Owner’s Manual
M50
Digital Music Player

SAVE THESE INSTRUCTIONS FOR LATER USE.
FOLLOW ALL WARNINGS AND INSTRUCTIONS MARKED ON THE AUDIO
EQUIPMENT.
1 Read instructions - All the safety and operating instructions should be read
before the product is operated.
2 Retain instructions - The safety and operating instructions should be retained
for future reference.
3 Heed Warnings - All warnings on the product and in the operating instructions
should be adhered to.
4 Follow Instructions - All operating and use instructions should be followed.
5 Cleaning - Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6 Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7 Water and Moisture - Do not use this product near water-for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a
swimming pool; and the like.
8 Accessories - Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious injury to a child or adult,
and serious damage to the product. Use only with a cart, stand, tripod, bracket, or
table recommended by the manufacturer, or sold with the product. Any mounting
of the product should follow the manufacturer’s instructions, and should use a
mounting accessory recommended by the manufacturer.
9 A product and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the product and
cart combination to overturn.
10 Ventilation - Slots and openings in the cabinet are provided for ventilation and
to ensure reliable operation of the product and to protect it from overheating, and
these openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or other similar surface. This
product should not be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer’s instructions have been
adhered to.
11 Power Sources - This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local power company.
The primary method of isolating the amplier from the mains supply is to
disconnect the mains plug. Ensure that the mains plug remains accessible at all
times. Unplug the AC power cord from the AC outlet if the unit will not be used
for several months or more.
12 Grounding or Polarization - This product may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the other). This
plug will t into the power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the plug. If the plug
should still fail to t, contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
13 Power Cord Protection - Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the product.
14 Outdoor Antenna Grounding - If an outside antenna or cable system is
connected to the product, be sure the antenna or cable system is grounded so
as to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information
with regard to proper grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention to Section 820-40 of
the NEC which provides guidelines for proper grounding and, in particular, species that
the cable ground shall be connected to the grounding system of the building, as close to
the point of cable entry as practical.
15 Lightning - For added protection for this product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will prevent damage
to the product due to lightning and power line surges.
16 Power Lines - An outside antenna system should not be located in the vicinity
of overhead power lines or other electric light or power circuits, or where it can
fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits
as contact with them might be fatal.
17 Overloading - Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of re or electric shock.
18 Object and Liquid Entry - Never push objects of any kind into this product
through openings as they may touch dangerous voltage points or short out parts
that could result in a re or electric shock. Never spill liquid of any kind on the
product.
WARNING: THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING
OR SPLASHING, AND OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHOULD NOT BE PLACED ON THE APPARATUS. AS WITH ANY ELECTRONIC
PRODUCTS, USE CARE NOT TO SPILL LIQUIDS INTO ANY PART OF THE
SYSTEM. LIQUIDS CAN CAUSE A FAILURE AND/OR A FIRE HAZARD.
19 Damage Requiring Service - Unplug this product from the wall outlet and refer
servicing to qualied service personnel under the following conditions:
a) When the power supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualied technician to
restore the product to its normal operation.
e) If the product has been dropped or damaged in any way.
f) when the product exhibits a distinct change in performance-this indicates a
need for service.
20 Replacement Parts - When replacement parts are required, be sure the
service technician has used replacement parts specified by the manufacturer
or have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
21 Safety Check - Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the product is in
proper operating condition.
22 Heat - The product should be situated away from heat sources such as radiators,
heat registers, stoves or other products (including ampliers) that produce heat.
IMPORTANT SAFETY INSTRUCTIONS
2
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

Battery must not be exposed to excessive heat such as sunshine, re or the
like.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
FCC WARNING USA NOTICE
This equipment may generate or use radio frequency energy. Changes or
modications to this equipment may cause harmful interference unless the
modications are expressedly approved in the manual. The user could lose the
authority to operate this equipment if an unathorized change or modication is made.
LABELING INFORMATION
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
RF EXPOSURE STATEMENT
The antenna(s) used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be located or operated in
conjunction with any antenna or transmitter other than those contained in this device.
RESPONSIBLE PARTY
LENBROOK AMERICA
6 Merchant Street
Sharon, MA 02067
USA
Telephone: [phone]
Facsimile: 781 784-8386
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
WARNING
Changes or modications to this unit not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
NOTE
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
CANADA NOTICE
“This Class B digital apparatus complies with Canadian ICES-003.”
This device complies with Industry Canada license-exempt RSS-210. Operation is
subject to the following two conditions: (1) this device may not cause Interference,
and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
• no naked ame sources such as lighted candles should be placed on the
apparatus;
• the use of apparatus in tropical climate
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN
EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE
PRESENCE OF UNINSULATED“DANGEROUS VOLTAGE”WITHIN THE
PRODUCT’S ENCLOSURE THAT MAYBE OF SUFFICIENT MAGNITUDE TO
CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED
TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING
AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE
ACCOMPANYING THE APPLIANCE.
CAUTION
This equipment employs a Laser System. To ensure proper use of this product, please
read the complete owner’s manual, available online at www.nadelectronics.com/
support, and retain for future reference. Should the unit require maintenance, contact
an authorized service location. Use of controls, adjustments or the performance of
procedures other than those specied may result in exposure to laser radiation. To
prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser
radiation when the enclosure is opened.
DO NOT STARE INTO BEAM
CAUTION REGARDING PLACEMENT
To maintain proper ventilation, be sure to leave a space around the unit (from the
largest outer dimensions including projections) that is equal to or greater than shown
below.
Left and Right Panels: 10 cm
Rear Panel: 10 cm
Top Panel: 10 cm
WARNING
If this product is used at 240VAC, a suitable attachment plug should be used.
IMPORTANT SAFETY INSTRUCTIONS
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
CLASSE 1 PRODUIT LASER
3
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

