Munchkin 360 Cloud User manual

Owner’s Guide
Notice d’utilisation
Manual del propietario
CCD0306000 REV 1
360° Cloud™
Clear seat high chair with 360° swivel
Chaise haute à siège transparent et
pivotant à 360°
Silla alta con asiento transparente
y giratorio a 360°
KEEP FOR FUTURE REFERENCE
Please read the instructions carefully before using this product. Adult Assembly Required.
CONSERVER POUR CONSULTATION FUTURE
Veuillez lire attentivement ces instructions avant d’utiliser ce produit. A monter uniquement par un adulte.
CONSERVAR PARA CONSULTAS FUTURAS
Leer atentamente estas instrucciones antes de utilizar el producto. Requiere montaje por parte de un adulto.

Table of Contents | Table des matières | Índice
2
IMPORTANT SAFEGUARDS
Important Safeguards......................................................................................................................... 5
INCLUDED PARTS
Included Parts....................................................................................................................................... 7
HOW TO USE
How to Assemble.................................................................................................................................8
Seating Your Child ..............................................................................................................................12
Attaching Tray......................................................................................................................................13
How to Clean........................................................................................................................................14
Technical Specications.....................................................................................................................14
CUSTOMER SERVICE
One-Year Limited Warranty ..............................................................................................................15
Contact Us ............................................................................................................................................15
RENSEIGNEMENTS IMPORTANTS
Renseignements importants...........................................................................................................17
PIÈCES INCLUSES
Pièces incluses....................................................................................................................................20
MODE D’EMPLOI
Assemblage..........................................................................................................................................21
Asseoir votre enfant..........................................................................................................................25
Attacher le plateau............................................................................................................................26
Nettoyage............................................................................................................................................27
Spécications techniques ................................................................................................................27
SERVICE À LA CLIENTÈLE
Garantie limitée d'un an...................................................................................................................28
Contactez-nous ..................................................................................................................................28

Table of Contents | Table des matières | Índice Table of Contents | Table des matières | Índice
3
INFORMACIÓN IMPORTANTE
Información importante...................................................................................................................30
PIEZAS INCLUIDAS
Piezas incluidas..................................................................................................................................33
INSTRUCCIONES DE USO
Instrucciones de montaje ................................................................................................................34
Colocación del niño ...........................................................................................................................38
Fijación de la bandeja.......................................................................................................................39
Limpieza...............................................................................................................................................40
Especicaciones técnicas.................................................................................................................40
SERVICIO DE ATENCIÓN AL CLIENTE
Garantía limitada de un año ............................................................................................................41
Contacto................................................................................................................................................41

ENGLISH
ANGLAIS
INGLÉS

Important Safeguards
5
IMPORTANT SAFEGUARDS
WARNING: FALL HAZARD
Children have suffered severe head injuries including skull
fractures when falling from high chairs. Falls can happen suddenly
if child is not restrained properly.
• The child should be secured in the high chair at all times by the
5-point harness. Always use restraints and adjust to t snugly.
• It is recommended that the high chair be used by children
capable of sitting upright unassisted.
• DO NOT leave child unattended during use. Always keep child
in view.
• Do not place the high chair near a counter or table. Your child
may be able to push hard enough against these surfaces to tip
the chair over.
• The tray is not designed to hold the child in the chair.
• Never use or modify high chair to use food tray without the
crotch post in place.
• This product is not intended for sleeping.
• Do NOT move or lift this product with the child inside it.
• Never use the high chair on uneven or reclined ground oor.
• ONLY USE PRODUCT AS INSTRUCTED.
• Check this product for damaged hardware, loose joints, missing
parts or sharp edges before and after assembly and frequently
during use. Do not use high chair unless all components are
correctly tted and adjusted. DO NOT use high chair if any
parts are missing.

Included Parts
Important Safeguards
6
WARNING: Do not use the high
chair unless all components are
correctly tted and adjusted.
Swivel
Latch
AGE REQUIREMENTS
This high chair is suitable for children 6-36 months.
WEIGHT REQUIREMENTS
This high chair is suitable for children under 33 lbs/15 kg.
SWIVEL POSITIONS
Push swivel latch upward on back of support frame, then rotate seat in either direction.
Release swivel latch to lock seat at quarter-turn positions.
Seat swivels 360° for easy on and off-loading, feeding, and interaction in any direction.

