MULTIQUIP Whiteman series User manual

OPERATION MANUAL
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
SERIES
MODEL HHXDF4-DF5
RIDE-ON TROWEL
(Kubota WG972 Dual Fuel Gasoline/Propane Engine)
Revision #5 (08/30/19)
PN: 32651
To find the latest revision of this publication or
associated parts manual, visit our website at:
www.multiquip.com

PAGE 2 — HHXDF4-DF5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #5 (08/30/19)
PROPOSITION 65 WARNING

PAGE 3 — HHXDF4-DF5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #5 (08/30/19)
Grinding/cutting/drilling of masonry, concrete, metal and
other materials with silica in their composition may give
off dust or mists containing crystalline silica. Silica is a
basic component of sand, quartz, brick clay, granite and
numerous other minerals and rocks. Repeated and/or
substantial inhalation of airborne crystalline silica can
cause serious or fatal respiratory diseases, including
silicosis.Inaddition, California and some other
authorities have listed respirable crystalline silica as a
substance known to cause cancer. When cutting such
materials, always follow the respiratory precautions
mentioned above.
WARNING
Grinding/cutting/drilling of masonry, concrete, metal and
other materials can generate dust, mists and fumes
containing chemicals known to cause serious or fatal
injury or illness, such as respiratory disease, cancer,
birth defects or other reproductive harm. If you are
unfamiliar with the risks associated with the particular
process and/or material being cut or the composition of
the tool being used, review the material safety data
sheet and/or consult your employer, the material
manufacturer/supplier, governmental agencies such as
OSHA and NIOSH and other sources on hazardous
materials. California and some other authorities, for
instance, have published lists of substances known to
cause cancer, reproductive toxicity,or other harmful
effects.
Control dust, mist and fumes at the source where
possible. In this regard use good work practices and
follow the recommendations of the manufacturers or
suppliers, OSHA/NIOSH, and occupational and trade
associations.Water should be used for dust
suppression when wet cutting is feasible. When the
hazards from inhalation of dust, mists and fumes cannot
be eliminated, the operator and any bystanders should
always wear a respirator approved by NIOSH/MSHA for
the materials being used.
WARNING
SILICOSIS WARNING RESPIRATORY HAZARDS
SILICOSIS/RESPIRATORY WARNINGS

PAGE 4 — HHXDF4-DF5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #5 (08/30/19)
TABLE OF CONTENTS
HHXDF4-DF5 Ride-On Trowel
Proposition 65 Warning ........................................... 2
Silicosis/Respiratory Warnings ................................ 3
Table of Contents..................................................... 4
Training Checklist .................................................... 6
Daily Pre-Operation Checklist ................................. 7
Safety Information ............................................. 8–16
Lifting and Transporting ................................... 17–19
Specifications (Trowel)........................................... 20
Specifications (Engine).......................................... 21
Dimensions............................................................ 22
General Information............................................... 23
Components (Trowel) ...................................... 24–26
Components (Engine)............................................ 27
Right Seat Frame Controls and Indicators............. 28
Inspection ........................................................ 29–31
Setup ..................................................................... 32
Operation......................................................... 33–36
Maintenance.................................................... 37–57
Troubleshooting ............................................... 58–64
Electrical Component Locator ............................... 65
Electrical Wiring Diagram (Lights) ................... 66–67
Electrical Wiring Diagram (Spray/Accessories) ... 68–69
Electrical Wiring Diagram (Engine/Seat Switch).. 70–71
Power and Ground Connections............................ 72
NOTICE
Specifications are subject to change without notice.

PAGE 5 — HHXDF4-DF5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #5 (08/30/19)
NOTES

PAGE 6 — HHXDF4-DF5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #5 (08/30/19)
TRAINING CHECKLIST
This checklist lists some of the minimum requirements for machine maintenance and operation. Please feel free to detach
it and make copies. Use this checklist whenever a new operator is to be trained or it can be used as a review for more
experienced operators.
Training Checklist
No, Description OK? Date
1Read operation manual
completely.
2
Machine layout, location of
components, checking of engine
and hydraulic oil levels.
3 Fuel system, refueling procedure.
4 Operation of spray and lights.
5Operation of controls (machine
not running).
6Safety controls, safety stop switch
operation.
7 Emergency stop procedures.
8Startup of machine, pre-heat,
engine choke.
9 Maintaining a hover.
10 Maneuvering.
11 Pitching.
12 Matching blade pitch. Twin-Pitch™
13 Concrete finishing techniques.
14 Shutdown of machine.
15 Lifting of machine (lift loops).
16 Machine transport and storage.

