MULTIQUIP WHITEMAN EPOXY/M Series Guide

OPERATION AND PARTS MANUAL
P/N 10487
THIS MANUAL MUST ACCOMPANYTHE EQUIPMENT AT ALLTIMES.
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
EPOXY/M SERIES
WALK-BEHIND TROWEL
Revision #5 (10/06/10)

PAGE 2 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
Engine exhaust and some of
itsconstituents,andsomedustcreated
of California to cause cancer, birth
defects and other reproductive harm.
by power sanding, sawing, grinding,
drillingandotherconstructionactivities
contains chemicals known to the State
Someexamplesofthesechemicalsare:
Leadfromlead-basedpaints.
Crystallinesilicafrombricks.
Cementandothermasonryproducts.
Arsenicandchromiumfromchemically
treatedlumber.
Your risk from these exposures varies,
dependingonhowoftenyoudothistype
of work.To reduce your exposure to
these chemicals: work in aALWAYS
well ventilated area, and work with
approved safety equipment, such as
dust masks that are specially designed
to filter out microscopic particles.
PROPOSITION 65WARNING

EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 3
SILICOSIS/RESPIRATORYWARNINGS
Grinding/cutting/drillingofmasonry,concrete,metaland
other materials with silica in their composition may give
off dust or mists containing crystalline silica. Silica is a
basic component of sand, quartz, brick clay, granite and
numerous other minerals and rocks. Repeated and/or
substantial inhalation of airborne crystalline silica can
cause serious or fatal respiratory diseases, including
silicosis. In addition, California and some other
authorities have listed respirable crystalline silica as a
substance known to cause cancer. When cutting such
materials, always follow the respiratory precautions
mentionedabove.
WARNING
Grinding/cutting/drillingofmasonry,concrete,metaland
other materials can generate dust, mists and fumes
containing chemicals known to cause serious or fatal
injury or illness, such as respiratory disease, cancer,
birth defects or other reproductive harm. If you are
unfamiliar with the risks associated with the particular
process and/or material being cut or the composition of
the tool being used, review the material safety data
sheet and/or consult your employer, the material
manufacturer/supplier, governmental agencies such as
OSHA and NIOSH and other sources on hazardous
materials. California and some other authorities, for
instance, have published lists of substances known to
cause cancer, reproductive toxicity, or other harmful
effects.
Control dust, mist and fumes at the source where
possible. In this regard use good work practices and
follow the recommendations of the manufacturers or
suppliers, OSHA/NIOSH, and occupational and trade
associations. Water should be used for dust
suppression when wet cutting is feasible. When the
hazardsfrom inhalationofdust, mistsandfumes cannot
be eliminated, the operator and any bystanders should
always wear a respirator approved by NIOSH/MSHAfor
thematerialsbeingused.
WARNING
SILICOSISWARNING RESPIRATORY HAZARDS