Included Parts Included Parts
7
INCLUDED PARTS
NOTE: Seat, Cushion Insert and 5-Point Harness are pre-assembled.
Tray and Insert Lower LegsSupport Frame
5-Point Harness
Cushion Insert
Seat

How to Use
8
HOW TO ASSEMBLE
Seat Lock
Side
Harness
Slot
Swivel
Latch
Strap
Adjuster
Hook
Clip
Strap
Anchor
Harness
Buckle
Support
Frame Foot Rest
Front Harness Slot
Tray
Release
Lever

How to Use How to Use
9
1.ATTACH LEGS TO FRAME
Attach lower legs (A, B, C, D) to
matching upper legs. Screw legs
counter-clockwise until secure.
NOTE: If letters do not match, leg
lengths may differ.
3.ADD CUSHION INSERT
Place (optional) cushion insert onto seat.
NOTE: Cushion insert is recommended
for infants.
NOTE: Seat, Cushion Insert and 5-Point
Harness are pre-assembled.
2.INSTALL SEAT
Push seat posts into support frame
until seat locks click into position.
Be sure seat is securely connected
to frame before using.
To uninstall, press seat locks on
both sides and lift seat.

How to Use
10
4.INSTALL SEAT
The 5-point harness is installed by preset. 5-point harness is recommended for your
child’s full security.
A.Lay lower harness straps across seat with
buckle facing upward. There should be
3 straps (2 side, 1 front) with anchors at
each end.
B.Starting at any end, turn anchor sideways.
Grasp anchor and end of strap together,
then push them through matching slots
in both cushion insert and seat. There are
2 side slots and 1 front slot.
C. Once anchor is through, atten it
against outside of seat to prevent strap
from retreating.
Repeat for anchors on remaining straps.

How to Use How to Use
11
D.Lay upper harness straps on seat. There
should be 2 side straps with anchors and
a pair of Y-straps with hook clips.
E.Strap adjusters on Y-straps should face back
of seat when straps are held straight up.
F.Turn anchor sideways and route through side
slot in cushion insert and seat. Use same slot
as for lower harness side strap, but BEHIND
that strap.
G.Flatten anchor against outside of seat to
prevent strap from retreating.
Repeat for anchor on other side. Y-straps do
not need to be attached to seat.

How to Use
12
SEATING YOUR CHILD
A.Unbuckle side straps by pressing harness
buckle release button. Place child in seat,
then re-connect side straps to harness
buckle.
B.Use strap adjusters to lengthen or shorten
straps, if necessary. All straps should be
snug against your child’s body but not
too tight.
C.After connecting lower strap buckles in
previous step, pull upper harness Y-straps
over your child’s shoulders and down to
harness buckle.
D.Use strap adjusters to lengthen or shorten
straps, if necessary. All straps should be
snug against your child’s body but not
too tight.
NOTE: Upper harness Y-straps should go
over your child’s shoulders like suspenders.
Attach hook clips to rings on harness
buckle. Check that Y-straps are not twisted
behind your child’s back.

How to Use How to Use
13
ATTACHING TRAY
IMPORTANT: Always secure child using harness when seated in chair.
Align grooves on underside of tray with
sides of seat.
Pull release levers on both sides of tray
outward, then slide tray toward seat until
it locks into place. There are two tray
positions.
To remove tray, pull release levers on both
sides and then slide tray out.
Tray has detachable insert for easy
cleaning. Simply lift to remove.

Customer Service
How to Use
14
HOW TO CLEAN
SURFACES
Wipe seat, tray, harness and frame using a damp sponge. Wipe dry.
CUSHION INSERT
Wipe with clean damp cloth, Do not bleach, Air-dry, Do not iron, Do not machine wash
or dry.
TRAY AND INSERT
Dishwasher safe.
TECHNICAL SPECIFICATIONS
• Product Name: 360° Cloud™
• Model: MCKA0817 REV1
• Dimension: Length 28" (71 cm), Weight 28" (71 cm) , Height 40" (102)
• Weight: 16 lbs. (7.2 kg)