PAGE 7 — HHXDF4-DF5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #5 (08/30/19)
DAILY PRE-OPERATION CHECKLIST
Daily Pre-Operation Checklist      
1 Engine oil level
2 Hydraulic oil level
3 Radiator coolant level
4 Condition of blades
5 Blade pitch operation
6 Safety stop switch operation
7 Steering control operation

PAGE 8 — HHXDF4-DF5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #5 (08/30/19)
SAFETY INFORMATION
Do not operate or service the equipment before reading
the entire manual. Safety precautions should be followed
at all times when operating this equipment.
Failure to read and understand the safety
messages and operating instructions could
result in injury to yourself and others.
SAFETY MESSAGES
The four safety messages shown below will inform you
about potential hazards that could injure you or others.The
safety messages specifically address the level of exposure
to the operator and are preceded by one of four words:
DANGER, WARNING, CAUTION
or NOTICE.
SAFETY SYMBOLS
DANGER
Indicates a hazardous situation which, if not avoided,
WILL result in DEATH or SERIOUS INJURY.
WARNING
Indicates a hazardous situation which, if not avoided,
COULD result in DEATH or SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided,
COULD result in MINOR or MODERATE INJURY.
NOTICE
Addresses practices not related to personal injury.
Potential hazards associated with the operation of this
equipment will be referenced with hazard symbols which
may appear throughout this manual in conjunction with
safety messages.
Lethal exhaust gas hazards
Explosive fuel hazards
Burn hazards
Rotating parts hazards
Symbol Safety Hazard
Pressurized fluid hazards
Hydraulic fluid hazards

PAGE 9 — HHXDF4-DF5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #5 (08/30/19)
SAFETY INFORMATION
DECALS
Decals associated with the operation of this equipment
are defined below.
To avoid injury you must read
and understand operator’s manual
before using this machine.
NOTICE
Read Manual
DANGER
Belt Guard Hazard
DECAL DEFINITION
DANGER
Rotating Blade Hazard
Keep hands, fingers, and feet clear
of engine fan blades and guard rings.
Keep hands and fingers clear from
engine belts. Moving parts can crush.
DO NOT remove belt guards.
P/N 23700
NEVER allow any person to stand
underneath the trowel while lifting.
CAUTION
Lifting/Crush Hazard
This machine to be operated by
qualified personnel only. Ask for
training as needed.
DANGER
Training
Attach lifting strap to this point.
NOTICE
Lifting Point
Moving parts can cut.
DO NOT remove guards.
Stop engine before servicing.
DO NOT lift trowel with pans attached.
ALWAYS make sure handle
is securely attached.
On Quick PitchTM models make sure
T-Handle latch is locked (engaged).
P/N 36099
ALWAYS wear appropriate clothing
before operating trowel.
NOTICE
Protective Clothing
To avoid injury, DO NOT disassemble
spring cylinders without qualified service
personnel. Possibility exist of severe bodily
harm and injury.
DANGER
Inhalation Hazard
DECAL DEFINITION
DO NOT use this equipment in an
enclosed area. The engine used with
this equipment emits harmful levels of
carbon monoxide which can cause
severe bodily harm — even death!
DANGER
DO NOT Remove Guards, Hazard
DO NOT operate equipment with
guards removed. Serious bodily
injury could result.
Indicates left-side blade pitch
direction.
LEFT-SIDE BLADE PITCH
DANGER
Flying Objects Hazard
DO NOT add water to the retardant tank.
DANGER
No Water Warning
7
0
8
3
2
N
/
P
6
0
8
3
2
N
/
P
P/N 23808
Burn Hazard
CAUTION
●HOT PARTS can burn skin.
●DO NOT touch hot parts. Allow machine
sufficient amount of time to cool before
performing maintenance.
Indicates right-side blade pitch
direction.
RIGHT-SIDE BLADE PITCH

PAGE 10 — HHXDF4-DF5 RIDE-ON TROWEL • OPERATION MANUAL — REV. #5 (08/30/19)
SAFETY INFORMATION
Indicates that lubrication is required where
this icon is displayed.
DECAL DEFINITION
LUBRICATION POINT
DO NOT light matches around or near this
equipment. This equipment contains highly
flammable fuel. If ignited, could start a fire
causing equipment damage and severe
bodily harm — even death!
DANGER
Fire Hazard
DO NOT smoke around or near this
equipment. This equipment contains highly
flammable fuel. If ignited, could start a fire
causing equipment damage and severe
bodily harm — even death!
DANGER
Fire Hazard
Hot steam or coolant may escape when
radiator cap is removed, causing severe
burns. Allow radiator to cool before
removing cap.
DANGER
Explosion Hazard
P/N 23809
The engine used in this equipment
can run on LPG/propane fuel.
DECAL DEFINITION
PROPANE/LPG TANK
The engine used in this equipment
can run on unleaded gasoline.
UNLEADED GASOLINE
When fuel selection rocker switch is in
this position, indicates that unit is in the
unleaded gasoline mode.
GASOLINE FUEL SELECTION MODE
LPG/PROPANE FUEL SELECTION MODE
P/N 32561
Cold weather starting below 40°F (4°C).
Run engine 3-5 minutes while moving
steering controls before depressing
blade control pedal.
CAUTION
Cold Weather Conditions
LIGHT SWITCH
L
P/N 23803-XXX
WA
XXX
dB
NOISE LEVEL
Indicates value of the sound power of the
equipment measured at operator’s seat.
When fuel selection rocker switch is in
this position, indicates that unit is in the
LPG/Propane mode.
When light rocker switch is in position 1
all halogen lights will turn on. Position 0
will turn off all lights.
