Napoleon Gourmet Grills BIPT450 Manual

BUILT-IN UNIT INSTRUCTION GUIDE
N415-0175 / JAN 02/08
Please use this manual in conjunction with your main manual to properly assemble your built-in grill. Refer to
the main manual for operating, cleaning, and maintenance instructions. This grill is designed for NON-COM-
BUSTIBLE enclosures only, and must be installed and serviced by a qualified installer to local codes.
BUILT IN PROPANE GAS HOOK-UP: The piping up to the gas grill is the responsibility of the installer and piping should be located as
shown in the built-in instructions. Do not use hose to connect the unit. It must be connected with either rigid pipe, copper tube or an
approved flexible metal connector. The installation must comply with CAN B149.1 Natural Gas and Propane installation code in
Canada, or to the National Fuel Gas code, ANSI Z223.1 in the United States. The minimum recommended piping size is NPS 1/2"
for rigid pipe, and 1/2" OD for copper tubing (based on a 20 ft run). Longer runs may require larger sizes to conform with local codes
or to conform with CAN B149.1. Propane Gas Installation Code in Canada or to the National Fuel Gas Code, ANSI Z223.1 in the
United States. The gas supply must be connected to the 3/8” flare elbow fitting located under the right hand side of the control panel.
If installing a side burner, a separate line must be branched off to the side burner unit and enter the side burner opening at the
specified location. If the enclosure is to house a propane cylinder, the tank portion of the enclosure must be ventilated according to
local codes, and must not have communication with the cavity used to enclose the gas grill. A propane tank can not be stored below
the gas grill.
BUILT IN NATURAL GAS HOOK-UP: The piping up to the gas grill is the responsibility of the installer and piping should be located as
shown in the built-in instructions. Do not use hose to connect the unit. It must be connected with either rigid pipe, copper tube or an
approved flexible metal connector. The installation must comply with CAN B149.1 Natural Gas and Propane Installation Code in
Canada, or to the National Fuel Gas Code, ANSI Z223.1 in the United States. The minimum recommended piping size is NPS 1/2"
for rigid pipe, and 5/8" OD for copper tubing (based on a 20 ft run). Longer runs may require larger sizes to conform with local codes
or to conform with CAN B149.1. Natural Gas Installation Code in Canada or to the National Fuel Gas Code, ANSI Z223.1 in the
United States.
Built in units are supplied with a drip pan which holds only a minimal amount of grease. To prevent grease fires, the pan must
be cleaned after each use.
SERIAL #______________________
DANGER: READ ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING GRILL. FAILURE TO FOLLOW
THESE INSTRUCTIONS EXACTLY COULD RESULT IN A FIRE CAUSING SERIOUS INJURY OR DEATH.

BIPT450 29 1/2” 20 5/8” 8 7/8”
BIPT600 37 3/4” 20 5/8” 8 7/8”
BIPT750 49 3/4” 20 5/8” 9 5/8”
BIU405 271/2” 16 3/4” 12”
SIDE BURNER 13 1/2” 17 1/2” 4”
Access must be provided for drip tray removal and cleaning.
Opening of at least 5 sq in must be provided for combustion air for side burner.
W DH
NOTES
MODEL OPENING DIMENSIONS
H
2”
34”
RECOMMENDED
W
D
H
W
D
3” MIN.
6”
7”
H
W
D
1¾”
1¾”
4”
OUTDOOR GFI ELECTRICAL
OUTLET RECOMMENDED -
LOCATE ON LEFT SIDE OF
GRILL FOR ROTISSERIE
USE.
MINIMUM 10 SQ IN OF
VENTILATION REQUIRED
ON EACH END OF CABINET
BIPT450 / BIPT600 / BIPT750
BUILT-IN GRILL HEADS
BIU405 BUILT-IN
GRILL HEADS
GAS INLET
OPENING
GAS INLET
OPENING
GAS INLET
OPENING
BUILT-IN UNIT OPENING DIMENSIONS BUILT-IN
SIDEBURNER
NON-COMBUSTIBLE MATERIAL
CABINET FRAME AND CABINET MUST BE
MADE FROM NON-COMBUSTIBLE MATERIAL

H
W
D
NOTE: ACCESSORY FRAMES OVERLAP
OPENING BY 1 ½” ON ALL 4 SIDES
Part # Description Picture
WH
N370-0070 Flat horizontal painted door
N370-0357SS
N370-0358SS
13 ¼” 18 ¼”
OPENING DIMENSION
N370-0356SS Curved stainless steel door - 308 size
N370-0072 Flat horizontal stainless steel door
N370-0069 Flat vertical painted door
N370-0071 Flat vertical stainless steel door
Curved stainless steel door - 450 size
Curved stainless steel double door - 600/750 size
N370-0361 PF style stainless steel door
N370-0359 PF style stainless steel single drawer
N370-0360 PF style stainless steel triple drawer
13 ¼” 18 ¼”
18 ¼” 13 ¼”
18 ¼” 13 ¼”
22 ½” 19 ¾”
27” 19 ¾”
17” 23 ¼”
17 ¼” 6 ¾”
17 ¼” 22 ¾”
BUILT-IN ACCESSORY OPENING DIMENSIONS
35 ¼” 19”
23”
23”
D

