MultiTable Mod-E Pro User manual

ASSEMBLY INSTRUCTIONS
MultiTable Mod-E Pro Electric Standing Desk
The Height of Healthy Design®

MultiTable Mod-E Pro Electric Standing Desk Frame PARTS AND TOOLS
2
PLEASE REVIEW these instructions before beginning the assembly procedures. Check that all the parts
shown below were provided with your order. Contact MultiTable if any materials are missing. Do not discard
the packaging until the product meets your satisfaction.
PARTS PROVIDED
Hardware
Motor Cable (2) Power Cable (1)
Top Supports (2)
Hole Cover (20)
Right
Left
M5x15 (2)
Round Head
Screw
M3x20 (3)
Round Head
Screw
M3.5x16 (10)
Flat Head
Screw
M6x15 (8)
Socket Cap
Bolt
M6x18 (12)
Socket Cap
Round Point Bolt
U-Bracket (4) Cord Clip (10) 5mm Allen Key (1)
Digital Keypad (1)Control Unit (1)
Legs with Motor (2) Cross Channels (2) Feet (2)
CAUTION: Hand-tighten bolts only.
ADDITIONAL TOOLS REQUIRED
•
•
Phillips screwdriver
Power Drill Optional (wood screws only)
CAUTION: Always check that screws
used to attach components to the
work surface are not too long for the
thickness of the surface.
Work
Surface
OPTIONAL PARTS INCLUDED
There are 8 plastic guides included to help direct the bolts when attaching the cross
channels to the frame legs in step 4. These are used to keep the bolts from dropping
into the holes when attaching.
#10 x 5/8" (16)
Table Top
Screw

ASSEMBLY MultiTable Mod-E Pro Electric Standing Desk Frame
3
Leg Columns
Right Top
Support
Left Top
Support
Cross
Channels
Set Screws
Face Upward
Front
Rear
Large Holes
Face Outward,
Offset Toward Rear
STEP 1
With the table top facing down on a soft, clean surface, arrange
the leg columns, top supports, and cross channels, as shown.
• Positioning does not need to be exact at this time.
• The set screws on the cross channels face upward.
• Holes on the sides of the top supports are offset to the rear,
and the large holes face outward.
STEP 2
Use M6x18 socket head bolt (with round point
tip) and the 5mm Allen key to attach the top
supports to the leg columns.
• Use 2 bolts per top support.
•The bolts fit through guides in the top supports.
•Be sure the short side of the top supports is toward
the rear of the table top.
IMPORTANT: Do not use the M6x15 socket head
bolt with the flat tip. Those bolts will be used to
attach the feet.
M6x18
Bolt
5mm
Allen Key
Rear
Short Side Long Side
Front
...
Pre-Drilled Holes
for Switch Are Always
on the Front Edge

MultiTable Mod-E Pro Electric Standing Desk Frame
STEP 3
ASSEMBLY
4
Loosen
Set Screws
Expand
Cross Channels
to Top Supports
• Use the 5mm Allen key to loosen the 8 set screws on the under
side of the cross channels.
• Position the leg columns and top supports so that the top supports
are aligned over the pre-drilled holes. (If you are adding your own
table top, position the top supports 1" from ends of table top.
• Expand the cross channels to the top supports.
• Center the inner piece in each cross channel.
STEP 4
Attach the cross channels to the leg columns with
4 M6x18 socket head bolts per leg.
• Use a 5mm Allen key.
•The bolts fit through guides in the sides of
the cross channel, if inserted.
(After completing this step, there should be no
remaining M6x18 bolts with the round point tip.)
M6x18
Bolt
5mm
Allen Key
1”
1”
Loosen
Set Screws
5mm
Allen Key
Inner piece
Inner piece
NOTE: Plastic guides are included with
your parts, and can be inserted prior to
attaching channels to leg columns.
These are used to keep the bolts from
dropping into the holes when attaching

