MultiTable Mod-E Pro User manual

ASSEMBLY INSTRUCTIONS
MultiTable Mod-E Pro Electric Standing Desk
The Height of Healthy Design®

#10 x 5/8"
Wood Screws (16)
MultiTable Mod-E Pro Electric Standing Desk Frame PARTS AND TOOLS
frame, small or standard
Small Standard
#10 x 5/8"
Wood Screws (12)
Small Frame Screws & Brackets
Standard Frame Screws
#10 x 5/8"
Wood Screws (2) (8)

ASSEMBLY MultiTable Mod-E Pro Electric Standing Desk Frame
With the table top facing down on a soft, clean surface, arrange the frame as shown below, with the short ends of the top supports toward the rear.
• Position the frame side to side.
— Loosen all eight set screws (if necessary) using the 5mm Allen key. Expand or compress he frame so that the top supports are aligned with the
pre-drilled holes. Center the middle portion of the cross channels, the tighten the eight set screws.
• Position the frame font to back.
— With tables that are 24.0" deep, position the rear cross channel 6.5" from the rear edge of the table. With 29" tables, position the rear cross channel 9.5"
from the rear edge of the table. These positions of the frame will align the rear of the feet to the rear of the table when the feet are installed in step 4.
• Use the #10 x 5/8" wood screws. The small frame requires 16 screws (eight for the frame abd eight for U-brackets) and the standard frame requires 12 screws.
• Withthe small frame, position the U-brackets between the set screws. The U-brackets take the place of the cross supports on the standard frame.
9.5" with 29" table foot for
29" table
#10 x 5/8"
Wood Screws
Standard frame
cross support
(Standard frame only)
U-bracket
(Small frame only)

ASSEMBLY
MultiTable Mod-E Pro Electric Standing Desk Frame

MultiTable Mod-E Pro Electric Standing Desk Frame
ASSEMBLY
#10 x 5/8" wood screws. #10 x 5/8"
wood screws

ASSEMBLY
MultiTable Mod-E Pro Electric Standing Desk Frame
call MultiTable Customer Service 602-773-6911.

ASSEMBLY MultiTable Mod-E Pro Electric Standing Desk Frame

ASSEMBLY
MultiTable Mod-E Pro Electric Standing Desk Frame
L
C

OPERATION MultiTable Mod-E Pro Electric Standing Desk Frame
L
C

OPERATION
MultiTable Mod-E Pro Electric Standing Desk Frame

© 2019 MultiTable. All rights reserved. MultiTable Mod-E Pro Electric Standing Desk Frame - Assembly v-2.1
MultiTable, LLC | 2255 W Desert Cove Ave., Suite E, Phoenix, AZ 85029
The Height of Healthy Design®
Quality Design | Free Shipping | 30-Day No Risk Returns | Over 85,000 Sold
855-469-6858 | [email protected] | www.MultiTable.com
