MyQ Chamberlain C2102C User manual

®
®
USER'S GUIDE
FOR RESIDENTIAL USE ONLY
Chain Drive Models - C2102C, C2202C, C2202TC, C2405TC, D2101C,
D2405C, D2405TC
Belt Drive Models - B2202TC, B2405TC, B4505TC
Wi-Fi®Garage Door Opener
•Please read this guide and the enclosed safety materials carefully!
•The door WILL NOT CLOSE unless the Protector System® is connected and properly aligned.
•Periodic checks of the garage door opener are required to ensure safe operation.
•This garage door opener is ONLY compatible with myQ® and Security+ 2.0® accessories.
•DO NOT install on a one-piece door if using devices or features providing unattended close.
Unattended devices and features are to be used ONLY with sectional doors.
•Attach warning labels to the location indicated on label.
Download the myQ®App to Set Up an Account and Connect
Open and close your door, get alerts and set schedules from anywhere. Connected smart garage door openers also receive software updates to
ensure the opener has the latest operational features. See page 1.
Available on most iOS and Android Devices
Download the free BILT App
before assembly
Easy step-by-step
interactive 3D instructions
for this product can be found in
Download the free myQ®App
Monitor and control your garage
from anywhere and get real-time alerts
with peace of mind.
To register your garage door opener to receive updates and offers from Chamberlain, visit chamberlain.registria.com or use the icon below:
CHAMBERLAIN
1. Take a photo of the camera icon including
the points ( ).
2. Send it in by texting the photo to 71403
(US) or visit www.chamberlain.photo
(Global).
1

Contents
Unattended Operation 2
Important Installation Instructions 3
Power 3
Important Safety Instructions 4
Connect With Your Smartphone 5
Test the Wi-Fi® Signal Strength 5
Programming 7
Remote Control 7
Wireless Keyless Entry 7
To Erase the Memory 7
Operation 8
To Open the Door Manually 8
Battery Backup 9
Door Control 9
The Protector System® (Safety Reversing Sensors) 10
Adjustment 11
Introduction 11
Adjustment 12
1 - Program the Travel 12
2 - Automatic Force Set Up 12
3 - Test the Safety Reversal System 13
4 - Test the Protector System® 13
Maintenance 14
The Remote Control Battery 14
Troubleshooting 14
Repair Parts and Accessories 15
Warranty 15
Automatic Garage Door Opener Safety & Maintenance Guide 16
myQ®Serial Number
Write down the following information for future reference:
myQ
®
Serial Number:
Product Serial Number:
Date of Purchase:
/ /
Serial
Number
myQ
®
Serial Number
Safety Symbol and Signal Word
Review
This garage door opener has been designed and tested to offer safe
service provided it is installed, operated, maintained and tested in
strict accordance with the instructions and warnings contained in this
manual.
When you see these Safety Symbols and Signal Words on the following
pages, they will alert you to the possibility of serious injury or death if
you do not comply with the warnings that accompany them. The
hazard may come from something mechanical or from electric shock.
Read the warnings carefully.
Mechanical
Electrical
When you see this Signal Word on the following pages, it will alert you
to the possibility of damage to your garage door and/or the garage
door opener if you do not comply with the cautionary statements that
accompany it. Read them carefully.
WARNING: This product can expose you to chemicals
including lead, which are known to the State of California to
cause cancer or birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
Unattended Operation
The Timer-to-Close (TTC) feature, the myQ® App, and myQ® Garage
Door and Gate Monitor are examples of unattended close and are to be
used ONLY with sectional doors. Any device or feature that allows the
door to close without being in the line of sight of the door is
considered unattended close. The Timer-to-Close (TTC) feature, the
myQ® App, and any other myQ® devices are to be used ONLY with
sectional doors.
2

Important Installation Instructions
IMPORTANT INSTALLATION INSTRUCTIONS
To reduce the risk of SEVERE INJURY or DEATH:
1. READ AND FOLLOW ALL INSTALLATION WARNINGS AND
INSTRUCTIONS.
2. Install garage door opener ONLY on properly balanced and
lubricated garage door. An improperly balanced door may NOT
reverse when required and could result in SEVERE INJURY or
DEATH.
3. ALL repairs to cables, spring assemblies and other hardware
MUST be made by a trained door systems technician BEFORE
installing opener.
4. Disable ALL locks and remove ALL ropes connected to garage
door BEFORE installing opener to avoid entanglement.
5. Where possible, install the door opener 7 feet (2.13 m) or more
above the floor.
6. Mount the emergency release within reach, but at least 6 feet
(1.83 m) above the floor and avoiding contact with vehicles to
avoid accidental release.
7. NEVER connect garage door opener to power source until
instructed to do so.
8. NEVER wear watches, rings or loose clothing while installing or
servicing opener. They could be caught in garage door or
opener mechanisms.
9. Install wall-mounted garage door control:
•within sight of the garage door.
•out of reach of small children at a minimum height of 5feet
(1.5m) above floors, landings, steps or any other adjacent
walking surface.
•away from ALL moving parts of the door.
10. Place entrapment warning label on wall next to garage door
control.
11. Place manual release/safety reverse test label in plain view on
inside of garage door.
12. Upon completion of installation, test safety reversal system.
Door MUST reverse on contact with a 1-1/2" (3.8cm) high object
(or a 2x4 laid flat) on the floor.
13. To avoid SERIOUS PERSONAL INJURY or DEATH from
electrocution, disconnect ALL electric and battery power
BEFORE performing ANY service or maintenance.
14. DO NOT install on a one-piece door if using devices or features
providing unattended close. Unattended devices and features
are to be used ONLY with sectional doors.
15. SAVE THESE
INSTRUCTIONS.
Power
To prevent possible SERIOUS INJURY or DEATH from electrocution or
fire:
•Be sure power is NOT connected to the opener, and disconnect
power to circuit BEFORE removing cover to establish permanent
wiring connection.
•Garage door installation and wiring MUST be in compliance with
ALL local electrical and building codes.
•NEVER use an extension cord, 2-wire adapter, or change plug in
ANY way to make it fit outlet. Be sure the opener is grounded.
To reduce the risk of electric shock, your garage door opener has a
grounding type plug with a third grounding pin. This plug will only fit
into a grounding type outlet. If the plug doesn’t fit into your outlet,
contact a qualified electrician to install the proper outlet.
Option A - Typical Wiring
1. Plug in the garage door opener into a grounded outlet.
2. DO NOT run garage door opener at this time.
Option B - Permanent Wiring
If permanent wiring is required by your local code, refer to the
following procedure. To make a permanent connection through the
7/8 inch hole in the top of the motor unit (according to local code):
Ground Tab
Green
Ground
Screw
Ground
Wire
White Wire
Black
Wire
Black
Wire
1. Remove the motor unit cover
screws and set the cover
aside.
2. Remove the attached 3-
prong cord.
3. Connect the black (line) wire
to the screw on the brass
terminal; the white (neutral)
wire to the screw on the silver
terminal; and the ground wire
to the green ground screw. The opener must be grounded.
4. Reinstall the cover.
3