1. BIPT450 BUILT-IN INSTRUCTIONS
This grill is designed for MASONRY, NON-COMBUSTIBLE enclosures only, and must be installed and serviced by a qualified installer
to local codes.
1. Attach side mounting brackets to each side of the grill using #14 x 1/2" screws (n570-0026).
2. Lay the rear trim piece across the back of the opening. To keep it in place, a dab of silicone may be applied to each wing of the
rear trim.
3. Lower the unit in place, and connect the gas supply line to the fitting at the end of the manifold.
4.The entire installation must be leak tested before operating the unit.
N010-0568
N715-0080
N080-0213
N080-0213
N570-0026

2. BIPT600 BUILT-IN INSTRUCTIONS
This grill is designed for MASONRY, NON-COMBUSTIBLE enclosures only, and must be installed and serviced by a qualified installer
to local codes.
1. Attach side mounting brackets to each side of the grill using #14 x 1/2" screws (n570-0026).
2. Lay the rear trim piece across the back of the opening. To keep it in place, a dab of silicone may be applied to each wing of the
rear trim.
3. Lower the unit in place, and connect the gas supply line to the fitting at the end of the manifold.
4.The entire installation must be leak tested before operating the unit.
N080-0213
N715-0081
N010-0569
N080-0213
N570-0026
N380-0009
N051-0001

3. BIPT750 BUILT-IN INSTRUCTIONS
This grill is designed for MASONRY, NON-COMBUSTIBLE enclosures only, and must be installed and serviced by a qualified installer
to local codes.
1. Attach side mounting brackets to each side of the grill using #14 x 1/2" screws (n570-0026).
2. Lay the rear trim piece across the back of the opening. To keep it in place, a dab of silicone may be applied to each wing of the
rear trim.
3. Lower the unit in place, and connect the gas supply line to the fitting at the end of the manifold.
4.The entire installation must be leak tested before operating the unit.
N715-0082
N010-0570
N080-0213 N570-0026
N380-0009
N051-0001
N080-0213

4. BIU405 BUILT-IN INSTRUCTIONS
N080-0215
N570-0026
N080-0215
N570-0026
N715-0083
N080-0155
N080-0155
23 ec-c
This grill is designed for MASONRY, NON-COMBUSTIBLE enclosures only, and must be installed and serviced by a qualified installer
to local codes. Access must be provided in the enclosure for drip tray removal and cleaning.
1. Attach the side mounting brackets and the rear trim to the unit using #14 x 1/2” screws (n570-0026). The wings on the rear trim
should be under the side mounting brackets.
2. Attach the supplied brackets flush with the front of the opening as per the dimensions in the above drawing (fasteners not in-
cluded).
3. Lower the unit in place ensuring the brackets installed in the previous step engage between the control panel and the base
bracket. Connect the supply line to the fitting at the end of the manifold.
4. The entire installation must be leak tested before operating the unit.
N570-0026

1. Fit the side burner frame into the opening. The frame should be attached to the opening to prevent any future movement (fasten-
ers not included).
2. Ensure that there is at least 5 sq in of opening in the bottom of the cut out, for combustion air.
3. Set the side burner into the frame.
4. Connect the gas supply to the side burner valve. Leak test the entire installation before operating the unit.
5. BUILT-IN SIDE BURNER INSTRUCTIONS
N280-0003P (BLACK)
N280-0004 (STN STL)

6. BUILT-IN ACCESSORY DRAWER INSTRUCTIONS
7. BUILT-IN ACCESSORY DOOR INSTRUCTIONS
1. Unpack the drawer frame assembly.
2. Remove the drawers from the enclosure by fully extending them and then lifting up to remove them from the slides.
3. Shim the opening to ensure that the enclosure fits snuggly into the opening. Ensure that the side shims are located at
the same height as the enclosure mounting holes. The bottom of the opening may need to be shimmed as well to ensure
that the front of the enclosure is plumb.
4. Once the enclosure is level and square, fasten into place. (Fasteners not included).
5. Re-install the drawers by tipping the back of the drawer down into the slide. Once the wheels are inserted into the slide,
lower the front of the drawer until it is level, then push in. Note: if the enclosure is installed with shims that are too thick, the
wheel will not engage into the slide. The shim thickness will need to be reduced.
6. Remove the protective coating from all remaining surfaces.
1. Unpack the door and frame.
a. For the curved stainless steel doors, remove the door(s) from the frame by lifting the door while holding on to the pivot
rod. This will allow the pivot rod to come out of the hole on the bottom of the frame. Once the pivot is removed from the
bottom hole, the entire door can be dropped and removed from the frame.
b. For the PF style stainless steel door, the door needs to be removed by loosening the center philips screw on the hinge
furthest away from the door. This will allow the hinge to separate.
2. Center the frame in the opening. Mark the location of the pivot holes, top and bottom. Remember on the PT600 double
doors, there will be a pivot rod on both ends. The PF style doors do not have pivot rods. Once all pivot holes are marked,
remove the frame and using a 3/8” drill bit, drill out the clearance holes for the pivot rod. These clearance holes should be
at least 1/2” deep. After the holes are complete, you may once again center the frame in the opening. Starting with the
hinged side, shim between the frame and side wall of the opening. Ensure the shims are close to the hinge on the PF style
doors. When the frame side wall is plumb, fasten it to the cabinet with screws (not provided). Attach the other side of the
frame in the same fashion, ensuring the frame is square.
3. Other than on the curved stainless steel double door kit, fasteners are not required on the top and bottom of the frame.
The curved stainless steel double door frame must be fastened in the center both at the top and bottom.
4. Once the frame has been secured and checked for squareness, the door can be re-installed.
5. Remove the protective coating from all remaining surfaces.

