NAD C375BEE User manual

Owner's Manual
Manuel d'installation
Manual
del Usuario
Manuale delle Istruzioni
Bedienungsanleitung
Gebru i kersha nd leid i ng
Bruksanvisning
1I1 HCTPYKl..\VlH no 3KcnnyaTa l..\VI VI
NAD
@C375BEE
Stereo Integrated Amplifier

IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS FOR LATER USE.
FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE
AUDIO EQUIPMENT.
Read instructions - All the safety and operating instructions should be
read before the product is operated.
2 Retain instructions - The safety and operating instructions should be
retained for future reference.
3 Heed Warnings - All warnings on the product and in the operating
instructions
should be adhered to.
4 Follow Instructions - All operating and use instructions should be
followed.
5 Cleaning - Unplug this product from the wall outlet before cleaning.
Do not use liqUid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6 Attachments - Do not use anachments not recommended by the
product manufacturer as they may cause hazards.
7 Water and Moisture - Do not use thiS product near water-for example,
near a bath tub, wash bowl, kitchen sink, or laundry tub; in awet
basement; or near aswimming pool; and the like.
8 Accessories - Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury to
a
child or adult, and serious damage to the product. Use only with a
cart, stand, tripod, bracket, or table recommended by the manufacturer,
or sold with the product. Any mounting of the product should follow
the manufacturer's instructions, and should use amounting accessory
recommended by the manufacturer.
9(I)Aproduct and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces may
cause the product and cart combination to overturn.
10 Ventilation - Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to
protect it
from overheating, and these openings must not be blocked
or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product should
not be placed in abuilt-in installation such as a bookcase or rack unless
proper ventilation is prOVided or the manufacturer's instructions have
been adhered to.
11 Power Sources - This product should be operated only from the type
of power source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your product dealer or
local power company.
The primary method of isolating the amplifier from the mains supply
is to disconnect the mains plug. Ensure that the mains plug remains
accessible at all times. Unplug the AC power cord from the AC outlet if
the unit will not be used for several months or more.
12 Grounding or Polarization - This product may be equipped with a
polarized alternating-current line plug (a plug having one blade wider
than the other). This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
13 Power - Cord Protection - Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular anent ion to cords at plugs, convenience
receptacles, and the point where they exit from the product.
2
14 Outdoor Antenna Grounding -If an outside antenna or cable system
is connected to the product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges
and built-up static charges. Article 810 of the National Electrical Code,
ANSIINFPA 70, provides information with regard to proper grounding
of
the mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit. size ofgrounding conductors, location
of
antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer's anention to Section
820-40 of the NEC which prOVides gUidelines for proper grounding and, in
particular, specifies that the cable ground shall be connected to the grounding
system of the bUilding, as close to the point of cable entry as practical.
15 Lightning - For added protection for this product during alightning
storm, or when it is left unanended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna or
cable system. This will prevent damage to the product due to lightning
and power-line surges.
16 Power Lines - An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or power circuits,
or where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be
fatal.
17 Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as thiS can result in a risk of fire or
electriC shock.
18 Object and Liquid Entry - Never push objects of any kind into thiS
product through openings as they may touch dangerous voltage points
or short-out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
WARNING: THE APPARATUS SHOULD NOT BE EXPOSED TO
DRIPPING OR SPLASHING, AND OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHOULD NOT BE PLACED ON THE APPARATUS.
AS WITH ANY ELECTRONIC PRODUCTS, USE CARE NOTTO SPILL
LIQUIDS INTO ANY PART OF THE SYSTEM. LIQUIDS CAN CAUSE A
FAILURE AND/OR A FIRE HAZARD.

IMPORTANT SAFETY INSTRUCTIONS
INDUSTRY CANADA REQUIREMENT
This Class Bdigital apparatus meets all requirements ofthe Canadian
Interference-Causing EqUipment Regulations.
FCC WARNING
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS
INTENDED TO ALERTTHE USER TO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN
THE LITERATURE ACCOMPANYING THE APPLIANCE.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN
AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERTTHE USER
TO THE PRESENCE OF UNINSULATED"DANGEROUS VOLTAGE"
WITHIN THE PRODUCT'S ENCLOSURE THAT MAYBE OF
SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC
SHOCK TO PERSONS.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
19 Damage Requiring Service -Unplug this product from the wall outlet
and refer servicing to qualified service personnel under the following
conditions:
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the product.
c) Ifthe product has been exposed to rain or water.
d) Ifthe product does not operate normally by following the operating
instructions.
Adjust only those controls that are covered by the
operating instructions
as an improper adjustment ofother controls
may result in damage and will often require extensive work by a
qualified technician to
restore the product to its normal operation.
e) Ifthe product has been dropped or damaged in any way.
f) when the product exhibits adistinct change in performance-this
indicates a need for service.
20 Replacement Parts -When replacement parts are required, be
sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions
may result in fire, electric
shock, or other hazards.
21 SafetyCheck- Upon completion of any service or repairs to this
product ask the service technician to perform safety checks to
determine that the product
is in proper operating condition.
22 Wall or Ceiling Mounting - The product should be mounted to a wall
or ceiling only as recommended by the manufacturer.
23 Heat- The product should be situated away from heat sources such as
radiators, heat registers, stoves or other products (including amplifiers)
that produce heat.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCTTO RAIN OR MOISTURE.
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
FCC NOTICE
This equipment has been tested and found to comply with the limits for a
Class Bdigital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and if
not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipmentoff and on, the user is encouraged to try
to
correct the interference by one or more of the following measures
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on acircuit different from
that to which the receiver is connected
Consult the dealer or an experienced radiolTV technician for help.
The equipment draws its nominal non-operational power from the AC
outlet with its POWER switch in the STANDBY position.
The socket-outlet shall be installed near the apparatus and shall be easily
accessible.
CAUTION
Changes or modifications to this equipment not expressly approved by
NAD Electronics for compliance could void the user's authority to operate
this equipment.
CAUTION REGARDING PLACEMENT
To maintain proper ventilation, be sure to leave a space around the unit
(from the largest outer dimensions including projections) that is equal to or
greater than shown below.
Left and Right Panels: 10 cm
Rear Panel: 10 cm
Top Panel: 50 cm
3

