CONTENTS
chap. Subject covered page 1 GENERAL INFORMATION 10 1.1. Purpose of this manual 10 1.2. General safety informations 10 1.3. Symbols 11 1.4. Warranty Booklet and Service Coupons 12 1.5. Identification data 13 2 SAFETY INFORMATION 22 2.1. Safety 22
2.1.1. How to report a safety-related defect 22 2.1.2 Noise emission warranty 22
2.1.3. Note on tampering 23
2.1.4. Information on the emission control
system 24
2.1.5. Safe riding 25 2.1.6. Maintaining your motorcycle 27 2.1.7. Before you ride 28 2.1.8. While you ride 29 2.1.9. After you ride 32 2.1.10. Installing accessories 33 2.1.11. Vehicle load 34
chap. Subject covered page 2.1.12. Modifications 36 2.1.13. Competitions 36 2.1.14. Customer satisfaction 36 2.1.14. Suggestions against theft 37 2.2. Safety labels - Location 38 2.3. Safety - Visual and acoustic signals 46 3 CONTROLS AND INSTRUMENTS 47 3.1. Location of controls and instruments 47 3.2. Kickstand 49 3.3. Handlebar controls, left side 50 3.4 Handlebar controls, right side 52 3.5. Ignition switch and steering lock 55 3.6. Gear lever 59 3.7. Instruments and warning lights 60 3.7.1. Warning lights 61 3.7.2. Generaldisplay/GearandWaterTemperatureDisplay 62 4 OPERATION 63 4.1. Using the motorcycle 63 4.2. Break-in 64 4.3. Starting the engine 66

- 5 -
CONTENTS
chap. Subject covered page
5.7. Adjusting the front suspension 112 5.7.1. Spring preload 113 5.7.2. Rebound damper (front suspension) 113 5.7.3. Compression damper (front suspension) 114 5.8. Adjusting the rear suspension 115 5.8.1. Rebound damper (rear suspension) 116 5.8.2. High speed compression damper (rear suspension) 117 5.8.3. Low speed compression damper (rear suspension) 117 5.9. Headlight adjustment 118 6 MAINTENANCE 120 6.1. Tables of scheduled maintenance and checks 120 6.2. Tools and accessories supplied 130 6.3. Table of lubricants and fluids 131 6.4. Checking the engine oil level 132 6.4.1. Topping up the engine oil level 133
6.5.
Checking the coolant level
135
6.5.1.
Topping up the coolant level
136
6.6. Checking the wear of the brake pads 138 6.7. Checking the brake fluid level 139 6.8. Checking the clutch fluid level 141
chap. Subject covered page 4.4. Selecting and setting the display functions 70 4.4.1. Selecting the display functions 71 4.4.2. Trip reset 75 4.4.3. How to set the measurement units 79 4.4.4. Chronometer 81 4.4.5. TC Mode 89 4.4.6. IMMOBILIZER Mode 90 4.4.7. How to select the mapping of the control unit 93 4.4.8. Warning/malfunction alerts 94 4.5. Refuelling 97 4.6. Glove compartment 99 4.7. Parking the motorcycle 100 4.8. Checks to be performed before riding 103 5 ADJUSTMENTS 105 5.1. List of adjustments 105 5.2. Table of adjustments 108 5.3. Adjusting the front brake lever 109 5.4. Adjusting the clutch lever 109 5.5. Adjusting the rearview mirrors 110 5.6. Adjusting the steering vibration damper 111

- 6 -
CONTENTS
chap. Subject covered page 6.9. Checking and replacing the tires 142
6.10. Checking and lubricating the drive chain 147 6.11. Checking the idle speed 151
6.12. Periodic emission check 152 6.13. Evaporative emission control system 153 6.14. Emission control system warranty
obligations (for U.S.A. only) 154
6.14.1 Your warranty rights and obligations 154 6.14.2 Manufacturer’s warranty coverage 154 6.14.3 Owner’s warranty responsibilities 155 6.15. Limited warranty on emission control
system (for U.S.A. only) 156
6.15.1 Coverage 156 6.15.2 Limitations 157 6.15.3 Limited liability 158 6.15.4 Legal rights 159 6.15.5 Additional information 159
6.16. Replacing parts - General information 160 6.16.1. Replacing the fuses 160 6.16.2. Replacing the low beam bulb 163
6.16.3.
Replacing the high beam bulb
166
chap. Subject covered page
6.16.4. Replacing the license plate light bulb 167 6.17. Battery 168 6.18. Cleaning the motorcycle 170 6.19. Prolonged inactivity 173 7 TROUBLESHOOTING FLOW CHART 174 7.1. Engine problems 174 7.2. Electrical equipment problems 179 8 TECHNICAL INFORMATION 182 8.1. Motorcycle overview 182 8.1.1. Front brake system 184 8.1.2. Rear brake system 185 8.1.3. Clutch system 186 8.1.4. Engine lubrication 187 8.1.5. Coolant system 188 8.1.6. Fuel system 189 8.2. Specifications 190 8.3. Measure equivalence tables for American
and metric systems 197