SERIAL #______________________
GUIDE D’INSTRUCTIONS POUR LES GRILS ENCASTRÉS
Veuillez utiliser ce guide conjointement avec votre manuel principal pour assembler votre gril encastré de
façon adéquate. Référez-vous au manuel principal pour connaître les instructions de fonctionnement, de
nettoyage et d’entretien. Ce gril est conçu pour des cabinets INCOMBUSTIBLES seulement et doit être installé
et entretenu par un installateur qualifié selon les codes locaux.
Les grils encastrés sont munis d’un plateau d’égouttement qui ne peut contenir qu’une petite quantité de graisse. Afin d’éviter
les feux de graisse, le plateau doit être nettoyé après chaque utilisation.
BRANCHEMENT DU PROPANE AU GRIL ENCASTRÉ: La tuyauterie jusqu’au gril à gaz est la responsabilité de l’installateur et doit
être positionnée comme illustré dans le manuel d’instructions du gril encastré. N’utilisez pas de boyau pour brancher l’appareil.
Il doit être branché avec un tuyau rigide, un tuyau de cuivre ou un raccord flexible métallique approuvé. L’installation doit se
conformer au Code d’installation du gaz naturel et du propane CAN B149.1 au Canada ou au National Fuel Gaz Code ANSI
Z223.1 aux États-Unis. La grosseur minimale recommandée des tuyaux est de 1/2" NPS pour les tuyaux rigides et de 1/2" OD
pour les tuyaux de cuivre (d’après une course de 20 pi). Les courses plus longues pourraient nécessiter des diamètres plus
grands afin de se conformer aux codes locaux ou au Code d’installation du propane CAN B149.1 au Canada ou au National Fuel
Gaz Code ANSI Z223.1 aux États-Unis. L’arrivée de gaz doit être branchée au raccord coudé évasé de 3/8" situé sous le côté droit
du panneau de contrôle. Si vous installez un brûleur latéral, une conduite séparée doit être embranchée au brûleur latéral en
entrant par l’ouverture du brûleur latéral à l’emplacement indiqué. Si le cabinet doit servir de rangement pour le réservoir de
propane, la partie du cabinet servant de rangement au réservoir doit être ventilée selon les codes locaux et ne doit pas
communiquer avec la partie servant à encastrer le gril. Un réservoir de propane ne peut pas être rangé sous le gril.
BRANCHEMENT DU GRIL ENCASTRÉ AU GAZ NATUREL: La tuyauterie jusqu’au gril à gaz est la responsabilité de l’installateur et
doit être positionnée comme illustré dans le manuel d’instructions du gril encastré. N’utilisez pas de boyau pour brancher
l’appareil. Il doit être branché avec un tuyau rigide, un tuyau de cuivre ou un raccord flexible métallique approuvé. L’installation doit
se conformer au Code d’installation du gaz naturel et du propane CAN B149.1 au Canada ou au National Fuel Gaz Code ANSI
Z223.1 aux États-Unis. La grosseur minimale recommandée des tuyaux est de 1/2" NPS pour les tuyaux rigides et de 5/8" OD
pour les tuyaux de cuivre (d’après une course de 20 pi). Les courses plus longues pourraient nécessiter des diamètres plus
grands afin de se conformer aux codes locaux ou au Code d’installation du gaz naturel CAN B149.1 au Canada ou au National
Fuel Gaz Code ANSI Z223.1 aux États-Unis.
DANGER : LISEZ ATTENTIVEMENT TOUTES LES INSTRUCTIONSAVANT DE FAIRE FONCTIONNER LE GRIL. SI CES INSTRUC-
TIONS NE SONT PAS SUIVIES À LA LETTRE, UN INCENDIE POURRAIT S’ENSUIVRE, CAUSANT DES BLESSURES GRAVES OU
LA MORT.
