Multitech RouteFinder MTASR2-201 User manual

LAN-to-LAN Routing
for Central-Site and
Branch Office Networks
DSU RouteFinder
Model MTASR2-201
User Guide

User Guide
88301701 Revision B
DSU RouteFinder (Model MTASR2-201)
This publication may not be reproduced, in whole or in part, without prior expressed written permission from
Multi-Tech Systems, Inc. All rights reserved.
Copyright © 1998, 1999, by Multi-Tech Systems, Inc.
Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from
time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or
organization of such revisions or changes.
Record of Revisions
Revision Description
AManual released; covers software revision 3.00.All pages at revisionA.
(11/3/98)
BManual revised to show E1 (2.048 Mbps) synchronous capability for WAN link;
(11/30/99) also added new command cable.All pages at revision B.
Patents
This Product is covered by one or more of the following U.S. Patent Numbers: 5.301.274; 5.309.562;
5.355.365; 5.355.653; 5.452.289; 5.453.986. Other Patents Pending.
TRADEMARK
Trademark of Multi-Tech Systems, Inc. is the Multi-Tech logo and RouteFinder.
Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, Minnesota 55112
[phone] or [phone]
Fax [phone]
Tech Support [phone]
BBS [phone] or [phone]
InternetAddress: http://www.multitech.com

iii
Contents
Chapter 1 - Introduction and Description
Introduction .......................................................................................................................................................6
Preview of this Guide ........................................................................................................................................7
Front Panel Description.....................................................................................................................................8
Back Panel Description .....................................................................................................................................9
RS232/V.35 Connector ...............................................................................................................................9
56K DSU Connector ...................................................................................................................................9
10Base-T (Ethernet) Connector..................................................................................................................9
Command Connector..................................................................................................................................9
Power Connector ........................................................................................................................................9
Related Documentation ...................................................................................................................................10
Safety Warning Telecom .................................................................................................................................10
Specifications .................................................................................................................................................. 11
Ethernet Port............................................................................................................................................. 11
56K DSU Port ........................................................................................................................................... 11
Command Port.......................................................................................................................................... 11
WAN Link .................................................................................................................................................. 11
Electrical/Physical..................................................................................................................................... 11
Chapter 2 - Installation
Safety Warnings ..............................................................................................................................................14
Unpacking your DSU RouteFinder ..................................................................................................................14
8-Position DIP Switch......................................................................................................................................15
V.35 Shunt Procedure .....................................................................................................................................16
Cabling Your DSU RouteFinder.......................................................................................................................17
Chapter 3 - Software Loading and Configuration
Introduction .....................................................................................................................................................20
Loading Your Software ....................................................................................................................................20
Chapter 4 - DSU RouteFinder Software
Introduction .....................................................................................................................................................26
Before You Begin ............................................................................................................................................26
Setup Menu.....................................................................................................................................................28
IP Setup ..........................................................................................................................................................29
IPX Setup ........................................................................................................................................................34
Spanning Tree Setup.......................................................................................................................................36
WAN Port Setup ..............................................................................................................................................37
PPP Port Setup ...............................................................................................................................................38
Applications Setup ..........................................................................................................................................39
Filtering ...........................................................................................................................................................40
Diagnostics......................................................................................................................................................41
Scripting ..........................................................................................................................................................42

RouteFinder User Guide
iv
Chapter 5 - Remote Configuration and Management
Introduction .....................................................................................................................................................44
Modem-Based Remote Configuration Procedure............................................................................................44
LAN-Based Remote Configuration Procedure ................................................................................................46
Windows Sockets Compliant TCP/IP Stack..............................................................................................46
Remote Management ......................................................................................................................................48
Telnet ........................................................................................................................................................48
Web Browser Management ......................................................................................................................50
Chapter 6 - Warranty, Service and Tech Support
Introduction .....................................................................................................................................................52
Limited Warranty .............................................................................................................................................52
On-line Warranty Registration...................................................................................................................52
Service ............................................................................................................................................................53
Tech Support ...................................................................................................................................................54
Recording DSU RouteFinder Information .................................................................................................54
The Multi-Tech BBS ........................................................................................................................................55
About the Internet............................................................................................................................................56
Appendixes
AppendixA - Cabling Diagrams.......................................................................................................................58
Appendix B - Scripting.....................................................................................................................................59
Appendix C - Regulatory Information ..............................................................................................................63
ClassA Statement ....................................................................................................................................63
FCC Part 68 Telecom................................................................................................................................64
Ringer Equivalence Number .....................................................................................................................65
Glossary of Terms
Index

