MWf Spark Gold Nugget User manual

Metal and Water Finder
User’s Manual

Page
Metal and Water Finder
Contents
1
Contents
Technical specification
Safety information
Device parts
Interfaces and components of Device
Overview
Assembly
Setup wizard
Page 1
Page 2
Page 3
Page 5
Page 7
Page 8
Page 10
Page 11
Start searching Page 13
Notes Page 17

The user must practice before starting the detecting operations and
discoveries
Store in Cool and dry place 15-40 C 5%-75% humidity Read & Understand
The User's manual
before using this device
Page
Safety information
2
The operating in high voltage areas
would limit the results and
performance
Don't operate two devices with
same method of search at the
same place
The operator Must remove any
metals that might affect the
opreatin eg:Rings,watch, belt....
Any attempt to tamper the device
or unapproved maintenance
would void the warranty
For best power endurance and
reliability. use heavy duty and high
quality batteries thats for the devices
which work on removable batteries
Don't store in high temperature or
high humidity
The cell signal interferes with the
device signal, so turn off the cell
while operating
Disconnect the batteries before
long time storage

Page
Technical specification
3
Bluetooth none
Wireless: none
Search system : long distance sensing system (LDS)
Operating processor: MICROCONTLLER PIC18
Operating frequency: From 1 kHz to 9 kHz
4AAA batteries 1.5 volts / Equivalent of -6volt interchangeable
Power consumption: Maximum of consumption 25 mAh
Battery life: 32 work hours
Charger: none
Display Type: LEDs Interface
Specialized to detects: Gold nugget (Small, Medium, Big and Tiny).
Targets Discrimination: Yes
Target Selection System: Yes, can choose the target type before the start search
Depth Search: 10m, With controlling system in the depth level
Distance Search: 200m, With controlling system in the distance level
Search principle:
Digital Frequency Signal Processing (DFSP) / To Receiving
Electrostatic Fields of the targets
Results feedback:
Through orientation toward to the target location
accompanied by acoustic Alerts
Power:

Technical specification
Page 4
Voice alerts: Yes
Vibrating alert: Yes
Operating temperature: From -15° C to 60° C
Storage temperature: From -15° C to 40° C
Humidity:
It can be stored and work in the degree rate of air humidity
of level 90%.
Weight: Compound: 700 gr – disjointed in the bag: 1 kg
Dimensions: 16X9.5X2.5 cm
Bag dimensions: 20X15X5 cm
none
Automatic smart
guidance system:

Page
Device parts
5
Transceiver Antennas
Antennas is responsible for transmit and receive signals and
searching waves. It has a special and unique properties .
Handel Grip
Coms with the device . Used to carry the device through for
the searching process, it has capability to rotation 360 degree.
Main Control Unit
فﺪﻬﻟا
ﻖﻤﻌﻟا
مﺎﺧ ﺐﻫذ
ﺮﯿﻐﺻ
ﺚﺤﺒﻟا ﺮﺷﺆﻣ
ﻖﯿﻗد
ﻂﺳو ﺮﯿﺒﮐ
ﻖﻤﻌﻟا
The unit which is responsible for adjusting the device and
setting inaddition to full exploration search through this it.

Page
Interfaces and components of Device
6
1
10
2
3
12
11
6
8
9
5
4
7
فﺪﻬﻟا
ﻖﻤﻌﻟا
مﺎﺧ ﺐﻫذ
ﺮﯿﻐﺻ
ﺚﺤﺒﻟا ﺮﺷﺆﻣ
ﻖﯿﻗد
ﻂﺳو ﺮﯿﺒﮐ
ﻖﻤﻌﻟا
Front-end
1
2
3
4
5
6
7
8
9
10
11
12
User interface.
Signal port ,connected with antennas
Depth levels interface .
Distance levels interface .
Target type interface .
Control buttons.
Sound and vibration controlling button
Scan button
LED Indicators for signal.
Battery level indicators.
Selection keys (depth, distance & target)
On / Off button.

Interfaces and components of Device
Page 7
13
14
15
13
14
Backend
15
Handle socket.
Battery compartment.
Audio out.

Page
Overview
8
Spark gold nugget is working on remote sensing system (LDS) developed
and compact with voice selection system to Gold path and point.
The Spark gold nugget device features in high precision waves to identify
and locate gold nugget with high specific. Where the device can locate
targets from a distance of 200 meters forward at 360 degree angle with
precise control in distance search front end.
Spark gold nugget device search depth up to 10m below the surface of the
earth with strict control on deep research of device control interface the
device of features a small size and ease of use. Where you can fit in your
pocket and navigates it conveniently and easily any one can use it without
having any experience or knowledge in the detectors.
The principle of search depends on digital frequency signal processing
(DFSP) to receive the energy of static electric field from the targets.
Provider device automatic tuning system (ATS) to operate in all types of
terrain, rocky soils, mountainous, sandy and clay.