PAGE 4 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
EPOXY/M SERIESTROWEL—TABLE OF CONTENTS
Proposition 65 Warning ............................................. 2
Silicosis/RespiratoryWarnings.................................. 3
Table Of Contents ..................................................... 4
Parts Ordering Procedures ....................................... 5
Training Checklist ...................................................... 6
Daily Pre-Operation Checklist................................... 7
Safety Information ................................................8-12
Operation And Safety Decals.................................. 14
Specifications (Trowel) ............................................ 15
Specifications (Engine & Electric Motor)................. 16
General Information ................................................ 17
MQ WHITEMAN — EPOXY/M SERIES
TROWEL
Controls and Components .................................18-19
Basic Engine ........................................................... 20
Assembly and Installation ..................................21-23
Pre-Inspection....................................................24-25
Initial Start-Up (Gasoline Engine) ......................26-27
Initial Start-Up (Electric Motor) ............................... 28
Operation ...........................................................29-30
Options...............................................................31-32
Maintenance ......................................................33-37
Troubleshooting .................................................38-41
Explanation of Codes in Remarks Column ............. 42
Suggested Spare Parts........................................... 43
Nameplate and Decals.......................................44-45
Standard Handle Assembly ...............................46-47
Quick Pitch™ Handle Assembly........................48-49
Thrust Bearing Kit Assembly..............................50-51
4-BladeSpider Assembly....................................52-53
Gearbox and Engine Mounts Assembly.............54-55
5.0 HP Honda Engine ........................................56-57
Hand Clutch Assembly S/N 42036 Above..........58-59
Hand Clutch Assembly S/N 42037 Below ..........60-61
Electric Motor Assembly.....................................62-63
Guard Ring Assembly ........................................64-65
Blades and Adjustment Fixture Assembly .........66-67
Lifting Bale Assembly.........................................68-69
HONDA GX160K1QA2 ENGINE
Cylinder Head Assembly...................................70-71
Cylinder Barrel Assembly...................................72-73
Crankcase Cover Assembly...............................74-75
Crankshaft Assembly .........................................76-77
Piston Rings Assembly.......................................78-79
Camshaft Assembly ...........................................80-81
Recoil Starter Assembly.....................................82-83
Fan Cover Assembly..........................................84-85
Carburetor Assembly .........................................86-87
Air Cleaner (Oil Bath ) Assembly .......................88-89
Muffler Assembly ...............................................90-91
Fuel Tank Assembly ..........................................92-93
Flywheel Assembly ............................................94-95
Ignition Coil Assembly........................................96-97
Control Assembly ...............................................98-99
Labels Assembly ............................................100-101
Gasket Kit Assembly ............................................. 103
Terms and Conditions of Sale — Parts................. 104
Specification and part number
are subject to change without
notice.
NOTE

EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 5
www.multiquip.com
Ordering parts has never been easier!
Choose from three easy options:
WE ACCEPT ALL MAJOR CREDIT CARDS!
When ordering parts, please supply:
RDealer Account Number
RDealer Name and Address
RShipping Address (if different than billing address)
RReturn Fax Number
RApplicable Model Number
RQuantity, Part Number and Description of Each Part
RSpecify Preferred Method of Shipment:
UPS/Fed ExDHL
NPriority OneTr u c k 
NGround
NNext Day
NSecond/Third Day
If you have an MQ Account, to obtain a Username
and Password, E-mail us at: parts@multiquip.
com.
To obtain an MQ Account, contact you
r
District Sales Manager for more information.
Order via Internet (Dealers Only):
Order parts on-line using Multiquip’s SmartEquip website!
NView Parts Diagrams
NOrder Parts
NPrint Specification Information
Note: Discounts Are Subject To Change
Goto www.multiquip.com and click on
Order Parts to log in and save!
Use the internet and qualify for a 5% Discount
on Standard orders for all orders which include
complete part numbers.*
Order via Fax (Dealers Only):
All customers are welcome to order parts via Fax.
Domestic (US) Customers dial:
1-800-6-PARTS-7 (800-672-7877)
Fax your order in and qualify for a 2% Discount
on Standard orders for all orders which include
complete part numbers.*
Order via Phone: Domestic (US) Dealers Call:
1-800-427-1244
Best Deal!
International Customers should contact
their local Multiquip Representatives for
Parts Ordering information.
Non-Dealer Customers:
Contact your local Multiquip Dealer for
parts or call 800-427-1244 for help in
locating a dealer near you.
Note: Discounts Are Subject To Change
Effective:
January 1st, 2006
NOTICE
All orders are treated as Standard Orders and will
ship the same day if received prior to 3PM PST.
PARTS ORDERING PROCEDURES

