NANLUX Evoke 900C User manual

Evoke 900C
LED RGBLAC Spot Light
USER MANUAL
Guangdong NanGuang Photo&Video Systems Co., Ltd.

WWW.NANLUX.COM 01
Thank you for purchasing Nanlux product-Eovke 900C!
Evoke 900C is a high power output, full color spot light with RGBLAC color mixing technology, owning fully adjustable color temperature ranging from 1800K-20000K
(G/M±200). It supports CCT, Advanced HSI, XY, RGBW, GEL and EFFECT lighting modes, and on board control, wire control, APP, DMX/RDM, LumenRadio CRMX
and Art-Net, sACN controlling modes. Besides, with IP55 rating, adjustable cooling system and various accessories, Evoke 900C can provide great performance and
versatile functions in virtual production or other professional projects.
1. Please do not look directly at the emitter when the light is on, to avoid eyes discomfort caused by high luminance.
2. Please do not place the fixture near any flammables and explosives, to avoid fire hazard caused by high luminance.
3. Please do not immerse the fixture in water. While with IP55 rating, the light fixture can be used in the rainy situations.
4. Please place the power cable and DC cable properly to avoid stumbled caused by long cables.
5. Please exchange the power cable if any damage is found, to avoid electric shock.
6. Please use the power cable and DC cable provided by the manufacturer as the power is high. Dangers like melting cable, electric shock or fire may happen if cables of
other brands are used.
7. Please do not block the vents when the fixture is on. The fixture is built with active cooling system, so ensure unimpeded vents to prevent the fixture from protection state
due to overheating.
8. Please do not disassemble the fixture to repair at will, so as not to cause damage to the fixture that contains precision electronic components. If repair is required, please
return to the distributor or have them repaired by any qualified technician.
9. Please switch the fixture off and unplug the cables before cleaning, to avoid electric shock.
10. Please do not use strong detergent for cleaning. Please wipe off the dirt by using a cloth with neutral cleanser when cleaning the fixture.
11. Please hold the handle securely when detaching the accessories or adjusting the beam directions, since the accessories such as Fresnel lens and softbox are heavy.
12. Please ensure that the power cable and DC cable are properly connected when using the fixture, to avoid sparking and heating of the plug.
Introduction
Notice

WWW.NANLUX.COM 02
Product Diagram
Evoke 900C LED RGBLAC Spot Light
Rated Power: 940W
Input: DC 48V/18.75A Max
AC 100-240V 50/60Hz
Color Temperature: 1800K-20000K (G/M±200)
CRI: Average 96
TLCI: Average 96
Technical Data

WWW.NANLUX.COM 03
4. Quick Release
Device
5. Lock Catch
7. Yoke
3. NL Mount
6. Eye Bolt
2. USB Port1. Wire Control
Socket
8. COB Protective Cap
Product Details

WWW.NANLUX.COM 04
16. Adjustable Handle
17. Right Knob
18. DMX IN
19. DMX OUT
20. DC IN
9. Display
10. Buttons
11. Left Knob
12. Middle Knob
13.LAN1
14.LAN2
15. Fixture Body Handle

WWW.NANLUX.COM 05
26. Reflector
24. DC Power
Output Socket
25. Quick Release
Plate
23. Power Switch
21. Power Supply Handle
22. AC Power Input Socket

WWW.NANLUX.COM 06
1. Wire control socket: Wire control interface.
2. USB port: For updating firmwares or providing current with maximum 5V/1A to external devices via connecting the USB cable.
3. NL mount: For installing the reflector or other NL mount accessories.
4. Quick release device: For quick installation and detachment of yoke.
5. Lock catch: To lock or release the reflector or other accessories. Note: Please pull in the direction indicated on it.
6. Eye bolt: For hanging safety rope.
7. Yoke: Mount the fixture on a stand, also for pan and tilt.
8. COB protective cap: For protection purpose, please cover the COB with the cap when the fixture is not in use.
(Note: Take off the cap before using.)
9. Display: To display data.
10. Buttons: Including MODE, MENU, PRESET and LOCK.
11. Left knob: For adjusting brightness.
12. Middle Knob: For adjusting settings for each option.
13. LAN 1: Network connecting port.
14. LAN 2: Network connecting port.
15. Fixture body handle: Offer convenient grip for adjusting direction of illumination.
16. Adjustable handle: Tighten or release the tilt movement of the fixture on the yoke.
17. Right knob: For selecting options.
18. DMX IN: DMX signal input interface.
19. DMX OUT: DMX signal output interface.
20. DC IN: DC power input interface.
21. Power supply handle: For lifting the power supply.
22. AC power input socket: For connecting AC cable and supplying power to power supply.
23. Power switch: To turn on/off the fixture.
24. DC power output socket: For connecting the fixture to the power supply with DC cable.
25. Quick release plate: For mounting the quick release clamp.
26. Reflector: For concentrating light to improve the central illumination.
Detailed Description

