MyGate PQ81S User manual

ver.: 09_2021
Q81SQ81S
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
CONTROL PANEL FOR
SLIDING GATES
Control panel for 230V ac sliding gates operators
• Automatic programming mode with obstacle detection
• Sequential programming mode: adjustable force, slow down, working time per single motor
• Immediate closing
• Pedestrian opening
• Multi-occupation feature
• Second radio channel interface (optional)
• Output for electrolock connection
• Hammer action and lock pulse function
• Built-in radio receiver 433,92 MHz (32 codes) suitable for fixed or rolling code transmitters
• Input for 8K2 resistive safety edge
• Self diagnosis of malfunctions by LED coding
230V ac
TECHNICAL FEATURES
Instructions Manual
Item code PQ81S
Pcb’s dimensions 137 x 84 x 37 mm
Pcb’s weight 160 g
Main power supply 230V, 50-60Hz
Power supply tolerance -10% +20%
Transformer 230/21Vac – 15VA
Main fuse 5 A
Rated power 600 W
Max. power draw 3,5 A
Power draw in stand-by 30 mA
Blinker 24Vac, max 20 W
Accessories 24Vdc , max 5 W
Accessories -20 +50 °C
Protection rating IP55

PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
Contents
1. SAFETY INSTRUCTIONS AND PRELIMINARY CHECKS ........................................................................................ pag. 01
2. DESCRIPTION AND MAIN COMPONENTS ......................................................................................................... pag. 02
3. ELECTRICAL CONNECTIONS .............................................................................................................................. pag. 03
3.1 LIMIT SWITCHES WIRING .......................................................................................................................... pag. 05
3.2 MAIN POWER ........................................................................................................................................... pag. 06
3.3 START DEVICES ......................................................................................................................................... pag. 06
3.3.1 TIMER
3.3.2 KEY-SWITCH
3.4 PEDESTRIAN OPENING ............................................................................................................................. pag. 06
3.5 EMERGENCY STOP BUTTON ..................................................................................................................... pag. 07
3.6 PHOTOCELLS ............................................................................................................................................. pag. 07
3.6.1 Photocells in CLOSING
3.6.2 Photocells in OPENING
3.7 SAFETY EDGE ............................................................................................................................................ pag. 08
3.7.1 Safety Edge in CLOSING
3.7.2 Safety Edge in OPENING
3.7.3 8K2 resistive safety edge in CLOSING ................................................................... pag. 11
3.7.4 8K2 resistive safety edge in OPENING
3.8 FLASHING LIGHT ....................................................................................................................................... pag. 10
3.9 HOV TO PLUG THE 2 RADIO CHANNEL JACK ..................................................................................... pag. 10
3.9.1 Auxiliary radio channel AUX
3.9.2 Signalling light
3.9.3 CCourtesy light
4. DEFAULT SETTINGS ............................................................................................................................................... pag. 11
5. BROWSING THE MENU
5.1 FUNCTIONS MENU
5.1.1 Automatic closing
5.1.2 8K2 RESISTIVE SAFETY EDGE INPUT (cut the power off)
6. OPERATION MODE ............................................................................................................................................ pag. 12
7. RADIO CODES .................................................................................................................................................... pag. 14
7.1 HOW TO DELETE EXISTING RADIO CODES
7.2 HOW TO STORE A RADIO CODE FOR START COMMAND
7.3 HOW TO STORE A RADIO CODE FOR PEDESTRIAN COMMAND
7.4 HOW TO STORE A RADIO CODE FOR THE 2° AUXILIARY RADIO CHANNEL
8. PROGRAMMING ................................................................................................................................................ pag. 15
8.1 AUTOMATIC mode
8.1.1 AUTOMATIC mode with OBSTACLE DETECTION
8.2 SEQUENTIAL mode .................................................................................................................................. pag. 16
8.2.1 SEQUENTIAL mode with OBSTACLE DETECTION
9. TROUBLE SHOOTING .......................................................................................................................................... pag. 17

