MTHTrains RailKing 30-9006 User manual

Service & Warranty Information
How to Get Service Under the Terms of the Limited One-Year Warranty
When you suspect an item is defective, please check the operator's manual for standard operation and trouble-
shooting techniques that may correct the problem. Additional information may be found on the M.T.H. Website.
Should you still require service, follow the instructions below to obtain warranty service.
First, e-mail, write, call or fax M.T.H. Electric Trains or a M.T.H. Authorized Service Center (ASC) in your area
to obtain Repair Authorization. You can find the list of ASCs on the M.T.H. Website, www.mth-railking.com.
Authorized Service Centers are required to make warranty repairs on items sold only from that store; all other
repairs may-- or may not be done at the store's own discretion. If you did not purchase the item directly from
the ASC, you will need to select a National Authorized Service Center (NASC) or contact M.T.H. Electric Trains
directly. NASC Dealers are compensated by M.T.H. to perform warranty service for any customer whose repair
qualifies for warranty service. A list of NASC retailers can be located on the M.T.H. Website or by calling 410-
381-2580. Should the warranty no longer apply, you may choose either an ASC or NASC retailer to service your
M.T.H. Product. A reasonable service fee will be charged.
CAUTION: Make sure the product is packed in its original factory packaging including its foam and plastic
wrapping material to prevent damage to the merchandise. There is no need to return the entire set if only one
of the components is in need of repair unless otherwise instructed by the Service Center. The shipment must be
prepaid and we recommend that it be insured. A cover letter including your name, address, daytime
phone number, e-mail address (if available), Return Authorization number (if required by the service
center, a copy of your sales receipt and a full description of the problem must be included to facilitate
the repairs. Please include the description regardless of whether you discussed the problem with a
service technician when contacting the Service Center for your Return Authorization.
Please make sure you have followed the instructions carefully before returning any merchandise for service.
Authorized M.T.H. Service Centers are independently owned and operated and are not agents or representatives
of M.T.H. Electric Trains. M.T.H. assumes no responsibility, financial or otherwise, for material left in their
possession, or work done, by privately owned M.T.H. Authorized Service Centers.
If you need assistance at any time email MTH Service at ser[email protected], or call 410 381-2580.
Limited One-Year Warranty
All M.T.H. products purchased from an Authorized M.T.H. Retailer are covered by this warranty.
See our Website to identify an Authorized M.T.H. Retailer near you.
M.T.H. products are warrantied for one year from the date of purchase against defects in material or
workmanship, excluding wear items such as light bulbs, pick-up rollers, batteries, smoke unit wicks, and traction
tires. We will replace or credit (at our option) any defective item with a manufactured suggested retail price of
$279.95 or less (excluding all motive power and electronic items), if the item is returned to an M.T.H. Authorized
Service Center (ASC) or M.T.H. National Authorized Service Center (NASC) within one year of the original date
of purchase. For any item with an MSRP greater than $279.95 (including all motive power and electronics), We
will repair, replace or credit (at our option) the defective item without charge for the parts or labor, if the item is
returned to an M.T.H. Authorized Service Center (ASC) or M.T.H. National Authorized Service Center (NASC)
within one year of the original date of purchase. This warranty does not cover damages caused by improper care,
handling, or use. Transportation costs incurred by the customer to ship the product for warranty service are not
covered under this warranty.
Items sent for repair must be accompanied by a return authorization number, a description of the problem, and
a copy of the original sales receipt from an Authorized M.T.H. Retailer stating the date of purchase. If you are
sending this product to an Authorized Service Center, contact that Center for their return authorization.
This warranty gives you specific legal rights, and you may have other rights that vary from state to state. Specific
questions regarding the warranty may be forwarded to M.T.H. directly.
Service Department
M.T.H. Electric Trains
7020 Columbia Gateway Drive
Columbia MD 21046-1532
410-381-2580
[e-mail]
The passenger platform adds a splash of life to your layout. Constructed
from sturdy ABS plastic and brightly painted, the passenger platform is a
perfect addition to any O-27 or O Gauge layout.
The passenger platform is pre assembled, so set up is quick and easy by
following the setup diagram on the inside.
Passenger Platform
PLEASE READ BEFORE USE AND SAVE
www.mthtrains.com

The RailKing Passenger Platforms can be used alone, or combined with other passenger platforms (as seen
below). Before the platform is placed on the layout, each platform (which contain pre-wired operating lamps)
must be wired together and attached to one another.
In order to connect power to each platform, the (2) enclosed wires must be connected to the wiring posts
located on the underside of each platform. Once the wires are attached to each platform, the (4) locking clips
should be pressed and snapped onto the roof and base bolsters where the platforms’ roofs and bases meet.
Follow the diagram to locate the correct wire post terminals for the wire harnesses and the bolster points
where the locking clips should be snapped into place.
Bottom View of
Passenger Platform
Push locking clip
up onto roof and
base bolsters
Strip Z-wire cable
harness insulation to
reveal 1/4“ of bare wire
CAUTION:
ELECTRICALLY OPERATED PRODUCT:
WARNING: When using electrical products, basic
safetyprecautionsshouldbeobserved,including
thefollowing:
Read this manual thoroughly before using this
device.
lM.T.H. recommends that all users and persons
supervising use examine the hobby transformer
and other electronic equipment periodically for
conditions that may result in the risk of fire,
electric shock, or injury to persons, such as
damage to the primary cord, plug blades,
housing,output jacks orother parts. Inthe event
such conditions exist, the train set should not be
useduntil properlyrepaired.
lDo not operate your layout unattended.
Obstructed accessories or stalled trains may
overheat,resulting indamagetoyour layout.
lThis train set is intended for indoor use. Do not
use if water is present. Serious injury or fatality
mayresult.
lDo not operate the hobby transformer with
damagedcord, plug,switches,buttonsorcase.
This product may be protected by one or more of
the following patents: 6,019,289; 6,280,278;
6,281,606; 6,291,263; 6,457,681; 6,491,263;
6,604,641; 6,619,594; 6,624,537; 6,655,640.
©2009, M.T.H. Electric Trains®, Columbia, MD
21046
Recommended for Ages 14 and up. Not
recommended for children under 14 years of
age without adult supervision. As with all
electric products, precautions should be
observed during handling and use to prevent
electric shock.
NOTE: Should
be powered by
10-14 Volts.
Voltage higher
than 14 may
damage the unit.