Chapter 1 - Introduction and Description

DSU RouteFinder User Guide
6 MTASR2-201
Introduction
Welcome to Multi-Tech's new DSU RouteFinder, Model MTASR2-201, which provides secure and
seamless LAN-to-LAN routing capability and can also provide dial-up capability. This unit
supports multiple WAN services and supports a wide range of routing protocols including IP, IPX,
TCP, and RIP version 2. When the WAN 2 port is configured to support it, this unit also supports
a secondary capability of dial-up Remote Access Server (RAS) access for telecommuters and
mobile users from any Point-to-Point Protocol (PPP) or Serial Line Internet Protocol (SLIP)
networking client. Refer to the Chapter 4, DSU RouteFinder Software, and your on-line help
system for more details on RAS.
The DSU RouteFinder features a 10Base-T port for local LAN connection, a command port for
configuration, a 56K bps DDS 4-wire WAN connection, and an RS232/V.35 port for an optional
Data Communications Equipment (DCE) device (i.e., external modem, T1/E1 CSU/DSU, etc.).
System management is provided through the command port using bundled Windows®based
software which provides easy-to-use configuration menus.
RD TD CL LK RD TD CD NS DS RD TD CD
V35
Figure 1-1. DSU RouteFinder
* Some DSU RouteFinder units may be marked “MultiRouter” or “MultiRouter 200-Series”; they
are equivalent to the “DSU RouteFinder” referred to throughout this user guide.

Chapter 1 - Introduction and Description
7
MTASR2-201
Preview of this Guide
This guide describes the DSU RouteFinder and tells you how to install and configure the unit.
The information contained in each chapter is as follows:
Chapter 1 - Introduction and Description
Chapter 1 describes the DSU RouteFinder. Front panel indicators, and back panel connector
descriptions are provided. In addition, a list of relevant specifications is provided at the end of the
chapter.
Chapter 2 - Installation
Chapter 2 provides information on unpacking and cabling your DSU RouteFinder. The installation
procedure describes each cable connection and shows how to switch the shunt position if the
unit is to be used with V.35.
Chapter 3 - Software Loading and Configuration
Chapter 3 provides instructions for software loading and initial configuration. The DSU
RouteFinder software disks are Windows® based. Later chapters, and your on-line help program,
describe the DSU RouteFinder software in greater detail.
Chapter 4 - DSU RouteFinder Software
Chapter 4 describes the DSU RouteFinder software package designed for the Windows®
environment. This chapter describes the DSU RouteFinder software from an applications
standpoint, and in so doing, not every screen is shown, nor is each field within a screen defined.
For explanations and parameters of each field within a dialog box, refer to the on-line help
system provided within the software.
Chapter 5 - Remote Configuration and Management
Chapter 5 provides procedures for changing the configuration of a remote DSU RouteFinder.
Remote configuration enables you to change the configuration of a unit by simply connecting two
modems between the two DSU RouteFinders and remotely controlling the unit. Chapter 5 also
describes typical client applications (i.e., Telnet and Web-based management) used for remote
configuration of the DSU RouteFinder.
Chapter 6 - Warranty, Service and Tech Support
Chapter 6 provides instructions on getting service for your DSU RouteFinder at the factory, a
statement of the limited warranty, information about our Internet presence and user bulletin board
service, and space for recording information about your DSU RouteFinder prior to calling Multi-
Tech’s Technical Support group.