Q81S_09_2021 1
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
1. SAFETY INSTRUCTIONS AND PRELIMINARY CHECKS
WARNING! Important instructions for the safety of people, READ CAREFULLY!
Save this manual for future consultation.
Do not allow children to play with the fixed command devices, or in the gate’s
area of operation.
Keep any remote control devices (i.e. transmitters) away from the children as
well
Children are forbidden to carry out cleaning and maintenance unless accom-
panied by adults.
Children over 8 years, persons with reduced physical, sensorial, mental capa-
bilities or unexperienced people are limited to use the operator unless accom-
panied by a supervisor or unless they get properly aware of potential hazards
associated.
Always cut the power off before operating.
Make sure the earth connection is duly wired.
Wiring, installation and functional tests must be carried out by expert qualified per-
sonnel in full compliance with current regulation EN12453.
Use of this control panel must be restricted to the transformer supplied by the Ma-
nufacturer.
A circuit breaker must be fitted close to the gate in compliance with the wiring
diagram and installation instructions (see paragraph 3).
Stay clear of the gate’s area of operation when in motion
Frequently check the system to see whetherany anomalies or signs of wear and
tear appear on the moving
parts, on the component parts, on the securing points, on the cables and any ac-
cessible connections.
If the system requires repairs or modifi cations, release the operator and do not use
it until safety conditions have been restored.

2 Q81S_09_2021
24Vac
230Vac
F2
J5
JP8 JP9
JP1
JP2 JP3
POWER
230Vac
5A
230Vac
DL1
- + - +
K4
K2
K3
FR1
21 22
SW1 SW2
DL2
START STOP PED
1 2 3 4 5 6 7 8 9 10 11 15 16 17 18 19 2012 13 14
V1
JP10
23 24
DL3
DL4 DL5 DL6 DL7 DL8
DL9 DL10
FR2
SENS POWER
SET SET TX
WORK BREAK
J1
SENS POWER
SET SET TX
WORK BREAK
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
2. DESCRIPTION AND MAIN COMPONENTS
J1 = radio receiver
J5 = input second radio channel jack
F2 = line fuse 230V 5A
FR1 = self resettable fuse 24V 1,6A
FR2 = self resettable fuse 24V 0,6A
V1 = varistor secondary
K1/K3 = motor relé
K4 = flashing light relé
TR2 = filter
JP1 = GREEN TERMINAL - aerial connection
JP2 = Secondary MOLEX card 24V ac
JP3 = Primary MOLEX card 230V ac
JP4 = BLUE TERMINAL – command devices
JP5 = RED TERMINAL - line and photocells
JP6 = YELLOW TERMINAL – flashing light
JP7 = BLACK TERMINAL - limit switch
JP8 = ORANGE TERMINAL - motor
JP9 = GREEN TERMINAL – line 230V / earth
JP10 = GREEN TERMINAL – safety edge (resistive or mechanical type) only in CLOSING
WARNING LED
DL1 = PROGRAMMING
DL2 = THRUST MOTOR
DL3 = SAFETY EDGE in CLOSING
DL4 = START
DL5 = STOP
DL6 = PEDESTRIAN START
DL7 = PHOTOCELL IN CLOSING
DL8 = PHOTOCELL IN OPENING
DL9 = LIMIT SWITCH in CLOSING
DL10 = LIMIT SWITCH in OPENING
PROGRAMMING BUTTONS

Q81S_09_2021 3
24Vac
230Vac
F2
J5
JP8 JP9
JP1
JP2 JP3
POWER
230Vac
5A
230Vac
DL1
- + - +
K4
K2
K3
FR1
21 22
SW1 SW2
DL2
START STOP PED
1 2 3 4 5 6 7 8 9 10 11 15 16 17 18 19 2012 13 14
V1
JP10
23 24
DL3
DL4 DL5 DL6 DL7
DL8 DL9 DL10
FR2
SENS POWER
SET SET TX
WORK BREAK
J1
M1
230V
N.C.
8K2
- + - +
TX RX - + - + TX RX
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
PHASE
NEUTRAL
EARTH
CLOSE
CAPACITOR
FLASHING LIGTH 24V ac MAX 20w
PEDESTRIAN
STOP
START
NEUTRAL
CLOSING
PHOTOCELLS
OPENING
PHOTOCELLS
PHOTOCELLS IN CLOSING
PHOTOCELLS IN OPENING
-24V RX
+24V TX/RX
TRANSFORMER
230V / 21V
RED
RED
BLACK
BLACK
WIRING Diagram for 230Vac OPERATORS
-24V TX
3. ELECTRICAL CONNECTIONS
CIRCUIT
BREAKER
OPEN
NEUTRAL
NEUTRAL
FC CLOSING
FC OPENING
THE CONTROL UNIT COMES FROM MANUFACTURER
PRE-WIRED AS FOLLOWS
N.B.:
ALL SAFETY DEVICES MUST BE CONNECTED BEFORE STARTING
PROGRAMMING, OTHERWISE THE CONTROL PANEL SHALL

