MULTILIFT Ultima S Flex Operating instructions

MULTILIFT Ultima Flex & Pro
3/2019
Hooklift Ultima S / SL Flex & Pro
USER AND MAINTENANCE MANUAL
114060421/US

2
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
>>>
Contents
MULTILIFT Ultima S / SL Flex & Pro HOOKLIFT .......................................................... 5
GENERAL DESCRIPTION .............................................................................................. 6
Main components ............................................................................................................. 7
CONTROLS ..................................................................................................................... 8
Control unit, Ultima 2GCC (Flex & Pro)............................................................................ 8
Safety instructions and safety rules........................................................................... 12
Safety during use - general ............................................................................................ 13
Ultima Mini-Radio and radio controller ........................................................................... 15
Requirements for the working area ground condition..................................................... 16
Working area .................................................................................................................. 17
Safety instructions and maintenance.............................................................................. 19
Container........................................................................................................................ 19
Loading and unloading of a container ............................................................................ 22
Tipping............................................................................................................................ 26
Before driving away........................................................................................................ 27
Safety facilities of the Ultima hooklift equipment ............................................................ 28
USE ................................................................................................................................ 29
Loading a container........................................................................................................ 29
Loading a short container............................................................................................... 41
Tipping a container ......................................................................................................... 42
Lowering the tipping device............................................................................................ 46
Unloading a container..................................................................................................... 50
Loading of rear heavy container..................................................................................... 61
Unloading of a rear heavy container............................................................................... 61
Loading of a front heavy container ................................................................................. 62
Loading a container onto a trailer or platform................................................................. 63
DESIGN DESCRIPTION ................................................................................................ 67
Technical specications Ultima 14S and Ultima 16S...................................................... 67
Technical specications Ultima 18S and Ultima 21S...................................................... 69
Technical specications Ultima 26S and Ultima 30S...................................................... 71

3
Ultima S / SL Flex & Pro 3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
>>>
>>>
Technical specications Ultima 18SL, 21SL, 22SL and 24SL ........................................ 73
Main components ........................................................................................................... 76
Construction ................................................................................................................... 77
Hydraulics....................................................................................................................... 78
Control devices, Ultima Flex & Pro 2GCC...................................................................... 81
Control devices, Ultima Flex & Pro 2GMR + 2GCC ....................................................... 82
Control devices, Ultima Flex & Pro 2GRC...................................................................... 83
Control devices, Ultima Flex & Pro 2GRC + 2GCC........................................................ 84
EQUIPMENT .................................................................................................................. 85
Hook models................................................................................................................... 85
Safety latch automatic opening ...................................................................................... 88
Locking mechanisms of the hook ................................................................................... 89
ADDITIONAL EQUIPMENTS......................................................................................... 93
Fast speed...................................................................................................................... 93
Fast speed in tipping ...................................................................................................... 94
Fast lowering option of the tipping device ...................................................................... 95
Hook height stop............................................................................................................. 97
Safespeed, End-of-movement damping......................................................................... 97
Safespeed+ / LoadBoost™ ............................................................................................ 98
SafePositioning............................................................................................................... 99
Automatic Sequence Control........................................................................................ 100
Enhanced automatic sequences .................................................................................. 101
Friction relief................................................................................................................. 102
Protection of main cylinder ........................................................................................... 103
Hydraulic front locks (Ultima S) .................................................................................... 104
Crane body locks (Ultima SL)...................................................................................... 106
Mechanical locks (Ultima SL) ....................................................................................... 107
Bogie blocking .............................................................................................................. 108
Stabilizer....................................................................................................................... 109
Hydraulic or electric under-run bar ................................................................................111

4
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
>>>
Trailer tipping device .................................................................................................... 113
Additional hydraulics..................................................................................................... 114
Hydraulically adjustable hook height ............................................................................ 115
Emergency operation ................................................................................................... 116
Mini-Radio (2GMR)....................................................................................................... 117
Radio controller (2GRC)............................................................................................... 121
Load indicator............................................................................................................... 127
Indicative weighing system........................................................................................... 128
FutureTouch™ Basic Display ....................................................................................... 129
FutureTouch™ Advanced Display ................................................................................ 135
MAINTENANCE........................................................................................................... 143
Service Indicator........................................................................................................... 143
Service table................................................................................................................. 147
Hydraulics service ........................................................................................................ 149
Safety functions............................................................................................................ 155
General inspection........................................................................................................ 157
Welding......................................................................................................................... 159
Electric system ............................................................................................................. 160
Repairing Damaged Paint Surface............................................................................... 160
How to change the backlight setting of the buttons, 2GCC.......................................... 161
FAULT FINDING .......................................................................................................... 163
MULTILIFT PLC - Diagnostic Codes ............................................................................ 163
Ultima S / SL Flex & Pro SENSORS ............................................................................ 182
LUBRICATION ............................................................................................................. 183
Periodical Service......................................................................................................... 186
Service Card................................................................................................................. 187
WARRANTY CONDITIONS ......................................................................................... 188
To the buyer.................................................................................................................. 188
Owner’s Warranty......................................................................................................... 189
DELIVERY CARD ........................................................................................................ 195

