NAD CI 8-150 DSP User manual

AUDIO OUT
LR
DIGITAL AUDIO OUT
OPTICAL COAXIAL
DIGITAL AUDIO OUT
OPTICAL COAXIAL
MODEM USBLAN 4
LAN 3LAN 2LAN 1
DISPLAY USB USB
2 CHANNEL AUDIO OUT
UNBALANCED
RBALANCED LBALANCED
L
R
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
1.
®CI 8-150 DSP Multi-Channel Amplier
Quick Setup Guide
© NAD CI 8-150 DSP
x1/x2x1/x2x1/x2
x1/x2/x3/x4
GUIDELINE FOR NETWORK SETUP CONNECTION
This guideline is applicable to PC, MAC or smartphone control devices. Adapt the guidelines according to your
control device.
1 Use an Ethernet cable (not supplied) to connect CI 8-150’s LAN port to your Wired network or router.
IMPORTANT NOTES
• For wired connection to be established, ensure that a broadband router that supports Ethernet is setup and
available.
• Ensure that CI 8-150 and the control device (PC, Mac or smartphone device) are connected to the same network.
• Use the information in the rear panel MAC ID sticker to identify the CI 8-150 from your network.
2 Power up your CI 8-150. The CI 8-150 will not communicate with the network when in Eco standby mode.
3 Use any network IP scanner to nd your CI 8-150’s Network ID (listed as the product name (NAD CI 8-150)
immediately followed by the last six digits in the MAC (Machine Access Control) address
(example: NAD CI8-150_123456). Note also the corresponding IP address assigned by the network.
4 Type the IP address into your control device’s web browser to access your CI 8-150’s User Interface (UI).
5 Congure your CI 8-150’s Identication, Input/Output, DSP and Settings parameters via User Interface.
FIRMWARE UPGRADE PROCEDURE
1 Upon gaining access to your CI 8-150’s User Interface, check immediately for any rmware update by selecting
“Check For Updates”from the “Settings”tab.
2 Follow the rmware upgrade prompt instructions to complete the upgrade process.
POWER OPTIONS
SETTING DESCRIPTION
Power button Press power button to set unit to operating or standby mode.
Always On Unit is always in operating mode. Shut down power by disconnecting unit’s AC plug from the mains power
source.
12V Trigger Presence or absence of +12V DC supply from compatible devices to rear panel +12V TRIGGER IN will
remotely switch the unit to operating or standby mode.
Signal Sense Unit will instantaneously turn from standby to operating mode if it senses any input signal (approximately
above 2 mV RMS input) applied through any of the GLOBAL, COAXIAL, OPTICAL or LINE INPUT sockets.
IMPORTANT
CI 8-150 factory default setting for Eco Mode is ON. With “Power Mode” set to “Signal Sense” and “Eco Mode” set
to “ON”, CI 8-150 will automatically go to Eco standby mode after 20 minutes of no active audio source input.
nadelectronics.com/product/ci-8-150-multi-channel-amplier
support.nadelectronics.com
!
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP

©2020 NAD ELECTRONICS INTERNATIONAL, A DIVISION OF LENBROOK INDUSTRIES LIMITED
All rights reserved. NAD and the NAD logo are trademarks of NAD Electronics International, a division of Lenbrook Industries Limited.
No part of this publication may be reproduced, stored or transmitted in any form without the written permission of NAD Electronics International.
CI8-150DSP-QS-EN-v06 - 01/20
4.
3.
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
2.
x1/x2/x3/x4
+ -- +
STEREO
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
© NAD CI 8-150 DSP
x1/x2/x3/x4
- +
BRIDGE
STANDBY AND CHANNEL LED STATUS INDICATORS
DESCRIPTION STANDBY LED STATUS CHANNEL LED 1-8 STATUS
Operating mode Blue If there is a signal, corresponding channel
LED is solid blue or no light if no signal.
Standby mode Amber O, no light
System reboot Flashing amber O, no light
Overvoltage or under voltage Red O, no light
AMP current error Blue Corresponding channel LED is red.
AMP DC error Red O, no light.
POWER CONSUMPTION AND HEAT OUTPUT
CONDITION
230V/50HZ 120V/60HZ
POWER
CONSUMPTION (W)
HEAT OUTPUT
(BTU/HR)
POWER
CONSUMPTION (W)
HEAT OUTPUT
(BTU/HR)
Eco mode Standby Power at 8 ohms 0.4 1.4 0.4 1.3
Network Standby Power at 8 ohms 1.2 4.2 1.2 4.1
Idle power at 8 ohms 86 295 88 299
Output power at 8
ohms, all channels
driven
1/8 rated power 243 826 246 836
1/3 rated power 529 1799 540 1836
1/2 rated power 758 2577 781 2655
Full rated power 1512 5140 1557 5294
Output power at 4
ohms, all channels
driven
1/8 rated power 251 853 255 867
1/3 rated power 552 1877 561 1907
1/2 rated power 790 2686 813 2764
Full rated power 1540 5236 1600 5440
IMPORTANT
Visit nadelectronics.com/product/ci-8-150-multi-channel-amplier or support.nadelectronics.com for further information and assistance.