- 7 -
INDEX
A BD
C
Accessories – installation 33 Adjustments – clutch lever 109 – front brake lever 109 – front suspension 112 – headlight 118 – list 105 – rear suspension 115 – rearview mirrors 110 – steering vibration damper 111 – table 108 Battery 168 Brakes – fluid level, check 139 – front brake system 184 – front brake lever, adjustment 109 – pads, wear check 138 – rear brake system 185 Break-in 64 Bulbs, replacement of – high beam 166 – license plate light 167 – low beam 163
Chain, check 147 – lubrication 149 Cleaning the motorcycle 170 Clutch – fluid level, check 141 – lever, adjustment 109 – system 186 Competitions 36 Controls and instruments, location 47 Coolant – level, check 135 – system 188 – topping up 136 Damper – compression (front suspension) 114 – high speed compression (rear suspension) 117 – low speed compression (rear suspension) 117 – rebound (front suspension) 113 – rebound (rear suspension) 116 Display, general 62 – selecting and setting functions 69 Electrical equipment – troubleshooting 179
E

- 8 -
INDEX
P
H
F
G
M
I
K
L
Emissions, control system 24 – control system warranty 154 – periodic check 152 Engine – lubrication 187 – oil level, check 132 – oil level, topping up 133 – serial number 13 – starting 66 – troubleshooting 174 Fuel system 189 Fuses, replacement 160 Gear lever 59 Glove compartment 99 Handlebar controls – left side 50 – right side 52 Headlight, adjustment 118 – high beam, bulb replacement 166 – low beam, bulb replacement 163
Identification data 13 Idle speed, check 151 Ignition switch and steering lock 55 Instruments and warning lights 60 Kickstand 49 Levels – brake fluid 139 – clutch fluid 141 – coolant 135 – engine oil 132 License plate light – bulb replacement 167 Location of controls and instruments 47 Lubricants and fluids, table 131 Maintenance and checks – tables 120 Motorcycle overview 182 Parking 100 Pre-ride checks 103

- 9 -
INDEX
R
S
T
V
W
Prolonged inactivity 173 Purpose of manual 10 Rearview mirrors, adjustment 110 Refuelling 97 Replacing parts, general information 160 Safety 22 – labels, location 38 – safe riding 25 – visual and acoustic signals 46 Scheduled maintenance tables 120 Specifications 190 Spring preload 113 Suspensions – front, adjustment 112 – rear, adjustment 115 Symbols 11 Tampering, note 22 Tires, check 142 – puncturing 143 – replacement 144 Tools and accessories supplied 130
Topping up – coolant 136 – engine oil 133 Troubleshooting flow chart – electrical equipment 179 – engine 174 Vehicle – identification number 13 – load 34 – modifications 36 Warning lights 61 Warranty – Booklet, Service Coupons and Dealers’
Guide 12
– emission control system 154

GENERAL INFORMATION 1
11.1. Purpose of this manual
Carefully read, understand and follow the instructions given in this manual. It is an essential part of the motorcycle as is intended to familiarize you with the controls, characteristics and features of the motorcycle. Keep it in a safe place for future reference. If you sell your motorcycle, please deliver this manual to the new owner. 1.2. General safety information
WARNING: Failure to follow the warnings and instructions provided in this manual could result in an accident, personal injury or death.
a. Throughout this manual, reference is made that “an acci- dent” could occur. Any accident could result in damage to your motorcycle or its components, and more importantly, cause you or a bystander to sustain severe personal injury or death. b. If you have any questions regarding the care, use or main- tenance of your motorcycle, please contact your nearest MV Agusta dealer. A list of dealers can be found in the World Dealer guide provided with this manual.
- 10 -
EN

- 11 -
GENERAL INFORMATION 1
1
EN
1.3. Symbols The words and symbols used below are used to help you recognize information that is important to your safety.
DANGER: Indicates an imminently haz- ardous situation which, if not avoided, will result in death or serious injury. WARNING: Indicates a potentially haz- ardous situation which, if not avoided, could result in death or serious injury. CAUTION: Indicates a potentially haz- ardous situation which, if not avoided, may result in minor or moderate injury. CAUTION: Used with a different alert symbol indicates potentially hazardous situation which, if not avoided, may result in property damage.
NOTE: Indicates important information rel- evant to the motorcycle, motorcycle use or to the sections of this documentation to which particular attention must be paid.
The following symbols give an indication of who is supposed to perform the different adjustments and/or maintenance operations:
Information on operations that can be carried out by the user. Information on operations that are sug- gested to be performed by your autho- rized MV Agusta dealer.
The following symbol is used to provide further information:
The “ ” symbol points out the requirement to use a tool or a special equipment in order to correctly perform the described operation.

