MTD BL410 User manual

Reissued 12/02
Item Part No. Description
1791-182059 Air Cleaner/Muffler Cover Assembly
(includes 2 & 40)
2791-180350 Air Cleaner Filter
3791-180351 Carburetor Mounting Screw Assembly
4791-180226 Wavey Washer
5791-182160 Choke Lever Assembly (includes 6)
6791-182161 Choke Knob and Screw
7791-182162 Choke Lever and Plate (includes 5)
8753-04333 Carburetor Assembly (includes 9 & 20)
9791-610675 Carburetor Gasket
10 791-181860 Carb Mount Screw
11 791-182607 Primer and Hose Assembly
12 753-1196 Carb Mount Assembly (includes 10 & 14)
13 791-684451 Reed Assembly
14 753-1208 Carburetor Mount Gasket
15 753-04369 Crank Case Service Assembly
(includes 10 & 23)
16 791-612134 Rear Mounting Pad
17 753-04306 Fuel Tank Assembly (includes 18-20)
18 791-182612 Fuel Cap Assembly
19 791-181168 Fuel Return Line
20 791-682039 Fuel Line Assembly
21 791-145308 Front Mounting Pad
22 791-683065 Shroud Assembly (includes 23)
23 791-181861 Shroud Screw
24 791-182064 Shroud Extension and Stand
25 791-182736 Flywheel Assembly
26 791-181065 Spacer
27 753-04232 Recoil Pulley Assembly
28 791-613102 Recoil Spring
29 791-180930 Pulley Retainer Assembly
30 791-611061 Rope Guide
31 791-180317 Fuel Tank Guard Assembly
32 791-181079 Pull Handle
33 791-613103 Rope
34 791-181912 Screw
Item Part No. Description
35 753-04238 Starter Housing Assembly
(includes 27-30, 32-34 & 40)
36 791-182368 Clutch Washer
37 791-182369 Clutch Rotor Assembly
38 791-153592 Clutch Drum Assembly
39 791-180098 Clutch Cover Assembly (includes 40)
40 791-181345 Screw
41 791-153597 Upper Clamp Assembly
42 753-04337 Module Assembly
43 791-182880 Wire Lead
44 791-610311 Spark Plug
45 753-04159 Exhaust Gasket
46 791-182174 Muffler Assembly (includes 45, 47 & 53)
47 791-182464 Muffler Mounting Bolt Assembly
48 753-04323 Cylinder Assembly (includes 50 & 51)
49 753-1207 Piston and Rod Assembly
50 753-1197 Cylinder Gasket
51 791-182723 Cylinder Bolt
52 791-611063 Ground Tab
53 791-182747 Spark Arrestor
*753-04134 Engine Gasket Kit
*791-180090 O.E.M. Carburetor Repair Kit
*791-180091 Gasket-Diaphragm Repair Kit
*753-1209 Piston Ring
*753-04359 Short Block Assembly
(includes 15, 44, 48-51)
*791-181599 Clutch Springs (Qty. 2)
*not shown
40
12
38
10
12
34
5
7
6
11
13
14 15 49
50
19
51 21
16 17
18
20
36 37
38
39
4140
31
32
25
26 27 29
40
33
35 34
29
24
43
28
42
48
44
45
47
23
30
22
9
52
ENGINE PARTS - MODEL BL410
2-CYCLE GAS CULTIVATOR
PPN 21BK410G163
53
46

Reissued 12/02
BOOM AND CULTIVATOR PARTS - MODEL BL410
2-CYCLE GAS CULTIVATOR
PPN 21BK410G163
32
4
11
13
10
16
17
18
19 24
20
25
26
28
29
23
27
22
12
9
6
7
8
6
5
Item Part No. Description
1791-00023 Throttle Trigger and Cable Assembly
2791-182882 Handle Bar Assembliy, Upper (includes 3 & 4)
3791-182675 Grip
4791-182676 Tube Closure
5791-182678 Washer
6791-182899 Bolt
7791-182898 Knob, 3 prong
8791-180943 Drive Shaft Housing Assembly
9791-181577 Flexible Drive Shaft
10 791-683295 Handle Bracket Assembly (includes 11-15)
11 791-181811 Screw
12 791-181812 Upper Handle Clamp
13 791-181813 Middle Handle Clamp
14 791-181814 Lower Handle Clamp
15 791-181815 Nut
16 791-181575 Grip
17 791-182900 Lower Handle Bar
18 791-182681 Hardware, Handle Bar Mounting (lower)
19 791-147467 Wheel Bracket Mounting Hardware
20 753-04266 Guard Mounting Hardware
21 753-04240 Guard
22 791-180320 Wheel Bracket Assembly
23 791-180944 Wheel Assembly
24 791-147474 Gear Box Assembly
25 791-182195 Screw
26 791-180288 Sleeve Retainer Bolt
27 791-147473 Tine Fastener Assembly
28 791-182729 Tine Assembly (Left Outer or Right Inner)
29 791-182730 Tine Assembly (Left Inner or Right Outer)
Optional Accessories
*791-147543 2-Cycle Oil
*not shown
3
4
1
20
18
27
14
15
19
1
21
