mundoclima MU-EMP 09 User manual

Before using this unit, please read
these instructions completely.
WIRING DIAGRAM
TECHNICAL PARAMETER
MAINTENANCE PRECAUTIONS
1. First, ensure that the air curtain is switched off.
2. Never use petrol, benzene, thinner or any other such chemicals for
cleaning the air curtain.
3. Do not allow water to contact electrical parts such as motor or switch.
4. Do not immerse impeller and other plastic parts in hot water over 60°C.
WARNING
If the product is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
NOTE: Rated voltage and frequency are stated as per rating label .
BLUE
GREEN
C
BLUE
GREEN
C
YELLOW/GREEN
M2M1
RED
BLACK(HI)
GRAY(LOW)
WHITE(MED)
BROWN
BLUE
IC SWITCH
IC
Model No .
Power (W) Air Volume
3
(m /h)
Noise (dB / A) Net Weight
(kg)
MU-EMP 09
Air Speed (m/s)
295
360
455
1020
1360
1700
17.2
20.9
28.0
HI MED LOW
15
HI MED LOW
54
56
53
HI MED LOW
217
272
333
175
235
272
12.5 10 53
54
52
51
53
50
MU-EMP 12
MU-EMP 15
Codes EC06467 to EC06469
English
SPEED
RECEIVER
HI
ON / OFF
MED LOW
IN-CEILING TYPE AIR CURTAIN
OPERATING INSTRUCTIONS

PRODUCT COMPARISON
EXTERNAL DIMENSION
Fig.3 Fig.4
INSTALLATION
There are 2pcs hooks (totally 4pcs) on the side board, installation information
as below (Attention: outlet should near the door direction):
Model No . A B C
1530
1230
1300
1000
1500
1200
Units: mm Units: mm
OPERATION
Below instructions could be carried out when electric power supply and
proper installation are ensured.
(Fig. 5)
(Fig. 6)
Operation of with remote controller:
1. Working with remote controller:
Operate the remote controller towards the receiver box. When it is 6 meter
(within 60 angle) away from the air curtain, press the "on/off" button for
high setting (default); Press "high/mid/low" for options of high/mid/low air
speed. Now the indicator light of high/mid/low flashes. Press "on/off" to
turn the unit off.
2. Working with receiver box:
Press "on/off" and "high/mid/low" for options of on, off and air speed.
SPEED ON/OFF
Fig.5
230
310
196
360
340
A
12
394
B
C
SPE ED
RECEIVER
HI
ON / OF F
MED LOW
Fig.6
M10
Suspension
Rod
Hexagon Nut
Fig.1 Fig.2
Hook
INSTALLATION CAUTIONS
1. Application environment: (a) 1000 meters below sea level; (b) Ambient
temperature between -10°C ~ 40°C; (C) Ralative Humidity 90%.
2. Please mounted the air curtain to the solid place, to ensure the safety when
there is vibration during operation. If the air curtain is installed indoors,
please make sure the installation height should be above 2.3 meters from
the ground.
3. Please do not install the air curtain in the environment of high temperature
or high humidity or exposure gas or corrosive materials.
≤
Recessed Air Curtains are designed for indoor ceiling fitment, supplement
the technical defect for the normal air curtains are installed for ceiling
fitment as well as energy-saving.
Indoor
Ceiling
Outdoor
Exhaust Gas Clean Air
Clean Air
Indoor
Ceiling
Exhaust Gas
Outdoor
MU-EMP 12
MU-EMP 15
Model No . A B C
930 700
900
MU-EMP 09
In-ceiling air curtain
Normal air curtain
