MyGate MYASTER NEW User manual

01_22
Installation manual
MYASTER NEW
Automation for swing gates
A9fw6w_ri3ell_8ok.pdfA9fwA9fw6w_ri3ellA9fw6w_ri3eA9o6eo01_1wtk798_8l8.pdfA9o6A9o6eo01_1wtkA9o6eo01_1w

01
................................................................................................................... page 01
01
02
...........................................................................................................................................
...................................................................................................................................... 02
......................................................................................................... 03
................................................................................................................... 04
3.4.1
3.4.2
11
page
.................................................................................................................................................. 12
page
.......................................................................................................................................................... 12
page
05
.................................................................................................................. 05
................................................................................................................................. 05
3.4.3 07
3.4.4 08
..................................................................................................................... page 13
02
02
page
3.4.5
1.
Contents
WARNINGS
2. INTENDED USE AND APPLICATION
Kit contents
3. INSTALLATION
Preliminary checks 3.1
3.2
3.3
3.4
Tools and materials (not included)
Wiring
Installing the operator
4. MANUAL RELEASE
............................................................................................................................................................. page 12
2.1
2.2
2.3
Technical data
Operator dimensions
........................................................................................................................................................
.............................................................................................................................
........................................................................................................................
..............................................................................................................
...............................................................................................................................................
.............................................................................................................................
page
page
..................................................................................................................... page
................................................................................................................. page
page
page
page
page
page
page
page
page
.............................................................................................................. page 09
Quotes from ground
Pillar quotes
Outward opening
Fixing the pillar bracket
Fixing the gate bracket
Wirings
3.4.6
.......................................................................................................................................... page 10
installation overview
5. MAINTENANCE
6. WARRANTY
7. DISPOSAL
8. COMPLIANCE DECLARATION CE

rev01_22
2. INTENDED USE AND APPLICATION
MYASTER operator is designed to automate swing gates.
The use of this product for purposes other than those described and installation executed in a manner
other than as instructed in this technical manual are prohibited.
All MYASTER systems are locked, therefore no electric-lock is needed.
In case of power cut the gate operator can be easily released by manual operation.
1
Connect the automation to the earth system, which must be efficient and properly carried out.
The installation of automatic doors and gates must comply with the Machine Directive 2006/42/CE, in
particular EN 12453 and performed by qualified personnel only.
Make sure the main power line is equipped with state of the art safety grounding system; as well be
sure the whole installation is protected by a power cut switch and against overcurrent.
Make sure the area is clear from flammable gases and/or electromagnetic interferences: it could lead
to very dangerous injuries.
Switch the power and batteries OFF before any operation.
After installation, packaging and waste materials (cardboard, plastic, metal parts etc.) must be kept
away from children as they could be potentially harmfull.
Use only original spare parts. Any alteration to the system is prohibited.
Proteco Srl will not respond in case of using additional and/or fake spares.
Before commissioning the system, deliver the last pages of this manual to the user.
Proteco S.r.l. reserves the right to make changes to the product without notice.
1. WARNINGS
This manual contains important information concerning personal safety. An incorrect installation or an
improper use may lead to severe injuries. Read carefully and store for future use.
Pay particular attention to this symbol
Double leaf composition
1
2
3
4
01
02
03
04
n°2
n°1
n°2
n°2
Operators
Fitting bag
Release keys
Capacitors
Installation manual
n°1