Customer Service Customer Service
15
How to Use
ONEYEAR LIMITED WARRANTY
Munchkin’s High chair includes a 1-year limited warranty against defects from the date
of purchase. In the event of a malfunction or defect during the in-warranty period,
Munchkin, Inc. at its option, will replace or repair the product under warranty. Upon
receipt of the product and proof of purchase with a valid date of purchase, the defective
part will be immediately repaired or replaced and returned to you free of charge (USA
only). Please send defective unit, proof of purchase and a description of the problem you
have encountered to:
Munchkin, Inc.
7835 Gloria Avenue
Van Nuys, CA 91406, USA
Attn: High chair Warranty
NOTE: This warranty does not cover misuse, abuse, abnormal wear & tear, negligence,
environmental exposure, alteration or accident. Any alteration or removal of the product
date code invalidates all claims against the manufacture.
CONTACT US
If you have any questions or wish to provide comments about this product, feel free to
contact our Customer Satisfaction team at 1-800-344-BABY (2229) (M-TH 8:00am- 5:00pm
PST, F 8:00am-1:00pm PST) or visit our website at www.munchkin.com.

Table of Contents | Table des matières | Índice
Renseignements importants
FRENCH
FRANÇAIS
FRANCÉS

Table of Contents | Table des matières | Índice Table of Contents | Table des matières | Índice
17
Renseignements importants Renseignements importants
PRÉCAUTIONS IMPORTANTES
MISE EN GARDE: DANGER
DE CHUTE
Des enfants ont subi de graves blessures à la tête, notamment
des fractures du crâne, en tombant de chaises hautes. Les
chutes peuvent se produire soudainement si l'enfant n'est pas
correctement attaché.
• L'enfant doit être attaché à tout moment sur la chaise haute par
le harnais à 5 points. Utilisez toujours des dispositifs de retenue
et ajustez-les de façon à ce qu’ils soient bien ajustés.
• Il est recommandé que la chaise haute soit utilisée par des
enfants capables de s'asseoir sans aide.
• Ne laissez pas l’enfant sans surveillance pendant l’emploi.
Restez à proximité et surveillez l'enfant pendant l'utilisation.
• Ne placez pas la chaise haute près d'un comptoir ou
d'une table. Votre enfant pourrait être capable de pousser
sufsamment fort contre ces surfaces pour faire basculer
la chaise.
• Le plateau n’est pas conçu pour retenir l’enfant dans la chaise.
• N’utilisez jamais ou ne modiez jamais une chaise haute pour
utiliser un plateau de nourriture sans que la tige d’entrejambe
ne soit en place.
• Ce produit ne doit pas être utilisé pour dormir.
• Ne déplacez PAS et ne soulevez PAS ce produit pendant que
l'enfant est à l’intérieur.
• N’utilisez jamais la chaise haute sur un sol inégal ou incliné.

Table of Contents | Table des matières | Índice
18
Renseignements importants
MISE EN GARDE: N'utilisez pas
la chaise haute si les composants
ne sont pas tous correctement
assemblés et ajustés.
• N’UTILISEZ LE PRODUIT QUE SELON LES INSTRUCTIONS.
• Avant et après l'assemblage et fréquemment pendant
l'utilisation, vériez que ce produit ne comporte pas de matériel
endommagé, de joints desserrés, de pièces manquantes
ou de bords tranchants. N'utilisez pas la chaise haute si les
composants ne sont pas tous correctement assemblés et
ajustés. N'utilisez pas la chaise haute s'il manque des pièces.
EXIGENCES EN MATIÈRE D’ÂGE
Cette chaise haute convient aux enfants de 6 à 36 mois.
EXIGENCES EN MATIÈRE DE POIDS
Cette chaise haute convient aux enfants de moins de 33 lbs/15 kg.

Table of Contents | Table des matières | Índice Table of Contents | Table des matières | Índice
19
Renseignements importants Renseignements importants
POSITIONS DE PIVOTEMENT
Poussez le loquet de pivotement vers le haut à l'arrière du cadre de support, puis faites
pivoter le siège dans un sens ou dans l'autre.
Déverrouillez le loquet de pivotement pour verrouiller le siège en position quart de tour.
Le siège pivote à 360° pour faciliter l'embarquement et le débarquement, l'alimentation
et l'interaction dans toutes les directions.
Loquet de
pivotement

Mode d’emploi
Pièces incluses
20
PIÈCES INCLUSES
REMARQUE : Le siège, le coussin et le harnais à 5 points sont préassemblés.
Plateau et plateau
encastrable
Pattes inférieuresCadre de support
Harnais à 5 points
Coussin
Siège
