Mytopia EuroChef User manual

Electric Air Fryer / Oven

User Manual

[Revision 7.0 February 2018]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY

DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by

this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

Electric Air Fryer / Oven

Table of Contents

Safety...............................................................................................................................................................3

Parts Identification .........................................................................................................................................4

Introduction ....................................................................................................................................................5

Before Use Check List ...................................................................................................................................5

Operation ........................................................................................................................................................6

Control Panel .............................................................................................................................................6

Cooking Guidelines....................................................................................................................................7

Using Cooking Pre-Sets.............................................................................................................................7

Manual Cooking .........................................................................................................................................8

Using Cooking Accessories .......................................................................................................................8

Roasting Using the Rotisserie or Rotary BBQ .....................................................................................8

Baking..................................................................................................................................................8

Steaming Using the Steaming Tray .....................................................................................................8

Defrosting ............................................................................................................................................9

"Frying" Using the Cage ......................................................................................................................9

Cleaning and Maintenance ............................................................................................................................9

Self-Cleaning .............................................................................................................................................9

Troubleshooting ...........................................................................................................................................10

Specifications ...............................................................................................................................................10

Recipe Suggestions .....................................................................................................................................11

Electric Air Fryer / Oven

Safety

Keep this user manual for future reference along with your purchase receipt and carton. The safety

precautions below reduce the risk of electrical shock, fire, personal injury and appliance and property

damage when correctly adhered to.

•Read all instructions before using the appliance.

•Do NOT touch hot surfaces. The temperature of outer surfaces can become very hot during use. Always

use suitable heat-proof gloves when handling hot materials and allow metal parts to cool before

cleaning. Allow the unit to cool thoroughly before inserting or removing parts. Always use the handles

when moving the unit.

•Do NOT use the appliance for anything other than its intended use.

•Before turning on, ensure the electrical voltage and frequency of the circuit corresponds to those

indicated on the rating label of the appliance.

•To protect against the risk of electric shock, do not immerse the appliance, electrical cord or plug in

water or any other liquids.

•The appliance is not intended to be operated by means of an external timer or any type of separate

remote control system.

•The use of attachments which are not recommended or sold by the manufacturer may cause fire, electric

shock or injury.

•This appliance is designed for indoor use only. Do NOT use outdoors.

•Do NOT use an extension cord with this product unless absolutely necessary. If an extension cord is

used, ensure that it has a rating equal to or exceeding the rating of this appliance.

•Do NOT pull or carry the appliance by the electrical cord. Keep the cord away from heated surfaces and

sharp edges etc. Do not bend or kink the power cord.

•Always unplug the appliance when not in use. To disconnect from the power supply, grip the plug and

pull from the power socket. Never pull by the cord. The power plug must be removed from the power

socket before cleaning, servicing, maintenance or moving the appliance .

•Never force the power cord plug into an electrical outlet.

•Do NOT place the appliance near a hot gas or electric burner.

•Do NOT cover the appliance whilst in use. If it is covered there is a risk of fire.

•Improper installation may result in the risk of fire, electric shock and/or injury.

•If the power cord or plug is damaged, DO NOT use the appliance. Return it to the place of purchase

along with your receipt for a refund or exchange.

•The manufacturer or retailer is not responsible for any damage caused by incorrect use.

•The appliance contains no user-serviceable parts. Do not attempt to repair, disassemble or modify the

appliance.

•Always operate the appliance on a dry and level surface. Operating in wet areas such as sinks or

uneven surfaces must be avoided.

•Do NOT clean the appliance with metal scouring pads, abrasives, flammable materials or solvents.

•Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.

•Do NOT move or lift the appliance while the power cord is still connected to the wall outlet. Metal items

inside the appliance, such as the racks, can get very hot during use. Use caution when removing these

items and always use the suitable heat-proof gloves and tongs.

EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF

Electric Air Fryer / Oven

Parts Identification

Note: The style and appearance of some accessories, such as prongs and rotisserie attachments may vary

slightly between various models. The basic function of each accessory, however, remains the same.

No. Name No. Name

1 Base 6 Tongs - For inserting and removing food,

plates, and racks.

2

Lid

7

Rack - For grilling, toasting and dry frying.

3 Control Panel (built into top of lid) 8 Steaming Tray - For steaming fish,

vegetables, etc.