Important Safety Instructions
IMPORTANT SAFETYINSTRUCTIONS
To reduce the risk of SEVERE INJURY or DEATH:
1. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS.
2. ALWAYS keep remote controls out of reach of children. NEVER
permit children to operate or play with garage door control push
buttons or remote controls.
3. ONLY activate garage door when it can be seen clearly, it is
properly adjusted, and there are no obstructions to door travel.
4. ALWAYS keep garage door in sight and away from people and
objects until completely closed. NO ONE SHOULD CROSS THE
PATH OF THE MOVING DOOR.
5. NO ONE SHOULD GO UNDER A STOPPED, PARTIALLY OPENED
DOOR.
6. If possible, use emergency release handle to disengage trolley
ONLY when garage door is CLOSED. Use caution when using
this release with the door open. Weak or broken springs or
unbalanced door could result in an open door falling rapidly
and/or unexpectedly and increasing the risk of SEVERE INJURY
or DEATH.
7. NEVER use emergency release handle unless garage doorway is
clear of persons and obstructions.
8. NEVER use handle to pull garage door open or closed. If rope
knot becomes untied, you could fall.
9. After ANY adjustments are made, the safety reversal system
MUST be tested.
10. ALWAYS KEEP GARAGE DOOR PROPERLY BALANCED. An
improperly balanced door may NOT reverse when required and
could result in SEVERE INJURY or DEATH.
11. ALL repairs to cables, spring assemblies and other hardware,
ALL of which are under EXTREME tension, MUST be made by a
trained door systems technician.
12. To avoid interference with the proper operation of the garage
door opener when using a welder in the garage, unplug garage
door opener before operating welder.
13. To avoid SERIOUS PERSONAL INJURY or DEATH from
electrocution, disconnect ALL electric and battery power
BEFORE performing ANY service or maintenance.
14. This operator system is equipped with an unattended operation
feature. The door could move unexpectedly. NO ONE SHOULD
CROSS THE PATH OF THE MOVING DOOR.
15. DO NOT install on a one-piece door if using devices or features
providing unattended close. Unattended devices and features
are to be used ONLY with sectional doors.
16. SAVE THESE
INSTRUCTIONS.
NOTICE: This device complies with part 15 of the FCC rules and Innovation, Science and Economic Development Canada license-exempt RSSs. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This device must be installed to ensure a minimum 20 cm (8 in.) distance is maintained between users/bystanders and device.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules and Industry Canada ICES standard.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
4

Connect With Your Smartphone
IMPORTANT: Set up a myQ®account and connect your garage door opener to the
Wi-Fi®network using the myQ App before finalizing installation
You must set up a myQ® account and connect the garage door opener to Wi-Fi® in order for it to be installed successfully.
You will need:
•Wi-Fi® enabled smartphone, tablet or laptop
•Broadband Internet Connection
•Wi-Fi® signal in the garage (2.4 GHz, 802.11b/g/n required)
•Password for your home network (router's main account, not guest network)
Test the Wi-Fi®Signal Strength
Make sure your mobile device is connected to your Wi-Fi® network. Hold your mobile device in the place where your garage door opener is installed
and check the Wi-Fi signal strength.
Check Signal Strength. If you see:
Wi-Fi signal is strong.
The garage door opener will
connect to your Wi-Fi network.
Wi-Fi signal is weak.
The garage door opener may connect to your
Wi-Fi network. If not, try one of the options
below to improve the Wi-Fi signal:
No Wi-Fi signal.
The garage door opener will not be able to
connect to your Wi-Fi network. Try one of the
options below to improve the Wi-Fi signal:
• Move your router closer to the garage door opener to minimize
interference from walls and other objects
• Buy a Wi-Fi range extender
For compatible router specifications and help, visit support.chamberlaingroup.com.
5