PAGE 6 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
TRAINING CHECKLIST
This checklist will lists some of the minimum requirements for
machinemaintenance andoperation. Pleasefeel freetodetach
itand makecopies.Usethischecklistwheneveranewoperator
istobetrainedoritcanbeusedasareviewformoreexperienced
operator’s.
Operator _________________________________________ Trainee __________________________________________
COMMENTS:
EPOXY/M SERIESTROWEL—TRAINING CHECKLIST
tsilkcehCgniniarT
.oN noitpircseD ?KO etaD
1 .yletelpmoclaunaMs’rotarepOdaeR
2dnaenignefognikcehc,stnenopmocfonoitacol,tuoyalenihcaM .slevelliociluardyh
3 .erudecorpgnileufer,metsysleuF
4 .sthgildnayarpsfonoitarepO
5 .)gninnurtonenihcam(slortnocfonoitarepO
6 .noitarepohctiwspotsytefas,slortnocytefaS
7 .serudecorppotsycnegremE
8 .ekohcenigne,taeh-erp,enihcamfoputratS
9 .revohagniniatniaM
01 .gnirevuenaM
11 .gnihctiP
21 ™hctiP-niwT.hctipedalbgnihctaM
31 .seuqinhcetgnihsinifetercnoC
41 .enihcamfonwodtuhS
51 .)spooltfil(enihcamfognitfiL
61 .egarotsdnatropsnartenihcaM

EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 7
DAILY PRE-OPERATION CHECKLIST
COMMENTS:
EPOXY/M SERIESTROWEL— DAILY PRE-OPERATION CHECKLIST
tsilkcehCnoitarepO-erPyliaD

1 .levellioenignE
2 .levelliociluardyH
3 .leveltnaloocrotaidaR
4 .sedalbfonoitidnoC
5 .noitarepohctipedalB
6 .noitarepohctiwSpotSytefaS
7 .noitarepolortnocgnireetS

PAGE 8 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
EPOXY/M SERIESTROWEL— SAFETY INFORMATION
Do not operate or service the equipment before reading
the entire manual. Safety precautions should be followed
at all times when operating this equipment.
Failure to read and understand the safety
messages and operating instructions could
result in injury to yourself and others.
SAFETY MESSAGES
The four safety messages shown below will inform you
about potential hazards that could injure you or others.The
safety messages specifically address the level of exposure
to the operator and are preceded by one of four words:
DANGER, WARNING, CAUTION or NOTICE.
SAFETY SYMBOLS
DANGER
Indicates a hazardous situation which, if not avoided,
WILL result in DEATH or SERIOUS INJURY.
WARNING
Indicates a hazardous situation which, if not avoided,
COULD result in DEATH or SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided,
COULD result in MINOR or MODERATE INJURY.
NOTICE
Addresses practices not related to personal injury.
Potential hazards associated with the operation of this
equipment will be referenced with hazard symbols which
may appear throughout this manual in conjunction with
safety messages.
Lethal exhaust gas hazards
Explosive fuel hazards
Burn hazards
Rotating parts hazards
Symbol Safety Hazard
Pressurized fluid hazards

EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 9
EPOXY/M SERIESTROWEL— SAFETY INFORMATION
GENERAL SAFETY
CAUTION
NEVER operate this equipment without proper protective
clothing, shatterproof glasses, respiratory protection,
hearing protection, steel-toed boots and other protective
devices required by the job or city and state regulations.
Avoid wearing jewelry or loose fitting clothes that may
snag on the controls or moving parts as this can cause
serious injury.
NEVER operate this equipment when not
feeling well due to fatigue, illness or when
under medication.
NEVER operate this equipment under the
influence of drugs or alcohol.
ALWAYS clear the work area of any debris, tools, etc.
that would constitute a hazard while the equipment is
in operation.
No one other than the operator is to be in the working
area when the equipment is in operation.
DO NOT use the equipment for any purpose other than
its intended purposes or applications.
NOTICE
This equipment should only be operated by trained and
qualified personnel 18 years of age and older.
Whenever necessary, replace nameplate, operation and
safety decals when they become difficult read.
Manufacturer does not assume responsibility for any
accident due to equipment modifications. Unauthorized
equipment modification will void all warranties.
NEVER use accessories or attachments that are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to user may result.
ALWAYS know the location of the nearest
fire extinguisher.
ALWAYS know the location of the nearest
first aid kit.
ALWAYS know the location of the nearest phone or keep
a phone on the job site. Also, know the phone numbers
of the nearest ambulance, doctor and fire department.
This information will be invaluable in the case of an
emergency.