2.2 TECHNICAL DATA
2.3 OPERATOR DIMENSIONS
MYASTER 3 NEW = 620 - MYASTER 4 NEW = 720
MYASTER 5 NEW = 820 - MYASTER 6 NEW = 920 MYASTER 3 NEW = 940 - MYASTER 4 NEW = 1140 MYASTER 5 NEW = 1340 - MYASTER 6 NEW = 1540
159 mm172 mm
117117 104104
5353
Motor 24V
Motor 230/115V 64
MYASTER 3 NEW
230V-50Hz
1,7
280
8
150°
2800
44
1400
100°
17"
350
2,00
40%
Power supply
Max. motor voltage
Rated power
Capacitor
Thermal cut off
Rated thrust
Ip rating
Revolutions
Max.opening angle
Opening time - 90°
Max. leaf weight
Max. leaf length
Duty cycle
V
A
W
µF
C°
N
IP
rpm
deg
s
Kg
m
%
24Vdc
0,75
50
--
--
2500
44
1700
100°
13,5"
275
2,00
80%
115V-60Hz
2,3
300
30
150°
3000
44
1700
100°
14"
300
2,00
40%
230V-50Hz
1,7
280
8
150°
2800
44
1400
110°
22"
350
2,8
40%
24Vdc
0,75
50
--
--
2500
44
1700
110°
18"
250
2,50
80%
115V-60Hz
2,3
300
30
150°
3000
44
1700
110°
18"
300
2,8
40%
230V-50Hz
1,7
280
8
150°
2800
44
1400
110°
27"
250
3,50
40%
24Vdc
0,75
50
--
--
2500
44
1700
110°
22,5"
150
3,00
80%
115V-60Hz
2,3
300
30
150°
3000
44
1700
110°
22"
200
3,50
40%
230V-50Hz
1,7
280
8
150°
2800
44
1400
120°
32"
250
4,00
40%
3. INSTALLATION
3.1 PRELIMINARY CHECKS
Before proceeding to installation, it is necessary to double check the good condition of every component
and make sure the site is suitable for installation purposes.
•All components must be integral and suitable to use.
•Make sure the area around the system is clear enough to allow eazy and safe manual operation.
•Make sure weight, dimensions and gate features are suitable to the model you have choosen.
•Make sure the gate area is fitted with ground stops both in opening and closing.
•Make sure the gate is mechanically free of friction.
•Make sure the automation fixing area is compatible with the dimensions of the brackets and that there is
sufficient space to carry out manual operation easily and safely.
•Make sure the automation positioning area is not subject to flooding.
•Make sure the electric circuit is connected to a state of the art safety grounding.
•Make sure the fixing surfaces of the photocells are flat and allow correct alignment between transmitter and
receiver.
2rev01_22
MYASTER 4 NEW MYASTER 5 NEW MYASTER 6

3
rev01_22
3.2 TOOLS AND MATERIALS (NOT INCLUDED)
brick
Ø 18mm
concrete
Ø 15mm
inox/alu. tubular stainless steel
PILLARS AND WALLS
LEAF
stainless steel/alu wood
3+3 3+3 3+3 3+3
2+2 2 +2

Key switch
Blinker
3.3 WIRING INSTALLATION OVERVIEW
NB: Cables necessary for the installation of the system (not included) may vary according to the quantity
and type of accessories and devices fitted.
• Switch the POWER OFF before starting any wiring.
• Fit a power cut switch to protect the electric plant against overcurrent.
The standard requires a separation of contacts of at least 3 mm in each pole(EN 60335-1).
• The installation requires skills in the electrical and mechanical fields; it must only be performed by qualified
personnel able to release the declaration of conformity (type A) on the whole installation (Machine Directive
2006/42/CEE, attachment IIA).
• The main electric plant shall comply with the oustanding regulation and shall be state of the art carried out.
•The power supply lines to the motors, control unit and accessories must be separated in order to avoid possible
interferences that could generate system malfunctions.
• The electric cable coming out of the actuator must not be stretched but make a wide downward curve to
avoid the backflow of water inside the actuator itself (see the picture above).
B
Operator
Control unit
C
C¹
D
E
F
RX photocell
TX photocell
Antenna
Radio receiver
ELENCO CAVI PER I VARI DISPOSITIVI
A
G
pic. B
4rev01_22
pic. A
3 x 1,5 mm² + Terra
2 x 1,5 mm² + Terra
4 x 0,5 mm²
2 x 0,5 mm²
2 x 0,5 mm²
230V/115V
2 x 0,5 mm²
2 x 0,5 mm²
RG58
24V
2 x 0,5 mm²
2 x 0,5 mm²
4 x 0,5 mm²
2 x 0,5 mm²
RG58
2 x 0,5 mm²
2 x 1,5 mm²
2 x 1,5 mm² + Terra

3.4 INSTALLING THE OPERATOR
Check the orientation of the motors, left or right hand, referring to picture A. If hinges are positioned on the right
(property view), the motor will be right hand, and viceversa.
Make sure the gate is fitted with ground stops both in opening and closing (picture C).
3.4.1. QUOTES FROM GROUND
Brackets must be positioned at a minimum height of (picture D). If the gate is particularly light, fit the
operator as closer as possible to gate centerline.
3.4.2. PILLAR QUOTES
The ideal approach is to fix the brackets complying with the measures A and B as indicated in the
below table for an opening angle of 90° (picture E/J).
pic. E
pic. J
B = ground stops
LH OPERATOR
pic. C
pic. D
minimo
30 mm
5
rev01_22
RH OPERATOR
Required
height
400 mm
min.
MYASTER 3 NEW: A=150 B=150
MYASTER 4 NEW: A=200 B=200
MYASTER 5 NEW: A=250 B=250
MYASTER 6 NEW: A=300 B=300
MYASTER 3 NEW: D= max 125 mm
MYASTER 4 NEW: D= max 175 mm
MYASTER 5 NEW: D= max 225 mm
MYASTER 6 NEW: D= max 275 mm

3.3.2. CONSIGLI PER L’INSTALLAZIONE
Tutti i collegamenti devono essere effettuati in assenza d’alimentazione.
Prevedere un dispositivo di sezionamento onnipolare nelle vicinanze dell’apparecchio (i contatti devono essere di
almeno 3mm). Proteggere sempre l’alimentazione per mezzo di un interruttore automatico da 6A, oppure per mezzo
di un interruttore monofase da 16A completo di fusibili.
Le linee di alimentazione ai motori, alla centrale e di collegamento agli accessori devono essere separate onde evitare
disturbi che potrebbero generare mal funzionamenti dell’impianto.
Il cavo elettrico in uscita dall’attuatore non deve essere teso ma fare un’ampia curva verso il basso onde evitare il
riflusso di acqua all’interno dell’attuatore stesso (fig.B)
fig. B
3.4 FISSAGGIO MOTORI
Identificare gli attuatori sinistro e destro in base alla figura (fig. C): se le cerniere sono sulla destra l’attuatore
è destro, viceversa se sono sulla sinistra. Accertarsi che il cancello sia dotato di fermi meccanici in apertura e in chiusura (fig. D)
Fig. C
B B
B
B = Fermi meccanici
Fig. D
3.4.1. DETERMINAZIONE ALTEZZA DI FISSAGGIO ATTUATORI
L’altezza di fissaggio consigliata è compresa tra 40-50 cm (fig.E).
In caso di cancelli con struttura leggera, tenere l’attuatore più vicino possibile alla mezzeria del cancello.
Fig. E
h min= 15 cm
h max= 60 cm
motore sinistro motore destro
If the ideal scenario of A and B is not applicable, then refer to the below table to get some other possible
combinations according to the width of the pillar.
Values are expressed in mm. MYASTER NEW can replace the previous model ensuring the same excursions
and the same opening angles, without having to replace the existing ones.
MYASTER 6 NEW (90°)
D275 250 225 200 175 150 125 100 75
A210 240 280 275 300 300 330 370 410
B335 330 305 310 285 290 265 240 215
Bracket 80 80 80 110 110 140 140 140 140
Minimum
leaf length 1320 1300 1280 1280 1260 1270 1240 1220 1200
MYASTER 5 NEW (90°)
D225 200 175 150 125 100 75 50 25
A165 190 200 200 200 200 250 300 345
B305 280 255 260 265 240 215 190 165
Bracket 80 80 80 110 140 140 140 140 140
1150 1130 1130 1130 1140 1120 1100 1070 1050
MYASTER 3 NEW (90°)
D125 100 75 50 25 0
A110 150 145 140 135 160
B205 150 155 160 165 140
Bracket 80 50 80 110 140 140
860 840 840 850 850 830
MYASTER 4 NEW (90°)
D175 150 125 100 75 50 25 0
A115 140 165 160 155 180 210 240
B255 230 205 210 215 190 165 140
Bracket 80 80 80 110 140 140 140 140
1000 980 980 970 970 970 950 930
30 mm
NB: for an opening
angle of 90° the
minimum
recommended
distance between
the hinge and the
pillar is 30 mm.
MYASTER 6 NEW (110°)
D150 125 100 75
A250 260 280 275
B260 235 210 215
Distance between
hinge and pillar 80 70 60 50
Bracket 110 110 110 140
Minimum leaf
length 1300 1280 1250 1260
MYASTER 6 NEW (120°)
D125 100 75
A290 285 185
B175 180 280
100 90 70
50 80 110
1250 1260 1260
MYASTER 5 NEW (110°)
D100 75 50 25
A220 220 215 235
B210 185 190 165
70 60 50 40
80 110 140 140
1100 1100 1200 1200
MYASTER 4 NEW (110°)
D50 0
A175 175
B140 140
40 30
80 140
925 920
MYASTER 3 NEW (110°)
D25 0
A165 140
B120 140
40 30
140 140
810 800
6rev01_22
Minimum
leaf length
Minimum
leaf length
Minimum
leaf length
Distance between
hinge and pillar
Bracket
Minimum leaf
length
Distance between
hinge and pillar
Bracket
Minimum leaf
length
Distance between
hinge and pillar
Bracket
Minimum leaf
length
Distance between
hinge and pillar
Bracket
Minimum leaf
length