DSU RouteFinder User Guide
8 MTASR2-201
Front Panel Description
The front panel, shown in Figure 1-2, contains four groups of LEDs that provide the status of the
Ethernet connection, 56K DSU port, WAN port, and general status of the DSU RouteFinder. The
Ethernet LEDs indicate the status of the LAN activity, the 56K DSU LEDs indicate the status of
the internal DSU port (WAN 1), and the WAN Link LEDs indicate the status of the external DCE
device (WAN 2). There are also two LEDs which indicate whether the self test passed or failed
(Fail) and if the power On/Off switch on the back of the DSU RouteFinder is turned On (Power).
RD TD CL LK RD TD CD NS OS RD TD CD
V35
Figure 1-2. Front Panel
Ethernet
RD Receive Data indicator blinks when packets are being received from the local area
network.
TD Transmit Data indicator blinks when packets are being transmitted to the local area
network.
CL Collision indicator lights when a collision is detected on the Ethernet link.
LNK Link indicator lights indicating that the RouteFinder is connected to the local area
network.
56K DSU
RD Receive Data indicator blinks when packets are being received from the wide area
network.
TD Transmit Data indicator blinks when packets are being transmitted to the wide area
network.
CD Carrier Detect indicator lights when a carrier signal is detected on the WAN link.
NS No Signal indicator lights when the DSU RouteFinder is unable to detect a signal on the
DSU (WAN 1) port.
OS Out of Service indicator lights when the DSU port is out of service.
WAN Link
RD Receive Data indicator blinks when packets are being received from the wide area
network.
TD Transmit Data indicator blinks when packets are being transmitted to the wide area
network.
CD Carrier Detect indicator lights when a carrier signal is detected on the WAN link.
V35 V.35 indicator lights when internal shunt is set for V.35 operation.
Fail
The Fail indicator lights for 3 minutes when power is applied to the DSU RouteFinder; if it
remains on for over 3 minutes, it indicates that a boot failure has occurred; this indicator also
lights when firmware is being downloaded to the DSU RouteFinder.
Power
The Power indicator lights when power is applied to the DSU RouteFinder.

Chapter 1 - Introduction and Description
9
MTASR2-201
Back Panel Description
The cable connections for the DSU RouteFinder are made at the back panel. Connectors include
Power, Command Port, 10BASET (Ethernet), 56K DSU and RS232/V.35. The cable connectors
are shown in Figure 1-3 and defined in the following groups.
10BASET COMMAND56K DSU POWER
ON
OFF
RS232/V.35
Figure 1-3. Back Panel
RS232/V.35 Connector
The RS232/V.35 (DB-25) connector is used to connect the DSU RouteFinder to an external
modem, DSU, or other Data Communications Equipment (DCE). This connection can be either
RS232C (default) or V.35. If the connection is V.35, then the shunt must be moved from the
default RS232 position to the V.35 position (for details on this procedure, refer to Chapter 2 - V.35
Shunt Procedure).
56K DSU Connector
The 56K DSU connector is used to connect the DSU RouteFinder to a Digital Data Service
(DDS) network connection. This connector is an RJ-45 jack.
10Base-T (Ethernet) Connector
The Ethernet 10Base-T connector is used to connect the DSU RouteFinder to a LAN using
unshielded twisted cable. This connector is an RJ-45 jack.
Command Connector
The Command connector is used to configure the DSU RouteFinder using a PC with an available
COM port and running Windows® software. The Command port connector is an RJ-45 jack and
an adapter cable is provided to plug into a standard 9-pin COM port on a PC.
Power Connector
The Power connector is used to connect the external power supply to the DSU RouteFinder. The
Power connector is a 6-pin circular DIN connector. Aseparate power cord is connected to the
power supply and the liveAC grounded outlet.

DSU RouteFinder User Guide
10 MTASR2-201
Related Documentation
The complete documentation package for the DSU RouteFinder includes this User Guide, a
Quick Start Guide, and a Remote Access Server Dial-Out Redirector User Guide. The printed
version of the Quick Start Guide, shipped with the unit, provides the necessary information for a
qualified person to unpack, cable, load software, and configure the unit for proper operation. The
Dial-Out Redirector User Guide is for those who need communications connectivity for their
Windows or DOS dial-out or fax-out programs. Copies of the guides are provided on the Manuals
disk that ships with each DSU RouteFinder unit, and you can always find the latest version of
these guides at Multi-Tech’s Web site.
At the Multi-Tech Home Page (http://www.multitech.com), click Support, then Manuals, then DSU
RouteFinder and you will find the DSU RouteFinder User Guide and the RemoteAccess Server
Dial-Out Redirector User Guide.
Safety Warning Telecom
1. Never install phone wiring during a lightning storm.
2. Never install phone jacks in wet locations unless the jacks are specifically designed for wet
locations.
3. This product is to be used with UL and cUL listed computers.
4. Never touch uninsulated phone wires or terminals unless the phone line has been disconnected
at the network interface.
5. Use caution when installing or modifying phone lines.
6. Avoid using a phone (other than a cordless type) during an electrical storm. There may be a
remote risk of electrical shock from lightning.
7. Do not use the phone to report a gas leak in the viciniity of the leak.