EUROPEAN UNION NOTICE FOR WIRELESS PRODUCT
Products bearing the CE marking comply
with the R&TTE Directive (1999/5/EC),
EMC Directive (2004/108/EC) and the Low
Directive (2006/95/EC) issued by the Commission of the European Community. Indoor
use only.
NOTES ON ENVIRONMENTAL PROTECTION
At the end of its useful life, this product must not be disposed of with
regular household waste but must be returned to a collection point for
the recycling of electrical and electronic equipment. The symbol on the
product, user’s manual and packaging, point this out.
The materials can be reused in accordance with their markings. Through re-use,
recycling of raw materials or other forms of recycling of old products, you are
making an important contribution to the protection of our environment. Your local
administrative oce can advise you of the responsible waste disposal point.
INFORMATION ABOUT COLLECTION AND DISPOSAL OF WASTE BATTERIES
DIRECTIVE 2006/66/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL
OF EUROPEAN UNION FOR EUROPEAN CUSTOMERS ONLY
Batteries bearing any of these symbols indicate that
they should be treated as “separate collection”and not
as municipal waste. It is encouraged that necessary
measures are implemented to maximize the separate
collection of waste batteries and to minimize the disposal
of batteries as mixed municipal waste.
End-users are exhorted not to dispose waste batteries
as unsorted municipal waste. In order to achieve a high
level of recycling waste batteries, discard waste batteries
separately and properly through an accessible collection point in your vicinity. For
more information about collection and recycling of waste batteries, please contact
your local municipality, your waste disposal service or the point of sale where you
purchased the items.
By ensuring compliance and conformance to proper disposal of waste batteries,
potential hazardous eects on human health is prevented and the negative impact of
batteries and waste batteries on the environment is minimized, thus contributing to
the protection, preservation and quality improvement of the environment.
RECORD YOUR MODEL NUMBER NOW, WHILE YOU CAN SEE IT
The model and serial number of your new M50 are located on the back of the cabinet.
For your future convenience, we suggest that you record these numbers here:
Model no: ......................................
Serial no.: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IMPORTANT SAFETY INSTRUCTIONS
23. Battery Disposal - When disposing of used batteries, please comply
with governmental regulations or environmental public instruction’s
rules that apply in your country or area. Batteries (battery pack or
batteries installed) must not be exposed to excessive heat such as
sunshine, re or the like.
24. Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
25. Wall or Ceiling Mounting - The product should be mounted to a wall
or ceiling only as recommended by the manufacturer.
WARNING
The lightning ash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sucient magnitude to constitute a risk of
electric shock to persons
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE AND
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHOULD NOT BE
PLACED ON THIS APPARATUS.
CAUTION REGARDING PLACEMENT
To maintain proper ventilation, be sure to leave a space around the unit
(from the largest outer dimensions including projections) than is equal to,
or greater than shown below.
Left and Right Panels: 10 cm
Rear Panel: 10 cm
Top Panel: 50 cm
IMPORTANT INFORMATION TO UK CUSTOMERS
DO NOT cut o the mains plug from this equipment. If the plug tted is
not suitable for the power points in your home or the cable is too short
to reach a power point, then obtain an appropriate safety approved
extension lead or consult your dealer. If nonetheless, the mains plug is
cut o, REMOVE THE FUSE and dispose of the PLUG immediately, to avoid
possible shock hazard by inadvertent connection to the mains supply. If
this product is not provided with a mains plug, or one has to be tted, then
follow the instructions given below:
IMPORTANT
DO NOT make any connection to the larger terminal which is marked
with the letter ‘E’or by the safety earth symbol or colored GREEN or GREEN
AND YELLOW. The wires in the mains lead on this product are colored in
accordance with the following code:
BLUE - NEUTRAL
BROWN - LIVE
As these colors may not correspond with the colored markings identifying
the terminals in your plug, proceed as follows:
• The BLUE wire must be connected to the terminal marked with the
letter ‘N’ or colored BLACK.
• The BROWN wire must be connected to the terminal marked with the
letter ‘L’ or colored RED
• When replacing the fuse, only a correctly rated and approved type
should be used, and be sure to re-t the fuse cover.
IF IN DOUBT CONSULT A COMPETENT ELECTRICIAN.
This product is manufactured to comply with the radio
interference requirements of EEC DIRECTIVE 2004/108/EC.
NOTES ON ENVIRONMENTAL PROTECTION
At the end of its useful life, this product must not be disposed
of with regular household waste but must be returned to a
collection point for the recycling of electrical and electronic
equipment. The symbol on the product, user’s manual and
packaging point this out.
The materials can be reused in accordance with their markings. Through
re-use, recycling of raw materials, or other forms of recycling of old
products, you are making an important contribution to the protection of
our environment.
Your local administrative oce can advise you of the responsible waste
disposal point.
RECORD YOUR MODEL NUMBER (NOW, WHILE YOU CAN SEE IT)
The model and serial number of your new C 355BEE are located on the
back of the cabinet. For your future convenience, we suggest that you
record these numbers here:
Model number : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial number : ......................................
IMPORTANT SAFETY INSTRUCTIONS
NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited
Copyright 2008, NAD Electronics International, a division of Lenbrook Industries Limited
3
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ
0979
NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited
Copyright 2014, NAD Electronics International, a division of Lenbrook Industries Limited
4
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .........................2
GETTING STARTED
WHAT’S IN THE BOX ..................................................6
QUICK SETUP GUIDE .................................................6
IDENTIFICATION OF CONTROLS
FRONT PANEL ........................................................8
REAR PANEL ........................................................ 10
REMOTE CONTROL ................................................. 12
OPERATION
USING YOUR iPad AS CONTROLLER................................. 13
NAVIGATION CONTROLS AND ICONS............................... 13
CONTROL PANEL ................................................... 13
HOW TO SWITCH BETWEEN SCREEN SECTIONS .................... 14
MENU SCREEN ..................................................... 15
LOCAL SOURCES ................................................... 15
LIBRARY ............................................................ 15
STREAMING SERVICES .............................................. 16
TUNEIN............................................................. 16
FAVOURITES ........................................................ 17
DISPLAY OF CURRENT BROADCAST ................................ 17
WiMP............................................................... 18
OTHER MUSIC SERVICE PROVIDERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
CREATING A PLAYLIST .............................................. 18
MANAGING YOUR PLAYLIST ........................................ 19
PLAYBACK DISPLAY OF CURRENT SONG............................ 20
NOW PLAYING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
PLAYER CONTROL .................................................. 21
CONFIGURE PLAYER ................................................ 21
RIP/ENCODE CONTROL PANEL ..................................... 22
CONFIGURE NETWORK SHARES .................................... 24
SETTINGS........................................................... 26
HELP ............................................................... 26
PLAYER NOTIFICATION ............................................. 26
LISTENING TO SPOTIFY ............................................. 28
SPECIFICATIONS .......................................... 29
5
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