4 Bowl 9 Rotisserie - For cooking using a rotating

action; for example, using the cage, roasting

cuts of meat, whole chicken etc.

5 Cage - For cooking small, high quantity

items such as chips, meatballs, etc.

10 Rotary BBQ - For cooking using a rotating

action; for example, roasting cuts of meat.

2

3

1

4

6

7

8

5

9

10

EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF

Electric Air Fryer / Oven

Introduction

With the electric air fryer/oven, you can prepare delicious, healthy meals in considerably less time to that of

traditional methods through the forced circulation of hot air around the food. The air fryer improves upon

traditional ovens in the following ways:

•The appliance uses a circular pot with a lid mounted fan and heating element that circulates hot air all

around the food. This creates a tornado-like flow of super-heated air that cooks and browns food quickly

and thoroughly.

•The appliance uses cooking racks that allow you to cook two separate items at once. In addition, when

meat, poultry, or fish is cooked, fats and oils are drained away. You will cook lighter, more nutritious

meals.

•The appliance cooks food from all sides to provide even cooking and is generally 50% faster than

traditional oven cooking.

•The appliance lid is glass, so you can clearly see the food being cooked.

Before Use Check List

Read the safety instructions in this manual before operating. Before using this appliance for the first time,

follow the steps below:

1. Remove all packing materials and literature from the appliance, and ensure that it is in good condition

and there are no missing parts or damage.

2. Wash the bowl and racks in warm soapy water or in the dishwasher, then dry thoroughly. NEVER

submerge the appliance lid in water or any other liquid.

3. Select a flat, heat-resistant and non-flammable surface to operate the appliance on.

4. Perform the self-cleaning function.

NOTE:This appliance has a pressure switch that prevents it heating if the appliance is empty. • A small

amount of smoke and burning smell may be emitted during the first few uses. Do not be alarmed, this is

normal.

5. Allow the appliance to cool to room temperature.

6. Wipe the inside of the bowl with a damp cloth. DO NOT use abrasive cleaners or scouring pads.

EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF

Electric Air Fryer / Oven

Operation

Control Panel

Control Description

Display - Shows the current setting for either temperature or time. The

indicator for either temperature or time illuminates according to the setting

being made. When the appliance is in use, the timer countdown displays.

Pre-Set Cooking Function Selector - Press to select a pre-set cooking

function, if required. Press again to step to the next function. As each function

is selected, the indicator next to it illuminates. Pre-set functions are:

Meat – Default settings are temperature = 250°C and timer = 10

minutes.

Poultry – Default settings are temperature = 250°C and timer =

30 minutes.

Fish – Default settings are temperature = 200°C and timer = 15

minutes.

Bake – Default settings are temperature = 230°C and timer = 10

minutes.

Chips – Default settings are temperature = 250°C and timer =

18 minutes.

Pizza – Default settings are temperature = 200°C and timer =

14 minutes.

Temperature Adjustment - Press to activate the temperature setting function.

The temperature indicator in the display illuminates (default value = 60°C). Use

+/ -to set the required temperature (range = 60 to 250°C). The temperature

can be adjusted at any time.

Timer Adjustment - Press to activate the cooking time setting function. The

time indicator in the display illuminates (default value = 30 minutes). Use +/ -

to set the required time (range = 01 to 30 minutes). The timer can be adjusted

at any time.

Settings Confirmation – Press to confirm the current cooking settings. Press

and hold for 2 seconds during cooking to cancel the current settings.

Increase Temperature / Time – Press to increase the time or temperature

setting. As the setting changes, the display update to show the current value.

Decrease Temperature / Time – Press to decrease the time or temperature

setting. As the setting changes, the display update to show the current value.

EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF

Electric Air Fryer / Oven

Cooking Guidelines

Always ensure that food is adequately cooked before consumption. • Ensure that you use the

supplied tongs, heat resistant mitts or other appropriate utensils to remove food and cookware from

the appliance. Do not touch the food or the appliance or any of the internal accessories as they may be

extremely hot. • Cooking time and temperature settings may need to be adjusted for food size/quantity, food

manufacturer instructions, and /or individual taste. All cooking settings can be adjusted at any time.

1. Before cooking, it is suggested that you lightly coat the inside of the bowl and racks etc with cooking

spray. This will help prevent food sticking and also make cleaning easier.

2. Place the bowl inside the appliance base, ensuring it is central and sits flat. The bowl has a protrusion on

one side that prevents it from being placed in an incorrect position.

3. Place the food to be cooked into the bowl using the appropriate accessory (rotisserie, rack etc). The type

of accessory used will be dependent on the type of food being cooked. When using the rack, the high

position (rack standing on long legs) is best for grilling, broiling, crisping or cooking well done cuts of

meat; the low position (rack standing on low legs) is best for baking, roasting etc.

4. Once the food has been placed into the appliance, place the lid on the appliance. Ensured the lid is

seated correctly and is secure. If the lid is not placed correctly, the appliance will not function.

5. Plug the appliance into the wall socket and switch it on. The display will show "88:88".

6. Use the control panel to set the required cooking functions. Once the settings are confirmed, the

appliance will start.

7. At the end of the cooking time, the appliance will beep, cooking will cease and the heating element will

switch off. Depending on the temperature of the unit, the fan may remain on in order to dissipate the

remaining heat.

Pausing Cooking - If you need to pause cooking, remove the lid – the appliance will stop automatically and

pause the current cooking settings. If you place the lid back on the appliance within 3 minutes, the appliance

will start automatically, resuming the original cooking settings. If you take longer than 3 minutes to resume

cooking, you may need to press the Confirm button.

Changing Cooking settings - If the cooking settings need to be changed or restarted, press and hold the

Confirm button for 2 seconds. The program will return to the default settings and you can then restart the

cooking process

Using Cooking Pre-Sets

The appliance includes pre-set cooking time and temperature settings for a range of popular food types. This

makes setting up the appliance for cooking easier – select the required pre-set, then adjust the settings, if

required. After placing the lid on the appliance and switching power to the unit on, the display will show

"88.88", then:

1. Press Menu repeatedly until the indicator lamp next to the required pre-set illuminates; for example,

"meat".

2. Press Confirm – the appliance beeps and begins operating and will apply the pre-set temperature and

time settings. Using "meat" as an example, the temperature will be 250°C and the time will be 10

minutes. To adjust settings:

•To change temperature, press Temp – the appliance defaults to "60°C" and the display indicator for

setting temperature illuminates. Press +or –as required (maximum = 250°C) until the desired

temperature is reached, then press Confirm.

•To change timer, press Time – the appliance defaults to "30.00" and the display indicator for setting

time illuminates. Press +or –as required (maximum = 30 minutes) until the desired time is reached,

then press Confirm.

EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF

Electric Air Fryer / Oven

Manual Cooking

The appliance can be used without selecting a cooking pre-set. When a pre-set is not selected it is

necessary to set the temperature and time manually.

After placing the lid on the appliance and switching power to the unit on, the display will show "88.88", then:

1. Press Temp – the appliance defaults to "60°C" and the display indicator for setting temperature

illuminates. Press +or –as required (maximum = 250°C) until the desired temperature is reached, then

press Confirm.

2. Press Time – the appliance defaults to "30.00" and the display indicator for setting time illuminates.

Press +or –as required (maximum = 30 minutes) until the desired time is reached, then press Confirm.

The following table provides a guide for cooking some popular food types.

Food Time (Minutes) Temperature (°C)

Prawns (medium size) 6 to 8 150 to 180

Sausages 6 to 8 120 to 150

Bread 5 to 7 120 to 140

Potatoes and Vegetables 8 to 10 180 to 200

Chicken Wings 15 to 20 150 to 180

Hot Dogs 5 to 8 190 to 210

Spare Ribs 8 to 12 220 to 240

Chicken Pieces 8 to 10 230 to 250

Using Cooking Accessories

Roasting Using the Rotisserie or Rotary BBQ

The rotisserie and rotary BBQ accessories are used to rotate the food during cooking, and is especially

suited to roasting whole chickens and larger cuts of meat. Place the food on to the rotisserie by passing the

rotisserie shafts through the food item, then attach the other end of the rotisserie to the shafts and secure it

using the thumbscrews (rotate right). With the rotary BBQ, hold the food item in position using the prongs to

pierce it. Place the rotisserie/food into the bowl – ensure that the end of the rotisserie shaft is properly

engaged with the appliance and the groove in the other end of the shaft is resting on the support bracket

inside the bowl.

NOTE: Roasting time may vary depending on the type of meat or other food, type of cut, amount of fat,

thickness and/or weight of the item. • It is not necessary to use oil for roasting, but you may do so for foods

that tend to become dry when cooked. • Ensure that the food item, when on the rotisserie or rotary BBQ,

does not contact either the lid or the food bowl when it rotates.

Baking

Use any oven-proof baking dish, preferably non-stick, that will fit comfortably inside the appliance bowl and

place it on the cooking rack in the low position (rack standing on short legs). Take special care when baking,

as it can be easy to over-cook. It is recommended to occasionally rotate the food item a little to help ensure

even browning.

Steaming Using the Steaming Tray

Add a cup (approximately 250ml) of water to the appliance bowl and season etc. Place the food item on to

the steaming tray and place it on the cooking rack in the high position (rack standing on long legs) inside the

bowl. For steaming vegetable whilst cooking other items, place the vegetables in an aluminium foil pouch,

add a few drops of water to the pouch and seal it.

EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF

Electric Air Fryer / Oven

Defrosting

You can use the appliance to defrost foods more evenly than a microwave oven. To defrost, set the

temperature to 100°C and check the food every 5 to 10 minutes.

"Frying" Using the Cage

You can get the effect of frying without cooking in oil by using the cage attachment and rotisserie. The

rotisserie rotates the cage during cooking. To assemble, slide the cage onto the rotisserie shaft. Place the

rotisserie/cage into the bowl – ensure that the end of the rotisserie shaft is properly engaged with the

appliance and the groove in the other end of the shaft is resting on the support bracket inside the bowl. It is

recommended to spray the food, for example, potato chips with a little cooking oil before placing it in the

cage.

Cleaning and Maintenance

Never immerse the appliance lid or base in water or any liquid. • Always ensure that the

appliance is disconnected from the mains electrical supply before performing any cleaning

or maintenance tasks. • After cleaning, do not use the appliance again until it is completely dry. • Do NOT

clean the appliance until it has cooled down. • Do NOT clean the appliance with metal scouring pads,

abrasives, flammable materials or solvents.

•Switch OFF and disconnect power from the appliance.

•Allow the appliance to completely cool.

•Wipe the appliance lid and fan housing using a dishcloth or damp sponge and mild dish washing

detergent – do not allow water to enter the fan housing.

•Wash the bowl and any accessories (cooking rack, rotisserie etc) using mild dish washing detergent and

warm water, then rinse thoroughly. For metal parts, if scrubbing is necessary, use a nylon or polyester

mesh pad. The bowl and accessories can also be safely cleaned in a dishwasher.

•Before storing, ensure that the entire appliance is completely dry.

Self-Cleaning

The appliance bowl can be cleaned using the self-cleaning function:

1. Add some water to the bowl ensuring it is no more than a few centimetres in depth.

2. Add a small amount of mild detergent to the water.

3. Connect the appliance to mains power and place the lid on it.

4. Set the temperature to 80°C and the timer to 10 minutes.

5. Press Confirm to begin the cleaning process.

6. The appliance will heat and swirl the water around the bowl - this will clean off most stains.

7. Rinse and dry as normal.

EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF

Electric Air Fryer / Oven

Troubleshooting

SYMPTOMS & PROCEDURES

Appliance will not turn on Check that the power cord is plugged into AC mains outlet and that power

is available to the appliance.

Ensure that the lid is placed on to the appliance base correctly. The

appliance will not start it the lid is not properly attached.

Check that the timer is set to a value other then "zero".

Check that the temperature is set to a value higher than the current

temperature inside the appliance.

Appliance will not heat up Check that the temperature is set to a value higher than the current

temperature inside the appliance.

Check that the timer is set to a value other then "zero".

Food not being cooked sufficiently Ensure that the appliance is not being over-loaded with food.

Adjust cooking temperature and time to suit size and type of food being

cooked.

The rotisserie stops turning during

cooking

Food item too large – ensure the food can rotate inside the appliance

without touching the lid or bowl and that the food is balanced on the shaft.

Specifications

Electrical Requirements 240VAC / 50Hz

Temperature Range Approximately 60 to 250°C

Timer Range 1 to 30 minutes

Capacity 13l

Weight Approximately 6kg (empty)

EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF EUROCHEF

Mytopia EuroChef User manual

Popular Fryer manuals by other brands