IMPORTANT SAFETY INSTRUCTIONS
Pb
Hg Cd End-users are exhorted not to dispose waste
batteries as unsorted municipal waste. In order
to achieve ahigh level of recycling waste batteries, discard waste batteries
separately and properly through an accessible collection point in your
vicinity. For more information about collection and recycling of waste
batteries, please contact your local municipality, your waste disposal service
or the point of sale where you purchased the items
INFORMATION ABOUT COLLECTION AND DISPOSAL OF
WASTE BATTERIES (DIRECTIVE 2006/66/EC OF THE EUROPEAN
PARLIAMENT AND THE COUNCIL OF EUROPEAN UNION) (FOR
EUROPEAN CUSTOMERS ONLY)
Batteries bearing any of these symbols indicate
that they
should be treated as "separate collection"
and not as municipal waste. It is encouraged that
necessary measures are implemented to maximize
the separate collection of waste batteries and
to minimize the disposal of batteries as mixed
municipal waste.
The wires in the mains lead on this product are colored in accordance with
the following
code:
BLUE ~ NEUTRAL
BROWN - LIVE
IMPORTANT
DO NOT make any connection to the larger terminal which IS marked with
the letter 'E' or by the safety earth symbol or colored GREEN or GREEN AND
YELLOW
IMPORTANT INFORMATION FOR UK CUSTOMERS
DO NOT cut off the mains plug from this equipment Ifthe plug fitted is not
suitable for the power points in your home or the cable is too short to reach
apower point, then obtain an appropriate safety approved extension lead
or consult your dealer If, nonetheless, the mains plug is cut off, REMOVE
THE FUSE and dispose ofthe PLUG immediately, to avoid possible shock
hazard by inadvertent connection to the mains supply. If this product is
not provided with a mains plug, or one has to be fitted, then follow the
instructions
given below:
As these colors may not correspond with the colored markings identifying
the
terminals in your plug, proceed as follows:
The BLUE wire must be connected to the terminal marked with the
letter 'N' or colored BLACK.
The BROWN wire must be connected to the terminal marked with the
letter 'I.' or colored RED.
By ensuring compliance and conformance to proper disposal of waste
batteries, potential hazardous effects on human health is prevented and
the negative impact of batteries and waste batteries on the environment
is minimized, thus contributing to the protection, preservation and quality
improvement of
the environment
When replacing the fuse, only acorrectly rated and approved type should
be used, and be sure to re-fit the fuse cover.
NOTE: THE C 37SBEE IS NOT AN AUTO VOLTAGE UNIT. CONNECT
ONLY TO THE PRESCRIBED AC OUTLET, I.E., 120V 60HZ OR 230V 50HZ.
IF IN DOUBT CONSULT A COMPETENT ELECTRICIAN.
NOTES ON ENVIRONMENTAL PROTECTION
R
At the end of its useful life, this product must not be disposed
ofwith regular household waste but must be returned to a
collection point
for the recycling ofelectrical and electronic
equipment
The symbol on the product, user's manual and
_ packaging, point this out
RECORD YOUR MODEL NUMBER (NOW, WHILE YOU CAN SEE IT)
The model and serial number of your new C 375BEE are located on the
back ofthe cabinet For your future convenience, we suggest that you
record these numbers here:
Model no: ..
Serial no.: .
The materials can be reused in accordance with their markings. Through
re-use, recycling of raw materials or other forms of recycling of old
products, you are making an important contribution to the protection of
our environment
Your local administrative office can advise you ofthe
responsible waste disposal point
NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited
Copyright 2008, NAD Electronics International, a division of Lenbrook Industries Limited
4

UNPAClUNG:AJiIQ SETUP
WHAT'S IN THE BOX
Packed with your C 375BEE you will find
The 5R 8 remote control with 2(two) AA batteries
This owner's manual
Adetachable AC power cord.
SAVE THE PACKAGING
Please save the box and all of the packaging in which your C 375BEE
arrived. Should you move or otherwise need to transport your C 375BEE,
this is by far the safest container in which to do so. We've seen too many
otherwise perfect components damaged in transit for lack of aproper
shipping
carton, so please: Save that box
l
INTRODUCTION
GETTING STARTED
BARE WIRES AND PIN COtl0NHlIC;;;CllnORS--:--::-
~
WARNING: The terminals marked with this symbol
are hazardous live. External wiring connected to these
terminals requires installation by an instructed person or
the use of ready-made leads or cords.
Bare wires and pin sockets should be inserted into the hole in the shaft
of the terminal. Unscrew the speaker terminal's plastic bushing until the
hole
in the screw shaft is revealed. Insert the pin or bare cable end into
the hole
and secure the cable by tightening down the terminal's bushing.
Ensure bare wire from the speaker cables does not touch the back panel or
another
socket. Ensure that there is only 1/2" (1 cm) of bare cable or pin and
no loose strands of speakers wire.
In case you simply cannot wait to experience the performance of your new
NAD C 375BEE, we provide the follOWing "QUICK START' instructions to get
you underway.
Please make all the connections to your C 375BEE with the unit unplugged.
It
is also advisable to power-down or unplug all associated components
while
making or breaking any signal or AC power connections.
1Connect the speakers to the rear Speaker terminals and sources to the
relevant rear input sockets.
2 Connect the AC cord to the C 37SBEE's AC Mains input and then plug
into
an AC outlet.
3
Switch the POWER switch on the rear panel to the "ON" setting in order
to turn the C 375BEE to standby mode. The Standby LED indicator
embedded
around the bezel ofthe STANDBY button will illuminate
amber. The C 375BEE will go to standby mode.
4 Press the STANDBY button to turn ON the C 375BEE. The Standby LED
indicator will turn from amber to blue.
S Press the required input selector.
CHOOSING A LOCATION
Choose alocation that is well ventilated (with at least several inches to
both
sides and behind), and that will provide a clear line of sight, within
23 feet/7 meters, between the C 375BEE's front panel and your primary
listening/viewing position.
This will ensure reliable infrared remote control
communications.
The C 375BEE generates amodest amount of heat, but
nothing that
should trouble adjacent components. It is perfectly possible to
stack the C 375BEE atop other components, but the reverse usually should
be avoided.
It is especially important that sufficient ventilation be provided. If you are
contemplating locating the C 375BEE within acabinet or other furniture,
consult your
NAD audio/video specialist for advice on providing adequate
airfiow.
NOTES ON INSTALLATION
Your NAD C 375BEE should be placed on a firm, level surface. Avoid
placing the unit in direct sunlight or near sources of heat and damp. Allow
adequate ventilation.
Do not place the unit on asoft surface like a carpet.
Do not place it in an enclosed position such a bookcase or cabinet that
may impede the air-fiow through the ventilation slots. Make sure the unit is
switched off before making any connections.
The RCA sockets on your NAD C 37SBEE are colour coded for convenience.
Red and white are Right and Left audio respectively.
Use high quality leads and sockets for optimum performance and reliability.
Ensure that leads and sockets are not damaged in any way and all sockets
are firmly pushed home.
For best performance, use quality speaker leads of 16 gauge (l.5mm)
thickness or more. Ifthe unit is not going to be used for some time,
disconnect the plug
from the AC socket.
Should water get into your NAD C 375BEE, shut offthe power to the unit
and remove the plug from the AC socket. Have the unit inspected by a
qualified
service technician before attempting to use it again.
DO NOT REMOVE THE COVER; THERE ARE NO USER-SERVICEABLE
PARTS INSIDE.
Use adry soft cloth to clean the unit. If necessary, lightly dampen the cloth
with
soapy water. Do not use solutions containing benzol or other volatile
agents.
c:
<.
5

