Multi MCM-8000 User manual

56
MINI DIGITAL CLAMP TESTER
AC CURRENT AC/ DC VOLTAGE RESISTANCE
Model MCM-8000
MULTI CIRCUIT LEAKAGE CURRENT MONITOR
AC ADAPTER RS-232C CABLE INSTRUCTION MANUAL
SOFTWARE CARRYING CASE
INSTRUCTION MANUAL
INSTRUMENTBODY PICTURE OF SOFTWARE
Measuring・display of leakage current values of multi circuit(max. 8 lines)successively
for a long term as well as memorizing the average leakage current values between the
intervals and the generated & terminated year, date, time and max. current values with
outputting signals, in case of exceeding the limit of value set in advance.
MEASURE・MEMORIZE・DISPLAY THE LEAKAGE CURRENT OF MAX. 8 CIRCUITS AT THE SAME TIME
EASY FOR DATA MANAGEMENT(STORAGE BY CSV FORMULA)
COST PERFORMANCE・HI-SPEED SAMPLIMG W/HI FREQUENCY CUT FUNCTION
STANDARD ACCESSORIES
DGSeals.com
6505 W Park Blvd · Suite 306 PMB 356 · Plano, TX 75093
TEL [phone] · FAX [phone] · [email protected]
MULTI MEASURING INSTRUMENTS CO., LTD.

57
Model MCM-8000
MULTI CIRCUIT LEAKAGE CURRENT MONITOR
SPECIFICATIONS
Number of Measuring Circuit ：8 circuits(channels)
Detection Method ：
Clamp-on CT method
Measuring Range ： 0 〜 2000mA
Minimum Resolution ：1mA
Measuring Accuracy ：±
3%rdg ± 2dgt(by standard CTs)
Sampling ： Approx. 20mS
Filter Function ：Internally equipped filter for cutting high frequency(Secondary low pass filter ：130Hz)
Range of Setting Values ：
10 〜 1000mA(Initial setting ： 50mA)
Recovery Range ：10 〜90% of the setting values
Measuring Temperature ：0〜50 ℃, less than 80%RH w/o condensing
Storage Temperature ：-10〜60 ℃, less than 80%RH w/o condensing
Measuring Circuit Voltage ：less than AC 500V(insulated conductor)
Insulation Resistance ：more than 100M Ωby DC 500V insulation tester(between input terminal and housing case)
more than 50M Ωby DC 500V insulation tester(between power supply source and housing case)
Withstanding Voltage ：AC 1500V(50/60Hz)one minute between power supply sorce and housing case
Power Supply ：AC 100V 〜240V with adapter
Internal Ni-hydride Battery
Current Consumption ：Approx. 40mA
Battery Life ：Approx. 4 days at continuous use by full charge
Dimensions & Weight ：190(W)×140(H)×42(D)mm, approx. 700gs
GENERAL
1.MEASURING FUNCTION
By Connecting Optional CT Sensors, the instrument can measure and memorize leakage cuurent of 8 circuits at the same time and
the memorized data can be seen even during measurement.
2.LOGGING MEASURING FUNCTION
This instrument displays and memorizes the average leakage current between the selected intervals.
Interval ：1/5/10/15/30/60 minutes
Contents of Memory ：Measuring Time/Measuring Circuit/The average current value
Capacity of Memory ：Approx. 28 days with 10 m. interval
3.PEAK VALUE MEASURING FUNCTION
In case of exceeding the setting value, the instrument displays and memorizes year, month, date, time of the leakage generation &
termination as well as the peak values by each circuit. High speed sampling, comply with ELB.
Range of Setting Current：10 〜1000mA
Contents of Memory ：Circuit No. of generation, setting current value and times of generation.
Year/Month/Date/Time of exceeding the setting value and recovery.
4.ELECTRICITY FAILURE COUNTING FUNCTION
In case of electricity failure, the instrument memorizes Year/Month/Date/Time of failure and recovery.
Capacity of Memory ：Failure and recovery Year/Month/Date/Time 4,000 times
5.ALARM SIGNAL OUTPUT FUNCTION
In case of exceeding the setting current value, output the signal of non-voltage contact.
6.TRANSMISSION SOFTWARE
The memorized data can be transmitted to PC by RS-232C.
Complying Software ：Windows 95/98/2000/ME/XP
Output Data ：Logging Measured Data/Peak Values/Electricity Failure Data
DGSeals.com
6505 W Park Blvd · Suite 306 PMB 356 · Plano, TX 75093
TEL [phone] · FAX [phone] · [email protected]
MULTI MEASURING INSTRUMENTS CO., LTD.

58
Model MCM-8000
MULTI CIRCUIT LEAKAGE CURRENT MONITOR
CLAMP CT SENSORS FOR LEAKAGE CURRENT MONITOR(OPTION)
ZCT-18SCM ZCT-30SCM ZCT-40SCM
ZCT-80SCM ZCT-1100SCM
Inside Diameter ：18mm
45 ×98 ×32mm, 65gs
Inside Diameter ：30mm
59 ×117 ×32mm, 95gs
Inside Diameter ：40mm
64 ×122 ×23mm, 125gs
Inside Diameter ：80 ×74mm
138 ×225 ×37mm, 500gs
Inside Diameter ：128 ×108mm
194 ×342 ×52mm, 1800gs
Carryng Case for CTs
ZCT-18/30/40SCM=8 pcs.,
ZCT-80SCM=4 pcs. per case
