Munters Farm Center Pro Instruction manual

Manual for use and maintenance
Farm Center Pro, Farm Master Pro
Controllers
Ag/MIS/UmGB-2288-10/15 Rev. 1.2
P/N: 110504
Farm Center
Pro / Farm
Master Pro

© Munters AB, 2015 2
Farm Center Pro, Farm Master Pro
Manual for use and maintenance
Revision
: N.1.2 of 12/2016
Product Software
: 2.0
This manual for use and maintenance is an integral part of the apparatus together with the attached
technical documentation.
This document is destined for the user of the apparatus: it may not be reproduced in whole or in part,
committed to computer memory as a file or delivered to third parties without the prior authorization of the
assembler of the system.
Munters reserves the right to effect modifications to the apparatus in accordance with technical and legal
developments.

© Munters AB, 2015 3
Index
chapter page
1
INTRODUCTION
----------------------------------------------------------------------------------------
6
1.1 Disclaimer
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
6
1.2 Introduction
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
6
1.3 Notes
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
6
2
PRECAUTIONS
------------------------------------------------------------------------------------------
7
2.1 Grounding
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
7
2.2 Checking the Battery Level
--------------------------------------------------------------------------------------------------------------------------------------------
7
2.3 Filtering
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
7
2.4 Frequency Inverters
------------------------------------------------------------------------------------------------------------------------------------------------------------
7
3
BEFORE USING
-----------------------------------------------------------------------------------------
8
3.1 Components
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------
8
3.2 General Description
----------------------------------------------------------------------------------------------------------------------------------------------------------
8
3.2.1 Farm Center Pro............................................................................................................................... 8
3.2.2 Farm Master Pro.............................................................................................................................. 8
3.3 Features
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
9
3.4 Network Diagrams
---------------------------------------------------------------------------------------------------------------------------------------------------------
10
3.5 Farm Center Pro Keyboard
----------------------------------------------------------------------------------------------------------------------------------------
11
3.6 Farm Center Pro Main Screen
----------------------------------------------------------------------------------------------------------------------------------
12
3.7 Main Menu
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------
13
4
MECHANICAL INSTALLATION GUIDE
-----------------------------------------------------------
15
4.1 Environmental Protection
---------------------------------------------------------------------------------------------------------------------------------------------
15
4.2 Sensors and Shielded Wiring
-----------------------------------------------------------------------------------------------------------------------------------
15
4.3 Installation and Electrical Connections
---------------------------------------------------------------------------------------------------------------
16
4.4 Farm Center Pro/Farm Master Pro Wiring Diagrams
--------------------------------------------------------------------------------
16
4.5 Dip Switch Configuration
--------------------------------------------------------------------------------------------------------------------------------------------
23
5
TECHNICAL SPECIFICATIONS
---------------------------------------------------------------------
24
6
CONTROL MENU
------------------------------------------------------------------------------------
25
6.1 Temperature Curve
---------------------------------------------------------------------------------------------------------------------------------------------------------
25
6.2 Minimum / Maximum Levels
------------------------------------------------------------------------------------------------------------------------------------
26
6.2.1 Day.................................................................................................................................................... 26