IDENTIFICATION OF CONTROLS
FRONT PANEL
-1-'--
~ - "«~'""r"'-. emBE'
~ [email protected] ---------------1
STANDBY: With the rear panel POWER switch set to ON position,
press this button to switch ON the (375BEE from standby mode.
The Standby LED indicator will turn from amber to blue, Pressing the
STANDBY button again turns the unit back to standby mode,
The (375BEE can also be switched ON from standby mode by pressing
any of the front panel buttons.
2 STANDBY LED: This indicator will light up amber when the C 375BEE
is in standby state, When the ( 375BEE is at ON state, this indicator will
illuminate blue. When infrared command from the SR B is received, this
indicator will also fiash momentarily.
In cases of serious abuse of the C 375BEE, such as excessively low
loudspeaker impedance and short circuit, the C 375BEE will engage its
Protection circuitry, indicated by the Standby LED turning from blue to
red and the sound being muted.
In such a case, turn the C 375BEE OFF by the rear panel POWER switch,
wait for it to cool down and/or check the speaker connections, making
sure the overall loudspeaker impedance doesn't go below 4 ohms or
B
ohms in Bridge Mode. Once the cause for the protection circuitry to
engage has been removed, switch ON the rear POWER switch and the
STANDBY button to resume normal operation,
3 BRIDGE MODE INDICATOR: This BRIDGE MODE indicator lights up
blue when the C 375BEE is switched to Bridge Mode, Refer also to the
item below about BRIDGE MODE at the IDENTIFICATION OF CONTROLS
- REAR PANEL.
4 MP SOCKET: Using a 3.5mm stereo plug, connect into this socket the
audio output ofa Media Player.
NOTES
If an external Media Player is connected to the front MP socket (using a
3.5mm stereo plug) while listening toa MP line-level source, the externol
Media Player will be directly selected with the MP line-level source
immediately disconnected.
It is recommended to mute the volume or switch toadifferent input
before plugging/unplugging the external Media Player cable.
6
S SOFT CLIPPING INDICATOR: The blue SOFT CLIPPING LED shows
that the SOFT (LIPPING mode is engaged. Refer also to the item below
about SOFT CLIPPING (item 13) at the IDENTIFICATION OF CONTROLS
- REAR PANEL.
6 REMOTE SENSOR: Point the SR 8 remote control at the remote
sensor and press the buttons. Do not expose the remote sensor of the
( 375BEE to a strong light source such as direct sunlight or illumination,
If
you do so, you may not be able to operate the C 375BEE with the
remote control.
Distance: About 23ft (7m) from the front of the remote sensor.
Angle: About 300 in each direction of the front of the remote sensor.
7 PHONES: A 1/4" stereo jack socket is supplied for headphone listening
and will work with conventional headphones of any impedance, The
headphone socket will work in parallel to the selected speakers. To
listen to headphones only, de-select Speakers Aand/or B. The volume,
tone and balance controls are operative for headphone listening. Use
a suitable adapter to connect headphones with other types of sockets,
such as 3.5mm "personal stereo" jack plugs.
NOTE
Make certain that the volume control is turned to minimum (fully
counter-clockwise) before connecting or disconnecting headphones.
Listening at high levels can damage your hearing.
8 SPEAKERS A. B: The SPEAKERS A and Bbuttons engage or disengage
the speakers connected respectively to the SPEAKERS A and SPEAKERS
B terminals on the rear panel. Press "A'to switch ON or OFF the speakers
connected to the SPEAKERS A terminals. Press "B"to switch ON or OFF
the speakers connected to the SPEAKERS B terminals. Press both "A" and
"B"to engage at the same time both SPEAKERS A and SPEAKERS B. The
corresponding blue LED indicator embedded around the SPEAKERS A
and SPEAKERS Bbuttons will illuminate accordingly when each or both
are engaged.

9INPUT SELECTORS: These buttons select the active input to the
NAD C 37SBEE and the signal sent to the loudspeakers, headphones
and the PRE OUT sockets. The buttons on the remote control handset
duplicate these buttons. When selected, the corresponding input LED
indicator embedded around the bezel ofthe particular input button will
illuminate
blue.
MP (MEDIA PLAYER): Selects aline-level source connected to the MP
sockets as the active input.
If
an external Media Player is connected to the front MP socket (using
a 3.5mm stereo plug) while listening to a MP line-level source, the
external Media Player will be directly selected with the MP line-level
source immediately disconnected. It is recommended to mute the
volume or
switch to adifferent input before plugging/unplugging the
external Media Player cable.
CD: Selects the CD (or other line-level source) connected to the CD
sockets as the active input.
TUNER: Selects the tuner (or other line-level source) connected to the
tuner sockets as the active input.
DISc/PHONO:
Selects aline-level source connected to the DISC
sockets. With the optional PP 37S PHONO MODULE installed, the DISC
input socket is disabled and the PHONO source selected as the active
input.
AUX: Selects aline-level source connected to the AUX sockets as the
active input.
TAPE 2: Selects Tape 2 as the active input.
TAPE MONITOR: Selects the output from atape recorder when playing
back tapes or monitor recordings that are being made through the Tape
Monitor sockets.
TAPE MONITOR does not override the current input selection. For
example, if CD is the active input when TAPE Monitor is selected, then
the
CD signal will continue to be selected and sent to both the TAPE
2 and TAPE Monitor OUTPUT sockets, but it is the sound from recorder
connected to Tape Monitor that will be heard on the loudspeakers.
Apart from the TAPE MONITOR LED illuminated to indicate it is engaged,
the corresponding LED indicator for the active input will also stay
illuminated.
IDENTIFICATION OF CONTROLS
FRONT PANEL
10 TONE DEFEAT: Tone Controls are enabled or disabled by pressing this
button. When enabled (TONE DEFEAT LED indicator is illuminated), the
Tone Control circuits are bypassed. The Tone Control circuits are active
when the TONE DEFEAT LED indicator stays extinguished.
11 TONE CONTROLS: The NAD C 37SBEE is fitted with BASS and TREBLE
tone controls to adjust the tonal balance of your system. The 12 o'clock
position is "flat"with no boost or cut, and an indent indicates this
position. Rotate the control clockwise to increase the amount of Bass or
Treble. Rotate the control counterclockwise to decrease the amount of
Bass or Treble. The Tone controls do not affect recordings made using
the Tape outputs but will affect the signal going to the Pre-amp outputs
(PRE OUT 1 and PRE OUT 2).
12 BALANCE: The BALANCE control adjusts the relative levels of the left
and right speakers. The 12 dclock position provides equal level to the left
and right channels. Adetent indicates this position. Rotating the control
clockwise moves the balance towards the right. Rotating the control
counterclockwise moves the balance to the left. The BALANCE control does
not affect recordings made using the Tape outputs but will affect the signal
going to the Pre-amp output (PRE OUT 1 and PRE OUT 2).
13 VOLUME: The VOLUME control adjusts the overall loudness of the signals
being fed to the loudspeakers or headphones. Turn clockwise to increase
the volume setting; counter clockwise to lower it. The VOLUME control does
not affect recordings made using the Tape outputs but will affect the signal
going to the Pre-amp output (PRE OUT 1 and PRE OUT 2).
7