WWW.NANLUX.COM 07
USER MANUAL
Evoke 900C
LED RGBLAC Spot Light
Guangdong NanGuang Photo&Video Systems Co., Ltd.
Evoke 900C × 1 Power Supply × 1
AC Power Cable × 1
User Manual × 1
DC Connection Cable × 1
Remote Controller × 1
Includes
USB Flash Drive × 1
AS-CP-QR-EV × 1Reflector × 1Yoke × 1 CC-ST-EV900C Trolley Case × 1

WWW.NANLUX.COM 08
Evoke 900C × 1
Yoke × 1
Power Supply × 1
Reflector × 1
DC Connection Cable 7.5M × 1
AC Power Cable 6M × 1
AS-CP-QR-EV × 1
USB Flash Drive × 1
WS-RC-C2 Remote Controller × 1
User Manual × 1
Carton Packaging
Evoke 900C × 1
Yoke × 1
Power Supply × 1
Reflector × 1
DC Connection Cable 7.5M × 1
AC Power Cable 6M × 1
AS-CP-QR-EV × 1
FL-35YK Lens × 1
USB Flash Drive × 1
WS-RC-C2 Remote Controller × 1
User Manual × 1
CC-EV1200-FL-YK-FT Flight Case × 1
Evoke 900C FL-YK-KIT Flight Case Kit
Multi-light Kit

WWW.NANLUX.COM 09
Evoke 900C × 1
Yoke × 1
Power Supply × 1
Reflector × 1
DC Connection Cable 7.5M × 1
AC Power Cable 6M × 1
AS-CP-QR-EV × 1
USB Flash Drive × 1
WS-RC-C2 Remote Controller × 1
User Manual × 1
CC-EV1200-FT Flight Case × 1
Evoke 900C Flight Case Kit

WWW.NANLUX.COM 10
1. Connection Between Light Fixture and Power Supply
Usage

WWW.NANLUX.COM 11
2. Installation and Detachment of Yoke
Lay down the light fixture on flat ground, with its
bottom up.
Press the quick release lever lock catch to release the
lever, and push the lever aside.
Firmly hold the yoke in place with one hand, and pull
the quick release lever with the other hand to lock the
plate.
Align and insert the quick release plates to the mounts
on both sides of the fixture.
Note: Please adjust the plate to right directions when
installing the quick release plate, then insert
them into the mount.

WWW.NANLUX.COM 12
Mount the fixture on heavy-duty light stand and lock
the fastening screws on the light stand.
When disassembling the yoke, remove the fixture
from the heavy-duty light stand first and lay it down
on flat ground.
Press the quick release lever lock catch of the fixture
on both sides, then release the quick release lever to
remove the fixture.

WWW.NANLUX.COM 13
Installation of Yoke (Method Two)
Press the quick release lever lock catch and push
the lever aside, align and insert the quick-release
plate mounts to the plates of the yoke.
(Note: Please adjust the plate to right directions
when installing the quick release plate,
then insert them into the mount.)
Mount the yoke on heavy-duty light stand and lock
the fastening screws on the light stand.
Pull the levers on both sides of the fixture to lock the
quick release plate in place. The installation of the
yoke is completed.

WWW.NANLUX.COM 14
3. Installation and Detachment of Reflector
When installing the reflector, align the reflector’s bayonet lock to the light’s mount, rotate the reflector clockwise and fasten the reflector on the light.
(Note: if the rotation is not smooth, pull the lock catch of the mount and rotate the reflector at the same time.)
When removing the reflector, pull the lock catch of the mount, rotate the reflector anticlockwise and remove.

WWW.NANLUX.COM 15
4. AS-CP-QR-EV Evoke Quick Release Clamp Installation
Rotate the adjustable handle to release the clamp.
Align the quick release plate on the power supply with the quick release mount
on the clamp, a click sound will be heard when the power supply is fastened in
place.
Mount the quick release clamp on the light stand, then rotate the adjustable handle
to tighten the clamp.
Press the lock catch on the clamp to remove the power supply from the light stand.