WHAT’S IN THE BOX
Packed with your NAD M50 you will nd
Accessories box containing the following
• 120V AC Power cord
• 230V AC Power cord
• M50 remote control with 2 AA batteries
• Wireless antenna
• Quick Setup Guide
IMPORTANT NOTES
• This manual uses iPad as the device controller with respect to NAD M50
App operation.
• iPad is not supplied with the M50.
• The iPad controller can be viewed in either landscape or portrait
orientation.
• M52 and USB mass storage device mentioned in this manual are for
reference only and not supplied with the M50.
QUICK SETUP GUIDE
This simple guide will help you get started with your M50.
CONNECT FOR SOUND
• Using corresponding cable connectors (not supplied), connect M50’s
DIGITAL AUDIO ports to corresponding digital audio input of receivers,
home theater systems or digital processors.
CONNECT TO NETWORK
• Using an Ethernet cable (not supplied), connect one end to M50’s LAN
port and the other end directly to your Wired home network or router.
Alternatively, the M50 can also be connected by Wireless connection. See
succeeding section about “CONNECT TO WiFi”.
CONNECT TO POWER
The M50 comes supplied with two separate AC power cords. Select the AC
power cord appropriate for your region.
1 Before connecting the AC power cord’s plug to the wall outlet, connect
rmly rst the other end of the AC power cord to M50’s AC Mains input
socket.
2 Set the POWER switch at the rear panel to ON and then press the front
panel Standby button.
3 Out of the box and the M50 powered up for the rst time, the M50 will
have its initial reboot process that will end with the VFD showing
With Wired connection
Ready
With Wireless connection
Ready
Hotspot Mode
NOTES
• Never force the plug into a wall outlet. An adaptor may be necessary in
certain regions.
• Always disconnect rst from the wall outlet the AC power cord’s plug,
before disconnecting the other end of the AC power cord from the M50’s
AC Mains input socket.
CONNECT TO WIFI
1 Connect the supplied wireless antenna to M50’s WiFi antenna terminal
at the rear panel. Set the rear panel POWER switch to ON.
IMPORTANT!
For wireless connection to be established, ensure that the supplied
wireless antenna is installed and Wireless (WiFi) broadband router with
broadband internet connection is setup and available.
2 Use your iPad (not provided) to search for the WiFi network matching
your M50’s unique network ID and join it.
For example: “M50-0064”where “0064” are the last four numbers of the
unique Internet MAC identier of your M50. You can check your M50’s
unique Internet MAC identier by undertaking the following steps
a Press front panel’s MENU button.
b VFD will show
}Info
Mass Storage Usage
Test Mass Storage
WiFi Hot Spot Mode
c Select “Info”. Press remote control’s [S] or front panel’s [8] and the
VFD will show
Ver: 1.4.0
192.168.1.16
96:55:88:00:00:64
“00:64” is the same last four numbers in the “M50-0064” example above.
3 By selecting “M50-0064” from the “Choose a Network… “ list in the
“Wi-Fi” tab of Settings menu of your iPad, the “Congure Player” menu
window should automatically open. If not, open a web browser on your
device and visit http://10.1.2.3/
GETTING STARTED
6
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

4 Select “Congure WiFi”.
5 Select your home network or applicable wireless network name (SSID)
from the “Congure wireless” drop down menu.
6 Enter your home network’s Wireless Password (Passphrase, WEP/WAP
key as applicable) in the eld “Enter password or key (if protected)”.
The Password (Passphrase, WEP/WAP key as applicable) is the same
Password that was setup or generated during the conguration of
your home router or gateway. An incorrect password entered in the
“Congure wireless” menu screen will simply cause the unit to timeout
and return to Hotspot Mode.
Trying multiple passwords will not damage the device in any way. If
you are not sure what is your Password, login to your router and locate
the Password in the applicable setup screen for Wireless Conguration
section. Refer to your router’s documentation for further information.
7 Select a “Player name” from the drop down list or use the on-screen
keyboard to create a customized room name in the eld “Custom
name”.
8 Select “Update”and wait for the VFD to show
Ready
Your M50 is now connected to your home network and ready to be
used with the NAD M50 controller App.
DOWNLOAD THE APP
Upon successful setup connection, you will be directed to the“Congratulations”
page where you can select the highlighted“iOS App from the Apple App Store”
to download and install the“M50 Remote”App to your iPad.
After successfully downloading the M50 Remote App, select from your
iPad screen to open the NAD M50 Control Panel.
CONNECT TO MUSIC
You’re now ready to stream music by
selecting any source from the Local
Sources or Streaming Services.
Follow the screen prompts, and open
your whole home to the pleasure of
streaming HiFi music.
6
8
5
7
7
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

