NAD T 515 User manual

NAD’s DVD Players are renowned for superb performance and great value. Unlike the “no name” players
sold as loss leaders by discount stores, NAD achieves picture quality that is impressive even on large format
TV’s and projectors where every minute imperfection is magnified. Whether your TV is analog or digital the
T515 is equipped to make the most of your TV’s performance offering both Component Video and HDMI
outputs.
If the picture is impressive, the sound quality can easily embarrass machines costing 3 and 4 times the
T515’s highly affordable price. Sonic performance on all audio formats easily rivals established performance
leaders. Whether you are listening to CD or DVD-A, or even MP3 and WMA files, bass is full and taught,
mids and highs are detailed and smooth, and the stereo image shows depth and scale. Over 30 years of
audio engineering excellence is both obvious and reassuring.
Features
The T515 is a very full-featured DVD player that offers a wide range of facilities such as Multi-Angle*,
Multi-Sound*, Multi-Subtitle*, Frame, 100x Zoom, Marker Search, Smooth Scan, Slow Motion, and Repeat.
Second time DVD buyers will really appreciate convenience features such as Auto-Play (skips the opening
warnings and advertisements and goes straight to the movie) and Last Scene Book Marking (picks up where
you left off if the viewing session is interrupted). All of these facilities can be easily accessed with the supplied
remote control.
With four video connection options and four audio connection options, complete compatibility with any Home
Theatre set-up is assured. Whether you simply want to add DVD to your current TV, or desire a complete
digital surround sound experience, the T515 is fully up to the task. Audio is available in two channel analogue,
Coax and Optical digital (SPDIF) and HDMI.
The T515 includes the latest type of connection, the High Definition Multimedia Interface (HDMI) with High
Definition Copy Protection (HDCP) to allow direct transmission of uncompressed HD video and audio in a
pure digital format. HDMI is not “just another connector” as it can transmit encrypted picture data at rates
up to 5 gbps – that’s 5 gigabytes per second! This very high speed demands precision in every aspect of
the signal path, including the connecting cable.
Standard 480i and 576i (480/576 lines interlaced picture) can be “upsampled” to resolutions as high as
1080i (1080 lines interlaced picture) thanks to the video processing chip. This allows you to make the most
of the high resolution capability of today’s HD projectors and flat panel displays. (The TV display must be
HDCP compatible to take advantage of this advanced feature.)
T 515 DVD/CD Player
• PlaysDVD-Video,DVD-R,DVD+-RW,VCD1.0,VCD2.0,
J-PEG,DivX
• PlaysDVD-Audio*†,CD,CD-R,CD-RW
• DolbyDigital/PCM/DTSdigitalout
• MP-3andWMAdecodersintegrated
(songtitlesdisplayedonvideooutput)
• CoaxialandOpticaldigitaloutputs
• AutoswitchfromPCMtoBitstream
• Audiophilequality24bit192kHzDACs
• 6x14bitVideoDACrunningat165MHz
• Progressivescanwithpixel-by-pixelprocessingforreduced
processingartifacts
• ComponentandCompositevideooutputs
• S-Videooutput(120Vonly),SCARToutput(230Vonly)
• HDMIoutput
• Videoupconversionto720pand1080i**(HDMIoutput)
• PALcompatible
• SceneBookmarking
• Zoom(X100),Marker,markerSearch
• SmoothScanandSlowMotion
• IRControlInput(rearpanel)
• NADDVD6RemoteControl
Features
Details
*ThesefeaturesneedtobesupportedbytheDVDsoftware.
†2-ChannelDVDAudio
**Theseresolutions(720p/1080i)needtobesupportedbythevideodisplay.

Most popular disc formats are supported by the T515, including
JPEG, as well as MP-3 and WMA (Windows Media Audio). DVD-R
recordable DVD format is fully supported. Other DVD recording
formats (DVD+R and DVD-RAM) may, or may not play properly,
depending on the specific recorder and blank disc used.
Performance
Audio performance is fully up to NAD’s high standards, and the
T515 is a superb music player for CD and two channel DVD-
Audio. With full support for CD-R and CD-RW formats the T515 is
right up to date. Even MP-3 and WMA files can be played back on
this versatile player, with one CD-R capable of up to 10 hours of
continuous music playback! Whichever audio format is chosen, the
signal will be processed and decoded with typical NAD precision.
The analogue output stages are fed from separate regulated
power supplies, and utilize audiophile quality parts to retain all the
dynamics and detail contained in the original recording.
Equal attention has been paid to the video performance capabilities:
Keeping signal paths short and direct to minimise any interference,
the 14 bit 165 MHz Video DACs are capable of reproducing the
finest of picture details, where black is truly black and with vivid
colours extremely faithful to the original.
The Component Video output (Y, Cr, Cb) sports Progressive Scan
to get the most out of the latest high-end digital video monitors
and projectors with significantly increased resolution when
compared to standard, interlaced video. For video displays without
Component Video input, the SCART (which supports RGB 230V
only) and S-Video connectors offer superior video performance.
Value
The NAD T515 brings NAD quality and performance to an
affordable price range. While this player is a natural partner to one
of NAD’s high performance AV Receivers, its superb performance
and exceptional value make it an outstanding choice in its own
right.
SPECIFICATIONS
Audio
Frequency Response CD Audio
Frequency Response DVD (96kHz)
Output Level
Signal/noise ratio, A-weighted
THD (at 0dB, 1kHz)
Wow and Flutter
Channel separation CD
Dynamic range
Number of discs
DVD Video
Signal to Noise
Signal System
4Hz to 20kHz
4Hz to 44kHz
2V rms
-100dB
0.005%
Quartz Accuracy
95dB
103dB
1
60dB
PAL/NTSC
Output
Digital Coaxial - PCM, DTS, MPEG, AC3
Digital Optical - PCM, DTS, MPEG, AC3
Composite Video
S-Video (North American 120 Volt Version only)
Component Video
HDMI
Remote Control
Physical Specifications
Dimensions (W x H x D)
Net Weight
Shipping Weight
0.5 p-p 75Ω, RCA x 1
3V p-p 75Ω
1v p-p 75Ω 1 x RCA
Y/C 4 pin x 1
RCA x 3 Y/Cb/Cr
SCART w/RGB
YES
NAD DVD-6
17 1/8 x 1 7/8 x 9 1/2”
(436 x 39 x 240mm)
5.0lbs (2.2kg)
7.0lbs (3.2kg)