JP6
FLASH
24V ac
JP8
M1
PED
J5
JP1
22
21
JP2
JP3
JP4
START
STOP
PED
JP5
RX -24V
TX - RX +24V
Test Photo TX -24
FOTO
FTAP
JP9
FN
4 Q81S_09_2021
JP7
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
JP1 = GREEN TERMINAL -Aerial connection
21 signal wire
22 earth wire
JP2 = RED WIRES - secondary MOLEX card 24V dc
JP3 = BLACK WIRES - primary MOLEX card 230V ac
JP4 = BLUE TERMINAL – command devices
1 START (N.O. contact)
2 STOP (N.C. contact)
3 PEDESTRIAN (N.O. contact)
4 NEUTRAL
JP5 = RED TERMINAL – line and photocells
5 photocell in closing (N.C. contact)
6 photocell in opening (N.C. contact)
7 RX photocells -24V
8 TX/RX +24V
9 TX photocells -24V
JP6 = YELLOW TERMINAL – flashing light
10 flashing light 24V ac - max 20W
11 flashing light 24V ac - max 20W
JP7 = BLACK TERMINAL – LIMIT SWITCH
12 neutral
13 limit switch in closing
14 limit switch in opening
JP8 = ORANGE TERMINAL - MOTOR
15 OPEN
16 NEUTRAL MOTOR OUTPUT
17 CLOSE
JP9 = GREEN TERMINAL - line 230V + earth
18 LINE
19 EARTH
20 NEUTRAL
Make sure a circuit breaker is properly fitted
to the gate electric box.
JP10 = GREEN TERMINAL – safety edge
23 safety edge in CLOSING
24 safety edge in CLOSING
J5 = input second radio channel jack
OPEN
CLOSE
FC OPENING
FC CLOSING
NEUTRAL

Q81S_09_2021 5
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
Il the motor is positioned on the left,
switch SW2 dip no.1 = ON
(the limit switch turns automatically.
No connections are needed)
Il the motor is positioned on the left,
switch SW2 dip no.1 = ON
(the limit switch turns automatically.
No connections are needed)
  
JP8
Brown
Whit
3.1 MOTORS wiring
Please check motor wirings according to the gate opening direction
Gate opening from left to RIGHT (viw from inside courtyard)
FCOPEN
NEUTRAL
FCCLOSING
Gate opening from right to LEFT (view from isnide property)
The control unit is pre-set for gate opening
from left to right (looking from inside the
courtyard as shown in the drawing).
OUTSIDE
INSIDE
OUTSIDE
INSIDE
Right
gear motor
Left
gear motor





 34
JP7
BROWN
BLACK
BLUE- COMMON
MECHANICAL
LIMIT SWITCH
MAGNETIC
LIMIT SWITCH
 34
JP7
BLACK

JP4 JP5 JP6

JP4 JP5 JP6
JP4 JP5 JP6
JP4 JP5 JP6
JP9
230V
6 Q81S_09_2021
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
3.3 START DEVICES
Wire the START contact (N.O. contact) to 1 – 4, terminal JP4.
An additional START contact can be wired in PARALLEL (N.O. contact)
3.4 PEDESTRIAN OPENING
Wire the PEDESTRIAN START (N.O. contact) to 3-4, terminal JP4.
An additional PEDESTRIAN START contact can be wired in PARALLEL
(N.O. contact).
OROLOGIO
3.3.2 KEY SWITCH
Wire the KEY SWITCH (N.O. contact) to 1-4, terminal JP4.
3.2 MAIN POWER
The main line must be protected by a proper CIRCUIT BREAKER.
Connect the line 230V to 18-19-20, terminal JP9, fulfilling the
polarity (18 PHASE – 19 EARTH – 20 NEUTRAL)
CIRCUIT
BREAKER
PHASE
NEUTRAL
PEDESTRIAN
START
3.3.1 TIMER
It is possible to wire a TIMER (N.O. contact) to 1-4, terminal JP4.
ATTENTION!:
when connecting a TIMER, the multi-users function
must be enabled. SW1 DIP 2 = ON

