Namron ZIGBEE DIMMER TW 400W User manual

Function introduction
Important: Read All Instructions Prior to Installation
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.
Safety & Warnings
“Reset” Key: for
network pairing,
touchlink, factory
reset of the dimmer,
turn on/off load
Operation
AC 100-240V power input
Min.Set
LL NN
OUT
L
N
AC 100-240V
Load output
• ZigBee AC phase cut tunable white dimmer based on latest ZigBee 3.0 protocol
• 100-240VAC Wide Input and Output Voltage
• Mini size, easy to be Installed into a standard wall box
• 1 Channel Output, Up to 400W
• Input and Output with Screw Terminals, Safe and Reliable
• Can directly pair to a compatible ZigBee remote via Touchlink without coordinator
• Supports self-forming zigbee network without coordinator and add other devices to the network
• Supports resistive loads and capacitive loads
• Supports find and bind mode to bind a ZigBee remote
• Compatible with universal ZigBee gateway products
• Radio Frequency : 2.4GHz
• Both leading edge version and trailing edge version are available for choosing, default factory setting is trailing edge
• Enables to control color temperature, light intensity, ON/OFF of phase cut dimming tunable white LED drivers or lamps
• ZigBee end device that supports Touchlink commissioning
• Can be controlled by universal push switches
• Waterproof grade: IP20
• Supports zigbee green power and can bind max. 20 zigbee green power remotes
Reset
Input Voltage Output Voltage Output Current
Product Data
Size(LxWxH)
Compatible Load Types
Load Symbol Load Type Maximum Load Remarks
Due to variety of LED lamp
designs, maximum number
of LED lamps is further
dependent on power factor
result when connected to
dimmer.
Maximum permitted number
of drivers is 200W divided
by driver nameplate power
rating.
Dimmable LED lamps
Dimmable LED drivers
Incandescent lighting,
HV Halogen lamps
Low voltage halogen
lighting with electronic
transformers
100-240VAC 1.8A max 100-240VAC 45.5x45x20.3mm
100W @ 110V
200W @ 220V
200W @ 220V
100W @ 110V
200W @ 110V
400W @ 220V
100W @ 110V
200W @ 220V
1.Do wiring according to connection diagram correctly.
3. Zigbee Network Pairing through Coordinator or Hub (Added to a Zigbee Network)
Step 1: Remove the device from previous zigbee network if it has already been added to, otherwise pairing will
fail. Please refer to the part "Factory Reset Manually".
Step 2: From your ZigBee Controller or hub interface, choose to add lighting device and enter Pairing mode as
instructed by the controller.
Step 3: power on the device, it will be
set into network pairing mode
(connected light flashes twice slowly),
the network pairing mode will last until
the device is added to a zigbee
network.
Step 4: Connected light will blink 5
times and then stay solid on, then the
device will appear in your controller's
menu and can be controlled through
controller or hub interface.
Input Clusters
• 0x0000: Basic • 0x0003: Identify • 0x0004: Groups • 0x0005: Scenes
• 0x0006: On/off • 0x0008: Level Control • 0 x 0 3 0 0 : C o l o r C o n t r o l • 0x0b05: Diagnostics
Output Clusters
• 0x0019: OTA
ZigBee Clusters the device supports are as follows:
2.This ZigBee device is a wireless receiver that communicates with a variety of ZigBee compatible systems. This
receiver receives and is controlled by wireless radio signals from the compatible ZigBee system.
L
N
Allowed Inrush Current
Cold Start 75A max.
“Min. Set” Key:
1) to set or delete a minimum
dimming level
2) to set or delete a startup
brightness level
S1
COM
Push switch input
Min.Set
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM

4. TouchLink to a Zigbee Remote
5. Removed from a Zigbee Network through Coordinator or Hub Interface
From your ZigBee controller or hub
interface, choose to delete or reset the
lighting device as instructed. The
connected light blinks 3 times to indicate
successful reset.
commissioning immediately
under any circumstances,
which lasts for 180S, once
time out, repeat this step.
Method 2: Power on the
device, whether the device
has been added to a Zigbee
network or not, it will be set
into Touchlink commissioning
immediately, Touchlink will
last for 180S, once time out,
reset power of the device to
set it into touchlink
commissioning again.
Step 1: Method 1: Short press
“Reset” button 4 times (or
reset power of the device 4
times) to start Touchlink
Step 4: There shall be indication
on the remote for successful link
and connected light will flash
twice.
Zigbee
Remote < 10cm
Step 2: Bring the remote or touch
panel within 10cm of the lighting
device.
Step 3: Set the remote or touch
panel into Touchlink
commissioning,
please refer to corresponding
remote or touch panel manual to
learn how.
3) To control by both gateway & remote, add remote and device to network first then TouchLink.
Note: 1) Directly TouchLink (both not added to a ZigBee network), each device can link with 1 remote.
2) TouchLink after both added to a ZigBee network, each device can link with max. 30 remotes.
4) After TouchLink, the device can be controlled by the linked remotes.
6. Factory Reset Manually
Step 2: Connected light
will blink 3 times to
indicate successful reset.
Step 1: Short press “Reset.”
key for 5 times continuously
or reset power of the device
for 5 times continuously if
the “Reset” key is not
accessible.
Note: 1) If the device is already at factory
default setting, there is no indication when
factory reset again .
2) All configuration parameters will
be reset after the device is reset or
removed from the network.
7. Factory Reset through a Zigbee Remote (Touch Reset)
Note: Make sure the device already added to a network, the remote added to the same one or not added to any
network.
Step 1: Reset power of the
device to start TouchLink
Commissioning, 180
seconds timeout, repeat
this step.
Step 4: There shall be indication
on the remote and connected light
flashes 3 times for successful
reset.
Zigbee
Remote < 10cm
Step 2: Bring the remote or touch
panel within 10cm of the lighting
device.
Step 3: Set the remote or touch
panel into Touch Reset procedure
to reset the device, please refer to
corresponding remote or touch
panel manual to learn how.
8. Find and Bind Mode
Step 1: Short press “Reset.”
button 3 times (Or reset
power of the device (initiator
node) 3 times) to start Find
and Bind mode (connected
light flashes slowly) to find
and bind target node, 180
seconds timeout, repeat this
step.
Zigbee
Remote
Step 2: Set the remote or touch
panel (target node) into find
and bind mode, and enable it
to find and bind initiator, please
refer to corresponding remote
or touch panel manual.
Step 3: There shall be
indication on the remote or
touch panel that it bind the
device successfully and can
control it then.
Note: Make sure the device and remote already added to the same zigbee network.
9. Learning to a Zigbee Green Power Remote
Step 1: Short press “Reset.”
button 4 times (Or reset
power of the device 4 times)
to start Learning mode
(connected light flashes
twice), 180 seconds timeout,
repeat this step.
Zigbee
Green Power
Remote
Step 2: Set the green power
remote into Learning mode,
please refer to its manual.
Step 3: Connected light will
flash twice to indicate
successful learning. Then the
remote can control the device.
Note: Each device can learn to max. 20 zigbee green power remote.
L
N
L
N
L
N
L
N
L
N
Min.Set
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM
Min.Set
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM
Min.Set
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM
Min.Set
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM
Min.Set
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM

L
N
11. Setup a Zigbee Network & Add Other Devices to the Network (No Coordinator Required)
Step 1: Short press “Reset.”
button 4 times (Or reset
power of the device 4 times)
to enable the device to setup
a zigbee network (connected
light flashes twice) to
discover and add other
devices, 180 seconds
timeout, repeat this step.
Zigbee
Remote
Step 4: Bind the added devices and remotes through Touchlink so that the devices can be controlled by the
remotes, refer to their manuals.
Step 2: Set another device or remote or touch panel into network pairing mode and pair to the network, refer to
their manuals.
Step 3: Pair more devices and remotes to the network as you would like, refer to their manuals.
< 10cm
TouchLink
10. Delete Learning to a Zigbee Green Power Remote
Step 1: Short press “Reset.”
button 3 times (Or reset
power of the device 3 times)
to start delete Learning mode
(connected light flashes
slowly), 180 seconds timeout,
repeat this step.
Zigbee
Green Power
Remote
Step 2: Set the paired green
power remote into Learning
mode, please refer to its manual.
Step 3: Connected light will
flash 4 times to indicate
successful deleting.
Note: 1) Each added device can link and be controlled by max. 30 added remotes.
2) Each added remote can link and control max. 30 added devices.
12. OTA
The device supports firmware updating through OTA, and will acquire new firmware from zigbee controller or
hub every 10 minutes automatically.
13.Setting minimum brightness:
Adjust brightness to a desired level from zigbee hub or controller interface or a remote, then press and hold down “Min.
Set ” key until connected light flashes, the minimum dimming level is set successfully, then the connected load can only
be dimmable between this minimum brightness and 100% brightness.
The dimming range of this dimmer is 1%-100%, but some load types may flicker when dimmed to 1%, thus a
minimum brightness shall be set higher than 1% to avoid flickering during dimming process.
14.Delete the minimum brightness:
15.Set Startup Brightness
16.Delete Startup Brightness
• Press and hold down the button to increase or decrease light intensity to desired level and release it, then
• Double click the button to switch between brightness mode and color temperature mode.
Adjust the brightness to 100% from zigbee hub or controller interface or a remote, then press and hold down the “Min.
Set” key on the dimmer until connected light flashes, which means minimum brightness is deleted successfully.
Step 1: adjust the brightness of connected load to 0%.
• Click the button to switch ON/OFF
17.Controlled by a push switch:
Step 1: adjust the brightness of connected load to a desired level between 1%-50%.
Note: startup brightness setting function is to avoid the phenomenon that some dimmable LED drivers can not be turned
on after turned off at a very low brightness level. Once setting a startup brightness, if the startup brightness is higher than
the brightness before turned off, the driver will first go to the startup brightness after turned on then drop down to the
level before turned off. If the startup brightness is lower than the brightness before tured off, the driver will directly go to
the brightness before turned off.
Step 2: double click “Min. set” key to set the brightness adjusted in step 1 as startup brightness, then the load will first go
to startup brightness when turned on every time, then drop down to the brightness before last time turned off.
repeat the operation to adjust light intensity to opposite direction. The dimming range is from 1% to 100%.
• Press and hold down the button to change color temperature under color temperature mode.
Step 2: double click “Min. set” key to delete the previously set startup brightness.
Wiring diagram
Notes for the diagrams:
L - terminal for live lead
N - terminal for neutral lead
Out - output terminal of the dimmer (controlling connected light source)
S1 - terminal for push switch
COM - terminal for grounding to the switch connected to the dimmer
L
N
1) With Single Push Switch
PUSH
LED+
WW-
CW-
Phase Cut Dim ming
Tunable Whi te LED Driver
ACL
ACN
L
N
V+ LED+
WW WW-
Tunable W hite LED St rip
CW CW-
Min.S et
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM
Push HV Mode
Min.Set
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM
Min.Set
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM
Min.Set
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM

PUSH
LED+
WW-
CW-
Phase Cut Dim ming
Tunable Whi te LED Driver
ACL
ACN
L
Tunable W hite LED Li ght
Min.S et
LL NN
OUT
L
N
AC 100- 240V
Reset
S1
COM
N
PUSH
LED+
WW-
CW-
Phase Cut Dim ming
Tunable Whi te LED Driver
ACL
ACN
L
N
V+ LED+
WW WW-
Tunable W hite LED St rip
CW CW-
Min.S et
LL NN
OUT
L
N
AC 100- 240V
Reset
S1
COM
Push LV Mode
LED+
WW-
CW-
Phase Cut Dim ming
Tunable Whi te LED Driver
ACL
ACN
L
Tunable W hite LED Li ght
Min.S et
LL NN
OUT
L
N
AC 100- 240V
Reset
S1
COM
N
PUSH
1) The max. allowed inrush current of this dimmer is cold start 75A, when connecting LED drivers or LED
luminaries in parallel, please make sure that the total inrush current of the parallel connected drivers or
luminaries do not exceed the max. allowed inrush current of this dimmer.
2) The recommended number of parallel connected drivers or luminaries shall not be more than 10, otherwise
the dimmer may be damaged due to the high inrush current at the moment of starting.
Note:
2) With Multiple Push Switches for Multiple Control Points
PUSH
LED+
WW-
CW-
Phase Cut Dim ming
Tunable Whi te LED Driver
ACL
ACN
L
PUSH
V+ LED+
WW WW-
Tunable W hite LED St rip
CW CW-
Min.S et
LL NN
OUT
L
N
AC 100-240V
Reset
S1
COM
N
Push HV Mode

L
LED+
WW-
CW-
Phase Cut Dim ming
Tunable Whi te LED Driver
ACL
ACN
Tunable W hite LED Li ght
PUSH
PUSH
Min.S et
LL NN
OUT
L
N
AC 100- 240V
Reset
S1
COM
N
PUSH
LED+
WW-
CW-
Phase Cut Dim ming
Tunable Whi te LED Driver
ACL
ACN
L
PUSH
V+ LED+
WW WW-
Tunable W hite LED St rip
CW CW-
Min.S et
LL NN
OUT
L
N
AC 100- 240V
Reset
S1
COM
N
Push LV Mode
L
LED+
WW-
CW-
Phase Cut Dim ming
Tunable Whi te LED Driver
ACL
ACN
Tunable W hite LED Li ght
Min.S et
LL NN
OUT
L
N
AC 100- 240V
Reset
S1
COM
N
PUSH
PUSH
This phase dimmer adopts leading edge dimming (forward phase control) or trailing edge dimming (reverse
phase control), two versions are available for choosing, default factory setting is trailing edge, leading edge
version available upon request. Please make sure the connected loads support the control type you choose.
Please refer to the user manual of the load or consult the supplier of the load.
1) The max. allowed inrush current of this dimmer is cold start 75A, when connecting LED drivers or LED
luminaries in parallel, please make sure that the total inrush current of the parallel connected drivers or
luminaries do not exceed the max. allowed inrush current of this dimmer.
2) The recommended number of parallel connected drivers or luminaries shall not be more than 10, otherwise
the dimmer may be damaged due to the high inrush current at the moment of starting.
Note:
Product Dimension
45.5 mm
20.3 mm
45 mm