1 STANDBY LED
• This indicator will light up amber upon switching ON the rear panel
POWER switch.
• When the front panel Standby button is pressed to power up the
M50 from standby mode, this indicator will illuminate blue.
2 STANDBY BUTTON
The rear panel POWER switch must be at ON position for the Standby
button to activate. Pressing the Standby button will result to varying
actions or responses and is best illustrated by the table below.
ACTION/RESPONSE
RESULT
STANDBY BUTTON STANDBY LED
After switching ON the rear
panel POWER button, press
from standby mode.
Turns from amber
to blue.
M50 is powered up.
VFD is illuminated.
With M50 already powered
ON, toggle button.
Remains illuminated
in blue.
M50 remains ON.
VFD is turned on or o.
Press and hold… until
Standby LED turns to solid
amber.
Flashing amber and
then turns to solid
amber.
M50 switches to
standby mode.
VFD is turned o.
With the M50 at standby
mode, press Standby button
or any front panel button.
Turns from amber
to blue.
M50 is powered up.
VFD is illuminated.
3 INPUT
Switch input Sources when available. Toggle INPUT button to select
through the following Sources
• USB - Playback music les from the USB mass storage device
connected to Front USB.
• Library - Makes available songs from shared computer, NAS,
connected USB mass storage device or M52.
• Audio/Data disc - Playback loaded audio or data disc.
4 STOP/OPEN
Pressing STOP/OPEN during disc playback will cause the M50 to stop
playback and then eject the loaded disc.
5 DISC SLOT
• Insert CD or audio disc face down into this slot and playback will
automatically start provided the M50 is not connected to an active
M52 or USB mass storage device.
• CD will not playback automatically if a playlist is already available or
active at the time of CD loading. Select Audio Disc source to browse
and playback CD content.
• Refer also to“RIP/ENCODE CONTROL PANEL” section below for Rip/
Play options when an audio CD is inserted.
IMPORTANT NOTES
• The M50 must stand-alone, i.e. not connected to an active M52 or USB
mass storage device, for a loaded CD to be automatically played back.
• Only Audio CD can be played back by a stand-alone M50. If a data disc
(CD-R/RW with data les) is inserted into the disc slot, select “Data Disc”
source to browse and playback music le contents.
6 VACUUM FLUORESCENT DISPLAY (VFD)
Display visual information about the current Source. Information
supplied is generated by the Source.
7 REMOTE SENSOR
• Point the remote control at the remote sensor and press the
buttons.
• Do not expose the remote sensor of the M50 to a strong light
source such as direct sunlight or illumination. If you do so, you may
not be able to operate the M50 with the remote control.
Distance: About 23ft (7m) from the front of the remote sensor.
Angle: About 30° in each direction of the front of the remote sensor.
8 PLAY/PAUSE
• Toggle to start, pause or resume playback of current source.
9 MENU
• Display main menu options. Use the remote control’s D/F buttons
to move up or down the menu selections. Press Sto select a menu
item (use Ato return to the main menu or previous display). Having
selected a menu item, use D/F buttons to select an option and
then press ENTER to conrm selection. Upon pressing ENTER, the
display will revert back to the main menu window.
• The front panel 7/8/ 9/0 and ENTER buttons perform
respectively the same functions of the remote control A/S /F/D
and ENTER buttons. Use these buttons to navigate through the
MENU options.
}Info
Mass Storage Usage
Test Storage Usage
WiFi Hot Spot Mode
IR Channel
Reboot
Factory Reset
IDENTIFICATION OF CONTROLS
© NAD M50
play/
pause menu
skip
skip
scan scan
input
stop/
open
digital music player
4 5 6 7 8 9 10 111 2 3
FRONT PANEL
8
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