© Munters AB, 2015 4
6.2.2 Time................................................................................................................................................... 27
6.2.3 Soft Minimum / Maximum by Day ....................................................................................... 27
6.2.4 Soft Minimum / Maximum by Time ...................................................................................... 28
6.2.5 Maximum Cold, Warm by Day.............................................................................................. 28
6.2.6 By Weight....................................................................................................................................... 29
6.3 Humidity
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
30
6.4 Static Pressure
--------------------------------------------------------------------------------------------------------------------------------------------------------------------
31
6.5 Heaters
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
32
6.6 Cool Pad
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
33
6.7 Fogger Pad
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------
33
6.8 Light
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
34
6.9 Feeding Schedule
------------------------------------------------------------------------------------------------------------------------------------------------------------
34
6.10 Timers
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
35
6.11 Extra System
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
35
7
MANAGEMENT MENU
-----------------------------------------------------------------------------
36
7.1 Alarm Reset
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------
36
7.2 Animal Inventory
--------------------------------------------------------------------------------------------------------------------------------------------------------------
36
7.3 Day & Group
---------------------------------------------------------------------------------------------------------------------------------------------------------------------
37
7.4 Alarm Setting
----------------------------------------------------------------------------------------------------------------------------------------------------------------------
37
8
HISTORY MENU
--------------------------------------------------------------------------------------
39
8.1 Temperature
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
39
8.2 Humidity
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
39
8.3 Water
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
40
8.4 Feed
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
40
8.5 Mortality
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
40
8.6 Heater
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
41
8.7 Alarm
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
41
8.8 Event
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
42
9
SYSTEM MENU: VENTILATION LEVELS
-----------------------------------------------------------
43
9.1 Ventilation Levels
--------------------------------------------------------------------------------------------------------------------------------------------------------------
43
9.2 Variable Fan Levels
---------------------------------------------------------------------------------------------------------------------------------------------------------
45
9.3 Curtain Levels
---------------------------------------------------------------------------------------------------------------------------------------------------------------------
46
9.4 Stir Fan
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
46
10
SYSTEM MENU: CALIBRATION
--------------------------------------------------------------------
47
10.1 Temperature
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
47
10.2 Humidity
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
47
10.3 Static Pressure
--------------------------------------------------------------------------------------------------------------------------------------------------------------------
48

© Munters AB, 2015 5
10.4 Water and Feed
---------------------------------------------------------------------------------------------------------------------------------------------------------------
48
11
SYSTEM MENU: INSTALLATION
-------------------------------------------------------------------
49
11.1 Relay Layout
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------
49
11.2 Analog Sensors Layout
-------------------------------------------------------------------------------------------------------------------------------------------------
50
11.3 Digital Input
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------
50
11.4 Analog Output
-------------------------------------------------------------------------------------------------------------------------------------------------------------------
51
11.5 Variable Speed Fan
-------------------------------------------------------------------------------------------------------------------------------------------------------
51
11.6 Temperature Definition
--------------------------------------------------------------------------------------------------------------------------------------------------
51
11.7 Curtain Setup
----------------------------------------------------------------------------------------------------------------------------------------------------------------------
52
11.8 Fan Air Capacity
--------------------------------------------------------------------------------------------------------------------------------------------------------------
53
11.9 About
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
53
12
FARM MASTER PRO FUNCTIONS
-----------------------------------------------------------------
54
12.1 Cold Start
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
54
12.2 Set Unit Number
---------------------------------------------------------------------------------------------------------------------------------------------------------------
54
12.3 Main Menu
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------
54
12.4 Calibration
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------
54
12.4.1 Temperature Sensor Calibration............................................................................................. 54
12.4.2 Calibration Procedure ................................................................................................................ 54
12.5 Test
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
55
13
WARRANTY
--------------------------------------------------------------------------------------------
56

© Munters AB, 2015 6
1Introduction
1.1 Disclaimer
Munters reserves the right to make alterations to specifications, quantities, dimensions etc. for production
or other reasons, subsequent to publication. The information contained herein has been prepared by
qualified experts within Munters. While we believe the information is accurate and complete, we make no
warranty or representation for any particular purposes. The information is offered in good faith and with
the understanding that any use of the units or accessories in breach of the directions and warnings in this
document is at the sole discretion and risk of the user.
1.2 Introduction
Congratulations on your excellent choice of purchasing an Farm Center Pro/Farm Master Pro!
In order to realize the full benefit from this product it is important that it is installed, commissioned and
operated correctly. Before installation or using the fan, this manual should be studied carefully. It is also
recommended that it is kept safely for future reference. The manual is intended as a reference for
installation, commissioning and day-to-day operation of the Munters Controllers.
1.3 Notes
Date of release: July 2010
Munters cannot guarantee to inform users about the changes or to distribute new manuals to them.
NOTE All rights reserved. No part of this manual may be reproduced in any manner whatsoever
without the expressed written permission of Munters. The contents of this manual are subject to
change without notice.