Page
Overview
9
This electronic device works on gold finder technology transmitter and receiver. It
sends waves and receives at the same time and do the search for gold by
frequency depending on the combination of physical and chemical interaction gold
too if the presence of gold underground they are affected by the magnetic fields
of the earth. It also acquires gold static electrical currents gained the soil through
the soil affected by different currents like ( power stations, broad casters radio,
satellites, lightening and a lot of stuff generated electrical energy and static
energy.
This machine adopts the gold detectors and targets underground through the
influence of waves emerging from the device by electrostatic fields formed on the
gold as a result he was underground and gold frequency at the same time. Device
waves work on inflate the size of these field and escalation of soil surface which
helps the device to locate the target from long distance, the device receives a
signal amplification and heading toward the target site directly and precise
destination.
Soil
Target

Page
Assembly
10
1
2
فﺪﻬﻟا
ﻖﻤﻌﻟا
مﺎﺧ ﺐﻫذ
ﺮﯿﻐﺻ
ﺚﺤﺒﻟا ﺮﺷﺆﻣ
ﻖﯿﻗد
ﻂﺳو ﺮﯿﺒﮐ
ﻖﻤﻌﻟا
SPARK
1
2
Connect the antennas in their places in front of the front part of the device as shown in
the drawing.
Connect the carrier handle in its place at the bottom of the machine as shown in the
drawing.

Page
Setup wizard
11
Power key Sound key
Battery level indicators
فﺪﻬﻟا
ﻖﻤﻌﻟا
ﺚﺤﺒﻟا ﺮﺷﺆﻣ
Characteristics and functionality
To turn on the device press and hold the power key (for seconds) and for
shut down process we do the same way.
To control the audio levels through the key sound and pressure intermit-
tently on the key to change the level.
The device is equipped with vibrating alert feature; you can control turn
and stop vibrating alerts through press and hold (for three second) on key
sound.
The device works on four batteries (1.5 AAA volts) subject to change after
its completion.
Battery level indicators are totally full where the battery is full and have
three levels with different color landing descending (green, yellow, and red)
and before the entry into force of the energy of the battery starts flashing
red.
Note: audio has five position in addition to silent mode and also there are
several voice functions (voices of the keys and press – search alerts sounds).

Page
Setup wizard
12
Search settings
Depth levels
Distance levels
Type of target
Select target key
Start scanning key
Lights indicators
Depth level options key
Distance level options key
فﺪﻬﻟا
ﻖﻤﻌﻟا
ﺚﺤﺒﻟا ﺮﺷﺆﻣ
مﺎﺧ ﺐﻫذ
ﺮﯿﻐﺻ
ﻖﯿﻗد
ﻂﺳو ﺮﯿﺒﮐ
ﻖﻤﻌﻟا
Do turn on device through turn and close key.
Choose the desired target type by pressing the target key and you will
notice the change in optical indicators that special for target part at the top
of device each target there is a special light and target is (Small, Medium,
Big and Tiny).
Choose the level of depth by pressing depth key and you will notice the
change in levels and depths interface there are several level and is (1m,
3m, 5m, 7m and 10m)
Choose the level of required distance to search by pressing on distance
key and you will notice the change in levels in the interface distances and
there are several levels and is (200m, 150m, 50m and 25m).
Press the scan key to start the research process and you will notice the
optical indicators started working and audio alarm started and this refer to
device ready to start searching process.

Page
Start searching
13
The user must carry the device through the carrier handle so the device
is horizontal with the ground and tilted slightly toward the soil as shown
in the drawing.
And then just do the stimulation for waves and area outside of the
device and we move the device by hand turn right and then left slowly
and then install the hand that the device.
Move to the right and left
Right
Left
Soil

Page
Start searching
14
Target Intersection
point
First Result
User
Second Result
Third Result User
User
If you find the target that was determined search for him. The device will
receive this read and signal and thus change the device path automatically
from normal path that was stable in it to another path and this trend is toward
target location. And then installs the device in the same direction. At the
mean time we do clearing target location and install starts to launch audio
alarm toward target location then we warp completely about the direction in
which the device went to him to face adverse parking to note change device
path at another time and toward to target location and launching audio alarm
constantly. Then we get away from first reading point to stand at another
location away from the first 10 meters sideways then do the process of
stimulation device waves again and prove the device and wait for reading if
the target was downright the device will go towards the site itself and we have
made sure that there was target and could we do that way more than once to
validate the target direction by taking more than the reading of device from
different points. And if we notice theories to all our readings that we have
made intersect in one point location and target point.

How to locate the target
Page
Start searching
15
The user can know and estimate target distance from starting point search
and to do that we change the distance level by pressing on distance key then
we select distance from a list of distance for example if we have chosen at
the beginning of search 200 search distance meters we reduce the distance
of 50 meters then press on key scan again and the device starts to search
and make previous steps. At this time hold the device and wait to read if we
have received target read we have known that target walks away from search
point is 50 meters. It is also possible restoring these settings again and
reduce the distance less to estimate target distance bitterly and then move on
to the stage to locate the target location.
After confirmation read over to the direction of the target we press on key
scan for installation and confirm the target location and we will notice that
the device beep towards target then we are walking in the same direction and
in the normal way to carry device to get point beyond the target location and
we will notice that the device has changed its direction from normal track to
warp back to the location and existence of the target point here we also spin
with the device to target location and walk slowly when we were above the
target directly we will notice the device will start to rotate left or right and this
shows that we have identified the target point presence.

Note: When you begin the process of tracking for target location you will
notice the device produce alerts and a acoustic signals toward target location
but if you notice that you are go out from derailing and direction of target this
sound will disappear and another sound is heard indicating the error mode. And
will light up one of the light optical indicators right or left to indicate the correct
path that will track it and to reach the target.
Page
Start searching
16
Soil
Target
Device derailed wraps
beyond target point.

Page
Notes
17

Metal and Water Finder
www.mwf-usa.com
[email protected]
+1 ( 708 ) 364 9602
United States of America - illinois
www.mwf-metaldetectors.com
[e-mail]
+90 ( 212 ) 222 0946
+90 ( 212 ) 222 0947
Turkey - istanbul