Q81S_09_2021 7
JP4 JP5 JP6
JP4 JP5 JP6
TR AS
+
+AC
-AC
TX
+
-
RX
+AC -AC
24
12Vdc
24Vac
24Vdc
12Vdc
24Vdc
24Vca
JP4 JP5 JP6
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
3.6 PHOTOCELLS
3.6.1 Photocells IN CLOSING
Feed the photocells through 7-8-9, terminal JP5.
Wire the photocell contact (N.C. contact) to 5-7, terminal JP5.
An additional photocell set can be wired in SERIES (N.C. contact).
- If the photocell beam is broken during CLOSING,
the gate stops and reverses after 1,5 sec.
- If the photocell beam is broken during OPENING,
the gate keeps on working normally.
The PHOTOCELLS IN CLOSING are important for
the safety of people and objects.
N.B.: To desable the photocell in closing
during installation, plug 5 and 9 together.
3.6.2 Photocells in OPENING
Feed the photocells through 7-8-9, terminal JP5.
Wire the photocell contact (N.C. contact) to 6-7, terminal JP5.
An additional photocell set can be wired in SERIES (N.C.
contact).
- If the photocell beam is broken during OPENING, the gate
stops and reverses for 3 sec
The PHOTOCELLS IN OPENING are important for the safety of
people and objects..
N.B.: Before wiring any PHOTOCELL in OPENING, remove the
jumper between terminal 6 and terminal 9.
EMERGENCY
STOP BUTTON
3.5 EMERGENCY STOP BUTTON
Wire the STOP BUTTON (N.C. contact) to 2-4, terminal JP4.
An additional STOP BUTTON contact can be wired in SERIES (N.C. contact)
The EMERGENCY STOP BUTTON is important for the safety
of people and objects
N.B.: Before wiring any STOP contact remove the jumper between
terminal 2 and terminal 4.
PLUG 5 - 9

8Q81S_09_2021
JP10
N.C.
JP4 JP5 JP6
N.C.N.C.
TR AS
+
+AC
-AC
TX
+
-
RX
+AC -AC
24
12Vdc
24Vac
24Vdc
12Vdc
24Vdc
24Vca
N.C.
TR AS
+
+AC
-AC
TX
+
-
RX
+AC -AC
24
12Vdc
24Vac
24Vdc
12Vdc
24Vdc
24Vca
N.C.
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
3.7 SAFETY EDGE
3.7.1 Mechanical safety edge in CLOSING
Wire the safety edge to 23 - 24, terminal JP10.
•If the contact is broken during CLOSING, the
gate stops and reverses.
•If the contact is broken during OPENING, the
gate keeps on working normally
Mechanical safety edge + photocells in CLOSING
Wire the safety edge and the N.C. contact of the
photocell in series.
•If the contact is broken during CLOSING, the gate
stops and reverses.
•If the contact is broken during OPENING, the gate
keeps on working normally.
3.7.2 Mechanical safety edge in OPENING
Wire the safety edge to 6 – 9, terminal JP5.
•If the contact is broken during OPENING,
he gate stops and reverses after 3 sec.
•If the contact is broken during CLOSING,
the gate keeps on working normally.
Mechanical safety edge + photocells in OPENING
Wire the safety edge and the N.C. contact of t
he photocell in series.
•If the contact is broken during OPENING, the gate
stops and reverses after 3 sec.
•If the contact is broken during CLOSING, the gate
keeps on working normally.
N.B.: Before wiring any SAFETY STRIP in
CLOSING, remove the jumper
between terminal 23 and
terminal 24.