PAGE 10 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
EPOXY/M SERIESTROWEL— SAFETY INFORMATION
TROWEL SAFETY
DANGER
Engine fuel exhaust gases contain poisonous carbon
monoxide. This gas is colorless and odorless, and can
cause death if inhaled.
The engine of this equipment requires an adequate free
flow of cooling air. NEVER operate this equipment in any
enclosed or narrow area
where free flow of the air is
restricted. If the air flow is
restricted it will cause injury
to people and property and
serious damage to the
equipment or engine.
NEVER operate the equipment in an explosive
atmosphere or near combustible materials.An
explosion or fire could result causing severe
bodily harm or even death.
WARNING
ALWAYS keep clear of rotating or moving
parts while operating the trowel.
DO NOT start or operate the trowel if the
drive train will not disengage. Centrifugal
force between the trowel and surface when starting can
cause uncontrolled handle movement that can cause
serious injury. The handle must not move while pulling
the engine recoil starter.
NEVER disconnect any emergency or safety devices.
These devices are intended for operator safety.
Disconnection of these devices can cause severe injury,
bodily harm or even death. Disconnection of any of these
devices will void all warranties.
CAUTION
NEVER stand on trowel during operation.
NEVER lubricate components or attempt service on a
running machine.
NEVER place your feet or hands inside the guard rings
while starting or operating this equipment.
DANGEROUS
GAS FUMES
NOTICE
ALWAYS keep the machine in proper running condition.
Fix damage to machine and replace any broken parts
immediately.
ALWAYS store equipment properly when it is not being
used. Equipment should be stored in a clean, dry location
out of the reach of children and unauthorized personnel.
A safety manual for operating and maintenance
personnel of concrete power trowels produced by the
Association of Equipment Manufacturers (AEM) can be
obtained for a fee by ordering through their website at
www.aem.org.
Order FORM PT-160
ENGINE SAFETY
WARNING
DO NOT place hands or fingers inside engine
compartment when engine is running.
NEVER operate the engine with heat shields or
guards removed.
Keep fingers, hands hair and clothing away
from all moving parts to prevent injury.
DO NOT remove the radiator cap while the
engine is hot. High pressure boiling water will gush out
of the radiator and severely scald any persons in the
general area of the trowel.
DO NOT remove the coolant drain plug
while the engine is hot. Hot coolant will
gush out of the coolant tank and severely
scald any persons in the general area of
the trowel.
DO NOT remove the engine oil drain plug while the
engine is hot. Hot oil will gush out of the oil tank and
severely scald any persons in the general area of the
trowel.
CAUTION
NEVER touch the hot exhaust manifold,
muffler or cylinder. Allow these parts to cool
before servicing equipment.

EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 11
EPOXY/M SERIESTROWEL— SAFETY INFORMATION
NOTICE
NEVER run engine without an air filter or with a dirty air
filter. Severe engine damage may occur.Service air filter
frequently to prevent engine malfunction.
NEVER tamper with the factory settings
of the engine or engine governor. Damage
to the engine or equipment can result
if operating in speed ranges above the
maximum allowable.
FUEL SAFETY
DANGER
DO NOT add fuel to equipment if it is placed inside truck
bed with plastic liner. Possibility exists of explosion or
fire due to static electricity.
DO NOT start the engine near spilled fuel or combustible
fluids. Fuel is extremely flammable and its vapors can
cause an explosion if ignited.
ALWAYS refuel in a well-ventilated area, away from
sparks and open flames.
ALWAYS use extreme caution when working with
flammable liquids.
DO NOT fill the fuel tank while the engine is running
or hot.
DO NOT overfill tank, since spilled fuel could ignite if it
comes into contact with hot engine parts or sparks from
the ignition system.
FUEL
FUEL
Store fuel in appropriate containers, in well-ventilated
areas and away from sparks and flames.
NEVER use fuel as a cleaning agent.
DO NOT smoke around or near the
equipment. Fire or explosion could result
from fuel vapors or if fuel is spilled on a
hot engine.
TRANSPORTING SAFETY
CAUTION
NEVER allow any person or animal to
stand underneath the equipment while
lifting.
NOTICE
Some walk-behind trowels can be lifted or moved by two
people utilizing lifting tubes or other special attachments.
Generally, however, they must be lifted using lifting bales
and cranes, hoists, or forklifts.
NEVER transport trowel with float pans attached unless
safety catches are used and are specifically cleared for
such transport by the manufacturer.
NEVER hoist the trowel more than three feet off the
ground with float pans attached.
Before lifting, make sure that the lifting bales are not
damaged.
Always make sure crane or lifting device has been
properly secured to the lifting bales of the equipment.
ALWAYS shutdown engine before transporting.
NEVER lift the equipment while the engine is running.
Tighten fuel tank cap securely and close fuel cock to
prevent fuel from spilling.
Use adequate lifting cable (wire or rope) of sufficient
strength.
DO NOT lift machine to unnecessary heights.
ALWAYS tie down equipment during transport by
securing the equipment with rope.

PAGE 12 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
GENERATOR SAFETY
If using a generator to power trowel, refer to
applicable generator manual safety information
section.
ELECTRICAL SAFETY
DANGER
NEVER let power cords or cables lay in water.
NEVER use damaged or worn cables or cords when
connecting equipment to generator. Inspect for cuts in
the insulation.
NEVER grab or touch a live power
cord or cable with wet hands. The
possibility exists of electrical shock,
electrocution or death.
Make sure power cables are securely connected.
Incorrect connections may cause electrical shock and
damage to the trowel.
NOTICE
ALWAYS make certain that proper power or extension
cord has been selected for the job.
ENVIRONMENTAL SAFETY
NOTICE
Dispose of hazardous waste properly.
Examples of potentially hazardous waste
are used motor oil, fuel and fuel filters.
DO NOT use food or plastic containers to dispose of
hazardous waste.
DO NOT pour waste, oil or fuel directly onto the ground,
down a drain or into any water source.
EPOXY/M SERIESTROWEL— SAFETY INFORMATION

EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 13
NOTES

PAGE 14 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
EPOXY/M SERIESTROWEL— OPERATION AND SAFETY DECALS
Machine Safety Decals
The J-Series walk-behind trowel is equipped with a number of safety decals.These decals are provided for operator safety and
maintenance information. Figure 1 below illustrates these decals as they appear on the machine. Should any of these decals
becomeunreadable,replacements can be obtained fromyour dealer.
Figure 1. EPOXY/M Trowel Decals

EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 15
EPOXY/M SERIESTROWEL— SPECIFICATIONS (TROWEL)
NOTE:
1. Sound pressure is a weighted measure. Measured at the
operators ear position while the walk-behind trowel is
operatingatfullthrottleonconcreteinamannermostoften
experiencedin“
normal ”circumstances.Sound pressure
may vary depending upon the condition of the concrete.
Hearingprotectionis alwaysrecommended.
Figure 2. EPOXY/M SERIES Trowel
Dimensions
2. The vibration level indicated is the maximum RMS (Root
Mean Square) value obtained at the handle grip while
operating the walk-behind trowel on curing concrete in a
manner mostoftenexperiencedin“
normal ”circumstances.
Values were obtained from all three axes of motion.The
values shown represent the maximum RMS value from
thesemeasurements.
SideView
snoitacificepSleworTseireSyxopE.1elbaT )kooHgnitfiL(thgieH–A )mm6.139(ni7.63
)reveLtnemegagnE(thgieH–B )mm2.440,1(ni4.14
htdiW–C )mm1.729(.ni5.63
htgneL–D )mm4.987,1(.ni5.07
gnitarepO–thgieW ).gk033(.bl051
erusserPdnuoS bd49
noitarbiV s/m6.91(g0.2
2
)
)xam(deepSedalB 0004@mpr921
deepSpiTedalB )s/m0.6(mpf281,1