WWW.NANLUX.COM 16
MENU
CH: 512
SMART
ADDRESS/DMX
WIRELESS CONTROL
NETWORK SETTINGS
Art-Net & sACN SETTINGS
FAN CONTROL
ROTATE SCREEN
Rotate the "right knob” to ADDRESS/DMX, and press the ''right knob'' to enter the secondary menu.
Remote Control
· Evoke 900C supports remote control via DMX/RDM, 2.4G, LumenRadio, Art-Net & sACN, and includes a built-in Bluetooth module as well.
▲The ADDRESS needs to be set before operating the remote control via DMX/RDM, 2.4G, LumenRadio, Art-Net & sACN.
1.1 ADDRESS
Press MENU button to enter the interface.
1. ADDRESS/DMX, including ADDRESS, DMX MODE, DMX REDUCED CHANNELS, DMX DIMMING CURVE and DMX SMOOTHING settings.
middle knob right knobleft knob
MODE MENU PRESET LOCK
MENU
CH: 512
SMART
ADDRESS/DMX
WIRELESS CONTROL
NETWORK SETTINGS
Art-Net & sACN SETTINGS
FAN CONTROL
ROTATE SCREEN
MENU
CH: 512
SMART
ADDRESS
DMX MODE
DMX REDUCED CHANNELS
DMX DIMMING CURVE
DMX SMOOTHING
PRESS “MENU” TO RETURN

WWW.NANLUX.COM 17
SET
MENU
CH: 512
SMART
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
ADDRESS
DMX MODE
DMX REDUCED CHANNELS
DMX DIMMING CURVE
DMX SMOOTHING
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
CCT & RGBW 8bit
CCT & RGBW 16bit
CCT & RGBLAC 8bit
CCT & RGBLAC 16bit
CCT & Adv.HSI 8bit
CCT & Adv.HSI 16bit
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
ADDRESS
DMX MODE
DMX REDUCED CHANNELS
DMX DIMMING CURVE
DMX SMOOTHING
PRESS “MENU” TO RETURN
1.2 DMX MODE
Rotate the ''right knob'' to ADDRESS, and press the ''right knob'' to enter the tertiary menu.
Rotate the ''right knob'' to select address number and press the ''right knob'' to set.
NOTE: Evoke 900C has 25 channels, for multiple lights remote control via DMX/RDM and LumenRadio, the address of the first light should be set in 001, the second
one in 023, the third one in 045, and so on.
Rotate the ''right knob'' to DMX MODE and press the ''right knob'' to enter the tertiary menu.
ADDRESS
512
MENU
CH: 512
SMART
PRESS “MENU” TO RETURN
ADDRESS
512
MENU
CH: 512
SMART
PRESS “MENU” TO RETURN

WWW.NANLUX.COM 18
SET
MENU
CH: 512
SMART
PRESS “MENU” TO RETURN
SET
MENU
CH: 512
SMART
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
OFF
ON
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
OFF
ON
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
CCT & RGBW 8bit
CCT & RGBW 16bit
CCT & RGBLAC 8bit
CCT & RGBLAC 16bit
CCT & Adv.HSI 8bit
CCT & Adv.HSI 16bit
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
ADDRESS
DMX MODE
DMX REDUCED CHANNELS
DMX DIMMING CURVE
DMX SMOOTHING
PRESS “MENU” TO RETURN
Rotate the ''right knob'' to select the needed DMX mode, and press the "right knob" to set.
1.3 DMX REDUCED CHANNELS
Rotate the ''right knob'' to select ON or OFF and press the ''right knob'' to set.
Rotate the ''right knob'' to DMX REDUCED CHANNELS, and press the ''right knob'' to enter the tertiary menu.

WWW.NANLUX.COM 19
SET
MENU
CH: 512
SMART
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
LINEAR
EXPONENT
LOGARITHM
S CURVE
GAMMA 2.2
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
LINEAR
EXPONENT
LOGARITHM
S CURVE
GAMMA 2.2
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
OFF
ON
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
ADDRESS
DMX MODE
DMX REDUCED CHANNELS
DMX DIMMING CURVE
DMX SMOOTHING
PRESS “MENU” TO RETURN
MENU
CH: 512
SMART
ADDRESS
DMX MODE
DMX REDUCED CHANNELS
DMX DIMMING CURVE
DMX SMOOTHING
PRESS “MENU” TO RETURN
1.5 DMX SMOOTHING
Rotate the ''right knob'' to DMX SMOOTHING and press the ''right knob'' to enter the tertiary menu.
1.4 DMX DIMMING CURVE
Rotate the “right knob” to select LINEAR, EXPONENT, LOGARITHM, S CURVE or GAMMA 2.2, and press the “right knob” to set.
Rotate the ''right knob'' to DMX DIMMING CURVE, and press the ''right knob'' to enter the tertiary menu.
