N1C L60 Operating manual

N1 Critical Technologies, Inc.
L60/L60i Lithium Ion UPS
© 2018 - N1 Critical Technologies, Inc., Rev 2/1/19
n1critical.com | lithium-ion-ups.com
User and Installation Manual
English
350VA Model

L60 User’s Manual Uninterruptible Power Supply
N1 Critical Technologies Page: 2
INTRODUCTION
Thank you for choosing N1 Critical Technologies for your Uninterruptible Power Supply needs! We
hope our Lithium-Ion UPS products serve you well. If they don’t, remember that we have a limited
lifetime warranty on electronic components and a 10-year battery warranty. For service needs,
please contact us at 877-226-3311. For sales, please contact us at 855-208-0011.
Please save this manual for future reference.
CONTENTS
Package Contents ..................................... 3
Product Introduction................................ 3
Product Overview ..................................... 3
Installation & Initial Startup ................... 3
Indicators & Alarm Conditions ................ 4
Important Safety Instructions ................ 4
Troubleshooting........................................ 5
Wall Mounting ........................................... 5
Battery Run Time ...................................... 5
Specications ............................................ 6
Obtaining Service...................................... 6
Limited Warranty...................................... 7
ATTENTION
The included software (found on CD in box) is compatible with the following
Operating Systems: Windows, Mac, Linux, Unix. Java required.

L60 User’s Manual Uninterruptible Power Supply
N1 Critical Technologies Page: 3
PACKAGE CONTENTS
The following items are inside the package:
• UPS Unit
• User Manual
• Local Monitoring Software CD
PRODUCT INTRODUCTION
Thank you for selecting this Uninterruptible Power Supply (UPS) from N1 Critical Technologies. It provides you with
protection for connected equipment Please read this manual before installing the L60 Series UPS as it provides
important information that should be followed during installation and maintenance of the UPS and batteries, allowing
you to correctly set up your system for maximum safety and performance. Included is information on customer
support and service, if required. If you experience a problem with the UPS, please refer to the Troubleshooting
section in this manual to correct the problem. If the problem is not corrected, please collect information so that the
Technical Support team can more eectively assist you.
PRODUCT OVERVIEW
N1C L60 features an advanced design that combines the benets of lithium-powered UPS an advanced surge
suppression technology. Slim form factor (just 1.25” tall), wall mounting and easy access receptacles make the L60
ideal for mounting behind thin display screens used in hotels, restaurants, hospitals, campuses, airports and other
commercial areas.
While the compact design is appealing to the digital signage industry, it is also excellent for providing protection to
kiosks, gaming machines, computers, point-of-sale equipment and small printers.
Front View Rear View
INSTALLATION & INITIAL STARTUP
Note: Before installation, inspect the unit and packaging to make sure that nothing inside has been damaged.
Connect UPS to Utility and Charging
Before the initial use of the UPS, plug the UPS input cord into the UPS and then into a wall outlet and turn on the UPS by
pressing the Power switch on the back of the UPS. For best results, the batteries in the UPS should be charged for at least
8 hours before use. The UPS charges its battery while it is connected to AC utility power and powered on.
Connecting the Loads
Plug the loads to be supported by the UPS into the output receptacles on the front of the UPS. Simply turn the power
switch on the UPS “on” and the devices connected to the UPS will be protected by the UPS unit.

L60 User’s Manual Uninterruptible Power Supply
N1 Critical Technologies Page: 4
Turn UPS On/O
To turn the UPS unit on, press the Power button on the back of the UPS. To turn the UPS unit o, press the Power button
on the back of the UPS unit again.
Connecting Local Monitoring Software (optional)
If it is desired to use the Local Monitoring Software, connect the USB cable to the UPS and a computer. Install the software
from the included CD and follow on-screen installation instructions for your operating system.
INDICATORS & ALARM CONDITIONS
Condition Visual Indicator Alarm
AC Mode LED illuminated No audible alarm
Battery mode LED ashes every 10 seconds Audible alarm sounds every 10 seconds
Low battery mode LED ashes every 1 second Audible alarm sounds every 1 second
Fault LED is illuminated Audible alarm is continuous
Alarm for over temperature
protection
Led ashes ever 0.5 seconds No audible alarm
IMPORTANT SAFETY INSTRUCTIONS
Note: Save These Instructions.
CAUTION! (UPS HAS INTERNAL BATTERIES) — Risk of electrical shock. Hazardous live parts inside this unit are
energized from the battery supply even when the input AC power is disconnected
CAUTION! (NO USER SERVICEABLE PARTS) — Risk of electrical shock. Do not remove cover. No user serviceable
parts inside. Refer servicing to qualied personnel.
CAUTION! (NON-ISOLATED BATTERY SUPPLY) — Risk of electrical shock. Battery circuit is not isolated from the AC
input. Hazardous voltage may exist between battery terminals and the ground. Test before touching.
CAUTION! RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE. DISPOSE OF USED BATTERIES
PROPERLY. CONTACT A LOCAL BATTERY RECYCLING FACILITY.
When replacing batteries, replace with the same type and number of batteries.
Manufacturer: BST Power (Shenzen) Co., Ltd.
Model: IFR18650P1200RD 4S2P 12.8V 2.4AH
WARNING! — Unit intended for installation in a controlled environment.
CAUTION! — Do not dispose of batteries in a re. The batteries may explode.
CAUTION! — Do not open or mutilate the battery. Released electrolyte is harmful to the skin and eyes.
CAUTION! — A battery can present a risk of electric shock and a high short circuit current. The following precaution
should be observed when working on batteries:
• Remove watches, rings or other metal objects.
• Use tools with insulated handles.
• Wear rubber gloves and boots.
• Do not lay tools or metal parts on top of batteries.
• Disconnect charging source and load prior to installing or maintaining the battery.
WARNING! — This is a Category C2 UPS product. In a residential environment, this product may cause radio
interference, win which case the user may be required to take additional measures.
To reduce the risk of electric shock, disconnect the UPS from the main power supply before installing a computer
interface signal cable. Reconnect the power cable only after signaling interconnections have been made.
Servicing of batteries should be performed or supervised by personnel with knowledge of batteries and the required
precautions. Keep unauthorized personnel away from batteries.
The instructions contained within this safety manual are deemed important and should be closely followed during
installations and follow-up maintenance of the UPS and batteries.

