent, sans s’y
limiter, les batteries, courroies, lames, adaptateurs de lame, sacs à herbe, roues du plateau de coupe des tondeuses
à siège, sièges, patins de souffleuses, roues de frottement, lames de raclage, le caoutchouc de la tarière et pneus,
l’huile à moteur, les filtres à air et bougies.
POUR FAIRE HONORER LA GARANTIE : Présentez UNE PREUVE D’ACHAT à la station technique agréée de
votre localité. Pour localiser une station technique agréée ou un concessionnaire dans votre région, adressez-vous à
MTD Products Limited, Kitchener, Ontario, N2G 4J1 ou appelez le 1-800-668-1238 ou visitez notre site web au www.
mtdcanada.com
Cette garantie limitée ne couvre pas:
a. Le moteur ou ses composants. Ces articles peuvent être couverts par une garantie séparée du fabricant.
Consultez la garantie du fabricant quant aux conditions. Le moteur Powermore à soupapes en tête n’est pas
exclus aux termes de cette garantie.
b. Les pompes, soupapes et pistons des fendeuses à bois sont couverts par une garantie séparée d’un an.
c. Les articles d’entretien courant tels que les lubrifiants, filtres, aiguisages de lame et révisions, les réglages de
frein, de l’embrayage ou du plateau de coupe et la détérioration normale de la finition du fait de l’utilisation de la
machine ou de son exposition aux intempéries.
d. L’entretien ou les réparations effectués par quiconque autre qu’une station technique agréée.
e. MTD ne garantit pas les produits vendus ou exportés du Canada, de ses possessions et territoires.
f. Les pièces de rechange si elles ne sont pas des pièces MTD authentiques.
g. Les frais de transport des machines et de déplacement des techniciens.
h. Les produits utilisés dans un but commercial. (Certains produits peuvent être accompagnés d’une garantie limitée
MTD séparée pour usage commercial. Renseignez-vous auprès du concessionnaire ou détaillant pour plus de
détails ou adressez-vous directement au service après-vente de MTD.)
Aucune garantie tacite, y compris toute garantie tacite de qualité marchande ou d’adaptabilité dans un but
particulier, ne s’applique aux pièces identifiées ci-dessus après la période de vigueur de la garantie écrite
expresse. Aucune autre garantie expresse, qu’elle soit verbale ou écrite, à l’exception des stipulations
ci-dessus, offerte par toute personne ou entité (y compris un concessionnaire/revendeur), pour tout produit,
n’engage MTD. Pendant la période de garantie, la réparation ou le remplacement du produit ci-dessus
constitue le recours exclusif à la disposition du client.
Les stipulations énoncées dans cette garantie offrent le seul recours à la suite de la vente. MTD ne peut être
tenue responsable pour toute perte ou tout dommage accessoire ou immatériel comprenant, sans s’y limiter,
les frais de remplacement ou de substitution des services d’entretien des pelouses ou les frais de location
pour remplacer temporairement un article sous garantie.
Certaines juridictions ne permettent pas l’inclusion ou la restriction des dommages accessoires ou immatériels ou
une limite à la durée de la garantie tacite. Par conséquent, les exclusions ci-dessus peuvent ne pas s’appliquer dans
votre situation.
Le remboursement ou remplacement quel qu’il soit ne sera en aucun cas supérieur au montant du prix d’achat du
produit vendu. Toute modification des caractéristiques de sécurité rendra la garantie nulle et non avenue.
L’utilisateur assume tout risque et toute responsabilité en cas de perte, de dommage matériel ou de blessure résultant
de l’utilisation incorrecte du produit ou de l’incapacité de l’employer.
Cette garantie limitée n’est offerte qu’à l’acheteur initial ou à la personne à laquelle le produit a été offert en cadeau.
LES LOIS LOCALES ET CETTE GARANTIE : Cette garantie limitée vous accorde des droits juridiques spécifiques
et vous pouvez bénéficier d’autres droits qui varient selon les juridictions.
IMPORTANT : Le propriétaire doit présenter le reçu original pour faire honorer la garantie.
MTD Products Ltd., C.P. 1386, Kitchener, Ontario N2G 4J1; téléphone: 1-800-668-1238 12.16.06