5
Ultima S / SL Flex & Pro 3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
Ultima ____ S Ultima ____ SL
Flex Pro
This manual is a translation from the original operating instructions
compiled in Finnish.
MULTILIFT Ultima S / SL Flex & Pro
HOOKLIFT
User Manual
This manual concerns the MULTILIFT Ultima S / SL Flex & Pro hooklift equipment.
Information about the equipment.
Type of system:
Serial number:
Date of commissioning:
Owner
Your Multilift dealer
Service workshop:

6
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
MULTILIFT Ultima 21S hooklift equipment
NOTE!
Cargotec Finland Oy reserves the right to change specications, equipment, operating and
maintenance instructions without prior notice.
GENERAL DESCRIPTION
MULTILIFT Ultima hooklift equipment is an exchange container loading and unloading
device mounted on a truck chassis. An experience of over 60 years is a proof of the reliability
and versatility of the equipment all over the world.
CE Statement of Conformity
Cargotec Finland Oy Multilift has been an ISO 9001 certied company since 1995 and
since 2002 the company has complied with the ISO 14001 environmental standard.
Multilift guarantees that the equipment contained within this manual conforms with the
EC Machine Directive.
Cargotec Finland Oy
Multilift
Raisio
Finland
2019

7
Ultima S / SL Flex & Pro 3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
4
1
2
3
5
6
7
8
9
Main components
1. Gripping hook and hook arm
2. Middle frame
3. Body locking, mechanical and hydraulic
4. Rear frame
5. Rear rollers
6. Sub-frame
7. Main cylinders
8. Sliding cylinder
9. Body locking cylinder
Due to continuous product development some picture details may look dierent when
compared to the actual device.

8
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
3
c
d
a
b
1
2
(e)
(f)
4 8 6 10 7 5
18
20
22
24
26
19
21
23
25
27
12 13
14 15 16 17
4
8
6
10
5
9
7
11
11 9
!
CONTROLS
Control unit, Ultima 2GCC (Flex & Pro)
NOTE!
Do not press any control unit button and do not move the control
lever while starting up the control unit.

9
Ultima S / SL Flex & Pro 3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
Ref. Component or function
1 CAN bus cable
2 Control panel cable
3 Control lever
a = main cylinders forward
b = main cylinders backward
c = telescopic hook arm (sliding) forward
d = telescopic hook arm (sliding) backward
(e) = automatic sequence control forward / friction relief
(f) = automatic sequence control backward / friction relief
4 & 5 Button FAST SPEED *)
6 & 7 Button HOOK SAFETY LOCK
8 & 9 Button TELESCOPIC HOOK ARM FORWARD (optional to 3c)
10 & 11 Button TELESCOPIC HOOK ARM BACKWARD (optional to 3d)
12 Four digit display
13 Point: voltage OK and system OK
14 Warning light FRAME NOT DOWN
15 Warning light HYDRAULIC BODY LOCKS NOT CLOSED
16 Warning light UNDER-RUN BAR RETRACTED / BOGIE BLOCK ENGAGED
17 Warning light AUXILIARY EQUIPMENT
18 Button HYDRAULIC BODY LOCKS CLOSED
19 Button HYDRAULIC BODY LOCKS OPEN
20 - 27 Alternative function buttons according to the equipment on the Ultima
device (cf. following pages)
Control unit components and basic functions
*) Relief of horizontal movement and oating of the main cylinders can
temporarily be by-passed by a quick action switch (push button).