IDENTIFICATION OF CONTROLS
REAR PANEL
ATTENTION!
Please make sure that the C 3758EE is powered offor unplugged before making any connections. It is also advisable to power-down orunplug all
associated components whife making orbreaking anysignal or AC power connections.
MP input: Input for a Media Player or other line-level signal source.
Use atwin RCA-to-RCA lead to connect the Media Player's left and right
"Audio Outputs" to this input.
NOTE
If an external Media Player is connected to the front MP socket (using a
3.5mm stereo plug) whife listening to a MP line-level source, the external
Media Player will be directly selected with the MP line-level source
immediately disconnected.
2 CD INPUT: Input for a CD or other line-level signal source. Use a
twin
RCA-to-RCA lead to connect the CD player's left and right "Audio
Outputs"to this input.
3 TUNER INPUT: Input for atuner or other line-level signal source. Use
atwin RCA-to-RCA lead to connect the tuner left and right "Audio
Outputs"to this input.
4 DISC INPUT: Input for additional line level input signals such as CD,
Mini Disc player or the output signal from astep-up amplifier for a
turntable.
Use atwin RCA-to-RCA lead to connect the auxiliary unit's left
and right "Audio Outputs"to this input.
NOTE
With the optional PP 375 PHONO MODULE installed, the DISC input
socket is disabledand the PHONO source selected as the active input.
5
AUX INPUT: Input for additional line level input signals such as
another CD player. Use atwin RCA-to-RCA lead to connect the auxiliary
unit's left and right "Audio Outputs" to this input.
8
6 TAPE 2IN/OUT: Connections for analog recording and playback to an
audio tape recorder of any type. Using twin RCA-to-RCA leads, connect
to the left
and right "Audio Output"of the tape machine to the TAPE 2 IN
sockets for playback. Connect the left and right "Audio Input"ofthe tape
machine to the TAPE 2 OUT sockets for recording.
7 TAPE MONITOR IN/OUT: Connections for analog recording and
playback to a secondary audio tape recorder of any type. Using twin
RCA-to-RCA leads, connect to the left and right"Audio Output"of
the tape machine to the TAPE MONITOR IN sockets for playback and
tape monitoring. Connect the left and right "Audio Input"ofthe tape
machine to the TAPE MONITOR OUT sockets for recording.
TO MAKE A RECORDING
When any source is selected, its signal is also fed directly to any tape
machine connected to the TAPE 2 OUT or TAPE MONITOR OUT for
recording.
TAPE TO TAPE COPYING
You can copy between two tape machines connected to your NAD
C 375BEE. Put the source tape in the recorder connected to Tape 2
and the blank tape into the recorder connected to Tape Monitor. By
selecting TAPE 2input you can now record from Tape 2to Tape Monitor
and monitor the signal coming from the original tape.
NOTE
There will be no Tape 2output when Tape 2 (or Tape Monitor OUT when
Tape Monitor) is the selected source input. This prevents feedback
through the recording component thereby preventing possible damage
to your speakers.

8 PRE OUT 1: The PRE OUT 1 sockets can be used to drive an additional
power amplifier.
Use atwin RCA-to-RCA lead to connect to the left and
right"Audio Input" of the Power amplifier or processor to the PRE OUT 1
sockets.
Always turn the C 37SBEE and associated external power amplifiers OFF
before connecting or disconnecting anything to the PRE OUT 1 sockets.
The PRE OUT 1output signal will be affected by the C 37SBEE's volume
and tone control settings.
9MAIN IN: Connections to an external pre-amplifier or processor, such
as asurround-sound decoder. In normal use, this should be connected
to
PRE OUT 2 sockets with the links supplied. To connect your NAD
C 37SBEE to external processor or pre-amplifier, remove first these links.
Use atwin RCA-to-RCA lead to connect the left and right"Audio Output"
ofthe pre-amp or
processor to the Main In sockets.
Always turn the C 37SBEE and associated external power amplifiers OFF
before connecting or disconnecting anything to the MAIN IN sockets.
10 PRE OUT2: Connections to an external poweramplifier or processor, such
as asurround-sound decoder. In normal use, thiS should be connected to
the
Main In sockets with the links supplied. To connect your NAD C 37SBEE
to external processor or amplifier sections, remove first these links. Use a
twin
RCA-to-RCA lead to connect the left and right "Audio Input" of apower
amplifier
or processor to the PRE OUT 2 sockets.
Always turn the C 37SBEE and associated external power amplifiers OFF
before connecting or disconnecting anything to the PRE OUT 2 sockets.
The PRE OUT 2output signal will be affected by the C 37SBEE's volume
and tone control settings.
11 VOLUME PRE OUT 2: The VOLUME PRE-OUT 2control allows for
adjustment
of the output level of the PRE OUT 2 sockets. Turn clockwise
to
increase the PRE OUT 2volume setting; counter clockwise to lower
it. When set to the maximum position, the output level will be identical
to that
of the PRE OUT 1 sockets. Refer also to the item below about
"Bi-Amping':
BI·AMPING
Some loudspeakers have separate connection terminals for the LF (Low
Frequency) and HF (High Frequency) sections of the speaker. This facility
allows to"Bi-Amp"these
speakers, where a separate power amplifier
is used for the LF and HF section, which may improve overall sound
quality.
The C 37SBEE provides two sets ofpreamplifier outputs (PRE OUT 1 and
PRE OUT 2) to facilitate the connections for Bi-Amping. Moreover, the level
from PRE OUT 2 can be reduced in relation to PRE OUT 1to accommodate
power
amplifiers with different gain (amplification factor).
To set up the C 37SBEE with power amplifiers first decide which power
amplifier
has the highest gain. This is easily done by comparing the
loudness level ofthe power amplifiers in an identical system (keep the
volume control
at the same level; use the same source and speakers).The
amplifier that plays louder has the highest gain (note that this does not
need to be the more powerful amplifier of the two). Connect the amplifier
with highest
gain to the PRE OUT 2 sockets; the other power amplifierto
the
PRE OUT 1 sockets. From the maximum level position, use the VOLUME
PRE OUT 2control to reduce the output level of PRE OUT 2 so that the
volume
level ofboth power amplifiers is exactly matched.
IDENTIFICATION OF CONTROLS
REAR PANEL
12 BRIDGE MODE: The C 37SBEE amplifier can be configured to be
MONO (Bridge Mode), more than doubling its output power. This way,
the C 37SBEE can be used as part of ahigh power stereo or home-
theatre
system, by connecting additional power amplifiers.
In BRIDGED MODE (switch at ON setting), the C 37SBEE will produce
apprOXimately 330W into an Bohm loudspeaker. In this mode, the
amplifier sections will
react as though the speaker impedance has been
halved. Low impedance speakers (under 8 ohms) are not recommended
when using Bridge Mode
as these may cause the amplifier's thermal
cut-out to operate if
played at high levels.
Set the BRIDGE MODE switch to the "ON" position and connect the
speaker to the terminals marked"L +" and "R+"ensuring that the "L+"
is connected to the" +"terminal of your loudspeaker and the "R+" is
connected to the loudspeaker's" -"terminal. Connect the source to
the Left
INPUT sockets.
The BRIDGE MODE indicator on the front panel will illuminate when the
C
37SBEE is in Bridge mode. Return normal speaker connections (Refer
also to the item below about "SPEAKERS A,B"). and keep BRIDGE MODE
switch to "OFF" position for normal stereo listening.
NOTE
Do notconnect anything to the Right Input socket when Bridge Mode is
selected.
13SOFT CLIPPING'": Enables NAD's proprietary Soft Clipping circuitry'
on all channels. At [ON] position, Soft Clipping gently limits the output
of the C 37SBEE to minimize audible distortion should the amplifier be
over-driven. Soft Clipping may simply be left ON at all times to reduce
the likelihood
of audible distortion from excessive volume settings.
However, for critical listening and to preserve optimum dynamics, you
may wish to defeat it by setting this switch to "OFF" position.
The SOFT CLIPPING indicatoron the front panel will illuminate when
the C
37SBEE is in Soft Clipping mode. See also below the item about
"POWERDRIVE~
POWER DRIVE
The C 37SBEE uses NAD's proprietary PowerDrive'" amplifier technology
for
all channels to preserve accurate, linear reproduction regardless
of the loudspeaker. This uniquely efficient power-supply topology
prOVides the real-world benefits of high dynamic power that remains
uncompromised by low-impedance speakers.
By adding a second high-voltage rail to our well regulated high-current
power
supply, we get an "overdrive"that can nearly double the continuous
power
on a short term dynamic power basis. PowerDrive offers greater
amplifier stability and low impedance drive capability, resulting in less
distortion when driving real speakers with real program material.
9