PAGE 16 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
EPOXY/MSERIESTROWEL—SPECIFICATIONS(ENGINE&ELECTRICMOTOR)
Table 2. Specifications (Engine & Electric Motor)
Engine/Electric Motor
Model HONDA GX-160QA2 Electric Motor
Ty p e
Air-cooled 4 stroke, Single
Cylinder, OHV, Horizontal
Shaft Gasoline Engine
N/A
Bore X Stroke 2.7 in. x 1.8 in.
(68 mm x 45 mm) N/A
Displacement 163 cc (9.9 cu-in) N/A
Max Output 5.0 H.P./3600 R.P.M. 1.0 HP
Fuel Tank Capacity Approx. 0.95 U.S. gallons
(3.6 liters) N/A
Fuel Unleaded Automobile
Gasoline N/A
Lube Oil Capacity .60 liters (0.63 qts) N/A
Speed Control Method Centrifugal Fly-weight
Ty p e N/A
Starting Method Recoil Start N/A
Input Voltage 12.0 x 14.4 x 13.2 in.
(304 x 362 x 335 mm)
115/230 VAC Single
Phase
Dimension (L x W x H) 33.1 lbs (15 Kg.) TBD
Dry Net Weight TBD

EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 17
EPOXY/M SERIESTROWEL— GENERAL INFORMATION
EPOXY/M SERIESWalk-BehindTrowel Familiarization
This walk-behind trowel is designed for the
floating and
finishing ofconcrete slabs.
Take a walk around the trowel. Take notice of all the major
components (see Figure 3, pages 16 and 17) like the engine,
blades, quick pitch control, air cleaner, centrifugal stop switch
etc.Checkthat thereisalways oil intheengine.
Read allthe safety instructions carefully.Safetyinstructionswill
be found throughout this manual and on the trowel. Keep all
safetyinformationingood,readablecondition.Operatorsshould
bewelltrained onthe operationandmaintenance ofthetrowel.
Beforeusingyour trowel,testitonaflatwatereddownsectionof
finishedconcretethat isfreeof any debrisand other objects.
Thistrialtestrunwillincreaseyourconfidenceinusingthetrowel
and at the same time it will familiarize you with the trowel’s
controls.In additionyou willunderstand howthetrowel handles
underactualconditions.
Engines
Thistrowelis availablewitha 5.0HPHONDA gasoline engine.
Inaddition,a1.0horsepower115/230VAC,singlephaseelectric
motor is also available.Refer to the engine owner’s manual for
instructions regarding the operation and maintenance of your
engine.The engine manual is included with your trowel at the
time of shipping from Whiteman. Please contact your nearest
Multiquip Dealer for a replacement should the original manual
disappear.
Drive System
Power is transferred from the engine or electric motor to the
gearbox inputshaftviaaV-beltorpulleydrivesystem.Thepulley
engagesusingeither acentrifugalor manual clutch.See page
23.
Gearbox
The
gearbox islocatedbeneaththeengineandtransferspower
to the
rotor or spider assembly. The gearbox controls the
rotational speed of the trowel and is equipped with two shafts
(inputandoutput).
Spider
The vertical output shaft of the gearbox connects to a cast hub
calledthe
spider .Thespiderhas either3or 4armsthatextend
outward that are used for attachment of blades or other
accessories.Rememberasthegearbox outputshaft rotatesso
doesthespider assembly.
Moving the EPOXY/M SERIESWalk-BehindTrowel
This walk-behind trowelisdesigned tobemoved andhandled
in several ways.The easiest way to lift the trowel is to use the
auxiliary lifting tube that is attached to the main handle. See
page 24, Figure 19. When using the auxiliary tube, always use
two persons to lift the trowel.
Some models have a
lifting bale (option) installed. A strap or
chain can be attached to the lifting bale, allowing a forklift or
crane to lift the trowel up onto a slab of concrete. Use a lifting
deviceofadequate liftingcapacityto liftthe trowel.
Training
For proper training, please use the “TRAINING CHECKLIST”
located in the front of this manual (Page 6).This checklist will
provideanoutlineforanexperienced operatortoprovidetraining
toanew operator
Blades
Thebladesof the trowel finishtheconcrete as theyarerotated
around the surface. Blades are classified as
combination (8
inches wide),
float (10 or 8 inches wide), and finish (6 inches
wide).This trowel comes equipped with either
three or four
blades per rotor equally spaced in a radial pattern and
attached to vertical rotating shaft by means of a
spider
assembly.
Centrifugal Stop Switch
In the event of a trowel runaway condition (operator releases
the handle), a
centrifugal stop switch , manual clutch or
micro-switch depending which trowel you have, will stop
the engine and bring the trowel to a halt.
CAUTICAUTI
CAUTICAUTI
CAUTION
NEVER attempt to lift the trowel by yourself.ALWAYS get
theassistanceofanotherperson tohelpliftthetroweloruse
acraneor lifting devicetomove thetrowel.