Q81S_09_2021 9
JP4 JP5 JP6
JP10
8K2
8K28K2
TR AS
+
+AC
-AC
TX
+
-
RX
+AC -AC
24
12Vdc
24Vac
24Vdc
JP4 JP5 JP6
12Vdc
24Vdc
24Vca
8K2
TR AS
+
+AC
-AC
TX
+
-
RX
+AC -AC
24
12Vdc
24Vac
24Vdc
JP4 JP5 JP6
12Vdc
24Vdc
24Vca
8K2
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
•If the contact is broken during CLOSING,
the gate stops and reverses.
•If the contact is broken during OPENING,
the gate keeps on working normally.
8K2 SAFETY EDGE + PHOTOCELLS IN CLOSING
(cut the power off before proceeding)
ATTENTION!:
Wire the 8K2 safety edge to 23 - 24, terminal JP10.
Press SET + SET TX together and feed the control panel
• If the contact is broken during CLOSING,
the gate stops and reverses.
• If the contact is broken during OPENING,
the gate keeps on working normally.
3.7.4 8K2 RESISTIVE SAFETY EDGE IN OPENING
(cut the power off before proceeding)
ATTENTION!:
Wire the 8K2 safety edge to 6 - 9, terminal JP5.
Press SET + SET TX together and feed the control panel.
•If the contact is broken during OPENING,
the gate stops and reverses for 3 sec.
•If the contact is broken during CLOSING,
the gate keeps on working normally
8K2 SAFETY EDGE + PHOTOCELLS IN OPENING
(cut the power off before proceeding)
ATTENTION!:
Wire the 8K2 safety edge contact in series to the N.C.
contact of the photocell.
Press SET + SET TX together and feed the control panel.
•If the contact is broken during OPENING,
the gate stops and reverses for 3 sec.
•If the contact is broken during CLOSING,
the gate keeps on working normally.
3.7.3 8K2 RESISTIVE SAFETY EDGE IN CLOSING
(cut the power off before proceeding)
ATTENTION!:
PWire the 8K2 safety edge to 23 - 24, terminal JP10.
Press SET + SET TX together and feed the control panel.
N.B.: Before wiring any SAFETY STRIP in
CLOSING, remove the jumper
between terminal 23 and
terminal 24.

1 2 3 4
ON ECE
SW1
1 2 3 4
ON ECE
SW1
1 2 3 4
ON ECE
SW1
1 2 3 4
ON ECE
SW1
1 2 3 4
ON ECE
SW1
10 Q81S_09_2021
JP6
FLASH
24V ac
max 20W
10 11
24Vac
230Vac
F2
J5
JP3 JP8 JP9
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
JP1
JP2 JP3
T2
T1
TR2
C21
C24
POWER
230Vac
5A
230Vac
DL2
- + - +
SENS POWER
K4
C26 C27
K2
K3
- + - +
OP2
OP1
V1
FR1
SET SET TX
WORK BREAK
21 22
SW1 SW2
DL1 DL8
START STOP PED
U2
1 2 3 4
ON ECE
1 2 3 4
ON ECE
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
3.9.1 Auxiliary radio channel AUX
To use the MRX01 interface as second radio channel, proceed this way
(see section 7.4):
Before setting the dip-switch SW1, make sure the power is OFF
MONOSTABLE COMMAND
The contact ACTIVATES when giving a start command by the remote control.
If you wish to choose this function mode, select the switches as follows:
1 = ON 2 = OFF 3 = OFF 4 = NO EFFECT
BISTABLE COMMAND
IThe contact ACTIVATES or DESACTIVATES every time you press the remote
control.
If you wish to choose this function mode, select the switches as follows:
1= OFF 2 = ON 3 = OFF 4 = NO EFFECT
TIMED COMMANDA
The contact ACTIVATES when giving a start command by the remote
control and stays for 90 seconds.
If you wish to choose this function mode, select the switches as follows:
1 = ON 2 = ON 3 = OFF 4 = NO EFFECT
3.9.2 Signalling LIGHT
TThe contact ACTIVATES at OPENING and DESACTIVATES only at FINAL
CLOSING POSITION.
If you wish to choose this function mode, select the switches as follows:
1= OFF 2= OFF 3= ON 4 = NO EFFECT
3.9.3 Courtesy LIGHT
The contact ACTIVATES at OPENING and DESACTIVATES after 90 from
complete duty cycle.
If you wish to choose this function mode, select the switches as follows:
1= ON 2= OFF 3= ON 4 = NO EFFECT
MRX01
jack
3.9 HOW TO PLUG THE 2 RADIO CHANNEL JACK
slideway
jack
MRX01
ATTENTION!:
CUT THE POWER OFF BEFORE PLUGGING THE INTERFACE
Plug the MRX01 jack (optional) onto connector J5, respecting the slot orientation.
3.8 FLASHING LIGHT
EWire the flashing light (max 20W) to 10-11, terminal JP6.
•QUICK blinking → OPEN
•SLOW blinking → CLOSE
•FIXED light on → PAUSE
contatto
N.O.