- 12 -
GENERAL INFORMATION 1
1
EN
1.4. Warranty Booklet and Service Coupons Besides this Owner’s Manual, the vehicle is accompanied by the following documents: a Warranty Booklet containing a Warranty and Pre-Delivery Certificate and recommended ser- vice coupons, and the MV Agusta Dealers’ Guide. IMPORTANT (for U.S.A. only) The copy of the Warranty and Pre-Delivery Certificate to be sent to MV Agusta must be filled in by the dealer and returned to MVAgusta USAwithin 10 days from the date of registration. Every time the vehicle is serviced by a dealer, the user must produce the Warranty Booklet so that the dealer can fill in the service coupon and return it to MV Agusta USA within 10 days from the date of the servicing. IMPORTANT (for Canada only) The copy of the Warranty and Pre-Delivery Certificate to be sent to MV Agusta must be filled in by the dealer and returned to Motovan Corporation - MV Agusta Canada within 10 days from the date of registration. Every time the vehicle is serviced by a dealer, the user must produce the Warranty Booklet so that the dealer can fill in the service coupon and return it to Motovan Corporation - MVAgusta Canada within 10 days from the date of the servicing.

- 13 -
GENERAL INFORMATION 1
1
EN
1.5. Identification data 1) vehicle identification number 2) engine serial number
Motorcycle identification
The motorcycle is identified by the vehicle identi- fication number. When placing orders for spare parts, in addition to this number, you may be required to provide the engine serial number, the color code and the key identification.
We recommend writing down the main numbers in the spaces provided below. VIN No.: ENGINE No.:
2) engine serial number
1) vehicle identification number

- 14 -
GENERAL INFORMATION 1
1
EN
ZCG JD F V U X Y V 000000
Manufacturer’s Letter Code
Motorcycle Type
Progressive vehicle number
Here below you can find a description of a vehicle identification number: The vehicle identification number must be provided each time you need to contact the MV Agusta Technical Assistance Service, in order to guarantee the traceability of your motorcycle.

- 15 -
GENERAL INFORMATION 1
1
EN
Motorcycle key identification
Akey is supplied in duplicate for both the ignition and all the locks. Keep the duplicate in a safe place. It is essential to provide the key identification number if you place an order for a spare motorcycle key . The key identification number is located on the MV Code Card equipped with the ignition keys.

- 16 -
GENERAL INFORMATION 1
1
EN
1
2
5
4
8
9
7
3
6
6
10

GENERAL INFORMATION 1
1
Bodywork parts reference colors
Bodywork parts are painted with the following reference colors, according to the corresponding motorcy- cle color combination (see page 20):
- 17 -
EN
7. - Fuel tank:
Color combination A:
F4 AGO Red Painting (Cod. Palinal 926R750) + F4AGO Silver Painting (Cod. Palinal 928XV025) Color combinations B-E: CRCIntenseBlackPainting (Cod.Palinal929R486H)+ CRC Pearly White (Code Palinal 927.PE20) Color combination C: CRCIntenseBlackPainting(Cod.Palinal929R486H)+ “Senna”MetalAntracitePainting(Cod.PPGGMWA9561)
Color combination F:
Titanium Grey (Code Palinal L821) + F4AGO Silver Painting (Cod. Palinal 928XV025)
1. - Rear right side panel; 2. - Rear left side panel; 3. - Right side panel tank; 4. - Left side panel tank:
Color combinations A-D-F: F4AGO Silver Painting (Code Palinal 928XV025) Color combinations B-E: CRC Pearly White (Code Palinal 927.PE20) Color combination C: “Senna”MetalAntracitePainting(CodePPGGMWA9561)
8. - Radiator protection right; 9. - Radiator protection left;
10. - Instrument panel cover;
Carbon Grey Metalized (Code Palinal L921)
5. - Front mudguard; 6. - Airbox side panels:
Color combinations A-D: F4AGO Red Painting (Code Palinal 926R750) Color combinations B-C-E: CRCIntenseBlackPainting(CodePalinal929R486H) Color combination F: Titanium Grey (Code Palinal L821)

- 18 -
GENERAL INFORMATION 1
1
EN
12
9
5
410
7
8
3
6

- 19 -
GENERAL INFORMATION 1
1
EN
Frame parts reference colors
Frame parts are painted with the following reference colors:
1. - Frame:
Color combinations A-B-C: B5 Matt Bronze Painting (Code Palinal 211F297) Color combinations D-E: MV Anthracite Grey Metalized (Code Palinal 211XH893) Color combination F: Frame Red (Code Palinal 211XH987)
2. - Headlight holder:
Color combinations A-B-C:
B5Matt Bronze Painting (CodePalinal211F297) Color combinations D-E-F: MV Anthracite Grey Metalized (Code Yi-Mei AC MAT Black Silver)
6. - Right frame side plate; 7. - Left frame side plate; 8. - Rear swingarm:
Carbon Grey Metalized
(Code Akzo Nobel RPU MIC 09 BP 1663/5)
4. - Tail piece; 5. - Steering base:
Carbon Grey Metalized
(Code Palinal L921)
3. - Engine:
Matt Black Painting (Code Pulverit 3500/0085)
9. - Right side rear footrest support;
10. - Left side rear footrest support:
Fine Grey Metalized Aluminium Painting (Code Palinal F444)