3.4.3. OUTWARD OPENING
It's possible to have your gate opening outward (picture F/G/H)
5 mm 5 mm
5 mm
30 mm
pic.F pic.G
pic.H
A91opudl4_12fsum_bko.pdfA91oA91opudl4_12fA91opudl4_1
MYASTER 3 NEW MYASTER 4 NEW MYASTER 5 NEW MYASTER 6 NEW
A115 115 115 115
B220 200 200 200
Distance from pillar 5 5 5 5
Bracket 140 140 140 140
Min. Leaf length 800 1000 1200 1200

3.4.4. FIXING THE PILLAR BRACKET
In order to properly cut the bracket start 12 mm from the hole center, as shown in the picture I.
Fix the motor to the bracket following the below procedure:
Linea di taglio
> 30
12 mm
pic.L
•Remove screw from plastic cap (picture L - A).
•Fit the bracket to the motor (picture L).
•Fit the pin (picture M).
•Put the cap back and screw (picture N).
RH cap = RH motor
LH cap = LH motor
pic.I
pic.M pic.N
NB: Be carefull when fitting the cap. It has to match the proper motor.
8rev01_22

2 cm
pic.O pic.P
pic.Q pic.R
pic.S
•Put the gate to CLOSING position.
•Unlock the operator (refer to section 4 Manual Operation).
•Extend the inox arm fully.
•Turn back the arm 2 cms. This avoids the motor to “leap forward” (picture O).
Press the plastic cap with little force, and gently slide it forward (picture P).
Insert the bracket in the motor and fit the pin (picture Q).
•Mount the arm of the motor onto the gate. Ensure the arm is perfectly straight. Check the manual opening of
the leaf before definitively fixing the bracket to make sure the gate can open fully to your required angle.
•If the bracket position is the correct one, remove the pin (picture S) and proceed to definitively fix it.
•Repeat steps shown in picture Q and R.
3.4.5. FIXING THE GATE BRACKET
Follow the below procedure to determine the bracket position on the gate:
9
rev01_22

3.4.6. WIRINGS
Attention!
An incorrect wiring could lead to failures and very dangerous injuries. Therefore carefully follow the
wiring instructions contained in this manual.
Switch the power and batteries OFF before any wiring operation.
The electric plant must be performed by qualified personnel and must comply with the outstanding
regulations.
ATTENTION!
The electric plant must be protected by a ground system, in accordance to the
current safety regulations.
Do not let the motor wire stretch during opening and closing.
Capacitors are provided just with 230V and 115V motors.
10 rev01_22
pic.T
ATTENTION!
The electric plant must be protected by a ground system, in
accordance to the current safety regulations.
Do not let the motor wire stretch during opening and closing.
Capacitors are provided just with 230V and 115V motors.
leleft right

•Switch the POWER OFF.
•Lift the plastic cap acting on the right side of the operator (picture U).
•Plug the release key and turn it 180° counter clockwise as shown in picture V.
•The operator is now unlocked, manually open and close the gate.
•Put the gate to closing position, lock the operator turning the release key 180° clockwise.
•Reposition the plastic cap as shown in pictures Y/Z.
Put a little force on the cap to reach the correct position.
•Switch the POWER ON.
4. MANUAL RELEASE
pic. U pic. V
pic.Y pic.Z
11
rev01_22

5.MAINTENANCE
ATTENTION!
Maintenance service must be carried out by qualified technical personnel, in full compliance with the safety
standards required by the laws in force. Maintenance has to be carried out every six months.
In order to proceed to maintenance service, follow the below checks:
•Turn the POWER OFF.
•Check the good condition of any component.
•Check screw connections are properly tightened.
•Unlock the operator, and make sure the gate opens and closes freely. Clean the inox arm using a dry cloth (no
lubrication needed).
•Put the gate to closing position, lock the operator and if necessary repeat the programming procedure.
RELEASE SYSTEM TEST:
•In order to check the good operation of the release system put the gate to closing position and unlock to motor.
The unlock operation has to be smooth and eazy.
•The gate has to move freely in both directions.
•The release key has to turn smoothly and eazily.
6.WARRANTY
PROTECO products are covered by a 3-year limited warranty from the production date printed on the product.
During this period, Proteco Srl offers a guarantee in case of malfunction due to construction, material or assembly
faults. Warranty terms are applicable just if the instructions and maintenance included in this manual are fully
respected and carried out.
Warranty is void when fake spares are used and doesn't respond for faults due to incorrect installation.
Installation and any maintenance works are responsibility of the person installing the system.
In no case and in no way will Proteco Srl be liable to the end user for damages, including any loss of profits, savings or
other accidental or indirect damages, resulting from the use or inability to use PROTECO products.
Any return without authorization number will be rejected.
The shipment of the returned product and the related costs are the end user/buyer charge.
All defective products must be returned together with the proof of payment to:
PROTECO Srl Via Neive 77, 12050 Castagnito (CN) - Italia
Warranty is void when:
-The product has been treated / stored under abnormal conditions of use and maintenance.
-The product has been repaired, modified or altered.
-The product has been subject to misuse, neglect, electrical problems, improper package, accident, or natural events.
-The product was installed improperly.
-The product warranty label is illegible or is missing entirely.
-The malfunction is due to improper installation or to natural and/or accidental causes (eg: falls, oxidation, overvoltage).
7.DISPOSAL
Any part of the system, including devices such as remote controls, must be disposed in compliance with current
legislation, as they may be harmfull for the environment.
Most of the materials used are similar to solid urban waste and can be handled accordingly.
They can be recycled through separate collection and disposed in authorized centers.
Other components (electronic boards, batteries, etc.) may instead contain polluting substances.
They must therefore be removed and delivered to companies authorized for their recovery and disposal.
Before proceeding, it is always advisable to check the specific regulations in force.
Disposal of packing
Packaging components (cardboard, plastics, etc.) are sare similar to solid urban waste and can be handled
accordingly without any difficulty, simply by carrying out separate collection for recycling. Before proceeding, it is
always advisable to check the specific regulations in force.
DO NOT POLLUTE THE ENVINRONMENT!
12rev01_22

Address:
Manifacturer: PROTECO S.r.l.
Via Neive, 77 - 12050 CASTAGNITO (CN) - ITALY
declares that:
The product type:
Models:
Automation for swing gates MYASTER
MYASTER 3 NEW, MYASTER 4 NEW, MYASTER 5 NEW, MYASTER 6 NEW,
MYASTER 3 24 NEW, MYASTER 4 24 NEW, MYASTER 5 24 NEW,
MYASTER 3 115 NEW, MYASTER 4 115 NEW, MYASTER 5 115 NEW.
Castagnito, 2021 November 21st Marco Gallo
CEO
is built to be integrated into a machine or to be assembled with other machinery to crate a machine
under provisions of 2006/42/EC Machinery Directive.
It complies with the essential requirements of EEC Directives:
2011/65/CE (RoHS 2) + 2015/863/UE (RoHS 3)
2014/35/UE (LVD)
2014/30/UE (EMC)
The product also complies with:
EN12453,
EN55014-1, EN55014-2,
EN61000-6-1, EN61000-6-3 EN 60335-1,
EN 60335-2-103
The manufacturer declares that the start-up of the machinery is not permitted unless the machine, in
which the product is incorporated or of which is becoming a component, has been identified and
declared as conformed to 2006/42/EC Machinery Directive.
13
rev01_22
COMPLIANCE DECLARATION

Via Neive, 77 - 12050 CASTAGNITO (CN) ITALY Tel. [phone]
mygateautomation.com [email protected]