Q81S_09_2021 11
SET SET TX
WORK BREAK
SET SET TX
WORK BREAK
SET SET TX
WORK BREAK
SET SET TX
WORK BREAK
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
5. BROWSING THE MENU
4. DEFAULT SETTINGS
LThe control panel is supplied with a DEFAULT SETTINGS:
working time, slow down and automatic closing for a standard gate.
To reload the DEFAULT SETTINGS:
- Press BREAK to cut the power OFF and to turn it ON
- Turn SENS to the maximum (+) and POWER to half position
5.1 FUNCTIONS MENU
5.1.1 AUTOMATIC CLOSINGA
The AUTOMATIC CLOSING DEFAULT is set at 3 sec.
To set the AUTOMATIC CLOSING TIME:
- Press SET for 3 sec. DL1 blinks, release SET.
- Press BREAK and release.
- The blinker and led DL1 light up, the control panel starts the count down.
- Press BREAK again when reached the desired time, the blinker turns off.
The time has been set (automatic closing time max. 120 sec.).
To desactivate the AUTOMATIC CLOSING:
-Press SET for 3 sec. and release, the led DL1 blinks.
- Press BREAK and hold for 5 sec., the AUTOMATIC CLOSING has been deactivated.
5.1.2 8K2 RESISTIVE SAFETY EDGE INPUT (cut the power off)
To activate the 8K2 input as safety in opening and closing press SET + SET TX and turn the control panel on.
SET
Use SET:
- To programm the control panel (section 8.1. AUTOMATIC MODE – 8.2. SEQUENTIAL MODE).
- To activate or desactivate the automatic closing (section 5.1.1)
SET TX
Use SET TX:
- To store or to delete a radio code.
WORK
Use WORK:
- As START command
- For SEQUENTIAL PROGRAMMING
BREAK
Use BREAK:
- To activate and set the AUTOMATIC CLOSING TIME (section 5.1.1)

12 Q81S_09_2021
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
SW1 SW2
ON
OFF
ON
OFF
ON
6. OPERATION MODE
Choose the operation mode you wish selecting the switches SW1 – SW2.
The control panel is supplied with the following default settings.
How to read switch positio:
ATTENTION:Turn the power off before setting the switches
SWITCH SW1
dip n° 1
This function gives priority to the first open command. The control unit won’t accept
additional START commands during OPENING and AUTOMATIC CLOSING COUNT DOWN.
dip n° 2
dip n° 3
dip n° 4
OFF = MULTI OCCUPATION mode DEACTIVATED
ON = MULTI OCCUPATION mode ACTIVATED
OFF = Soft start mode DEACTIVATED
At opening motors work at the set thrust (POWERO)
ON = Soft start mode ACTIVATED
At opening motors perform at maximum thrust for 1,5 sec., to continue after at the set thrust
OFF = Motor and photocell TEST DEACTIVATED
ON = Motor and photocell TEST ACTIVATED
WHITE switch DOWNWARD = Function OFF WHITE switch UPWARD = Function ON
SOFT START
MOTOR TEST
PHOTOCELL TEST
ACTIVATED
ON
OFF
OFF = Immediate closing mode DEACTIVATED
ON = Immediate closing mode ACTIVATED
The gate starts CLOSING after 1,5 sec. bypassing the AUTOMATIC CLOSING COUNT DOWN
OFF

Q81S_09_2021 13
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
1 2 3 4
ON ECE
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
SWITCH SW2
dip n° 1
dip n° 2
dip n° 3
dip n° 4
ON
OFF = = Motor positioned on the RIGHT (Default)
ON = Motor positioned on the LEFT
OFF
ON
OFF = Standard slow down (Default)
ON = Soft slow down ACTIVATED
OFF
ON
OFF = Mantained action DEACTIVATED (Default)
ON = Maintained action ACTIVATED
OFF
ON
OFF = N.C. contact limit switches(Default)
ON = N.O. contact limit switches
OFF