PAGE 18 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
EPOXY/M SERIESTROWEL— CONTROLS AND COMPONENTS
Figure 3. EPOXY/M SERIES Walk-Behind
Trowels

EPOXY/M SERIES WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #5 (10/06/10) — PAGE 19
Figures3showsthelocationofthebasiccontrolsorcomponents,
for the EPOXY/M SERIES trowel. Listed below is a brief
explanationofeach controlorcomponent
1. Quick Pitch™ Control Handle – To adjust the pitch of
theblades,graspthehandlethensqueezeandeithermove
the handle forward or backward to achieve the desired
bladepitch.
2. ThrottleControl Lever– Controlsthespeedoftheengine.
Move the hand lever towards the operator to increase
enginespeed(high),away from theoperatorto decrease
enginespeed(low).
3. HandGrip/Handle Bar–Whenoperatingthetrowel,place
bothhandson eachgripto maneuver thetrowel.Replace
handgripswhen they becomewornor damaged.
4. Centrifugal Kill Switch – Intheeventtheoperatorlooses
controlofthetrowel,this switchwill shut-downtheengine.
5. Engine – This troweluses Honda,Robin and Briggs and
Strattontypegasoline engines.
6. Auxiliary LiftingTube - Usethistubeto liftthe trowelonto
aslab.Tubeisto be insertedintosocket located infrontof
thegearbox.
7. Pitch Control (standard models) -Turnthis"StarWheel"
clockwiseforincrease bladepitch, andcounter-clockwise
fordecreaseblade pitch.
8. Clutch Lever - Clutch engagement lever.When this lever
is engaged, the blades will begin to rotate. May be used
witheitherQuick Pitch™ or Standard handle.
9. MainTube -When disassemblingcomponents insidethe
tube exercise extreme CAUTION! Tube is spring-loaded,
severeinjurycouldresult if notdisassembledcorrectly.
10. Trowel Lifting Point – Insert theauxiliaryliftingtubehere.
See Figure 19.
11. AC Power Plug (Electric Models Only) – Insert thisplug
intoanAC powersource.
12. Micro-Switch (Electric Models Only) – In the event the
operator loses control of the trowel, this micro-switch will
shut-downtheelectricmotor.
13. Electric Switch Box (Electric Models Only) – Provides
ACpowertotheelectric motor.
14. Guard Ring- NEVER! puthandsor feetinsideguard ring.
15. Electric Motor (Electric Models Only) –Thistroweluses
a 2HP,115/230VAC singlephaseelectric motor.
16. TrowelArm–NEVERoperatethetrowelwithabent,broken
orout ofadjustment trowelarm. Ifthe bladesshowuneven
wearpatternsorsomeblades wearoutfasterthanothers,
the trowel arm may need to be adjusted. Use the trowel
armadjustmenttool P/N1817to adjustthe trowelarms.
17. Blades –This trowelis equippedwith combinationblades.
These blades are versatile and should take care of most
trowelingneeds.In additionfloatdiscs can beattachedto
the trowel arms that will allow the trowel to float on "wet"
concrete.
18. V-Belt Cover – Remove thiscoverto gainaccess totheV-
belt.NEVER operatethetrowelwith thiscover removed.
19. Weights – The trowel may be equipped with two 10 lbs.
weights. The weights may be removed to reduce the
operatingweightof thetrowel.
20. Stabilizer Ring – Reduces trowel arm vibration. Helps
stabilizetrowelarm.
EPOXY/M SERIESTROWEL— CONTROLS AND COMPONENTS