Chapter 1 - Introduction and Description
11
MTASR2-201
Specifications
• Routing Protocols - IP and IPX and Bridging all others
• Protocols - Point-To-Point Protocol (PPP) and Serial Line Internet Protocol (SLIP)
• Two 1 Meg by 32 byte, 70 nanosecond SIMMs (8 Mb DRAM, total)
Caution: SIMM speed and size cannot be mixed
• One Meg of flash memory
Ethernet Port
• Single Ethernet Interface - 10Base-T (twisted pair) RJ-45 jack
56K DSU Port
• Single 56K bps DDS 4-wire RJ-45 jack
Command Port
• Single 19.2 Kbps asynchronous Command Port using a short RJ-45 to DB-25 cable with
a DB-25 female connector
WAN Link
• One 115200 bps async or T1/E1 (1.544/2.048 Mbps) sync link using a DB-25 (RS232/
V.35) female connector
Electrical/Physical
• Voltage - 115 VAC (Standard), 240 Volts AC (Optional)
• Frequency - 47 to 63 Hz
• Power Consumption - 10 Watts
• Dimensions - 1.625" high x 6" wide x 9" deep
5.63 cm high x 22.34 cm wide x 33.51 cm deep
• Weight - 2 pounds (.92 kg)

DSU RouteFinder User Guide
12 MTASR2-201

Chapter 2 - Installation

DSU RouteFinder User Guide
14 MTASR2-201
Safety Warnings
1. Never install telephone wiring during a lightning storm.
2. Never install telephone jacks in wet locations unless the jack is specifically designed for wet
locations.
3. Never touch uninsulated telephone wires or terminals unless the telephone line has been
disconnected at the network interface.
4. Use caution when installing or modifying telephone lines.
5. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a
remote risk of electrical shock from lightning.
6. Do not use the telephone to report a gas leak in the vicinity of the leak.
Unpacking your DSU RouteFinder
The shipping box contains the DSU RouteFinder, external power supply, a plastic bag containing
cables, your Quick Start Guide, and three diskettes (i.e., the DSU RouteFinder User Guide, and
the DSU RouteFinder Software). Inspect the contents for signs of any shipping damage. If
damage is observed, do not power up the unit, contact Multi-Tech’s Technical Support for advice
(refer to Chapter 6 - Warranty, Service and Tech Support). If no damage is observed, place the
DSU RouteFinder in its final location and perform the Cabling Procedure.
Save the shipping box (Figure 2-1) in case reshipment is necessary.
MADE IN U.S.A
MADE IN U.S.A
RD TD CL LK RD TD CD NS DS RD TD CD V35
Figure 2-1. Unpacking

Chapter 2 - Installation
15 MTASR2-201
8-Position DIP Switch
The DSU RouteFinder is equipped with an 8-position DIP switch. Figure 2-2 shows the DIP
switch, and the chart that follows details the default positions and other options.
56781234
Figure 2-2. 8-position DIP switch
Position 1: OPEN* (up) Normal Mode operation
Closed (down) Loopback Mode operation
Position 2: OPEN* (up) DDS clocking
Closed (down) Internal Clocking
Positions 3 - 8: Reserved for future use.
* Denotes Factory Default setting
Note: The DIP switch settings cannot be changed externally; you must remove the circuit board
from the chassis. Refer to the steps in the next section, V.35 Shunt Procedure, for instructions on
removing the circuit board.