IDENTIFICATION OF CONTROLS
REAR PANEL
14 IR IN/OUT: These mini-jacks accept and output remote-controlled
codes in electrical format, using industry-standard protocols, for use
with 'IR-repeater' and multi-room systems and related technologies.
IR IN: This input is connected to the output of an IR (infrared) repeater
(Xantech or similar) or the IR output ofanother component to allow
control ofthe C
37SBEE from a remote location.
IR OUT: When connected to the IR IN of an ancillary equipment, direct
the
ancillary equipment's own remote control to the C 37SBEE's infrared
receiver to command or control the linked unit.
All NAD products with IR IN/IR OUT features are fully compatible with
the C
37SBEE. For non-NAD models, please check with your other
product's
service specialists as to their compatibility with the C 37SBEE's
IR features.
15 +1 2V TRIGGER OUT: The + 12VTRIGGER OUT is used for controlling
external eqUipment that is equipped with a+ 12Vtrigger input. This output
will
be 12Vwhen the C 37SBEE is ON and OVwhen the unit is either OFF or
in standby. This output can drive a load up to SOmA at 12V
16 R5-232: Connect thiS interface via RS-232 serial cable (not supplied) to any
Windows· compatible PC to allow remote control of the C 37SBEE through
NAD's proprietary PC software or other compatible external controllers.
NAD is a certified partner of MAX and Crestron and fully supports these
external devices. See your NAD audio specialist for more information.
17 Me INPUT: Input for aMoving Coil phono cartridge. Connect the twin
RCA lead from your turntable to this input if you are using aMoving
Coil cartridge.
18 MC-MM SWITCH: Slide this switch to either MM (MOVing Magnet) or
MC (Moving Coil) depending upon the phono cartridge being used.
19 PHONO GROUND CONNECTOR: Turntables normally includes a single
wire earth lead. Use the C 37SBEE phono ground connector to connect
this
lead. Unscrew the terminal to expose the hole, which will accept
the lead. After insertion, tighten the terminal to secure the lead.
20 MM INPUT: Input for aMoving Magnet phono cartridge. Connect
the twin RCA lead from your turntable tothis input if you are using a
Moving Magnet cartridge.
21 SPEAKERS A, B: The C 375BEE is equipped with two sets of speaker
connectors. Use the Speakers Aterminals for the "main" speakers and
use the Speakers Bterminals for a second pair, for example, extension
speakers located in another room.
Connect the right speaker tothe terminals marked"R +" and "R-"
ensuring that the"R+"is connected to the "+"terminal on your
loudspeaker and the "R-" is connected to the loudspeaker's '-"terminal.
Connect the
terminals marked "I. +"and "L-" to the left speaker in the
same way.
In Bridge Mode, connect the single speaker to the terminals marked
"R +" and "L+"ensuring that the"L+"is connected to the"+" terminal
on your loudspeaker and the "R+" is connected tothe loudspeaker's "-"
terminal. Refer also to the section above about "BRIDGE MODE~
Always use heavy duty (16 gauge; l.5mm, or thicker) stranded wire to
connect
loudspeakers toyour C 375BEE. The high-current binding post
terminals can be used as a screw terminal for cables terminating in
spade or pin sockets or for cables with bare wire ends.
10
22 AC MAINS INPUT: The C 375BEE comes supplied with a separate AC Mains
cable. Before connecting the cable to a live wall socket, ensure that it is
firmly connected to the C 375BEE's AC Mains input socket first. Connect
only to the prescribed AC Outlet, i.e., 120V 60 Hz or 230V 50 Hz. Always
disconnect the AC Mains cable plug from the live wall socket first, before
disconnecting the cable from the C 375BEE's Mains input socket.
23 POWER SWITCH: The POWER switch supplies the master AC mains
power for the C 375BEE. When this switch is at ON position, the
C
375BEE is in standby mode as shown by the amber status condition
ofthe standby
LED. Toggle the front panel's STANDBY button to switch
ON the C 375BEE or back to standby mode. If you intend not to use the
C 375BEE for long periods oftime (such as when on vacation), switch
the POWER switch to the OFF position. When the POWER switch is at
OFF position, the front panel power button or SR B remote control
cannot activate the C
375BEE.
24 SWITCHED AC OUTLET (120V version only): This convenience outlet
can supply switched power to another component or accessory. With
the
Power switch at the rear panel set to ON position, this outlet is
powered ON or OFF by the front panel STANDBY switch or by the SR 8's
[ON/OFF] buttons. The total draw of all devices connected to this outlet
must not
exceed 100 watts.
25 FUSE HOLDER: In the unlikely event a fuse may need to be replaced,
unplug the AC cord from the wall. Then, remove all connections from
the amplifier. Use a fiathead screw driver or similar to open the fuse
holder via the slot indicated. With the screw driver in place, push and
turn counterclockwise to open the fuse holder. Only replace the
fuse with the same type, size, and specification - T1 OAL 250V for 120V
version or T5AL 250V for 230V version.
IMPORTANT NOTICE
Do not use any substitute fuses of different types orwith different ratings
or values. Failure to observe this precaution may cause damage to the
amplifier circuits andmay create a fire hazard and/or defeat the safety
builtinto the C 375BEE and may void the warranty.

SR.
IDENTIFICATION OF CONTROLS
SR 8REMOTE CONTROL
The SR 8 remote control handset handles the key functions of the C 375BEE as well as other NAD Stereo
Receivers, Integrated Amplifiers and Preamplifiers. It has additional controls to remotely operate NAD CD
Players, AMlFM Tuners and dedicated AMlFMlDAB Tuners. It will operate up to a distance of 23ft (7m).
Alkaline baneries are recommended for maximum operating life. Two AA baneries should be fined in the
banery compartment at the rear of the Remote Control handset. When replacing baneries, check that they
have been put in the right way round, as indicated on the base of the banery compartment.
When acommand from the remote control is received, the Standby LED indicator will blink. Note that
the indicator may also blink when receiving commands not necessarily for the C 375BEE but for other
components
in the system. Please refer to previous sections ofthe manual for a full description of
individual
functions.
NOTE
._---- ----
The remote control handset suppliedwith the C 375BEE is of a universal NAD type, designed to
operate several NAD models. Some buttons are applicableonly to specilic NAD models. Contact
your
dealer or NAD audio specialist for assistance.
POWER ON & OFF: The SR 8remote has a separate ON and OFF button. Press the ON button
to
switch the unit from Standby to operating mode. Press the OFF button to switch the unit to
Standby mode.
2DEVICE SELECTOR: A Device Selector button determines only what component the SR Bwill
command; it does not perform any function on the C 375BEE. Press desired Device Selector button
for the applicable buttons to be directed to a'page'of commands relevant to the selected device.
Upon selecting a Device, you can now press the corresponding SR 8control buttons applicable for
the selected Device.
3INPUT SELECTORS: Refer to the corresponding labels printed in the remote control faceplate
and their respective assigned buttons to make use of these functions. Set the DEVICE SELECTOR
to 'AMP" in order to gain access to these buttons. The input selector buttons perform the same
functions as the buttons labeled the same on the front panel.
4NUMERIC KEYS: The numeric keys allow for direct input of tracks for CD players, and direct
channel/preset
access for tuners and receivers.
S SLEEP: Switch off the NAD Receiver or Tuner after a preset number of minutes.
6MUTE: Press the [MUTE] button to temporarily switch OFF the sound to the speakers and
headphones. MUTE mode is indicated by the Standby LED indicator flashing for NAD Integrated
Amplifiers or
"Mute" shown in the VFD of NAD Receivers. Mute does not affect recordings made
using the TAPE outputs but will affect the signal going to the PRE OUT outputs. Press MUTE again
to restore sound.
7 DIM Ifor use with NAD Stereo Receiver, Tuner and CD Player): Reduce, turn offor restore VFD
brightness. Depending on the NAD model, the brightness of the front panel display will vary when
you toggle this button.
11