PAGE 20 —EPOXY SERIES WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #5 (10/06/10)
Figure 4. Engine Controls and Components
INITIALSERVICING
Theengine(Figure 4) mustbechecked for properlubricationand
filledwithfuelpriortooperation. Refertothemanufacturersengine
manual for instructions & details of operation and servicing.The
engine shown above is a HONDA engine, operation for other
typesofenginesmayvarysomewhat.
1. Fuel Filler Cap – Remove this cap to add unleaded
gasoline to the fuel tank. Make sure cap is tightened
securely.DO NOT over fill.
5. FuelValve Lever – OPEN to let fuel flow, CLOSE to stop
theflowof fuel.
6. Choke Lever – Usedinthe starting ofacold engine,orin
cold weather conditions. The choke enriches the fuel
mixture.
7. Air Cleaner – Preventsdirtandotherdebrisfromentering
the fuel system. Remove wing-nut on top of air filter
cannistertogain accesstofilter element.
8. Spark Plug – Provides spark to the ignition system. Set
spark plug gap to 0.6 - 0.7 mm (0.028 - 0.031 inch) Clean
sparkplugonce a week.
9. Muffler – Usedtoreduce noise andemissions.
10. Fuel Tank – Holds unleaded gasoline. For additional
informationreferto engineowner's manual.
NOTE
Operating the engine without an air filter,
withadamagedairfilter,orafilterinneedof
replacement will allow dirt to enter the
engine, causing rapid engine wear.
EPOXY/M SERIESTROWEL— BASIC ENGINE
HONDA engine shown.
Adding fuel to the tank should be done only when
theengine isstoppedandhashad anopportunity
to cool down. In the event of a fuel spill, DO NOT
attempttostarttheengineuntilthefuelresiduehas
been completely wiped up, and the area
surroundingtheengineisdry.
2. Throttle Lever – Usedto adjustengineRPMspeed(lever
advanced forward
SLOW , lever back toward operator
FAST ).
3. Engine ON/OFF Switch – ON position permits engine
starting,OFFposition stops engineoperations.
4. Recoil Starter (pull rope) – Manual-startingmethod.Pull
thestartergrip until resistanceisfelt, then pullbrisklyand
smoothly.
DANGERDANGER
DANGERDANGER
DANGER
WARNINGWARNING
WARNINGWARNING
WARNING
Engine components can generate extreme
heat.To prevent burns, DO NOT touch these
areas while the engine is running or
immediatelyafteroperating.NEVER operate
theenginewiththemufflerremoved.
