MultiTable Desktop Sit to Stand Workstation User manual

ASSEMBLY INSTRUCTIONS
MultiTable Desktop Sit to Stand Workstation
The Height of Healthy Design®

2
PLEASE REVIEW these instructions before beginning the assembly and adjustment procedures. Check
that all the parts and tools listed below were provided with your order. Contact MultiTable if any
materials are missing. Do not discard the packaging until the product meets your satisfaction.
The MultiTable Desktop Sit to Stand Workstation PARTS AND TOOLS
Assembly (1)
Ratchet Wrench
PARTS AND TOOLS PROVIDED
CAUTION:
Hand-tighten screws only. Do not use power tools.
4mm Allen Key (1)
WARNING: When you first squeeze the paddle lever to operate this product, firmly
hold the top platform with both hands to control the rate of movement. Take all
appropriate precautions to avoid pinching or otherwise injuring yourself.
CAUTION: This is a heavy product. It is recommended that two people lift the product when
moving it from location to location.
Located in the built in clips
underneath the worksurface.
Located in the built in clips
underneath the worksurface.

24”
36"
3
Placement of Monitor(s) and Keyboard
The Desktop Sit-To-Stand Workstation can accommodate up to two monitors. However,
certain dimension and weight limitations must be observed.
• The combined weight of all added items should notexceed 35
lbs.
• If two monitors are used, the monitors and other items
on the unit must be equal to or less than 48" wide in total.
• Do not connect any cords or cables at this time.
Wait until after you test operation and have made
any necessary adjustments.
CAUTION: Do not exceed maximum weight capacity.
Serious injury or property damage may occur.
The MultiTable Desktop Sit to Stand Workstation
Rise:
15.7"
(400mm)
Monitor
Height:
18"
(457mm)
space for the product and monitor(s)
to rise to the maximum height.
— The top of the product rises 15.7".
In addition, allow at least 18" for
monitor height. See figure 2.
24"
24"
WARNING:WARNING: Do not allow any part
of the base of this product to hang
over the edge of the table top!
Figure 1
Figure 2
SET-UP
Position the Desktop Sit to Stand Workstation Table Top
•

4
SET-UP
The MultiTable Desktop Sit to Stand Workstation
Test Operation
• To prevent the product from abruptly raising up, hold the top of the unit while squeezing the paddle lever.
Raise the product to its maximum height and release the lever.
CAUTION: Keep both hands on the top platform to control the rate of movement when operating the
paddle lever. Be prepared to release the lever immediately if it appears there is not enough clearance for
the monitor(s).
• Check that there is at least 1" of clearance between the top of the monitor(s) and any overhead
obstructions.
• Squeeze the paddle lever again and press the top platform down to its lowest level.
• Ideally, it should take about the same amount of force to raise the unit as it does to lower it. If there is a
Paddle
Lever

5
ADJUSTMENT The MultiTable Desktop Sit to Stand Workstation
Make Any Necessary Adjustments
If the product operates to your satisfaction, there is no need to make any adjustments. You may skip to
“Final Set-Up” on page 6.
The two possible adjustments are for keyboard platform projection (below) and load weight (page 6).
Increase Keyboard Platform Extension
• To extend the keyboard platform approximately 13/4
remove the 12 screws holding the keyboard platform in place.
— This adjustment may be performed with the product upside down or right-side up. The upside method
is shown below.
• After removing the screws, move the keyboard platform forward and re-attach the screws.
Remove
12 Screws
4mm Allen Key

6
ADJUSTMENT
The MultiTable Desktop Sit to Stand Workstation
Adjust for Load Weight
This adjustment can be used to maximize ease of operation. When operating this product, the platform
should move easily to any position and hold that position.
•
• – ).
• Use the 6mm ratchet wrench to turn the adjusting mechanism — counterclockwise to increase load,
clockwise to decrease it. The ratchet only turns one direction, therefore if it doesn’t turn, flip it over.
• Test operation and re-adjust as necessary.
CAUTION: Do not overtighten the MAX (+) adjustment.
Final Set-Up
• Move the product to its maximum height.
• Connect the monitor cable(s) and power cord(s), as well as the
keyboard and mouse cords, if applicable.
— Use cable extensions, if necessary (not included). The cables
and cords must reach their connections when the unit is at its
highest point.
• Use the circular clips at the bottom rear of the top platform to
capture the cables and cords.
6mm Wrench
Tool storage
• When finished, the ratchet and Allen key can be stored in the built clips on the underside of the worksurface.
Note: 180° lock-out feature must be utilized with monitor
arms (see monitor arm instructions).

© 2017 MultiTable. All rights reserved. The MultiTable Desktop Sit to Stand Workstation - User Guide v-1.1