Info
Display information about the current software version, IP address and
unique Internet MAC identier.
Mass Storage Usage
Information is shown about the status of the M52 hard drives or USB
mass storage device like total, used and remaining disk space.“No Disk”
is displayed if there’s nothing connected at the rear panel’s USB 2 port.
Test Mass Storage
The connected M52 or USB mass storage device will be tested and
the result will be shown in the display. “No Mass Storage”is displayed if
there’s nothing connected at the rear panel’s USB 2 port.
WiFi Hot Spot Mode
• Enabled: Upon powering up, M50 goes to normal procedure of
connecting to network and then to Hot Spot mode.
• Disabled: M50 bypasses connecting to a network and goes directly
to “Ready” mode. It does not go to Hot Spot mode.
IR Channel
The M50 has the capability to operate via alternate IR channel. This is
practically useful if you have two NAD products that can be operated
by similar remote control commands. With alternate IR Channel, two
dierent NAD products can be controlled independently in the same
zone by setting each one to a dierent IR channel.
• Channel 0: Default IR channel setting of M50 to Channel 0. The
IR Channel for both the M50 and remote control must be set to IR
Channel 0 for full interface.
• Channel 1: Default IR channel setting of M50 to Channel 1. The
IR Channel for both the M50 and remote control must be set to IR
Channel 1 for full interface.
IMPORTANT NOTES
• The IR Channel feature is compatible only with programmable NAD
remote controls like the AVR 4 and HTR-series remote controls.
• The M50 remote control is defaulted to IR Channel 0. The M50 remote
control has no feature that will allow it to switch IR channels so
ensure that the corresponding IR Channel setting of your M50 is set to
Channel0.
Reboot
Yes: Restart your M50 again.
No: Reboot is not initiated.
Factory Reset
Yes: Restore your M50 to its factory default settings.
No: Do not initiate factory reset.
Another way to restore your M50 to its factory default settings is by
undertaking the following steps.
HOW TO MANUALLY RESET M50
a While keeping hold of front panel Standby button (press and hold),
set the POWER switch at the rear panel to ON. The blue Standby LED
will continuously ash and the VFD will show
NAD M50
Upgrade Mode
b Continue press and hold of Standby button(for more than 30
seconds)until VFD will show
NAD M50
Factory Reset…
c Release hold of the Standby button.
d With the blue Standby LED continuously ashing, the M50 will
eventually restart and undergo normal start up procedure.
e The VFD will end up showing
Ready
Hotspot Mode
(If connected via Wireless connection)
Ready
(If connected via Wired connection)
You are now ready to use or congure your M50.
10 FRONT USB
•
Connect to this input a USB mass storage device with music les.
Typical USB mass storage devices compatible with M50 include
portable flash memory devices and external hard drives (NTFS,
EXT4 formatted).
11 9/0/7/8, ENTER
• Press 0to skip forward or 9to skip backward a track or song.
• Press 7/8 to scan fast-forward or fast-reverse during playback.
• The front panel 7/8/ 9/0 and ENTER buttons perform
respectively the same functions of the remote control A/S /F/D
and ENTER buttons. Use these buttons to navigate through the
MENU options.
IDENTIFICATION OF CONTROLS
9
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

1 AES/EBU OUT
Connect AES/EBU OUT to corresponding AES/EBU IN of compatible
devices (like the NAD M2 or NAD M51) to stream digital audio content.
For high-end sources with higher sampling rates like 176kHz and
192kHz, it is highly recommended that this AES/EBU OUT be interfaced
with the AES/EBU IN connector. Such interface is well suited to handle
such sources with high sampling rate.
2 COAXIAL OUT, OPTICAL OUT
Connect COAXIAL OUT or OPTICAL OUT to corresponding digital audio
input of compatible devices such receivers, computer soundcard or
other digital processors.
3 USB 1 (TYPE B)
Use for servicing purposes only. Not for consumer use. Only authorized
NAD service personnel can access this USB port.
4 HDMI OUT
Connect HDMI OUT to compatible devices with HDMI input. This is not
video output. It output audio component only and supports 24/192 HD
Audio in PCM’s native I2S format.
5 USB 2 (TYPE A)
• USB 2 is the corresponding USB input for M52 Digital Music Vault
connection.
• A USB mass storage device with music les can also be connected
to USB 2. Typical USB mass storage devices compatible with M50
include portable flash memory devices and external hard drives
(NTFS, EXT4 formatted).
• When a USB mass storage device is connected to this port, a “Music”
folder will be automatically created on the USB device. Put all your
music les in this “Music” folder, connect it to M50’s USB 2 and then
re-index – this “Music” folder is now your“Library” where all songs
are stored or ripped.
6 ETHERNET/LAN
LAN connection must be setup for wired connection to be established.
Set up a Wired Ethernet broadband router with broadband internet
connection. Your router or home network should have a built-in DHCP
server to consummate the connection.
• Using a standard straight-through Ethernet cable (not supplied),
connect one end of the Ethernet cable to the LAN port of your
wired Ethernet broadband router and the other end to M50’s LAN
port.
7 RS232
Use a RS232 serial cable (not supplied) with RS232 adapter (if necessary)
to interface this port to the corresponding RS232 connector of the
optional M2, M51, C390DD or any compatible NAD models. Through
this RS232 connection, the VOLUME slider in the App can be adjusted to
increase or decrease the audio output level of the M50.
NOTE
Use a NULL modem cable or cross serial RS232 gender changer adapter
to interface the M50 with the compatible NAD model.
8 IR IN, IR OUT
These mini-jacks accept and output remote-controlled codes in
electrical format, using industry-standard protocols, for use with “IR-
repeater” and multi-room systems and related technologies.
• All NAD products with IR IN/IR OUT features are fully compatible
with M50. For non-NAD models, please check with your other
product’s service specialists as to their compatibility to the M50’s IR
features.
IR IN
This input is connected to the output of an IR (infrared) repeater
(Xantech or similar) or the IR output of another compatible device to
allow control of the M50 from a remote location.
IR OUT
Connect IR OUT to the IR IN jack of a compatible device. Command
and control the linked compatible device by directing its own remote
control to M50’s infrared receiver.
IDENTIFICATION OF CONTROLS
© NAD M50
100-240V 50/60Hz
POWER
ON
DIGIT AUDIO
COAXIAL
OUT
OPTICAL
OUT
USB 1 USB 2
AES/EBU OUT
HDMI
OUT
AL ETHERNET RS232
WIFI
+12V TRIGGERIR
IN IN
OUTOUT
4 5 6 7 8 9 10 11 12 131 2 3
REAR PANEL
10
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