Connect With Your Smartphone
Download the myQ®App to Set Up an Account and Connect
Open and close your door, get alerts and set schedules from anywhere. Connected smart garage door openers also receive software updates to
ensure the opener has the latest operational features.
The garage door opener must run through a complete cycle before it will activate Wi-Fi® programming.
1. Download the myQ® App.
2. Set up an account and connect.
If you already have the myQ® App installed:
1. Check that your mobile device has the latest software.
2. Download the latest version of the myQ®App.
For more information on connecting your garage door opener, visit support.chamberlaingroup.com.
Wi-Fi Status
LED Definition
Blue Off - Wi-Fi® is not turned on.
Blinking - Garage door opener is in Wi-Fi® learn mode.
Solid - Mobile device connected to the garage door opener.
Blue and Green Blinking - Attempting to connect to router.
Green Blinking - Attempting to connect to the Internet server.
Solid - Wi-Fi® has been set up and garage door opener is connected to the Internet.
An LED on the garage door
opener will indicate Wi-Fi
status. See table.
LED
Google Play and the Google Play logo are trademarks of Google LLC.
App Store and the Apple and App Store logos are trademarks of Apple Inc.
6

Programming
Remote Control
Below are the steps to program a new or existing remote control. Test
remote control before reprogramming.
1. Press and release the LEARN Button on the
garage door opener.
2. Press and hold the button on the remote
control that you wish to use. Release the
button when the garage door opener lights
blink or two clicks are heard.
Note: Remote may vary.
OR
For Multi-Function Control Panel
LEARN Button
1. Press the LEARN button on the
door control to enter
Programming Mode.
2. Press the LEARN button again, the
LED will flash once.
3. Press the button on the remote
control that you wish to operate
your garage door.
OR
For Push Button Door Control
Push Button
Light/Learn
Button
1. Press and hold the Light button
and the Push button until the
Push button LED begins to blink.
2. Press the button on the remote
control that you wish to operate
your garage door.
If your vehicle is equipped with a
Homelink®, you may require an external adapter depending on the
make, model, and year of your vehicle.
Visit www.homelink.com for additional information.
Wireless Keyless Entry
Refer to the instructions provided with your keyless entry OR go to
Chamberlain.com to download instructions.
To Erase the Memory
LEARN
Button
Erase ALL Remote Controls and Keyless
Entries
Press and hold the LEARN button until
the LED goes out (approximately 6
seconds).
All remote controls and keyless entries are now erased.
Erase ALL Devices (Including myQ® enabled accessories)
1. Press and hold the LEARN button until the LED goes out
(approximately 6 seconds).
2. Immediately press and hold the LEARN button until the LED goes
out. All codes are now erased.
Adjustment
Button
Erase the Wi-Fi Network from the
Garage Door Opener
Press and hold the adjustment button
until 3 beeps are heard
(approximately 6 seconds).
Programming
Buttons
7

Operation
To prevent possible SERIOUS INJURY or DEATH from a
falling garage door:
•If possible, use emergency release handle to
disengage trolley ONLY when garage door is CLOSED.
Weak or broken springs or unbalanced door could
result in an open door falling rapidly and/or
unexpectedly.
•NEVER use emergency release handle unless garage
doorway is clear of persons and obstructions.
•NEVER use handle to pull door open or closed. If rope
knot becomes untied, you could fall.
Use an A19 incandescent (100W maximum) or compact fluorescent 26W
(100W equivalent) light bulb. DO NOT USE halogen, short neck, or specialty
light bulbs. DO NOT USE LED bulbs.
To Open the Door Manually
NOTE: Disengage any
door locks before
proceeding.
1. The door should be
fully closed if
possible.
2. Pull down on the
emergency release
handle.
Lockout Feature
1. Pull the emergency
release handle
down and back. The
door can then be
raised and lowered
manually as often
as necessary.
2. To disengage the lockout feature, pull the handle straight
down.
The trolley will reconnect on the next time the opener is
activated.
8

Operation
Battery Backup
The battery backup allows access in and out of your garage when the
power is out. When the garage door opener is operating on battery
power, the garage door opener will run slower and the lights, Timer-to-
Close, and remote close features (myQ® App) are disabled. In battery
backup mode, the Automatic Garage Door Lock will unlock when the
garage door is opened, and will remain disabled until power is restored.
During a power outage the battery supplies power for up to 24 hours of
operation. For maximum battery life and prevent damage, disconnect the
battery when the garage door opener is unplugged for an extended
period of time.
Battery
Status LED
Green battery status LED: All
systems are normal.
•A solid green LED light
indicates the battery is fully
charged.
•A flashing green LED
indicates the battery is being
charged.
Orange battery status LED: The garage door opener has lost power
and is in battery backup mode.
•Solid orange LED while the motor is on, indicates the garage
door opener is operating on battery power.
•A flashing orange LED while the motor is on, indicates the
battery is low.
Red battery status LED: The garage door opener's 12V battery needs
to be replaced.
•A solid red LED indicates the 12V battery will no longer hold a
charge.
Door Control
Multi-Function Control Panel
Service LED
LEARN Button
LOCK Button
Command LED
Light Button
Push Bar
OR
Push Button Door Control
Push Button
Light/Learn
Button
•The garage door opener must run through a complete cycle before it
will activate Wi-Fi®programming. For help related to Wi-Fi, visit
support.chamberlain.com.
9