14 Q81S_09_2021
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
7. LOADING RADIO CODESO
The control panel DOESN’T ALLOW TO LOAD any remote control if SAFETY DEVICES are DISCONNECTE.
Make sure inputs no. 2 STOP (DL5), no. 5 photocell in CLOSING (DL7), no. 6 photocell in OPENING (DL8) and no. 23
SAFETY EDGE IN CLOSING (DL3), are connected.
LED OFF = input DEACTIVATED
LED ON = input ACTIVATED
If no safety device has been wired, proceed to bridge temporarily the terminal according to chapter 3.6.1.
The control panel has been designed to operate with fixed code or rolling-code remote controls.
Choose the remote control you wish to store carefully: once the remote control has been loaded and memorized,
the control panel shall only recognize that kind of radio code without possibility of reset.
Before starting proceed to delete all existing radio codes.
7.1 DELETING EXISTING RADIO CODES
- Press SET-TX and keep pressed for 10 seconds (DL1 blinks).
-DL1 turns off. All codes have been deleted.
7.2 LOADING A REMOTE CONTROL AS START COMMAND
- Press SET-TX once: DL1 blinks (1 blink – stop – 1 blink ….)
- Load within 5 sec. the remote control you wish to store.
The control panel has stored the radio code and goes out the programming automatically.
It is possible to load until 32 different radio codes (Start + Pedestrian + 2° radio channel).
7.3 LOADING A REMOTE CONTROL AS PEDESTRIAN COMMAND
- Press SET-TX twice. DL1 blinks (2 blinks – stop – 2 blinks ….)
- Load within 5 sec. the remote control you wish to store.
The control panel has stored the radio code and goes out the programming automatically.
7.4 LOADING A REMOTE CONTROL AS 2° RADIO CHANNEL COMMAND (MRX01 jack)
- Press SET-TX three times. DL1 blinks (3 blinks – stop – 3 blinks ….)
- Load within 5 sec. the remote control you wish to store.
The control panel has stored the radio code and goes out the programming automatically.

Q81S_09_2021 15
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
8. PROGRAMMING
The control panel is supplied with a SEQUENTIAL PROGRAMMING DEFAULT (obstacle detection excluded)
ATTENTION:
Before starting PROGRAMMING make sure mechanical ground stops have been properly fitted.
8.1 AUTOMATIC mode
8.1.1 AUTOMATIC mode with OBSTACLE DETECTION
ATTENTION!:
Before proceeding to programming, start a functional cycle test to proof the motor’s thrust.
The thrust has to be proper to the gate weight no matters if light or heavy gates.
If adjustments are needed, regulate POWER so that the gate doesn’t stop opposing a light contrast pressure.
• Start programming with cool operator.
• The AUTOMATIC MODE PROGRAMMING can only perform if mechanical ground endstops are fitted,
in Opening and Closing
- Gate in CLOSING POSITION.
-SENS in half position.
-If during programming the gates stop before reaching the ground endstops, turn SENS (sensitivity) clockwise (to +).
- Press SET and keep pressed for 10 sec., DL1 starts blinking.
- When motor starts working release SET.
- Motor runs firstly a FULL OPENING till reaching the limit switch in opening.
Then it starts CLOSING till reaching the closing limit switch.
- When the procedure is finished, all time settings are saved.
The control panel is now ready for normal operation.
ATTENTION!:
Check the proper GATE OPERATION SENSITIVITY.
If adjustments are needed, turn SENS clockwise (to +) and regulate accordingly.
The sensitivity has to be proper in order to prevent uncorrect operation.
OBSTACLE DETECTION OPERATION
- If an obstacle is detected in opening, the gate stops and reverses for 10 cm.
- The gate starts closing automatically after 30 sec., and this will be for 3 attempts.
If the area still remains unclear the gate stays open.
- If an obstacle is detected in closing, the gate stops and reverses till fully open.
- The gate starts closing automatically after 30 sec., and this will be for 3 attempts.
If the area still remains unclear the gate stays open.