© Munters AB, 2015 7
2Precautions
•Grounding
•Checking the Battery Level
•Filtering
•Frequency Inverters
2.1 Grounding
•Always connect temperature and sensor shields to earth ground. Avoid mixing high voltage
wiring with sensor and low voltage wiring.
•Keep the controller as far as possible from heavy contactor boxes and other sources of
electrical interference.
•Do not connect communication wire shields, which go from one house to another at both ends.
Connect them at one end only. Connection at both ends can cause ground loop currents to
flow, which reduce reliability.
•The COM connection for communications is not the shield wire. The COM, RX and TX wires
must connect to each other at all controllers.
2.2 Checking the Battery Level
Check the battery once a year. The output must be 2.7 volts (minimum). Authorized personnel only must
replace the battery if the output is below the minimum required level or every five years.
2.3 Filtering
If this installation includes a power inverter to drive variable speed fans, install an EMI filter in front of the
inverter, according to the specifications provided by the inverter manufacturer. Referto the inverter
documentation.
2.4 Frequency Inverters
Frequency inverters can cause severe electrical and electromagnetic interference. Therefore, when
employing a frequency inverter, it is critical that you carefully follow the manufacturer's installation
instructions.
In particular verify:
•that the cable shielding between the inverter and any motor meets industry standards
•proper grounding of the inverter's chassis and motor power cable
•proper grounding of low voltage cable shield wire
•that the controller and inverter cables are kept in separate conduits or wire bundles

© Munters AB, 2015 8
3Before using
The following section provides an introduction to the Farm Center Pro / Farm Master Pro Climate Controller
units.
•Components
•General Description
•Features
•Network Diagrams
•Farm Center Pro Keyboard
•Farm Center Pro Main Screen
•Main Menu
3.1 Components
•Farm Center Pro
•Farm Master Pro
•Extension Box (optional)
•Farm Communication 485 Communication / Farm Guard (optional)
3.2 General Description
•Farm Center Pro
•Farm Master Pro
3.2.1 FARM CENTER PRO
Farm Center Pro provides you maximum capability with minimal complexity in programming and
controlling up to 10 Farm Master Pro units.
Farm Center Pro is the ultimate pig house controller. Equipped with an easy programming interface, it
provides programmable outputs for all major features and an advanced graphic user interface that
provides simple, fast navigation, informative main screen, display feedback on the programming and
device status.
The Farm Center Pro communicates with up to ten Farm Master Pro units to access history, collect events
and alarms for each and all relevant data up to 100 days.
3.2.2 FARM MASTER PRO
Farm Master Pro is Munters’s latest advance in environmental controllers specially designed for the pig
house industry.
The user-friendly has high performance and quick response time. Farm Master Pro features accurate
temperature and humidity sensors, secure transmission of data even in noisy environments and the added
convenience of eight output relays as well as four analog outputs.

© Munters AB, 2015 9
Each Farm Master Pro can operate independently in case of Farm Center Pro malfunction or loss of
power. Using an internal battery when the Farm Master Pro is operating “alone”, there is no history
collection or possibility to change parameters.
There are three Farm Master Pro models:
•
5020
: No variable speed
•
5021
: One channel variable speed
•
5022
: Two channels variable speed
3.3 Features
•Farm Center Pro
oEasy programming
oGraphic user interface screens
oPositioning scrollbar
oSwift device and feature selection
oUSB data port
oLarge numeric keypad
oCommunication with up to ten Farm Master Pro units
oExtensive history of events & alarms
oData collection
oReal time visual outlook
oAlarm system (for every Farm Master Pro unit)
oMulti language Support
oPC communication
•Farm Master Pro:
oEasy programming
oProgrammable outputs
oAlarm system
oLarge display
oUp to 4 temperature sensors
oUp to 8 heavy duty relays (1 HP)
oOn/Off/Auto override switches
oStatic pressure control (optional)
o4 analog outputs (0 - 10 volts)
oVariable speed fan output with bypass
oWater, feed, and humidity control
oAutomatic calibration of curtains

© Munters AB, 2015 10
3.4 Network Diagrams
The following diagrams illustrate sample Farm Center Pro – Farm Master Pro networks.
Figure 1: Farm Center Pro – Farm Master Pro – MUX Network
Figure 2: Farm Center Pro – Farm Master Pro – Farm Guard Network
