KOD-10 CONVENTIONAL
OPTICAL SOMOKE DETECTOR
INSTALLATION & OPERATING GUIDE

1
Important Warnings
General
✓Before using the device read this manual carefully. Keep it just in case of necessity.
✓Abide all the rules and precautions stated in the manual. Follow all the instructions one by one.
✓Keep the devices away from water and moisture
Conditions
Do not energize the device above or below the given limits of extreme hot or cold conditions,
Temperature: Between -10°C and +55°C
Relative Humidity: %95 RH max
Service
Do not try to fix the device on your own. Removal of cover may end up with electricity shock.
In case of any defect or malfunction, contact with your dealer or with authorized service. All the technical interventions have to be done by
technicians of company.
Malfunctions that require technical service
In case of any malfunction or below conditions contact with your authorized service,
✓When Mains cable or the plug is harmed,
✓Contact of device with a fluid,
✓Exposure of rain and water,
✓Fell down of device or harmed outer cover,
✓Serious performance fall on the device,
✓Depending on the instructions stated in manual, if your device not working properly
Contact with your authorized service in such terms.
Maintenance on your own
Do not try to fix the device on your own. Removal of cover may end up with electricity shock. In case of any defect or malfunction, contact with
your dealer or with authorized service. All the technical interventions have to be done by technicians of company. Device must be cleaned up with a
dry fabric. No-chemicals are allowed for cleaning
Transportation
Device must be carefully transported avoiding all physical bump, stroke and possible fluid entry. Malfunctions that caused by improper transportation
is not under warranty.
Human and Environmental Health
This device contains no chemical or biological elements that could harm human condition.
General Features
✓Advanced smoke detection algorithm that minimizes false alarms
✓Rejection of transient signals that can be detected as alarms
✓Adaptive intelligent protection by constantly sampling the environment
✓Dust algorithm and warning to understand that it is getting polluted and unable to detect
✓Easy to clean smoke chamber
✓Ability to connect an remote indicator
✓Two leds used for status indicators
✓15s start time
✓Compatible with TFA-0120 Universal Detector Base
Technical Features
Power Input
18V(min) –30V(max)
Average Current Consumption
30uA (@24V)
Maximum Alarm Current
50mA (@24V) –(470ohm resistance limited)
Warning: Do not attempt to remove the electronic board from its plastic case. The electronic board is
closed for your safety. Users should avoid from interference.

2
Maximum External Device Current
10mA (@24V) –(2K2 resistance limited)
Operating Temperature Range
-10C ~ +70C (14F ~ 158F)
Humidity
95% RH (max)
Dimensions (mm)
Ø110, h42
Housing Material
White Color, ABS Plastic
Used Cable Cut
0.4mm ² ~ 1.5mm ²
Weight (incl. Base / excluding base)
183 gr / 125 gr
Startup Time
15 sec
Indicator Leds
Blue Led
Red Led
When the unit is first energized for
15 s, while sampling the
environment
Blinks for 5s period
X
Any error condition
(dust or power failure)
Blinks for 1s period
X
In normal operating condition
Blinks for 20s period
X
In alarm condition
X
It is constantly lit
Terminals
Number 1
Negative (-) power input
Number 2
Negatif(-) input of the remote indicator
Number 3
Positive supply out and Positive (+) input of remote indicator
Number 4
Positive (+) power input
Number 5
Earth connection

3
Mounting and Connection
1. Remove the head of the detector by pulling it upwards (2) by turning it (1) up to the short line in the direction of the counterclockwise direction
as seen from the base.
2. Mount the base using the 2 mounting locations shown.
3. Make the cable connection according to the following diagram. Make a connection with pole 4 + pole and pole 1 - by taking pole + number 3
from pole 3 of the next detector.
4. Use the 3 (+) and 2 (-) connections for the remote indicator.
5. Replace the detector head. Make sure the line on the head matches the long line on the base
6. Give the detector power from alarm panel. In the absence of an alarm, the LED on the detector indicates that it is operating with a blue color for
approximately 20 seconds. (the first 15 seconds a blue LED lights up in the detector for 5 seconds).
Test
Smoke Test:
For the smoke test, allow the smoke to enter the smoke detection chamber for at least 1 minute with a flammable material or a test aerosol. When
enough amount of smoke enters the chamber, the LED illuminates and reports the alarm.
1. Remove the smoke source when the alarm condition is reached.
2. Check that the red LEDs are lit continuously. Reset the detector on the panel.
3. If the detector does not give an alarm within 1 minute, the detector should go to service.
4. The system can be activated after the test has been performed.