16 Q81S_09_2021
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
8.2 SEQUENTIAL MODE
8.2.1 SEQUENTIAL mode WITHOUT Obstacle Detection
ATTENTION!:
Before proceeding to programming, start a functional cycle test to proof the motors’ thrust.
The thrust has to be proper to the gate weight no matters if light or heavy gates.
If adjustments are needed, regulate POWER so that the gate doesn’t stop opposing a light contrast pressure.
• Start programming with cool operator.
• The AUTOMATIC MODE PROGRAMMING can only perform if mechanical ground endstops are fitted,
in Opening and Closing
-SENS in maximum position (to +)
- Programming can be carried out both with the remote control or WORK button.
- Press TEST for 3 sec., DL1 starts blinking, release.
- Press the button of the remote control previously loaded. The gate STARTS OPENING.
- At 80% of opening press the remote control to start SLOW DOWN till reaching the opening limit switch.
- Now operational settings are LOADED.
- The gate starts closing until reaching the closing limit switch.
- When the procedure is finished, all time settings are saved, the control panel goes out from
the sequential programming and is ready for normal operation.
Check the good operation of the gate. If time settings need to be adjusted go back to programming
and repeat the whole programming procedure.

Q81S_09_2021 17
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
possible cause
• Closing limit switch ACTIVATED
• Photocell test
• Motor test
• Power supply disconnected
• Permanent START command
•STOP button disconnected.
• Incorrect wiring.
• Photocell in closing non-aligned.
• Obstacle detected between the
photocel.
•Incorrect electric wiring.
• Disconnected photocell.
• Disconnected photocell
active input.
• Disconnected safety edge.
• Photocell in opening non-aligned.
• Obstacle detected between the
photocel.
•Incorrect electric wiring.
• Disconnected photocell.
• Permanent PEDESTRIAN command.
• Opening limit switch ACTIVATED.
• Incorrect electric wiring.
• Bordo sensibile non collegato.
• Faulty safety edge.
Solution
Release and open the gate manually, the LED must turn on.
Check the wiring and operation of the photocell.
Check the wiring and operation of the motors.
Check the connection to the power supply (230V).
Check the operation of the ACCESSORIES wired to the START
(N.O. contact, see section 3.3).
Check the wiring otherwise deactivate the input.
Check the wiring diagram (see section 3.5)
Check the photocell alignment.
Check and remove the obstacle.
Check the wiring diagram.
Check the power connection.
Disable the photocell input (see section 3.6)
Check the connection (N.C.) and the good operation of the
safety edge.
Check the photocell alignment.
Check and remove the obstacle.
Check the wiring diagram.
Check the power connection.
Check the operation of the ACCESSORIES wired to the
PEDESTRIAN START (N.O. contact).
Release and close the gate manually, the LED must turn on.
Check the wiring diagram and the good operation of the
micro switch in opening.
Check the wiring.
Check the safety edge conditions.
Led Error
DL9 OFF
DL1 2 blinks, stop,
2 blinks ....
3 blinks, stop
3 blinks ....
OFF
DL4 ON
DL5 OFF
DL7 OFF
DL8 OFF
DL6 ON
DL10 OFF
DL3 OFF
9. TROUBLE SHOOTING – ERROR MESSAGES
The control panel is designed to display errors through a LED lighting system.
Here below the trouble shooting table.

Il nostro Servizio Assistenza è a tua dis
per qualsiasi chiarimento
sul prodotto, sull'installazione o sulla garanzia:
dal Lunedì al Venerdi, dalle 8.30 alle 12.00 e dalle 13.30 alle 17.00
346/4192300 [email protected]
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. [phone] - Fax [phone] [email protected] - www.proteco.net
Managing Director
CE COMPLIANCE DECLARATION
Manufacturer: PROTECO S.r.l.
Address: Via Neive, 77 – 12050 Castagnito (CN) – ITALIA
declares that
The product type: Q81S electronic controller for sliding gate automa�on (1 motor), 230V
Models: S
Accessories: MRX01
Is built to be integrated into a machine or to be assembled with other machinery to crate a machine
under provisions of 2006/42/EC Machinery Direc�ve.
It complies with the essen�al requirements of EEC Direc�ves:
20 / 5/EC ow Voltage Direc ve
20 4/ 0/EC Electromagne c Compa�bility Direc ve
2014/53/ Radio & Telecommunica�ons Terminal Equipments Direc�ve
The manufacturer declares that the start-up of the machinery is not permi d unless the machine, in
which the product is incorporated or of which is becoming a component, has been ide ed and declared
as conformed to 2006/42/EC Machinery Dire ve.
Note: These products have undergone test in a typical uniform on
Castagnito, January 19 th 2018
Marco Gallo
Managing Director