10
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
31
33
35
37
39
41
43
45
47
32
34
36
38
40
42
44
46
48
>>>
Ref. Function
31 Hydraulic body locking closed
32 Hydraulic body locking open
33 Bogie blocking engaged
34 Bogie blocking released
35 Under run bar retracted
36 Under run bar extended
37 PTO engagement / release
38 Day position / night silence
(turns o outside buzzer)
39 Additional hydraulics (cylinder out)
40 Additional hydraulics (cylinder in)
41 Additional hydraulics 2 (cylinder out)
42 Additional hydraulics 2 (cylinder in)
43 Additional hydraulics 3 (cylinder out)
44 Additional hydraulics 3 (cylinder in)
45 Additional hydraulics 4 (cylinder out)
46 Additional hydraulics 4 (cylinder in)
47 Trailer tipping or trailer hydraulics
(cylinder out)
48 Trailer tipping or trailer hydraulics
(cylinder in)
Alternative function buttons (items 20 - 27 on the previous page)

11
Ultima S / SL Flex & Pro 3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
49
51
53
55
57
59
61
63
65
50
52
54
56
58
60
62
64
66
Ref. Function
49 Tail gate opener (gate closed)
50 Tail gate opener (gate open)
51 Tail gate opener 2 (gate closed)
52 Tail gate opener 2 (gate open)
53 Load cover system, UK (arms out)
54 Load cover system, UK (arms in)
55 Hydraulic adjustable hook (up)
56 Hydraulic adjustable hook (down)
57 Recovery hydraulics (on)
58 Recovery hydraulics (o)
59 Hoist (on)
60 Hoist (o)
61 Crane hydraulics (on)
62 Crane hydraulics (o)
63 Additional electric function (on)
64 Additional electric function (o)
65 RPM adjustment
66 Working lights

12
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
Control unit, 2GMR (Mini-Radio)
see chapter “ADDITIONAL EQUIPMENTS - Mini-Radio”
Radio control unit, 2GRC
see chapter “ADDITIONAL EQUIPMENTS - Radio control”
Use the radio control unit’s buttons which symbols are represented in operating phase
images.
Safety instructions and safety rules
MULTILIFT Ultima hooklift equipment was developed for the loading, unloading, tipping
and transporting of removable containers/bodies on vehicles. All other use of the Multilift
hooklift equipment is strictly forbidden. Multilift accepts no liability whatsoever with regard
to such other use.
The hooklift equipment meets all safety and stability standards that apply at the moment of
its delivery from the factory. Use the hooklift equipment only if it is in good condition, and
only for the purpose for which it was designed and in accordance with the instructions and
guidelines specied in this manual.
Cargotec Finland Oy Multilift accepts no liability whatsoever for any loss or damage caused
by the failure to strictly adhere to the safety instructions specied in this manual or due
to carelessness during the operation, adjustment, maintenance or repair of the hooklift
equipment. Depending on the specic working conditions, additional safety instructions may
be required. Contact your Multilift dealer immediately if you have encountered an unsafe
situation with Ultima hooklift equipment that is not described in this manual.

13
Ultima S / SL Flex & Pro 3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
>>>
Safety during use - general
The driver must be familiar with the contents of this manual and should strictly follow the
directions and instructions. He must see to it that his Ultima hooklift equipment is technically
in perfect condition. Control of the suspension, condition of the tyres, tyre pressures,
condition of the container and loading of it, are all his responsibility. The driver must handle
the Ultima equipment with care. For example during loading and unloading the front wheels
of the truck must not be lifted up from the ground.
Ultima hooklift equipment may only be used when sitting on the driver´s seat.
If it is necessary to leave the cabin during loading, unloading or tipping,
always engage the parking brake and disengage the power take-o.
In the vicinity of the control units there must be no obstacles or loose objects that might
accidentally activate unit´s functions.
If the equipment has not been used for two weeks or longer, all safety functions must be
checked before the equipment is used again.
Avoid the unnecessary use of the main pressure relief valve. Heating up of the oil reduces
the quality of it and results in shorter life span of retaining rings and gaskets.
In subzero temperatures <32°F (< 0°C) it is recommended to let the pump idle for around
1 minute in order for the hydraulic oil to be warmed up
During the use of the equipment the engine noise will increase due to additional loading.
Noise level will also increase if the container is pulled along the ground during loading or
unloading of it.
When the equipment is used carefully and in a sensibly planned manner, the noise level
can be kept lower.
The hook equipment control system includes several functions assisting the
operator, but it is the operator who is always responsible for the proper and
safe use of the equipment.

14
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
Take care that the truck or the hooklift is not overloaded. Observe the factory data for
the truck with regard to maximum permissible axle load/GVW. See also the axle load
calculations!
Strong winds will have an eect on the operation during loading, unloading or tipping of
the container.
If several successive containers switches are performed, the hydraulic oil may
overheat >140ºF (60ºC) making it necessary to install an oil cooler to the system.

