MULTISPAN PS12-8A User manual

MECHANICAL INSTALLATION
Physical :
Protection :
Size (H) x (W) x (D)
Mounting Type
Input Fused
Din Rail Mount
105 x 45 x 110
Page 1
96W rated power
Compact Size
LED Indicate For Power ON
Din Rail Mount
Cooling by free air convection
Input Specification :
Supply Voltage 100 to 270V AC±10%,(L-N)
Frequency Range 50 / 60Hz
AC Current (TYP.) 1.6A@100V AC, 0.74A@270V AC
Start UP time <1 sec@230V AC &
<3 sec@100VAC (Full Load)
Output Specification :
Output Voltage 11.50V - 13.50V DC
Output Current
8A at 12V ; 7.1A at 13.50V DC
Ripple & noise <1% of Vout*
Line & Load
Regulation ±1%
Hold UP Time <60ms at 230V AC &
>15ms at 100V AC (Full Load)
Protection Available :
Overload
Over Voltage
Output short circuit
Over Temperature
3.15A-250V AC Internal
110% of rated output
Current protection
Protection Type : hiccup mode;
recover automatically after fault
condition is removed
Hiccup mode when output is
shorted;Recovers automatically
after fault condition is removed.
SMPS Latches off if output
voltage Exceeds the specified
output voltage Limits.
Power supply shuts down when
the temperature goes above
specified limit;
Turns on automatically after
temperature goes back to
Normal operating conditions.
Output Over Load
Output Short Circuit
Output Over Voltage
Over Temperature
Material ABS
Environmental :
Working
Temperature
-25°C to 77°C * De-rate
output power at 3w/°C
above +50°C Ambient
-40°C to 85°C
5 minutes
95% RH Non-condensing
Storage
Temperature
Relative Humidity
Warm up time
Efficiency (TYP.) >85%@230V AC
Features :
TECHNICAL SPECIFICATION
PS12-8A
Switch Mode Power Supply
45
105
110

Specifications are subject to change, since development is a continuous process,
So for more updated operating information and Support,
Please contact our Helpline: [phone]/9978991481 or
Email at Ver:2102[email protected]
Read complete instructions prior to installation
and operation of the unit.
WARNING : Risk of electric shock.
SAFETY PRECAUTION
!
All safety related codifications, symbols and instructions that
appear in this operating manual or on the equipment must be
strictly followed to ensure the safety of the operating personnel
as well as the instrument.
If all the equipment is not handled in a manner specified by
the manufacturer, it might impair the protection provided by the
equipment.
WARNING GUIDELINES
WARNING : Risk of electric shock.
1. To prevent the risk of electric shock, power supply to the
equipment must be kept OFF while doing the wiring
arrangement. Do not touch the terminals while power is
being supplied.
2. To reduce electro magnetic interference, use wire with
adequate rating and twists of the same of equal size shall
be made with shortest connection.
3. Cable used for connection to power source, must have a
cross section of 1mm or greater. These wires should have
insulations capacity made of at least 1.5kV.
4. When extending the thermocouple lead wires, always use
thermocouple compensation wires for wiring for the RTD
type, use a wiring material with a small lead resistance
(5 max per line) and no resistance differentials among
three wires should be present.
5. A better anti-noise effect can be expected by using
standard power supply cable for the instrument.
Ω
INSTALLATION GUIDELINES
1. This equipment, being built-in-type, normally becomes a
part of main control panel and in such case the terminals
do not remain accessible to the end user after installation
and internal wiring.
2. Do not allow pieces of metal, wire clippings, or fine metallic
fillings from installation to enter the product or else it may
lead to a safety hazard that may in turn endanger life or
cause electrical shock to the operator.
3. Circuit breaker or mains switch must be installed between
power source and supply terminal to facilitate power ‘ON’
or ‘OFF’ function. However this mains switch or circuit
breaker must be installed at convenient place normally
accessible to the operator.
4. Use and store the instrument within the specified ambient
temperature and humidity ranges as mentioned in this
manual.
MECHANICAL INSTALLATION GUIDELINES
1. Prepare the panel cutout with proper dimensions as shown
above.
2. Fit the unit into the panel with the help of clamp given.
3. The equipment in its installed state must not come in close
proximity to any heating source, caustic vapors, oil steam,
or other unwanted process Byproducts.
4. Use the specified size of crimp terminal (M3.5 screws) to
wire the terminal block. Tightening the screws on the
terminal block using the tightening torque of the range of
1.2 N.m.
5. Do not connect anything to unused terminals.
MAINTENANCE
1. The equipment should be cleaned regularly to avoid blockage
of ventilating parts.
2. Clean the equipment with a clean soft cloth. Do not use
isopropyl alcohol or any other cleaning agent.
3. Fusible resistor must not be replaced by operator.
Page 2