MultiTable Mod-E Pro Electric Standing Desk Frame
ASSEMBLY
5
• Place the square opening on the foot over the leg.
• Use the 5mm Allen key and M6x15 socket head
bolts (with flat tip) to secure the feet in position.
STEP 6
• Check that the top supports are aligned over the
table top's pre-drilled holes.
STEP 7
Attach the top supports to the table top.
• Use the #10 x 5/8" Table Top Screws (8 total
required) and a Phillips screwdriver.
•
supports.
Align Rear of Feet with Rear of Table
6½" with 24" Table
9½" with 30" Table
1" 1"
M6x15
Rear
Front
#10 x 5/8"
Adjust the position of the frame before attaching it
to the table.
If attaching to a MultiTable Table Top:
•Check that the top supports on each side are
approximately 1" (25mm) from the ends of the table.
•The rear of the feet should align with the rear of the
table. With feet for a 24" deep table, the rear cross
channel will be 6½" from the rear of the table. With
feet for a 30" table, the rear cross channel will be
9½" from the rear of the table. (See illustration)
If attaching to your own Table Top:

ASSEMBLY
MultiTable Mod-E Pro Electric Standing Desk Frame
STEP 8
Use the 5mm Allen key to tighten the set screws (8 total)
both cross channels.
6
STEP 9
Attach the cross channels to the table.
• Position one U-bracket over each section of cross
channel, between the set screws, as shown (four
brackets total). Align with pre-drilled holes if
attaching to a MultiTable table top.
• Use the remaining #10 x 5/8" Table Top Screws (8
total) to fasten the U-brackets to the table top.
STEP 10
•
•
Align with pre-drilled holes and attach.
If attaching to your own Table Top:
Position the digital keypad on the left or right side
of the table, according to user preference.
Mount the keypad 1 1/
16 ” from the front edge of
the table and expand to make flush. This will
prevent overhang and collision with the keypad.
Digital
Keypad
M3x20
MOUNT 1
1
/
16
”
FROM EDGE
Tighten All
8 Set Screws
5mm
Allen Key
#10 x 5/8"
U-Brackets
Attach the digital keypad using the three M3-20
Phillips round head screws.
If attaching to a MultiTable Table Top:
•

ASSEMBLY MultiTable Mod-E Pro Electric Standing Desk Frame
7
STEP 11
Attach the control unit using the two M5-15 Phillips
round head screws.
• Simply align with pre-drilled holes and attach.
If attaching to your own Table Top:
•Position the control unit near the back of the
table, on the same side as the digital keypad.
• Be sure that the cable from the keypad can
reach the control unit and the motor cables can
extend from the control unit to both motors.
STEP 12
Make connections to the control unit and motors.
• Connect the cable from the digital keypad.
• Connect the motor cables to the control unit and
to each of the motors on the table legs.
• Connect the power cord to the control unit.
• Plug the power cord into an AC outlet.
CAUTION: Do not operate the table until after
resetting the system. See the following step.
STEP 13
Reset the system before testing operation.
IMPORTANT: The resetting procedure below
must be completed before operating the table.
• Press and hold the UP ▲ and DOWN ▼ buttons
simultaneously for more than 3 seconds.
— The legs will begin to move down at half
speed of normal operation.
• Continue to press the UP ▲ and DOWN ▼ buttons.
— The legs will move down to the lowest position, then rebound 1/16" to 3/16" (2mm to 5mm) and stop.
• Release the UP ▲ and DOWN ▼ buttons at the same time. This completes the resetting procedure.
Note: Until the table is turned
upright, the DOWN button points
up and the UP button points down.
Press and Hold
UP and DOWN Buttons
Digital
Keypad
Cable
Motor
Cables
Power
Cord
M5x15
Control
Unit
If attaching to a MultiTable Table Top:

ASSEMBLY
MultiTable Mod-E Pro Electric Standing Desk Frame
STEP 14
Test operation.
8
Cord Clip
M3.5x16
buttons individually to test operation. End your test with the legs completely
• If there are problems with operation, check that all cable and cord connections are secure. If problems
continue, contact MultiTable Customer Service (see page 11).
STEP 15
Use the cord clips to secure the cables and cords in position.
• Cables must not interfere with table operation.
• Cables must not interfere with the user.
•
clips to the table.
STEP 16
If desired, snap hole covers over all screw holes with
guides (12 total).
STEP 17
With the assistance of another person, turn the table upright and place it in its
IMPORTANT: There must be 1" (25mm) of clearance on
all sides of the table top (and other moving parts)
to ensure free, unobstructed movement.
•
•
•
Note: If the desk is unplugged or
power is lost, the desk must be
reset.
Adjust the leveling glides on the feet to
level the table top, if necessary.
Plug the power cord into an AC outlet and
reset the desk.
See the steps #13 & 14 for operating
procedures.
Hole Cover
• Press the UP ▲ and DOWN ▼
lowered to the shortest position and unplug the power cord.

OPERATION MultiTable Mod-E Pro Electric Standing Desk Frame
9
GENERAL OPERATION
• Raise or lower the desk to the position you want to save.
— The display on the digital keypad shows the work surface
height.
• Press the S button. Then press the desired memory button — 1,
2 or 3 — within the next 3 seconds.
— Position 1, 2 or 3 is now saved.
To move the desk to a memory stop position:
• Press and hold the desired memory button, 1, 2 or 3.
— The desk will move to the saved position and then
stop.
LOWER STOP POSITION
This feature can be used to set the minimum height of the desk.
• Raise or lower the desk to the desired minimum height.
• Press and hold S, then press and hold 1. Continue to press both
buttons for about 3 seconds.
— The letter “L” appears on the display. This means the
minimum height of the desk is locked at its current position.
• Release both buttons.
To erase the lower stop position:
• Press and hold S, then press and hold 2. Continue to press both
buttons for about 3 seconds.
— The letter “C” appears on the display, indicating the lower
stop position has been erased.
• Release both buttons.
CAUTION: The resetting procedure must
be completed before operating the
desk. See Step 13 on page 7.
If there is a memory stop position
lower than the lower stop position,
the memory stop will be erased.
Desk movement stops when you
release the UP
▲ or DOWN ▼ button.
If you release the memory button
before the saved position is reached,
desk movement will stop.
Memory
Buttons
UP
Button
DOWN
Button
“SET”
Button
Digital
Display
Move the desk up or down by pressing UP ▲ or DOWN ▼ until
the desk reaches the desired height.
The desk will continue to move up or down until you release the
button or until the maximum or minimum height is reached.
MEMORY STOP POSITIONS
Up to three memory stop positions can be used to save specific
heights of the desk. To set a specific position:

OPERATIONMultiTable Mod-E Pro Electric Standing Desk Frame
CHANGING THE HEIGHT DISPLAY UNITS
This function allows you to change the display units from
centimeters to inches or the other way around.
10
• Press and hold S, then press and hold the DOWN ▼ button.
Continue to press both buttons for about 3 seconds.
— The height information will change between centimeters
and inches.
• Release both buttons.
RESET THE CONTROL UNIT TO FACTORY SETTINGS
To reset the control unit to factory settings, reset the desk.
• Press and hold the UP ▲ and DOWN ▼ buttons simultaneously
for more than 3 seconds.
— The legs will begin to move down at half speed of normal
operation.
• Continue to press the UP ▲ and DOWN ▼ buttons.
— The legs will move down to the lowest position, then
rebound 1
/16" to 3/16" (2mm to 5mm) and stop.
• Release the UP ▲ and DOWN ▼ buttons at the same time. This
completes the resetting procedure.
If one or more motors are changed
in a system, the control unit must be
reset to factory settings.

© 2017 MultiTable. All rights reserved. MultiTable Mod-E Pro Electric Standing Desk Frame - Assembly v-1.1
MultiTable, LLC | 2255 W Desert Cove Ave., Suite E, Phoenix, AZ 85029
The Height of Healthy Design®
Quality Design | Free Shipping | 30-Day No Risk Returns | Over 37,000 Sold
855-469-6858 | [email protected] | www.MultiTable.com
11