9 +12V TRIGGER IN
With this input triggered by a 12V DC supply, the M50 can be switched
ON remotely from standby mode by compatible devices such as
ampliers, preampliers, receivers, etc. If the 12V DC supply is cut o,
the M50 will return to standby mode.
• Connect this +12V trigger input to the remote device’s
corresponding +12V DC output jack using a mono cable with
3.5mm male plug.
• The controlling device must be equipped with a +12V trigger
output to use this feature.
+12V TRIGGER OUT
• The +12V TRIGGER OUT is used for controlling external device that is
equipped with a +12V trigger input.
• Use a 3.5mm mini-jack connector to pass +12V to a compatible
device equipped with +12V TRIGGER IN.
• This output will be 12V when the M50 is ON and 0V when the unit is
either OFF or in standby mode.
10 WIRELESS (WIFI) ANTENNA TERMINAL
• Install the supplied wireless antenna into this wireless antenna
terminal (WiFi).
• For wireless connection to be established, ensure that the supplied
wireless antenna is installed and Wireless (WiFi) broadband router
with broadband internet connection is setup and available.
11 POWER
• Supply AC mains power to the M50.
• When the POWER switch is set to ON position, the M50 goes to
standby mode as shown by the amber status condition of the
Standby LED. Press the front panel Standby button or remote
control’s [ON] button to switch ON the M50 from standby mode.
• If you intend not to use the M50 for long periods of time (such as
when on vacation), switch o the POWER switch.
• With POWER switched o, neither the front panel Standby button
nor remote control’s [ON] button can activate the M50.
12 FUSE HOLDER
Only NAD service personnel can access the fuse holder in the unlikely
event a fuse may need to be replaced. Refer all servicing to authorized
NAD service centers.
13 AC MAINS INPUT
The M50 comes supplied with two separate AC power cords. Select the
AC power cord appropriate for your region.
• Before connecting the AC power cord’s plug to the wall outlet,
connect rmly rst the other end of the AC power cord to M50’s AC
Mains input socket.
• Always disconnect the AC power cord’s plug from the wall outlet
rst, before disconnecting the cable from the M50’s AC Mains input
socket.
IDENTIFICATION OF CONTROLS
11
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

REMOTE CONTROL
1 ON: Switch M50 from Standby mode to operating mode.
OFF: Switch M50 to standby mode.
2 DISP: Display information about current track, le or song.
MENU: Display main menu.
3 D/F/A/S:Navigate or select through menu items or options.
ENTER: Conrm selected option. Go to next option.
CD: Select CD mode.
USB 1: Select Front USB source.
4 RPT: Repeat playback of current track or le. Repeat playback of whole disc or playlist.
RAND: Play tracks/les in random order.
5 [k]: Eject loaded disc.
[;]: Pause playback temporarily.
[0]: Go to next track or le.
[9]: Go to the beginning of current track or le.
[4]: Start playback.
Only above buttons are compatible with M50. Other available buttons are not applicable for M50 or
are non-functional.
IMPORTANT NOTICE ABOUT M50 REMOTE CONTROL
The M50 remote control can be used for either M51 Direct Digital DAC or M50 Digital Music
Player.By undertaking the following steps, the M50 remote control can be defaulted for use by
either M51 or M50.
For M50: Press and hold “5” and “0” at the same time until the remote control’s blue transmit LED
ashes twice.
For M51: Press and hold “5” and “1” at the same time until the remote control’s blue transmit LED
ashes twice.
Release the corresponding buttons above as soon as the blue transmit LED ashed twice.
IDENTIFICATION OF CONTROLS
VO LUME
AES/
EBU HDM I
1
HDM I
2
USB
CO AX
OPT
EQ
POL AR.
DISP MENU
DIM
SETUP
5
46
8
7 9
0
23
1
MUTE
RPT RAND
ENTER
CD
NET W
USB
1
USB
2
1
2
3
4
5
12
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

USING YOUR iPad AS CONTROLLER
This version of the manual employs the iPad as the device controller of the
NAD M50. iPad is not supplied with your NAD M50.
Use your iPad to download and install the free NAD M50 Remote App from
the iTunes App Store.
Select from your iPad screen to open the NAD M50 Control Panel.
The NAD M50 Control panel is compatible with iPad’s method of navigating
through its features and functions. Use your ngers to pinch, swipe, tap and
double-tap an item you want to command, control or manipulate. Refer to
your iPad’s user guide for further information on how to use multi-tasking
gestures to go about the task you want to perform.
NAVIGATION CONTROLS AND ICONS
The following are other navigation controls and icons that you will
encounter as you use your iPad to open the NAD M50 App and navigate
through its features.
Launch NAD M50 app.
Return to Source mode. Display available sources.
Show all active NAD devices available within the same
network.
Return to Home mode – display device’s control panel.
Return to previous display or menu window.
Exit current menu window or page display.
Slide to increase or decrease volume or audio output
level.
Skip forward or backward a song from your current
playback list. At TuneIn or WiMP Source mode, tapping
either control will revert the source to“Library”mode.
Start playback of song or broadcast.
Pause playback of song or broadcast.
Songs in the current playback list are played in random
order.
Repeat playback of current song.
Repeat all songs in the playlist.
NOTE
Audio output level is adjustable via the Volume slider in the NAD App
only if the respective RS232 ports of M50 and the optional M2, M51,
C390DD or any compatible NAD models are interfaced and connected
together. The Volume slider in the NAD App is disabled and not
functional in the absence of such interconnection.
CONTROL PANEL
The NAD M50 Control Panel is divided into three main screen sections
1 Center Screen
Reect all playback controls and other information depending upon the
source selected.
2 Menu Screen
Show all congurable menu settings.
3 Player Screen
Display all available players in the same network.
OPERATION
13
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