IDENTIFICATION OF CONTROLS
SR 8 REMOTE CONTROL
8 VOL [AI'" J: Press [AI"'] button to increase or decrease the loudness level. Release the button
when the desired level is reached. For NAD Receivers, the VFD will also show"Volume Up" or
"Volume Down" while pressing SR 8's [VOL AI"'] . The VOLUME buttons do not affect recordings
made using the TAPE outputs but will affect the signal going to the PRE OUT outputs.
9 SPK A, SPK B: The [SPK A] and [SPK B] buttons engage or disengage the speakers connected
respectively to the Speakers A and Speakers B terminals. Toggle [SPK A] to switch ON or OFF the
speakers connected to the Speaker A terminals. Toggle [SPK B] to switch ON or OFF the speakers
connected to the Speaker B terminals. Press both buttons to engage both speakers.
10 TONE OFT: Tone Controls are enabled or disabled by pressing this button.
\ VOl
12
~
:N
TUNE
...... I );_}) \ •
}
.~
([)' <~) (II)
888
TUNER
GBBEl
CD PLAYER CONTROL (for use with NAD CD Player): Set the DEVICE SELECTOR to "CD" in orderto
gain access to these buttons. Some of the control buttons below are applicable only to specific NAD
CD Player models; check the owner's manual of your NAD CD Player for control button compatibility.
SCAN [ ... /~~ J: Fast reverse/forward search.
[~J: Open or close disc tray.
[. J: Stop playback.
[II] : Pause playback temporarily.
[ ~~I J: Go to next track/file.
[ .... J: Go to beginning of current track/file or to previous track/file.
[~J: Start playback.
FOLDER/FILE [AI'" J: Select through folder list/Select through WMNMP3 files.
ENTER: Select desired folder or WMNMP3 file.
DISP: Show playback time and other display information.
RAN: Play tracks/files in random order.
RPT: Repeat track, file or whole disc.
PROG: Enter or exit program mode.
CLEAR: Delete programmed track/file.
CD: Select CD as the active source.
USB: Select USB as the active source.
OPT: Select optical input as the active source.
SRC:Toggle to select desired SRC mode.
TUNER CONTROL (for use with NAD AM/FM/DABTuner): Set the DEVICE SELECTOR to "TUN" in
order to gain access to these buttons. Refer to the corresponding labels printed in the remote control
faceplate and their respective assigned buttons to make use of these functions. Some of the control
buttons below are applicable only to specific NAD Receiver orTuner models; check the owner's
manual of your NAD Receiver orTuner for control button compatibility.
AUTO TUNE: In DAB mode, press this button to automatically scan all available local stations.
TUNE [ /~~ I or ["'/~ I: Step up or down between AM or FM frequencies.
PRESET [ / ~~I J or [AI'" J: Step up or down between stored radio presets.
AM/FM/DB: Select AM, FM, DAB or XM band (if applicable).
TUNER MODE: In FM mode, toggle between "FM Mute On" and "FM Mute OW In DAB mode,
pressing this button will activate Dynamic Range Control (DRC), Station Order or other applicable
DAB menu options.
BLEND: Engage or disengage BLEND feature.
MEMORY: Save current station into preset memory.
DELETE: Press and hold for about 2 seconds and the selected preset memory is erased.
[ "'/~ J: In DAB mode, in combination with TUNER MODE or other compatible buttons, toggle
to select through DAB feature options like Dynamic Range Control, Station Order and other
appropriate DAB options.
ENTER: In AM/FM mode, toggle to select Preset or Tune mode. In DAB mode, press and hold to
check signal strength.
INFO: Repeatedly pressing this button will show information as supplied by the current radio
station. The applicable display contents include related DAB display information and RDS
broadcast data.

REFERENCE
TROUBLESHOOTING
CONDITION
POSSIBLE CAUSES POSSIBLE SOLUTIONS
--------------------
No sound. • Power AC lead unplugged or power not ·
Check if AC lead is plugged in and power
switched
ON.
switched ON.
• Tape Monitor selected.
•De-selectTape Monitor mode.
.-
•Mute on.
• Switch off Mute.
• Rear Pre-out/Main-in amp links not fitted. • Fit links.
f----------
-------
- >----_ ... _._-_.
No sound one channel. • Balance control not centered. • Center Balance control.
--
.
.-
• Speaker not properly connected or damaged. • Check connections and speakers.
•Input lead disconnected or damaged. • Check leads and connections.
Weak bass/diffused stereo image. • Speakers wired out of phase.
• Check connections to all speakers in the
system.
--
Remote control handset not working. •
Battery fiat or incorrectly inserted. · Check or replace battery.
• IR transmitter or receiver windows obstructed. • Remove obstruction.
•
IR receiver in direct sun or very bright ambient • Place unit away from direct sun, reduce
light. amount of ambient light.
Standby LED turns red during operation. • C
375BEE has overheated. • Turn C 375BEE OFF; make sure ventilation
slots on top and bottom ofC 375BEE are not
blocked. After C 375BEE has cooled down,
turn
back ON.
• Overall impedance of loudspeakers too low. Ensure the overall loudspeaker impedance is
not below 4 ohms.
13

REFERENCE
SPECIFICATIONS
LINE LEVEL INPUT, PRE OUT
THD (2 Vin 2 Vout, CCIF IMD, DIM 100)
Signal/Noise ratio IHF
Channel separation - 1 kHz
10kHz
Input impedance
(R and C)
Maximum input signal
Output impedance - Pre out
Variable out
Tape out
Input sensitivity
Frequency response
Maximum voltage output -IHF load
600 ohms load
TONE CONTROLS
Treble
Bass
MAIN IN, SPEAKER OUT
Continuous output power into 80 and 40 (Stereo)
Continuous output power intoB0 (Mono, Bridge mode)
Rated THD (CCIF IMD, DIM 100)
Clipping power
IHF dynamic power -80
40
20
IHF dynamic power (Bridge mode) -B0
40
Peak output current
Signal/noise ratio
Damping factor
Frequency response
Input impedance
Input sensitivity
Voltage gain
Headphone output impedance
Channel separation - 1 kHz
10 kHz
TRIGGER OUT
Output resistance
Output current
Output voltage
14
>0.004 % (ref. 20 Hz - 20 kHz)
>1 02 dB (A-weighted, ref. 500 mV)
> 11 0 dB (A-weighted, ref. 2V, Volume maximum)
>92 dB (A-weighted, ref. 100 mV in 100 mV out -unity gain)
>80dB
>70dB
100 kO+ 320 pF
>8 Vrms (ref. 01 THD)
750
<3250
Source Z+ 1 kO
158 mV (ref. 500 mV out)
± 0.1 dB (ref. 20 Hz - 20 kHz, Tone defeat ON)
±05 dB (ref. 20 Hz - 20 kHz, Tone defeat OFF)
>10V (ref. 0.03% THD)
>10V (ref. 0.03% THD)
± 5 dB at 10 kHz
±8dBat 100Hz
>150W
(ref. ratedTHD, 20 Hz-20 kHz, both channels driven)
>330W
<0.009 % (ref. 20 Hz - 20 kHz)
>170W(ref.1 kHz l%THD)
250W
410W
600W
BOOW
1200W
>50 A (ref. 10, 1 ms)
>1 02 dB (A-weighted, ref. 1 W)
> 123 dB (A-weighted, ref. 150 W)
>200 (ref. 80, 50 Hz and 1 kHz)
± 0.1 dB (ref. 20 Hz - 20 kHz)
3 Hz - 70 kHz (ref. -3 dB)
10 kO + 200 pF
1.2 V (ref. rated power)
29dB
680
>B5 dB
>75 dB
<1200
50mA
+12V