Operation
The Protector System®(Safety Reversing Sensors)
Be sure power is NOT connected to the garage door opener
BEFORE installing the safety reversing sensor.
To prevent SERIOUS INJURY or DEATH from closing garage door:
•Correctly connect and align the safety reversing sensor.
This required safety device MUST NOT be disabled.
•Install the safety reversing sensor so beam is NO HIGHER
than 6" (15 cm) above garage floor.
The door will not close if the sensors have not been installed and
aligned correctly.
When the light beam is obstructed or misaligned while the door is
closing, the door will reverse. If the door is already open, it will not
close.
The sensors can be aligned by loosening the wing nuts, aligning the
sensors, and tightening the wing nuts. Check to make sure the LEDs
in both sensors are glowing steadily. The LEDs in both sensors will
glow steadily if they are aligned and wired correctly.
Wing Nut Wing Nut
Light Beam Protection Area
Sending sensor - amber LED
6" (15 cm) max. above floor
Receiving sensor - green LED
6" (15 cm) max. above floor
Receiving sensor has a
sticker on the back.
If either of the sensor LEDs are off, there is no power to the sensor:
1. Check that you have power to the garage door opener.
2. Check the sensor wire is not shorted or broken.
3. Check that the sensors are wired correctly; white wires to white terminal and white/black wires to grey terminal.
If the green receiving sensor LED is blinking, the sensors are obstructed or misaligned:
1. Check for obstructions in the sensor light beam.
2. Align the sensors.
3. If the receiving sensor (green LED) faces direct sunlight, switch the sensors to opposite sides of the door to assure proper operation.
10

Adjustment
Introduction
Without a properly installed safety reversal system, persons
(particularly small children) could be SERIOUSLY INJURED or
KILLED by a closing garage door.
•Incorrect adjustment of garage door travel limits will
interfere with proper operation of safety reversal system.
•After ANY adjustments are made, the safety reversal system
MUST be tested. Door MUST reverse on contact with 1-1/2"
(3.8 cm) high object (or 2x4 laid flat) on floor.
To prevent damage to vehicles, be sure fully open door provides
adequate clearance.
Your garage door opener is designed with electronic controls to make
setup and adjustments easy. The adjustments allow you to program
where the door will stop in the open (UP) and close (DOWN) position.
The electronic controls sense the amount of force required to open
and close the door. The force is adjusted automatically when you
program the travel.
NOTE: If anything interferes with the door’s upward travel it will stop.
If anything interferes with the door’s downward travel, it will reverse.
Programming
Buttons
Programming Buttons
The programming buttons are located
on the back panel of the garage door
opener and are used to program the
travel. While programming, the UP
and DOWN buttons can be used to
move the door as needed.
UP Button
Adjustment
Button
DOWN Button
11

Adjustment
1- Program the Travel
Without a properly installed safety reversal system, persons (particularly small children) could be SERIOUSLY INJURED or KILLED by a closing
garage door.
•Incorrect adjustment of garage door travel limits will interfere with proper operation of safety reversal system.
•After ANY adjustments are made, the safety reversal system MUST be tested. Door MUST reverse on contact with 1-1/2" (3.8 cm) high
object (or 2x4 laid flat) on floor.
Note: While programming the travel, the UP and DOWN buttons can be used to move the door as needed. During the Automatic Force Setup, the
door will automatically open and close.
1Press and hold the Adjustment
Button until the UP Button begins to
flash and/or a beep is heard. The
Safety Reversing Sensors will be
disconnected during the Program the
Travel process.
2Press and hold the UP
Button until the door is in
the desired UP position.
3Once the door is in the desired UP
position press and release the
Adjustment Button. The garage door
opener lights will flash twice and the
DOWN Button will begin to flash.
4Press and hold the
DOWN button until the
door is in the desired
DOWN position.
5Once the door is in the desired DOWN
position press and release the Adjustment
Button. The garage door opener lights will
flash twice. Program the Travel is now
complete. If the garage door opener
lights flash 5 times, then programming
has timed out and the Travel Limits have
not been set. Please restart the Program the Travel process.
2- Automatic Force Set Up
Once both the up and down positions have been manually set, the Safety Reversing Sensors will reconnect and become operational. Then, the
opener will enter a force-sensing operation by automatically moving the door open and close. The garage door opener will sound an audible and
visual alert before automatically opening and closing the door. The garage door opener will beep three times, confirming that the Automatic Force
Setup completed successfully. Adjustment is complete.
If you hear one long beep after the door attempts to move, then the Automatic Force Set Up has not completed successfully. Please start over at
step 1 of Program the Travel.
12

Adjustment
3- Test the Safety Reversal System
Without a properly installed safety reversal system, persons
(particularly small children) could be SERIOUSLY INJURED or
KILLED by a closing garage door.
•Safety reversal system MUST be tested every month.
•After ANY adjustments are made, the safety reversal system
MUST be tested. Door MUST reverse on contact with 1-1/2"
(3.8 cm) high object (or 2x4 laid flat) on the floor.
1With the door fully open, place a 1-1/2 inch (3.8 cm) board (or a
2x4 laid flat) on the floor, centered under thegarage door.
2Press the remote control push button to close the door. The door
MUST reverse when it makes contact with the board.
If the door stops but does not reverse:
1. Repeat Program the Travel (seeAdjustment Step 1);
2. Repeat the Safety Reversal test.
If the test continues to fail, call a trained door systems technician.
4- Test the Protector System®
Without a properly installed safety reversing sensor, persons
(particularly small children) could be SERIOUSLY INJURED or
KILLED by a closing garage door.
1Open the door. Place an obstruction in the path of thedoor.
2Press the remote control push button to close the door. The door
will not move more than an inch (2.5 cm).
The garage door opener will not close from a remote control if the
LED in either safety reversing sensor is off (alerting you to the fact
that the sensor is misaligned or obstructed).
If the garage door opener closes the door when the safety reversing
sensor is obstructed (and the sensors are no more than 6 inches [15
cm] above the floor), call for a trained door systems technician.
13