L60 User’s Manual Uninterruptible Power Supply
N1 Critical Technologies Page: 5
CAUTION
The UPS has a dangerous amount of voltage. If the UPS indicator is on, the unit’s outlets may
have a dangerous amount of voltage even when not plugged into the wall outlet because the
battery may continue to supply power.
Care should be taken to undertake installation indoors, free from electrically-conductive particles which
are under temperature and humidity control, in order to reduce the risk of electric shock.
It is best to disconnect the device using the power supply cord. Ensure that the equipment is placed in a
position near the outlet where easily accessible.
All servicing on this equipment must be carried out by qualied service personnel.
Before conducting any maintenance, repair, or shipment, rst ensure that everything is turned o
completely and disconnected.
TROUBLESHOOTING
Condition Visual Indicator Alarm
No LED Display on the rear UPS
panel
Low battery Charge the UPS at least 8 hours
Battery fault Replace the battery with the same
type of battery
The UPS is not turned on Press the Power Switch on the rear
of the UPS
Alarm continuously sounds when
the AC input is normal
The UPS is overloaded Remove some of the load from the
output of the UPS
UPS fault Return the unit for service
Alarm sounds every 2 seconds when
the AC input is normal
Battery defect Replace the battery with the same
type of battery
Charging circuit is damaged Return the unit for service
When the power fails, backup time is
shorter than expected
The UPS is overloaded Remove some of the load from the
output of the UPS
Battery voltage is too low Charge the UPS at least 8 hours
Battery defect Replace the battery with the same
type of battery
The AC input is normal but the LED
is ashing
Power cord is loose Reconnect the input power cord
properly
WALL-MOUNTING
Fix two ears on the two sides of the unit with four
screws (M3 * 6mm) as shown on left.
SYSTEM LOAD 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
L60 - 120V, 350VA 65 32 21 16 13 10 9 8 7 6
L60 - 230V, 350VA 65 32 21 16 13 10 9 8 7 6
Runtime estimates are shown in minutes and will vary based on battery age and site/usage conditions.
BATTERY RUN TIME