REFERENCE
SPECIFICATIONS
CD IN. SPEAKER OUT
THD (250 mW to rated power, CCIF IMD, DIM 100)
Signal/Noise ratio
Frequency response
Channel separation - 1 kHz
10 kHz
POWER CONSUMPTION
Rated power
Standby power
Idle power
Dimensions (W xHx D)
Net weight
Shipping weight
"- Gross dimensions include feet, volume knob and extended speaker terminals.
<0.009 % (ref. 20 Hz - 20 kHz)
>94 dB (A-weighted, ref 1 W)
> 113 dB (A-weighted, ref. 150 W, volume set for 2V input)
± 0.2 dB (ref. 20 Hz - 20 kHz, Tone Defeat ON)
10 Hz - 65 kHz (ref. -3 dB)
>80dB
>70dB
290 W (ref. nov AC 50 Hz; 120V AC 60 Hz)
<lW
<120W
435 x 133 x 352 mm (Net)
435 x 150 x 396 mm (Gross")
153 kg
180 kg
Specifications are subject to change without notice. For updated documentation and features, please log onto www.NADelectronics.com for the latest
information about C 375BEE.
15

iii
www.NADelectronlcs.com
<02008 NAD ELECTRONICS INTERNATIONAL
ADIVISION OF LEN BROOK INDUSTRIES LIMITED
All rights reserved. No part of this publication may be reproduced, stored or transmined in any form without the written permission of NAD Electronics International
C 375BEE ONne(s Manual Issue 1-11/08

PP375 Moving Coil Moving Magnet
Input Sensitivity 1.6mV 18mV
Input Overload >4mV (20Hz – 20kHz) >40mV (20Hz – 20kHz)
RIAA Accuracy +/- 0.25dB +/- 0.25dB
Total Harmonic Distortion <0.03% (20Hz – 20kHz) <0.03% (20Hz – 20kHz)
IHF A Signal to Noise >76dB (100 Ohms load) >77dB (IHF cartridge load)
Channel Separation 1kHz >80dB >80dB
10 kHz >70dB >70dB
Specications
The PP 375 is a simple dealer-installed module that integrates a very high performance phono input with our top
Classic Series Integrated Amps, the C 375BEE and C 356BEE. This high performance phono stage supports both low
and high output moving coil cartridges, as well as the broad selection of moving magnet and moving iron cartridges on
the market today.
> Fantastic Vinyl Playback
An extremely accurate RIAA lter (required for LP
playback) with excellent sensitivity, high overload
margins and extremely low levels of noise and distortion,
extract every nuance of sound from your LPs.
> MDC Modular Design Construction
This MDC upgrade module represents our belief that
customers should be able to easily add new features
in the future without replacing the entire component.
MDC not only reduces cost, but also the impact on the
environment.
>Award-winning Design
The PP 375 circuit, designed by Director of Advanced
Development, Bjorn Erik Edvardsen, is based on many
award-winning preamp designs. MDC also received the
prestigious RedDot Design Award in 2009.
> Seamless Integration
Unlike other external phono preamps, the PP 375 does
not need extra wires, power supplies or interconnect
cables. Automatically assigned to the DISC input
selection on the MDC amp, the level is well matched to
other line level inputs.
PP 375 Phono Preamplier MDC Module
Features
NAD Electronics International reserves the right to change specications or features without notice. NAD is a registered trademark of NAD Electronics
International. All rights reserved. No part of this publication may be reproduced, stored, or transmitted in any form whatsoever without the written
permission of NAD Electronics International. © 01/11 11-001 NAD Electronics International.
www.NADelectronics.com

A OPTICAL IN
• Connect OPTICAL IN to corresponding optical output of sources
such as CD, DVD or BD players, digital cable box, digital tuners and
other applicable components.
B DAC MODULE INPUT SELECTOR
• Slide this switch to select the active input to the DAC module. Set to
OPTICAL for the S/PDIF source to be selected. For computer audio
to be selected, set to USB.
• Set to PHONO if the optional PP375 Phono Preamplier module is
installed.
NOTE
Press DISC/PHONO input selector of C 375BEE to switch to the DAC
module’s current active source.
C USB
• Using Type A to Type B cable connector (not supplied), interface
computer audio to this asynchronous Type B USB input to directly
stream 24 bit/96 kHz PCM content from your PC or MAC.
• In order to stream computer audio to the DAC module, ensure that
the Sound or Audio device of your computer is set to“NAD USB
Audio”. Check with your computer’s operating system on how to set
up or select “NAD USB Audio”as the Sound or Audio device.
SPECIALNOTEABOUTPCCOMPATIBILITYWITHTHE
USBINPUTOFTHISPRODUCT
Because of the great variety of PC-compatible computer systems,
operating system versions, and peripherals currently in use, we do not
guarantee ‘glitch free’ performance with all such systems. This NAD
product uses a special ‘asynchronous’ USB mode that eliminates the very
high levels of jitter (digital timing errors) endemic to the USB interface.
While this mode oers superior audio quality, it is not a common mode
of operation for some USB driver software. If you experience audio
dropouts we suggest trying an alternate PC or PC operating system.
In general, we nd Apple computers to be the most stable for this
application.
For those using PCs, we have developed a NAD USB Audio driver that
improves your PC’s performance, especially those running Windows 7.
Visit NAD’s website (http://nadelectronics.com) and go to this product’s
page. Then, download “NAD USB Audio Driver” from the “Manuals and
Downloads” tab. Install the NAD USB Audio Driver to your computer by
following the instructions provided.
MDC DAC
MODULAR DESIGN CONSTRUCTION DIGITAL-TO-ANALOG CONVERTER
OPTICAL
IN
USB
OPTICAL
USB
DAC MODULE
PHONO
A B C
The C 375BEE has added the MDC DAC module to bring the convenience of
computer music to your system with NAD musical performance fully intact.
USB is a computer standard for high speed data transmission but it has a
feature set tilted towards PC use. USB sends information in “data packets”
which makes the system very robust. There is also a trac manager that can
vary the size and sequence of the packets – good for PC, bad for music.
These timing variations create a condition called“jitter”– small
variations that create a harsh distortion. Thanks to a technique known as
“asynchronous USB”, MDC DAC module’s high precision clock eliminates this
distortion (jitter) usually associated with music in a computer environment.
With the DAC module now installed in the C 375BEE, refer below for
descriptions of key DAC module parts.
ENGLISHPORTUGUÊS FRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