HOW TO SWITCH BETWEEN SCREEN SECTIONS
CENTER SCREEN TO MENU SCREEN
CENTER SCREEN TO PLAYER SCREEN
1 Tap to show Menu Screen along with a portion of the Center
Screen display.
2 Swipe from left to right to show Menu Screen along with a portion of
the Center Screen display.
3 Tap to show Player Screen along with a portion of the Center
Screen display.
4 Swipe from right to left to show Player Screen along with a portion of
the Center Screen display.
MENU SCREEN TO CENTER SCREEN
1 Tap or anywhere within the Center Screen display portion to return
full Center Screen display.
2 Swipe from right to left within the Center Screen display portion to
return full Center Screen display.
PLAYER SCREEN TO CENTER SCREEN
1 Tap or anywhere within the Center Screen display portion to return
full Center Screen display.
2 Swipe from left to right within the Center Screen display portion to
return full Center Screen display.
OPERATION
1
2
3
4
1
2
1
2
14
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

MENU SCREEN
The Menu Screen consists of several sections as follows
• Local Sources
• Streaming Services
• Now Playing
• Player Control
• Settings
• Help
LOCAL SOURCES
Show current sources. When available, these sources could be
Library
Collection of personal music you have backed up, stored or ripped in
• A M52 Digital Music Vault or USB mass storage device connected to the
USB 2 (Type A) input of your M50
• Shared network (PC, MAC, NAS)
Audio Disc/Data Disc
Tracks or les playable from the audio or data disc loaded at the disc slot.
USB
Stored music les accessible from the USB device connected to the Front
USB.
LIBRARY
Selecting “Library” allows you to listen to your personal music collection
stored on your network (PC, MAC, NAS), ripped to your M52 Digital Music
Vault or contained in a USB mass storage device connected to the USB 2
(Type A) input of the M50.
Upon selection of “Library”, your music catalogue will appear on-screen.
The category buttons (located at the bottom portion) allows your music to
be sorted in several ways as follows
• Artist
• Album
• Song
Select an alphabet letter on the right side for quick redirection to the
corresponding list of artists, albums or songs that starts with the selected letter.
• New: List albums in the order they were encoded with the latest
item at the top of the list. This is an easy way to locate ripped CD’s or
purchases that were recently downloaded.
• Playlist: Show favourite songs that were grouped together and saved
for easy access. Several playlists can be created like your Favourite
playlist, Contemporary playlist, Oldies playlists, etc.
• Info: Open on Last.fm a small browser showing related information
(like biography, albums) about the current artist being played back.
If no information about the artist is available, the browser will display
“[unknown]”.
OPERATION
15
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

SEARCH …
You can search a song by directly entering its name at the “Search…” box.
Select the “Search…” box and the on-screen keyboard appears.
Enter the song’s name (even just a part of it) and several relevant songs,
albums or artists pop up as you type.
If available, select from the suggested list the song you were looking for.
Otherwise, try searching again.
NOTE
Above category buttons and features apply also to Audio/Data disc and
USB source modes.
STREAMING SERVICES
Show streaming services supported by NAD M50. Enter your account log-in
details or credentials for the applicable streaming service you subscribe.
TuneIn
Tune to radio stations streamed across the Internet via TuneIn.
WiMP
Rdio
Listen to music streaming service providers supported by NAD M50.
TUNEIN
TuneIn Radio is a music service provider supported by NAD M50. TuneIn
Radio allows listeners to experience the whole world of radio within a
single application. It is a global service where one can listen to music,
sports or news from every corner of the earth. Users in Vancouver can enjoy
broadcasts from London, Sydney, New York, Tokyo or any other location in
the world.
TuneIn allows listeners to quickly and easily nd their favourite radio
stations and personalities plus discover new ones. Radio stations are
classied according to the following preferences.
• Local Radio: Tune in to radio stations in your local area.
• Music: Select radio stations by categories or genres like Adult
Contemporary, Classical, Country, Reggae, etc.
• Talk: Oer a variety of topics like Business, Comedy, News, Religious, etc.
• Sports: List popular sports news or content providers that you can
listen in.
• By location: Listen to radio stations by countries. Radio stations are
grouped by continents and then by countries.
• By language: Radio stations are grouped according to the language
they are broadcast like Arabic, Chinese, Spanish, Tagalog, etc.
• Podcasts: Listen to Talk, Music, Sports or other available audio
podcasts.
SEARCH STATIONS, SHOWS, SONG…
Search a radio station, show, song or any type of broadcast by directly
entering the name at the “Search stations, shows, songs…” box.
1 Select the “Search stations, shows, songs…” box and the on-screen
keyboard appears.
2 Enter the name of station, show, song or broadcast you are searching
and then select “Search” from the on-screen keyboard. Several
suggested stations, shows, songs or broadcasts corresponding to your
search will be shown.
3 Select from the suggested list the station, show, song or broadcast you
were looking for. Otherwise, try searching again.
OPERATION
16
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

FAVOURITES
Create, save and easily access your favourite radio stations.
TO ADD FAVOURITE
Go to desired station page and select the TuneIn icon in the thumbnail of
the selected station. A menu window will pop-up. Select “Add Favourite”
and the selected radio station will be added in your “Favourites”list.
TO DELETE FAVOURITE
From the same menu window, select“Delete Favourite”to remove the
selected station from the “Favourites”list.
OTHER OPTIONS
The menu window that pops-up may include other options like the
playable audio format and the reliability of the signal, i.e. “Play I 48 kbps
MP3 – 75% reliable”. These options are dependent upon the capability or
information supplied by the selected radio station.
NOTE
The added or deleted favourite may not be reected immediately in
the “Favourites” menu window. Refresh the display by selecting “Local
Radio” or any other options and then return to “Favourites” – the
Favourite would be by now included or deleted in the Favourites list.
DISPLAY OF CURRENT BROADCAST
When a particular radio station is being broadcast, a thumbnail of the radio
station logo is shown at the lower left corner of the screen display.
Select the thumbnail.
Upon selection, the thumbnail image will be maximized into a full
screen display. In this full screen view, the following features, functions or
information are available.
1 Return to previous display or menu window.
2 Slide to the right to increase volume level
Slide to the left to decrease volume level
3 Play or pause current broadcast.
Skip backward and skip forward are not applicable for TuneIn.
4 Elapsed time listening in to current broadcast.
5 Show all devices in the network
6 Show clickable TuneIn menu options like Add Favourite, Delete
Favourite, Report a Problem and other available options.
7 Display related information as supplied by the radio station
When TuneIn icon is selected, among the options that appear is the “Report
a problem”. Follow all prompt commands to complete the report.
OPERATION
1
3 42
5
6
7
17
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