L60 User’s Manual Uninterruptible Power Supply
N1 Critical Technologies Page: 6
MODEL NUMBER L60 (120V, 350VA) L60i (230V, 350VA)
CAPACITY Power Rating 350VA (200W)
INPUT Voltage 120VAC 230VAC
Frequency 50/60Hz
OUTPUT Voltage 120VAC 230VAC
Waveform Sine wave (normal), simulated sine wave (battery mode)
Frequency 50/60Hz
Surge Suppression 312 joules
Eciency Up to 98%
Transfer Time 2-6ms (typical)
BATTERY Battery Type Lithium Iron Phosphate (LiFePO4)
Battery quantity/size (8) 18650 cells, 2400mAh
Battery Runtime (est) 6 min at 100% load; 14 min at 50% load (See chart below)
PHYSICAL Dimensions (WxDxH) 6.9 x 8.5 x 1.25 in (17.5 x 21.6 x 3.2 cm)*
Weight 3.4 lbs (1.54 kg)
Line cord Detachable 5-15P to C13 (3ft) C14 inlet
Receptacles (3) 5-15R (2) IEC C13
ENVIRONMENT Temperature 32º-104ºF (0-40ºC)
Humidity 0-90%
Altitude 11,500 ft above sea level
APPROVALS UL-1778, cTUVus, FCC, and RoHS CE and RoHS
WARRANTY 5 years on electronics and battery (USA & Canada)**
COMMUNICATIONS INTERFACE USB Port
AVAILABLE OPTIONS Optional oset right angle 5-15P 18-in or 6-ft (L60 only)
INCLUDED IN BOX Mounting brackets, ViewPower CD, user manual, 5-15P to C13 line cord (L60 only)
*Wall mount brackets add about 5/8” (1.5cm) to each side. **Warranty outside of USA & Canada is 3 years.
SPECIFICATIONS
If the UPS requires Service:
1. Use the TROUBLESHOOTING section in this manual to eliminate obvious causes.
2. Verify there are no circuit breakers tripped.
3. Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the problem, call N1Critical Technolo-
gies Technical Support at 877.226.3311. Technical support inquiries can also be made at [email protected].
Please have the following information available BEFORE calling the Technical Support Department:
OBTAINING SERVICE
• Your name and address.
• The serial number of the unit.
• Where and when the unit was purchased.
• All of the model information about your UPS.
• Any information on the failure, including LED’s that may or
may not be illuminated.
• A description of the protected equipment, including model
numbers if possible.
• A technician will ask you for the above information and, if
possible, help solve your problem over the phone. In the
event that the unit requires factory service, the technician
will issue you a Return Material Authorization number
(RMA) and provide you the return address.
If you are returning the UPS to N1C for service, please follow
these procedures:
1. Pack the UPS in its original packaging. If the original
packaging is no longer available, use suitable replace-
ment packaging material. It is important to pack the UPS
properly in order to avoid damage in transit. Never use
Styrofoam beads for a packing material.
2. Include a letter with your name, address, daytime phone
number, RMA number, a copy of your original sales re-
ceipt, and a brief description of the problem.
3. Mark the RMA number on the outside of all packages.
N1C cannot accept any package without the RMA number
marked on the outside of the boxes.
4. Return the UPS by insured, prepaid carrier to the address
provided by the N1C Technician.
5. Refer to the Warranty statements in this manual for addi-
tional details on what is covered.

L60 User’s Manual Uninterruptible Power Supply
N1 Critical Technologies Page: 7
N1C L60/L60i Limited Warranty
Product(s) must be registered at www.lithium-ion-ups.com/warrantyregistration for warranty validation. Model Num-
ber and Serial Number are required for completion. Registration must be completed using the end-user’s Company,
Name, Address, and Email.
In the United States and Canada, N1 Critical Technologies, Inc. (N1C) warrants N1C equipment, when properly applied
and operated within the conditions set forth in the proper N1C User Manual, against faulty materials or workmanship
for a period of ve (5) years for L60/L60i products from the date of shipment to the original end user. N1C warrants
the original internal lithium battery for a period of ve (5) years from the date of shipment. For equipment sites within
the United States and Canada, this warranty covers repair or replacement, at the sole discretion of N1C. For equipment
sites within the United States and Canada, N1C will cover fully the standard ground freight expense of sending out a
new UPS unit or battery for warranty exchange. The customer is responsible for the costs of shipping the defective
product to N1C. For sites outside of the United States or Canada, the warranty period is for three years against faulty
materials or workmanship and the internal lithium battery. Also, the customer is responsible for freight to and from
N1C for all warranty claims.
This warranty applies only to the original purchaser, for a maximum term of ve years (USA and Canada) or three years
(outside of USA and Canada) from the ship date of the original UPS.
If equipment provided by N1C is found to be Dead-on-Arrival (DOA), N1C will be responsible for the costs of shipping
product to and returning equipment from the customer in a timely manner as agreed to with the customer, once the
customer has requested and received a Return Material Authorization (RMA) number. DOA equipment is dened as
equipment that does not properly function according to user documentation when initially received and connected in
conjunction with proper procedures as shown in the user documentation or via support provided by N1C personnel or
authorized agents.
This warranty shall be void if (a) the equipment is repaired or modied by anyone other than N1C or a N1C approved
third party; (b) the equipment is damaged by the customer, is improperly used or stored, is subjected to an adverse
operating environment, or is operated outside the limits of its electrical specications; or (c) the equipment has been
used or stored in a manner contrary to the equipment’s operating manual, intended use or other written instructions.
Any technical advice furnished by N1C or a N1C authorized representative before or after delivery regarding the use or
application of N1C equipment is furnished on the basis that it represents N1C’s best judgment under the situation and
circumstances, but it is used at the recipient’s sole risk.
EXCEPT AS STATED ABOVE, N1C DISCLAIMS ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCEPT AS STATED ABOVE, IN NO EVENT WILL N1C BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSE-
QUENTIAL DAMAGES ARISING OUT OF THE USE OF N1C EQUIPMENT, including but not limited to, any costs, lost prots
or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, cost of substitutes, or claims by
third parties. Purchaser’s sole and exclusive remedy for breach of any warranty, expressed or implied, concerning N1C
equipment, and the only obligation of N1C under this warranty, shall be the repair or replacement of defective equip-
ment, components, or parts; or, at N1Cs sole discretion, refund of the purchase price or substitution of an equivalent
replacement product.
LIMITED WARRANTY