Garantie
NAD Electronics of America et Lenbrook/NAD Canada garantissent que la presente composante est exempte de tout vice de materiau et de fabrication selon les
modalites suivantes :
Composantes electroniques (preamplificateurs, amplificateurs, amplificateurs integres, syntoniseurs, processeurs AN et produits NV integres)
Composantes electromecaniques (platines cassettes, lecteur de disques compacts et platines tourne-disques) 2ans, pieces et main-d'ceuvre
2ans, pieces et main-d'ceuvre
La presente garantie est valide uniquement dans Ie pays ou Ie produit aete achete et n'est pas transferable. Elle est offerte en exclusivite a la personne ayant effectue
I'achat, aI'origine, chez
un depositaire agree de produits NAD. Seuls les depositaires agrees peuvent se presenter en cette qualite, et I'acheteur peut verifier la qualite
de depositaire agree
du marchand en communiquant avec NAD/Lenbrook au numero suivant : 1 800 263-4641.
Obligation de NAD:
Si, pendant la duree de la garantie, la composante NAD cesse de fonctionner correctement en raison d'un vice de fabrication, NAD/Lenbrook, aleur seule discretion,
repareront
ou remplaceront celle-ci gratuitement.
Pour une reparation:
Pour faire reparer Ie produit, veuillez I'apporter, avec la facture ou Ie coupon de caisse original, avotre depositaire NAD. Si cet etablissement n'est pas un centre de
reparation NAD autorise,
il vous indiquera ou se trouve Ie centre Ie plus proche. Vous pouvez aussi appeler au 1800 263-4641 pour connaltre I'emplacement du centre
de reparation NAD agree Ie plus proche.
Ce qui nous payons:
Nous assumons tous les frais de main-d'reuvre et de materiaux des articles garantis, mais ne payons pas les frais d'expedition si vous devez faire parvenir Ie produit a
NAD/Lenbrook ou a un centre de reparation NAD agree. Si les reparations sont couvertes par la garantie, NAD/Lenbrook ou Ie centre de reparation assumeront les frais
de transport pour
Ie retour de votre produit.
Etendue de la garantie:
La presente garantie ne couvre par les composantes :
1. endommagees dans Ie transport ou dans un cas de force majeure;
2. soumises aune trop forte charge, utilisees de fa<;:on abusive, mal utilisees ou combinees a un equipement defectueux ou inapproprie ou encore utilisees d'une
maniere contraire aux directives donnees dans Ie manuel accompagnant Ie produit;
3. reparees par du personnel non autorise;
4. dont Ie numero de serie aete enleve ou altere.
LE GARANT NE POURRA, EN AUCUNE CIRCONSTANCE, ETRE TENU RESPONSABLE POUR LES DOMMAGES ACCESSOIRES, qu'ils resultent de I'inexecution
d'une garantie explicite
ou indirecte, d'un delit, d'une negligence ou d'une autre cause.
Certains etats et certaines provinces ne permettent pas I'exclusion ou la limitation des dommages accessoires; il est possible que les limitations et exclusions ci-dessus
ne s'appliquent pas avous.
La presente garantie vous accorde des droits reconnus par la loi. II se pourrait que vous en ayez d'autres, qui peuvent varier d'un etat ou
d'une province aI'autre ou d'un pays aI'autre.
IMPORTANT: La garantie peut etre differente d'un pays a un autre. Le distributeur local atous les details.
AVERTISSEMENT
NE CONFIEZ PAS LA REPARATION DU PRODUIT AUNE PERSONNE NON AUTORISEE. LES PIECES NECESSAIRES POUR VEILLER A
CE QUE VOTRE PRODUIT FONCTIONNE COMME AL:ORIGINE NE PEUVENT ETRE OBTENUES QUE PAR L:ENTREMISE DES
DEPOSITAIRES ET DES DISTRIBUTEURS AGREES. LA PRESENTE GARANTIE EST NULLE
SI L:EQUIPEMENT AETE ALTERE OU SI
DES PIECES INADEQUATES ONT ETE UTILISEES.
NAD Electronics of America, 6Merchant Street, Sharon, Massachusetts, 02067 Lenbrook /NAD Canada, 633 Granite Court, Pickering, Ontario L
lW 3Kl
Formule 101 Rev. 3/98

Warranty
NAD Electronics of America and Lenbrook/NAD Canada warrants this component to be free from all defects in materials and workmanship as follows:
Electronic components (preamplifiers, amplifiers, integrated amplifiers, receivers, AN processors, &integrated AN products)
Electro-mechanical products (cassette decks, CD players &changers, turntables) 2years,
parts & labor
2years, parts & labor
This warranty is valid only in the country of purchase. This warranty is non-transferable, and is valid for the first, original purchaser purchasing from an Authorized Dealer
of NAD products. Only Authorized Dealers represent themselves as such, and purchasers may confirm the status of Authorized Dealers
by calling NAD/Lenbrook at 1-
800-263-4641.
What we will do:
Should your NAD component fail to function properly due to amanufacturing defect, NAD/Lenbrook,
at its sole discretion, will repair or replace it free of charge during the
warranty period.
How to obtain service:
To obtain warranty service, please bring your unit along with the original invoice or bill of sale to your NAD dealer. If he is not an authorized NAD service center he will
direct
you to the nearest one or you may call 1-800-263-4641 for the location of the nearest NAD service center.
Note: The NAD warranty requires proof-of-purchase prior to any in-warranty repairs. Always retain your original sales slip.
What we
will pay for:
We will pay all labor and material expenses for covered items, but you must pay any shipping charges if it is necessary to ship the product to NAD/Lenbrook or to an
authorized NAD service center. If the repairs are covered by the warranty, NAD/Lenbrook or the service center will pay the return shipping charges.
What
is not covered:
This warranty does not cover acomponent which has been:
1. Damaged in transit or by act of God;
2. Overloaded, abused, misused, or operated with faulty or unsuitable equipment, or contrary to instructions contained in the accompanying product manual;
3. Serviced by unauthorized personnel;
4. The serial number has been altered or removed.
IN NO EVENT SHALL THE WARRANTOR BE LIABLE FOR INCIDENTAL, OR CONSEQUENTIAL DAMAGES, whether damages result from breach of express or implied
warranties, tort, negligence, or otherwise.
Some states(provinces)
do not allow exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you. This
warranty gives you specific legal rights, and
you may also have other rights which vary from state(province) to state(province) or between countries.
IMPORTANT: Warranty in other countries may vary. Contact your local distributor for details.
WARNING
DO NOT ENTRUST ANY REPAIR WORK TO UNAUTHORIZED PERSONS. THE COMPONENTS NECESSARY
TO MAINTAIN THE
ORIGINAL PERFORMANCE OF THIS PRODUCT ARE AVAILABLE ONLY THROUGH AUTHORIZED DEALERS AND DISTRIBUTORS. THE
WARRANTY WILL
BE INVALIDATED IF THE EQUIPMENT IS TAMPERED WITH OR INCORRECT PARTS ARE SUBSTITUTED.
NAD Electronics of America, 6Merchant Street, Sharon, Massachusetts, 02067 Lenbrook /NAD Canada, 633 Granite Court, Pickering, Ontario L1W
3K1
Form 101 Rev. 3/98