15
Ultima S / SL Flex & Pro 3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
!
!
!
!
!
!
!
!
>>>
Ultima Mini-Radio and radio controller
Safety regulations
WARNING!
The driver must apply the parking brake before leaving the
cabin to manoeuvre the hooklift by radio control. Otherwise
the vehicle may start mowing during loading/unloading.
WARNING!
When loading/unloading is done on sloping ground, the driver
must sit in the cabin and operate the brakes of the vehicle.
WARNING!
The driver must use great caution when loading/unloading
from outside the cabin because he/she may e.g. be standing
in the danger zone described above.

16
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
!
!
10 m
10 m
>>>
!
!
33 ft (10 m) 33 ft (10 m)
Requirements for the working area ground condition
Before you start loading, unloading or tipping using the Ultima hooklift equipment, you
must inspect the following:
- the ground must be rm and free from potholes into which the truck could move
during operation
· - the ground must not be slippery
- the ground must be level

17
Ultima S / SL Flex & Pro 3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
! !
! !
6 m
Working area
Load or unload only where there is sucient space; this also applies to free height. There
must be at least 33 ft (10 m) free space at both sides of the vehicle.
Check the vicinity for possible dangers.
When loading, the container must be placed in line with the driving direction of the truck.
If working in the dark, use working lights shining backwards in addition to the standard
truck lights.
20 ft
(6 m)

18
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
!
!
!
!
It is the responsibility of the driver to ensure that there are or there will be no other persons
within the danger zone of the working area. It is strictly forbidden for anybody to be close
to the truck or the container.
Tip Mark out the working area, for example, with cones.
Tip Ensure that the warning buzzers are operational (remember the night time
limitations)
In case of emergency:
Disengage the clutch and the PTO.

19
Ultima S / SL Flex & Pro 3/2019
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
114060421
WID
Safety instructions and maintenance
Always follow the maintenance instructions and use only original Multilift spare parts.
See chapter Maintenance.
Container
The demountable body can be a container, tank, gravel body, body for transporting
machinery etc. according to standards (e. g. DIN 30722, SFS 4417, SS 3021 or CHEM).
Check to be sure that the container is suitable for the load to be transported. Generally each
container has a model plate (ID) on which the length and permissible load are specied.
Before picking up the container, check that the hook height (H), tunnel height (T) and the
width (W) correspond with the Ultima hooklift dimensions and that the notches for the body
locks are in correct positions.
If there is even the slightest doubt of the container dimensions, measure them rst in order
to prevent the equipment and the container from being damaged.
Gripping height (H), tunnel height (T) and width (W) of the container can vary from one
container to another. Note that they are country specic dimensions. If there is doubt about
the origin of the container, the tunnel height and width must be checked in order to ensure
that they are compatible with those of the Multilift equipment.
Country specic standard dimension table of the container is on the next page.

20
Ultima S / SL Flex & Pro 3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
H
L
T
min. SFS 300 mm / DIN 240 mm
min. SFS 205 mm / SS 200 mm / DIN 280 mm
Gripping height (H), tunnel height (T) and width (W) of the container can vary from one
container to another. Note that they are country specic dimensions. If there is doubt about
the origin of the container, the tunnel height and width must be checked in order to ensure
that they are compatible with those of the Ultima equipment.
Country specic standard dimension table of the container is on the next page.
If your country is not mentioned on the list, check the matter in your hooklift equipment
technical specications.
The condition of the container must be checked regularly. Especially if you are going to
use a type of container with which you are not familiar. In particular, check the condition
of the locking points and the condition and position of the lifting hook.
The maximum allowed wear of the lifting hook is 10 % from its nominal diameter. Nominal
diameter must be checked with the hooklift equipment supplier.
The longitudinal rails at the bottom of the container are under heady burden. Carry out
daily checks of these components for wear or damage.
If the container is frozen to the ground, do not pull it loose by using the Ultima hooklift
equipment.Use, for example, a forklift truck.
H
L
T
min. SFS 300 mm / DIN 240 mm
min. SFS 205 mm / SS 200 mm / DIN 280 mm
min. SFS 11.8 in (300 mm) / DIN 9.4 in (240 mm)
min. SFS 8 in (205 mm) / SS 7.9 in (200 mm) / DIN 11 in (280 mm)
This manual suits for next models
3
Table of contents
Other MULTILIFT Construction Equipment manuals