WiMP
WiMP (Wireless Music Player) is a streaming music service currently
available in Sweden, Denmark, Norway and Germany. WiMP on NAD M50
allows you to gain access to millions of songs.
LOGIN TO YOUR WiMP ACCOUNT
1 Select “Congure Music Services” from the “Congure Player” menu.
2 Log-in to your WiMP account by entering applicable details like User
name, Password and Country.
3 Select “Update”to register and store your corresponding WiMP account
details.
Upon successful log-in, select “WiMP” from the available list of music
services and you will be ushered in to all kinds of music: pop, rock, metal,
hip hop, r & b, jazz, classical and more - both old, classics and the latest
nds.
MANAGING YOUR WiMP PLAYLIST
When at WiMP source mode, features like Edit, Shue, Clear, Save, Artist,
Album, Song and sections like “Creating Playlist” and “Deleting Playlist”are
managed in the same manner as they are handled at Library source mode.
Refer these features and sections to their corresponding descriptions at the
LIBRARY section above.
OTHER WiMP FEATURES
(Applies to Songs and Albums)
• New - Latest songs or albums
• Recommended - Acclaimed recordings
• Popular - Most sought-after songs or in demand albums
PLAYLIST
• My Playlists - Include selections from WiMP and Library.
• My WiMP Playlist - Consist of selections only from WiMP.
OTHER MUSIC SERVICE PROVIDERS
For other music service providers supported by NAD, follow similar
procedure above for WiMP in activating and conguring their services.
More music service providers or streaming services will be supported by
NAD going forward. These music service providers may be added up when
your player receives notication for software upgrade. Watch out then for
your favourite music service providers as NAD gets to support their services!
CREATING A PLAYLIST
The playlist, reected in the left side of the screen display, is a register of
songs you have individually or collectively selected from your library and
music service provider. The listed songs can be played back in sequential or
shued order.
OPERATION
2
1
18
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

A playlist can be created by the following easy steps.
1 Select desired songs by picking through the Album, Song or Artist list
of your music Library or your music service provider. Select on the
upper right corner to close out the album.
2 Each selected song will be reected in the current playlist.
3 After completing your playlist, press“Save” and the on-screen keyboard
and playlist naming window will appear.
4 Type desired Playlist name. When done, press “Save”on the upper right
corner to complete the naming process.
This newly named Playlist will be included in the Playlist register. It will be
recalled along with other saved Playlists when “Playlist” tab is selected.
MANAGING YOUR PLAYLIST
A current Playlist can be managed by selecting any of the following options
EDIT
Delete songs from the current playlist.
1 Press “Edit” and will precede each song.
2 Select desired song to be deleted. and a “Delete”box will appear
on the same row as the selected song.
3 Select “Delete”to conrm removal of the song from the list. Repeat the
same for other desired songs to be deleted.
4 Once you complete all the songs you want deleted, select “Done”to exit
edit mode.
While at Edit mode, the order of the songs can be rearranged according
to your preference. Press and hold the on the right side of the desired
song you like to relocate. Then drag and drop said song to the desired
location in the playlist.
SHUFFLE
Playback in random order the songs in the current playback list only.
CLEAR
Songs in the current playlist are all cleared out. From the “Clear playlist”
window that will pop-up, select “Yes”to clear the current playlist or“No” to
retain the current playlist
SAVE
Group current list of songs into one Playlist and create a name for the
collection.
1 Press“Save”during playback and the on-screen keyboard and playlist
naming window will appear.
2 Type desired Playlist name.
3 When done, press“Save” on the upper right corner to complete the
naming process.
DELETING A PLAYLIST
A Playlist can be deleted from the Playlist register by the following steps.
1 Select “Playlist” and the Playlist register appears. Press “Edit” and will
precede each Playlist.
OPERATION
19
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

2 Select desired Playlist to be deleted. and a“Delete”box will appear
on the same row as the selected Playlist.
3 Select “Delete”to conrm removal of the desired Playlist. Repeat the
same for other Playlists to be deleted.
4 Once you complete all the Playlists you want deleted, select “Done”to
exit edit mode.
PLAYBACK DISPLAY OF CURRENT SONG
When a particular song from either your library or music provider is being
played back, a thumbnail of the album is shown on the lower left corner of
the screen display
Select the thumbnail.
Upon selection, the thumbnail will be maximized into a full screen display.
In this full screen view, the following features, functions or information are
available.
1 Return to previous display or menu window.
2 Slide to the right to increase volume level
Slide to the left to decrease volume level
3 Play or pause current song
Skip backward to previous song
Skip forward to next song
4 Slide to the left to scan backward
Slide to the right to scan forward
Song elapsed time
Total playback time of current song
5 Show all devices in the network
6 Repeat playback of current song
Repeat all songs in the playlist
Repeat o
7 Random playback
8 Scroll through thumbnail images of the playlist.
Select thumbnail image of desired song for immediate playback.
OPERATION
1
42 3
5
6
7
8
20
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ
