MULTIQUIP J36E2 User manual

OPERATION MANUAL
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
MODEL J36E2
WALK-BEHIND TROWEL
(2 HP 230 VAC ELECTRIC MOTOR)
S/N LE0118040 AND ABOVE
Revision #3 (08/26/19)
PN: 30573
To find the latest revision of this publication or
associated parts manual, visit our website at:
www.multiquip.com

PAGE 2 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION MANUAL — REV. #3 (08/26/19)
Grinding/cutting/drilling of masonry, concrete, metal and
other materials with silica in their composition may give
off dust or mists containing crystalline silica. Silica is a
basic component of sand, quartz, brick clay, granite and
numerous other minerals and rocks. Repeated and/or
substantial inhalation of airborne crystalline silica can
cause serious or fatal respiratory diseases, including
silicosis.Inaddition, California and some other
authorities have listed respirable crystalline silica as a
substance known to cause cancer. When cutting such
materials, always follow the respiratory precautions
mentioned above.
WARNING
Grinding/cutting/drilling of masonry, concrete, metal and
other materials can generate dust, mists and fumes
containing chemicals known to cause serious or fatal
injury or illness, such as respiratory disease, cancer,
birth defects or other reproductive harm. If you are
unfamiliar with the risks associated with the particular
process and/or material being cut or the composition of
the tool being used, review the material safety data
sheet and/or consult your employer, the material
manufacturer/supplier, governmental agencies such as
OSHA and NIOSH and other sources on hazardous
materials. California and some other authorities, for
instance, have published lists of substances known to
cause cancer, reproductive toxicity,or other harmful
effects.
Control dust, mist and fumes at the source where
possible. In this regard use good work practices and
follow the recommendations of the manufacturers or
suppliers, OSHA/NIOSH, and occupational and trade
associations.Water should be used for dust
suppression when wet cutting is feasible. When the
hazards from inhalation of dust, mists and fumes cannot
be eliminated, the operator and any bystanders should
always wear a respirator approved by NIOSH/MSHA for
the materials being used.
WARNING
SILICOSIS WARNING RESPIRATORY HAZARDS
SILICOSIS/RESPIRATORY WARNINGS

J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION MANUAL — REV. #3 (08/26/19) — PAGE 3
TABLE OF CONTENTS
J36E2 Electric
Walk-Behind Trowel
Silicosis/Respiratory Warnings ................................ 2
Table of Contents..................................................... 3
Training Checklist .................................................... 4
Daily Pre-Operation Checklist ................................. 5
Safety Information ............................................. 6–10
Specifications ........................................................ 11
General Information............................................... 12
Components .......................................................... 13
Electric Motor ........................................................ 14
Setup ..................................................................... 15
Inspection .............................................................. 16
Operation......................................................... 17–19
Options .................................................................. 20
Maintenance.................................................... 21–28
Troubleshooting ..................................................... 29
Electrical Wiring Diagram ...................................... 30

PAGE 4 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION MANUAL — REV. #3 (08/26/19)
TRAINING CHECKLIST
Training Checklist
No. Description OK? Date
1Read operation manual
completely.
2
Machine layout, location of
components, checking of gearbox
oil level.
3Operation of controls (machine
not running).
4Safety controls, safety stop switch
operation.
5 Emergency stop procedures.
6Startup of machine, applying
power.
7 Maintaining a hover.
8 Maneuvering.
9 Pitching.
10 Concrete finishing techniques.
11 Shutdown of machine.
12 Lifting of machine.
13 Machine transport and storage.

J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION MANUAL — REV. #3 (08/26/19) — PAGE 5
DAILY PRE-OPERATION CHECKLIST
Daily Pre-Operation Checklist      
1 Gearbox oil level
2 Condition of blades
3 Blade pitch operation
4 Safety stop switch operation
5 Main ON/OFF switch operation

PAGE 6 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION MANUAL — REV. #3 (08/26/19)
SAFETY INFORMATION
DO NOT operate or service the equipment before reading
the entire manual. Safety precautions should be followed
at all times when operating this equipment.
Failure to read and understand the safety
messages and operating instructions could
result in injury to yourself and others.
SAFETY MESSAGES
The four safety messages shown below will inform you
about potential hazards that could injure you or others.The
safety messages specifically address the level of exposure
to the operator and are preceded by one of four words:
DANGER, WARNING, CAUTION
or NOTICE.
SAFETY SYMBOLS
DANGER
Indicates a hazardous situation which, if not avoided,
WILL result in DEATH or SERIOUS INJURY.
WARNING
Indicates a hazardous situation which, if not avoided,
COULD result in DEATH or SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided,
COULD result in MINOR or MODERATE INJURY.
NOTICE
Addresses practices not related to personal injury.
Potential hazards associated with the operation of this
equipment will be referenced with hazard symbols which
may appear throughout this manual in conjunction with
safety messages.
Electric shock hazards
Explosive area hazards
Rotating parts hazards
Symbol Safety Hazard
Crush hazards
Respiratory hazards

J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION MANUAL — REV. #3 (08/26/19) — PAGE 7
SAFETY INFORMATION
SAFETY DECALS
Decals associated with the safe operation of this equipment
are defined below.
To avoid injury you must read
and understand operator’s manual
before using this machine.
WARNING
Read Manual
WARNING
Belt Guard Hazard
DECAL DEFINITION
WARNING
Rotating Blade Hazard
Keep hands, fingers, and feet clear
of engine fan blades and guard rings.
Keep hands and fingers clear from
engine belts. Moving parts can crush.
DO NOT remove belt guards.
P/N 23700
NEVER allow any person to stand
underneath the trowel while lifting.
DANGER
Lifting/Crush Hazard
This machine to be operated by
qualified personnel only. Ask for
training as needed.
WARNING
Training
Moving parts can cut.
DO NOT remove guards.
Stop engine before servicing.
DO NOT lift trowel with pans attached.
ALWAYS make sure handle
is securely attached.
On Quick PitchTM models make sure
T-Handle latch is locked (engaged).
DECAL DEFINITION
Visually inspect designated locations
before operating trowel. Check that
all components are in appropriate
operating condition.
NOTICE
Visual Inspection
This is the symbol for a belt drive.
NOTICE
Belt Drive
P/N 360 99
ALWAYS wear appropriate clothing
before operating trowel.
NOTICE
Protective Clothing

PAGE 8 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION MANUAL — REV. #3 (08/26/19)
SAFETY INFORMATION
GENERAL SAFETY
CAUTION

NEVER operate this equipment without proper protective
clothing, shatterproof glasses, respiratory protection,
hearing protection, steel-toed boots and other protective
devices required by the job or city and state regulations.

Avoid wearing jewelry or loose-fitting clothes that may
snag on the controls or moving parts as this can cause
serious injury.

NEVER operate this equipment when not
feeling well due to fatigue, illness or when
on medication.

NEVER operate this equipment under the
influence of drugs or alcohol.

ALWAYS clear the work area of any debris, tools, etc.
that would constitute a hazard while the equipment is
in operation.

No one other than the operator is to be in the working
area when the equipment is in operation.

DO NOT use the equipment for any purpose other than
its intended purposes or applications.
NOTICE

This equipment should only be operated by trained and
qualified personnel 18 years of age and older.

Whenever necessary, replace nameplate, operation and
safety decals when they become difficult to read.

Manufacturer does not assume responsibility for any
accident due to equipment modifications. Unauthorized
equipment modification will void all warranties.
NEVER
use accessories or attachments that are not
recommended by Multiquip for this equipment. Damage
to the equipment and/or injury to the user may result.
ALWAYS know the location of the nearest
fire extinguisher.
ALWAYS know the location of the nearest
first aid kit.
ALWAYS know the location of the nearest phone or
keep
a phone on the job site.
Also, know the phone numbers
of the nearest ambulance, doctor and
fire department.
This information will be invaluable in the case of an
emergency.

J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION MANUAL — REV. #3 (08/26/19) — PAGE 9
SAFETY INFORMATION
TROWEL SAFETY
DANGER

NEVER operate the equipment in an explosive atmosphere
or near combustible materials. An explosion or fire could
result causing severe bodily harm or even death.
WARNING

ALWAYS keep clear of rotating or moving
parts while operating the trowel.

DO NOT start or operate the trowel if the
drive train will not disengage. Centrifugal
force between the trowel and surface when starting can
cause uncontrolled handle movement that can cause
serious injury. The handle must not move while starting
the electric motor.

NEVER disconnect any emergency or safety devices.
These devices are intended for operator safety.
Disconnection of these devices can cause severe injury,
bodily harm or even death. Disconnection of any of these
devices will void all warranties.
CAUTION

NEVER stand on the trowel during operation.

NEVER lubricate components or attempt service on a
running machine.

NEVER place your feet or hands inside the guard rings
while starting or operating this equipment.
NOTICE

ALWAYS keep the machine in proper running condition.

Fix damage to the machine and replace any broken
parts immediately.

ALWAYS store equipment properly when it is not being
used. Equipment should be stored in a clean, dry location
out of the reach of children and unauthorized personnel.

A safety manual for operating and maintenance
personnel of concrete power trowels produced by the
Association of Equipment Manufacturers (AEM) can be
obtained for a fee by ordering through their website at
www.aem.org. Order FORM PT-160
ELECTRIC MOTOR SAFETY
WARNING
NEVER
operate the electric motor with guards
removed.
Keep fingers, hands, hair and clothing away
from all moving parts to prevent injury.
GENERATOR SAFETY
If using a generator to power the trowel, refer
to the applicable generator manual safety
information section.
ELECTRICAL SAFETY
DANGER
NEVER let power cords or cables lay in water.
NEVER use damaged or worn
cables or cords when
connecting equipment to a generator or power source.
Inspect for cuts in the insulation.
NEVER grab or touch a live power
cord or cable with wet hands. The
possibility exists of electrical shock,
electrocution or death.

Make sure power cables are securely connected.
Incorrect connections may cause electrical shock and
damage to the trowel.

PAGE 10 — J36E2 ELECTRIC WALK-BEHIND TROWEL • OPERATION MANUAL — REV. #3 (08/26/19)
SAFETY INFORMATION
TRANSPORTING SAFETY
CAUTION

NEVER allow any person or animal to
stand underneath the equipment while
it is being lifted.
NOTICE

Some walk-behind trowels can be lifted or moved by two
people utilizing lifting tubes or other special attachments.
Generally, however, they must be lifted using lifting bails
and cranes, hoists, or forklifts.

NEVER transport the trowel with float pans attached
unless safety catches are used and are specifically
cleared for such transport by the manufacturer.

NEVER hoist the trowel more than three feet off the
ground with float pans attached.

Before lifting, make sure that the lifting bail is not
damaged.

ALWAYS make sure the crane or lifting device has been
properly secured to the lifting bails of the equipment.

ALWAYS shut down the electric motor before transporting.

NEVER lift the equipment while the motor is running.

Use adequate lifting cable (strap or rope) of sufficient
strength.

DO NOT lift the machine to unnecessary heights.

ALWAYS tie down the equipment during transport by
securing the equipment.
ENVIRONMENTAL SAFETY/DECOMMISSIONING
NOTICE
Decommissioning is a controlled process used to safely
retire a piece of equipment that is no longer serviceable.
If the equipment poses an unacceptable and unrepairable
safety risk due to wear or damage or is no longer cost
effective to maintain (beyond life-cycle reliability) and is to
be decommissioned (demolition and dismantlement), be
sure to follow the rules below.

Contact your country’s Department of Public Works or
recycling agency in your area and arrange for proper
disposal of any electrical components, waste or oil
associated with this equipment.

When the life cycle of this equipment is over, it is
recommended that the trowel frame and all other metal
parts be sent to a recycling center.
Metal recycling involves the collection of metal from
discarded products and its transformation into raw
materials to use in manufacturing new products.
Recyclers and manufacturers alike promote the process
of recycling metal. Using a metal recycling center
promotes energy cost savings.