Maintenance
Every Month
•Manually operate door. If it is unbalanced or binding, call a
trained door systems technician.
•Check to be sure door opens and closes fully. Adjust if necessary,
page 12.
•Test the safety reversal system. Adjust if necessary, page 13.
Every Year
•Oil door rollers, bearings and hinges. The garage door opener
does not require additional lubrication. Do not grease the door
tracks.
•(If applicable) Test the battery backup and consider replacing the
battery to ensure the garage door opener will operate during an
electrical power outage.
1. Unplug the garage door opener from AC power. The battery
status LED will glow solid orange (opener is operating on
battery power) or will flash (low battery power).
2. Open and close the door using the remote control or door
control.
3. In battery backup mode, the Automatic Garage Door Lock will
unlock when the garage door is opened, and will remain
disabled until power is restored.
4. Plug in the garage door opener. Verify the battery status LED
is flashing green (battery is charging).
Every Two to Three Years
•Use a rag to wipe away the existing grease from the garage door
opener rail. Reapply a small layer of white lithium grease to the
top and underside of the rail surface where the trolley slides.
The Remote Control Battery
To prevent possible SERIOUS INJURY or DEATH:
•NEVER allow small children near batteries.
•If battery is swallowed, immediately notify doctor.
To reduce risk of fire, explosion or chemical burn:
•Replace ONLY with 3V CR2032 coin batteries.
•DO NOT recharge, disassemble, heat above 212°F (100°C) or
incinerate.
1 button
1
3
2
Replace with
only 3V CR2032
coin cell battery.
Pry open the case first
in the middle (1), then
at each side (2 and 3)
with visor clip.
3-Button
1
3
2
Replace with
only 3V CR2032
coin cell battery.
Pry open the case first
in the middle (1), then
at each side (2 and 3)
with visor clip.
Troubleshooting
Below are basic troubleshooting tips, for additional help and support
videos visit support.chamberlain.com or contact your installing dealer.
My garage door opener will not close:
Check to make sure the LEDs in both sensors are glowing steadily. The
LEDs in both sensors will glow steadily if they are aligned and wired
correctly. See page 10.
My vehicle’s Homelink® is not programming to my garage door
opener:
Depending on the make, model, and year of your vehicle an external
adapter may be required. Visit www.homelink.com for additional
information.
My garage door opener beeps:
The garage door opener can beep for several reasons:
•The opener senses an obstruction while traveling.
•Garage door opener has been activated through a device or
feature such as Timer-to-Close, garage door monitor or Internet
Gateway.
My neighbor’s remote control opens my garage door:
Erase the memory from your garage door opener and reprogram the
remote control(s).
The garage door moves 6-8", stops or reverses:
•Manually open and close the garage door. Garage door may be
binding or there may be an obstruction. If the door is binding, call
a trained door systems technician.
•Possible travel module failure.
My remote control will not activate the garage door:
Verify the lock feature is not activated on the door control or
reprogram the remote control.
The wall-mounted door control will not function:
The wires for the door control are shorted or the door control is faulty.
Garage door opener hums for 1-2 seconds with no movement and 5
flashes and 5 beeps occur:
Manually open and close the garage door. Garage door may be binding
or there may be an obstruction. If the door is binding, call a trained
door systems technician.
Cannot connect garage door opener to home Wi-Fi network:
Ensure the myQ® Serial number was entered correctly and try again.
The myQ® characters are between A-F and 0-9 only.
For complete manuals or available parts and accessories, visit
support.chamberlaingroup.com.
14

Repair Parts and Accessories
To see repair parts or accessories for your garage door opener, identify the model number on the end panel of the opener and visit
support.chamberlaingroup.com to download or print the installation manual.
Warranty
CHAMBERLAIN®LIMITED WARRANTY
The Chamberlain Group LLC® (“Seller”) warrants to the first retail purchaser of this product, for the residence in which this product is originally
installed, that it is free from defects in materials and/or workmanship for a specific period of time as defined below (the “Warranty Period”). The
warranty period commences from the date of purchase. The Chamberlain Group LLC warrants to the first retail purchaser of this product, for the
residence in which this product is originally installed, that it is free from defects in materials and/or workmanship for a specific period of time as
defined below (the “Warranty Period”). The warranty period commences from the date of purchase.
WARRANTY PERIOD
Model Parts Motor Accessories Belt or Chain
B2202TC 1 year 6 years 1 year 5 years
B2405TC 1 year 10 years 1 year 15 years
B4505TC 5 years Lifetime 1 year Lifetime
C2102C 1 year 6 years 1 year 1 year
C2202C,C2202TC 1 year 6 years 1 year 1 year
C2405TC 1 year 10 years 1 year 1 year
D2101C 1 year 6 years 1 year 1 year
D2405C,D2405TC 1 year 6 years 1 year 1 year
The proper operation of this product is dependent on your compliance with the instructions regarding installation, operation, and maintenance and
testing. Failure to comply strictly with those instructions will void this limited warranty in its entirety.
If, during the limited warranty period, this product appears to contain a defect covered by this limited warranty, visit chamberlain.com, before
dismantling this product. You will be advised of disassembly and shipping. Then send the product or component, pre-paid and insured, as directed
to our service center for warranty repair. Please include a brief description of the problem and a dated proof-of-purchase receipt with any product
returned for warranty repair. Products returned to Seller for warranty repair, which upon receipt by Seller are confirmed to be defective and covered
by this limited warranty, will be repaired or replaced (at Seller’s sole option) at no cost to you and returned pre-paid. Defective parts will be repaired
or replaced with new or factory-rebuilt parts at Seller’s sole option. [You are responsible for any costs incurred in removing and/or reinstalling the
product or any component].
ALL IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE APPLICABLE LIMITED WARRANTY PERIOD SET FORTH ABOVE FOR
THE RELATED COMPONENT(S), AND NO IMPLIED WARRANTIES WILL EXIST OR APPLY AFTER SUCH PERIOD. Some States and Provinces do not
allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. THIS LIMITED WARRANTY DOES NOT
COVER NON-DEFECT DAMAGE, DAMAGE CAUSED BY IMPROPER INSTALLATION, OPERATION OR CARE (INCLUDING, BUT NOT LIMITED TO
ABUSE, MISUSE, FAILURE TO PROVIDE REASONABLE AND NECESSARY MAINTENANCE, UNAUTHORIZED REPAIRS OR ANY ALTERATIONS TO
THIS PRODUCT), LABOR CHARGES FOR REINSTALLING A REPAIRED OR REPLACED UNIT, REPLACEMENT OF CONSUMABLE ITEMS (E.G.,
BATTERIES IN REMOTE CONTROL TRANSMITTERS AND LIGHT BULBS), OR UNITS INSTALLED FOR NON-RESIDENTIAL USE. THIS LIMITED
WARRANTY DOES NOT COVER ANY PROBLEMS WITH, OR RELATING TO, THE GARAGE DOOR OR GARAGE DOOR HARDWARE, INCLUDING BUT
NOT LIMITED TO THE DOOR SPRINGS, DOOR ROLLERS, DOOR ALIGNMENT OR HINGES. THIS LIMITED WARRANTY ALSO DOES NOT COVER ANY
PROBLEMS CAUSED BY INTERFERENCE. UNDER NO CIRCUMSTANCES SHALL SELLER BE LIABLE FOR CONSEQUENTIAL, INCIDENTAL OR
SPECIAL DAMAGES ARISING IN CONNECTION WITH USE, OR INABILITY TO USE, THIS PRODUCT. IN NO EVENT SHALL SELLER’S LIABILITY FOR
BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE OR STRICT LIABILITY EXCEED THE COST OF THE PRODUCT COVERED HEREBY.
NO PERSON IS AUTHORIZED TO ASSUME FOR US ANY OTHER LIABILITY IN CONNECTION WITH THE SALE OF THIS PRODUCT.
Some states and provinces do not allow the exclusion or limitation of consequential, incidental or special damages, so the above limitation or
exclusion may not apply to you. This limited warranty gives you specific legal rights, and you may also have other rights, which vary from state to
state and province to province.
15

Automatic Garage Door Opener Safety & Maintenance Guide
Garage Door Opener Safety – An Automatic Decision
A garage door is the largest moving object in the home. An improperly adjusted garage door and opener can exert deadly force when the door
closes – which could lead to entrapment of children or adults and subsequent injury or death.
Proper installation, operation, maintenance, and testing of the garage door and automatic opener are necessary to provide a safe, trouble-free
system. Careless operation or allowing children to play with or use garage door opener controls are also dangerous situations that can lead to tragic
results. A few simple precautions can protect your family and friends from potential harm. Please review the safety and maintenance tips in this
guide carefully and keep it for reference. Check the operation of your garage door and opener to ensure they function in a safe and trouble-free
manner. Be sure to read all Important Safety Information found in your garage door opener’s manual as it provides more details and safety
considerations than can be supplied with this guide.
Garage Door Openers are Not Toys
Discuss garage door and opener safety with your children. Explain the danger of being trapped under the door.
Stay away from a moving door.
Keep transmitters and remote controls out of reach of children. Do not let children play with
or use transmitters or other remote control devices.
The wall-mounted push button should be out of reach of children, at least 5feet from the
nearest standing surface and away from all moving parts. Mount and use the button where you
can clearly see the closing garage door.
Keep the door in sight until it completely closes when using the wall-mounted push button or
transmitter.
16

Routine Maintenance Can Prevent Tragedies
Make monthly inspection and testing of your garage door and opener system a part of your regular routine. Review your owner’s manual for both
the door and door opener. If you don’t have the owner’s manuals, contact the manufacturer(s) and request a copy for your specific model(s). Look for
the opener model number on the back of the power unit.
WARNING – Springs are under high tension. Only qualified individuals should adjust them.
Visually check the door and installation:
•Starting with the door in the closed position, use the manual disconnect on the opener to
disconnect the door.
•Look for signs of wear or damage on hinges, rollers, springs, and door panels.
•These parts may require periodic lubrication. Check the owner’s manual for suggested
maintenance.
•If any signs of damage are evident, contact a trained door systems technician for
assistance.
•Verify the photoeye height is no higher than 6" from the garage floor.
Test the door for proper operation:
•Open and close the door manually using handles or suitable gripping points.
•The door should move freely and without difficulty.
•The door should balance and stay partially open 3–4 feet above the floor.
•If you detect any signs of improper operation, contact a trained door systems technician
for assistance.
1
2
Test the opener safety features:
•Reconnect the opener to the door using the manual disconnect and open the door.
•Place a 2x4 board flat in the path of the door (1) and try to close it (2). The door should
stop when it comes in contact with the 2x4 and then reverse direction.
•Block the photoelectric sensor by waving an object in front of the sensor and attempt to
close the door. The door should not close unless the wall-mounted push button is
manually held during operation.
•If the opener does not perform as described, contact a trained door systems technician
for assistance.
17

®
®
GUIDE D’UTILISATION
USAGE RÉSIDENTIEL UNIQUEMEN
Modèles à entraînement par chaîne - C2102C, C2202C, C2202TC, C2405TC,
D2101C, D2405C, D2405TC
Modèles à entraînement par courroie - B2202TC, B2405TC, B4505TC
Ouvre-porte de garage Wi-Fi®
•Veuillez lire attentivement ce guide et les documents relatifs à la sécurité ci-joints!
•La porte NE SE FERME PAS tant que le Protector System® n’est pas connecté et aligné correctement.
•Des vérifications périodiques de l’ouvre-porte de garage sont nécessaires pour assurer un fonctionnement sûr.
•Cet ouvre-porte de garage est SEULEMENT compatible avec les accessoires myQ® et Security+ 2.0®.
•Ne l’installez PAS sur une porte monobloc si vous utilisez des dispositifs ou des fonctionnalités permettant une fermeture
sans surveillance.
Les dispositifs et fonctionnalités sans surveillance doivent être utilisés UNIQUEMENT avec des portes sectionnelles.
•Fixez les étiquettes d’avertissement à l’endroit indiqué sur l’étiquette.
Téléchargez l’application myQ®pour ouvrir un compte et vous connecter
Ouvrez et fermez votre porte, recevez des alertes et définissez des horaires à partir de n’importe où. Les ouvre-portes de garage intelligents
connectés reçoivent également des mises à jour logicielles afin de garantir que l’ouvre-porte dispose des dernières fonctionnalités
opérationnelles. Voir la page 1.
Disponible sur la plupart des appareils iOS et Android
Téléchargez l’application gratuite myQ®
Téléchargez l'application gratuite BILT
avant assemblage
Pour enregistrer votre ouvre-porte de garage afin de recevoir des mises à jour et des offres de Chamberlain, visitez
chamberlain.registria.com ou utilisez l’icône ci-dessous:
CHAMBERLAIN
1. Prenez une photo de l’icône d’appareil
photo incluant les points ( ).
2. Envoyez-la par SMS au numéro 71403
(États-Unis) ou en visitant le site
www.chamberlain.photo (monde).
1

Contenu
Fonctionnement sans surveillance 2
Instructions d’installation importantes 3
Alimentation 3
Consignes de sécurité importantes 4
Connectez-vous avec votre téléphone intelligent 5
Testez la force du signal the Wi-Fi® 5
Programmation 7
Télécommande 7
Entrée sans clé sans fil 7
Pour effacer la mémoire 7
Operation 8
Ouvrir la porte manuellement 8
Batterie de Secours 9
Commande de porte 9
Le Protector System® (capteurs d’inversion de sécurité) 10
Ajustements 11
Introduction 11
Ajustements 12
1 - Programer le déplacement 12
2 - Réglage de la force automatique 13
3 - Tester le système d’inversion de sécurité 14
4 - Tester le Protector System® 14
Maintenance 15
Batterie de la télécommande 15
Dépannage 15
Pièces détachées et accessoires 16
Garantie 16
Guide de sécurité et d’entretien de l’ouvre-porte de garage
automatique 17
Numéro de série myQ®
Notez les renseignements suivants pour références futures:
Numéro de série myQ
®
:
Numéro de série du produit :
Date d’achat :
/ /
Numéro
de série
Numéro de série myQ
®
Examen des symboles de sécurité et
des notes d’avertissement.
Cet ouvre-porte de garage a été conçu et testé pour offrir un service
sûr à condition qu’il soit installé, utilisé, entretenu et testé en stricte
conformité avec les instructions et les avertissements de ce manuel.
Lorsque vous voyez ces symboles de sécurité et notes d’avertissement
aux pages suivantes, ils vous avertissent du risque de blessures graves
voire mortelles si vous ne respectez pas les avertissements qu’ils
accompagnent. Le danger peut provenir de quelque chose de
mécanique ou d’un choc électrique. Lisez attentivement les
avertissements.
AVERTISSEMENT
Mécanique
AVERTISSEMENT
Électrique
Lorsque vous voyez ce mot d’avertissement aux pages suivantes, il vous
avertit du risque que votre porte de garage et/ou l’ouvre-porte soit
endommagé(e) si vous ne respectez pas les mises en garde qui
l’accompagnent. Lisez-les attentivement.
ATTENTION
AVERTISSEMENT: Ce produit peut vous exposer à des
produits chimiques, dont le plomb, qui sont reconnus par
l’État de Californie comme provoquant le cancer, des
malformations congénitales ou d’autres problèmes de
reproduction. Pour plus d’information, visitez
www.P65Warnings.ca.gov
Fonctionnement sans surveillance
La fonction de minuterie de fermeture (TTC), l’application myQ®et le
moniteur de porte de garage et de portail myQ®sont des exemples de
fermeture sans surveillance et doivent être utilisés UNIQUEMENT avec
des portes sectionnelles. Tout dispositif ou fonction permettant à la
porte de se fermer sans être dans le champ de vision de cette dernière
est considéré comme une fermeture sans surveillance. La fonction de
minuterie de fermeture (TTC), l’application myQ®et tout autre appareil
myQ®doivent être utilisés UNIQUEMENT avec des portes sectionnelles.
2

Instructions d’installation importantes
INSTRUCTIONS D’INSTALLATION IMPORTANTES
AVERTISSEMENT
Pour réduire le risque de BLESSURES GRAVES voire
MORTELLES:
1. LISEZ ET SUIVEZ TOUS LES AVERTISSEMENTS ET TOUTES LES
INSTRUCTIONS D’INSTALLATION.
2. Installez l’ouvre-porte de garage UNIQUEMENT sur une porte de
garage correctement équilibrée et lubrifiée. Une porte mal
équilibrée risque de ne PAS s’inverser lorsque cela est
nécessaire et pourrait entraîner des BLESSURES GRAVES voir
MORTELLES.
3. TOUTES les réparations de câbles, ressorts et autre matériel
DOIVENT être effectuées par un technicien en systèmes de
portes qualifié AVANT l’installation de l’ouvre-porte.
4. Désactivez TOUTES les serrures et retirez TOUTES les cordes
connectées à la porte de garage AVANT d’installer l’ouvre-porte
pour éviter qu’elles s’enchevêtrent.
5. Dans la mesure du possible, installez l’ouvre-porte à une hauteur
minimum de 2,13m (7pi) du sol.
6. Montez le déverrouillage d’urgence à portée de main, mais à une
hauteur minimum de 1,83m (6pi) du sol et en évitant tout
contact avec les véhicules afin d’éviter un déclenchement
accidentel.
7. Ne branchez JAMAIS l’ouvre-porte de garage à une source
d’alimentation avant d’y être invité.
8. NE portez JAMAIS de montres, bagues ou vêtements amples en
installant ou entretenant l’ouvre-porte. Ils pourraient être
happés dans les mécanismes de porte de garage ou d’ouvre-
porte.
9. Installez la commande de porte de garage murale:
•en vue de la porte du garage.
•hors de portée des jeunes enfants, à une hauteur minimale de
1,5m (5pieds) au-dessus du sol, des paliers, des marches ou
de toute autre surface de marche adjacente.
•loin de TOUTES les pièces mobiles de la porte.
10. Placez une étiquette d’avertissement de piégeage sur le mur, à
côté de la commande de porte de garage.
11. Placez l’étiquette de test d’inversion de sécurité/déverrouillage
d’urgence bien en vue à l’intérieur de la porte de garage.
12. Une fois l’installation terminée, testez le système d’inversion de
sécurité. La porte DOIT s’inverser au contact d’un objet de
3,8cm (1-1/2po) de haut (ou un 2x4 posé à plat) sur le sol.
13. Pour éviter des BLESSURES PERSONNELLES GRAVES voire
MORTELLES électrocution, débranchez TOUTE l’alimentation
électrique et la batterie AVANT d’effectuer tout entretien ou
TOUTE maintenance.
14. Ne l’installez PAS sur une porte monobloc si vous utilisez des
dispositifs ou des fonctionnalités permettant une fermeture sans
surveillance. Les dispositifs et fonctionnalités sans surveillance
doivent être utilisés UNIQUEMENT avec des portes sectionnelles.
15. CONSERVER CES
INSTRUCTIONS.
Alimentation
Pour éviter les risques de BLESSURE GRAVE ou FATALE par
électrocution ou incendie:
•Assurez-vous que le courant n’est PAS connecté à l’ouvre-porte,
et débranchez le courant du circuit AVANT de retirer le couvercle
pour établir une connexion permanente.
•L’installation et le câblage de la porte de garage DOIVENT être
conformes TOUS les codes électriques et de construction locaux.
•N’utilisez JAMAIS de rallonge, d’adaptateur à 2fils ou ne
modifiez en AUCUN cas la fiche pour l’adapter à la prise.
Assurez-vous que l’ouvre-porte est mis à la terre.
Pour réduire le risque de choc électrique, votre ouvre-porte de garage
est équipé d’une fiche de type mise à la terre avec une troisième
goupille de mise à la terre. Cette fiche rentre seulement dans une
prise de terre. Si la fiche ne rentre pas dans la prise, communiquer
avec un électricien qualifié pour faire installer une prise adéquate.
Option A - Câblage typique
1. Branchez l’ouvre-porte de garage dans une prise de courant
mise à la terre.
2. Ne faites PAS fonctionner l’ouvre-porte de garage à ce moment-
là.
Option B - Câblage permanent
Si un câblage permanent est requis par votre code local, consultez la
procédure suivante. Pour effectuer une connexion permanente à
travers le trou de 7/8pouces dans le haut de l’unité moteur (selon le
code local):
Onglet de terre
Vis de
terre
verte
Fil de
terre
Fil blanc
Fil
noir
Fil
noir
1. Retirez les vis du couvercle de
l’unité moteur et mettez le
couvercle de côté.
2. Retirez le cordon à trois broches
qui y est attaché.
3. Connectez le fil noir (ligne) à la
vis de la borne en laiton; le fil
blanc (neutre) à la vis de la
borne argentée; et le fil de terre
à la vis de terre verte. L’ouvre-
porte doit être mis à la terre.
4. Réinstallez le couvercle.
3