DSU RouteFinder User Guide
16 MTASR2-201
V.35 Shunt Procedure
If you are using an external DCE device on the WAN 2 RS232/V.35 port, and the connection will
be a V.35 connection, the internal shunt must be moved from the RS232C (default) position prior
to cabling and power-up. The following steps detail the procedures for switching the shunt.
Step Procedure
1 Ensure that the external power supply is disconnected from the DSU RouteFinder.
2 Turn the DSU RouteFinder over and remove the cabinet mounting screw (Figure 2-3) from
the chassis.
Front Panel Back Panel
Cabinet Mounting Screw
Figure 2-3. Cabinet Mounting Screw Location
3 While supporting the back panel, turn the DSU RouteFinder right side up, tilt the back panel
down, and slide the circuit board out of the chassis.
4 Place the unit on a flat, grounded surface.
5 Pry the shunt out of the RS232 position, and insert it in the V.35 position. See Figure 2-4.
5678
V.35 Shunt Position
RS232C Shunt Position
Back Panel Connectors
8-Position DIP Switch
RAM Sockets
LEDs
Figure 2-4. Shunt Positions
Note: if you wish to make changes to the 8-position DIP switch, do so at this time. For details
on DIP switch settings, refer to the previous section, 8-Position DIP Switch.
6 Align the board with the guide slots on the inside of the chassis and carefully slide the board
back into the chassis.
7 While supporting the back panel, turn the DSU RouteFinder over again, and replace the
cabinet mounting screw.
8 Turn the DSU RouteFinder right side up again and proceed to the next section to connect the
cables.

Chapter 2 - Installation
17 MTASR2-201
Cabling Your DSU RouteFinder
Cabling your DSU RouteFinder involves making the proper Power, Command Port, Ethernet and
56K DSU connections.An optional WAN connection is provided to connect to an external WAN
device. Figure 2-5 shows the back panel connectors and the associated cable connections.
Power Connection
PC Connection
10BASET COMMAND56K DSU POWER
ON
OFF
RS232/V.35
Ethernet Connection
DDS WAN Connection
To DCE
Device Command Cable
Figure 2-5. Cable Connections
The following steps detail the procedures for connecting the cables to your DSU RouteFinder.
1. Connect one end of the power supply to a liveAC outlet and connect the other end to the
DSU RouteFinder as shown in Figure 2-5. The power connector is a 6-pin circular DIN
connector.
2. Connect the DSU RouteFinder to a PC using the RJ-45 to DB-9 (female) cable provided with
your unit. Plug the RJ-45 end of the cable into the Command port of the DSU RouteFinder
and the other end into the PC’s COM port. See Figure 2-5.
3. Connect a network cable to the ETHERNET 10BASET connector on the back panel of the
DSU RouteFinder. Connect the other end of the cable to your network.
4. Connect one end of an RJ-45 cable to the 56K DSU connector on the back of the DSU
RouteFinder. Connect the other end to your Digital Data Service (DDS) WAN connection.
5. If you plan to use the optional RS232 port for dial backup, connect one end of an RS232
cable to the RS232/V.35 connector on the back panel of the DSU RouteFinder and connect
the other end of the cable to an external DCE device such as a modem or T1/E1 CSU/DSU.
6. Turn on power to the DSU RouteFinder by setting the ON/OFF switch to the ON position.
Wait for the FAIL LED on the DSU RouteFinder to go OFF before proceeding. This may take
a couple of minutes to go OFF.
At this time your DSU RouteFinder is completely cabled. Proceed to Chapter 3 - Software
Loading and Configuration, to load the RouteFinder software.

DSU RouteFinder User Guide
18 MTASR2-201

Chapter 3 - Software Loading and Configuration

DSU RouteFinder User Guide
20
MTASR2-201
Introduction
The following loading procedure does not provide every screen or option in the process of
installing the DSU RouteFinder software. It is assumed that a technical person with a thorough
knowledge of Windows and the software loading process is doing the installation.
Loading Your Software
1 Run Windows on the PC that is connected to the DSU RouteFinder’s Command Port.
2 Insert the RouteFinder Disk 1 into the disk drive on the PC that is connected to the DSU
RouteFinder.
3Win3.1 users - in the Program Manager, access Run by clicking File | Run. In the Run
dialog box, type a:\setup.exe or b:\setup.exe (depending on the letter of your floppy disk
drive) in the Command Line field and then click OK.
Win95/98/NT users - click Start | Run. In the Run dialog box click the down arrow and
choose a:\setup or b:\setup (depending on the letter of your floppy disk drive), then click
OK.
4 When the Welcome screen appears, press Enter or click Next> to continue.
5 Press Enter or click Next> to continue.
