Napoleon MIRAGE 605 User manual

WARNING
Do not try to light this appliance without
reading the “LIGHTING” instrucons secon of
this manual.
Do not store or use gasoline or other am mable
liquids or vapors in the vicinity of this or any
other appliance. An L.P. cylinder not connect ed
for use must not be stored in the vicinity of
this or any other appliance. If the informaon
in these instrucons is not followed exactly, a
re or explosion may result, causing property
damage, personal injury or death.
DANGER
IF YOU SMELL GAS:
• Shut o gas to the appliance.
• Exnguish any open ame.
• Open lid.
• If odor connues, keep away from the
appliance and immediately call your gas
supplier or re department.
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
MIRAGE 605
Noce to Installer: Leave these instrucons with the grill owner for future reference.
This gas grill must be used only outdoors in a well-venlated space and must not be used inside a
building, garage, screened-in porch, gazebo or any other enclosed area.
Napoleon Appliance Corp.,
214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Phone: [phone]
Fax: [phone] email: [e-mail] web site: www.napoleongrills.com


2

THANK YOU FOR CHOOSING NAPOLEON











Condions And Limitaons


























Napoleon Gas Grill President’s Limited Warranty











 




3

WARNING! Failure to follow these instrucons could result in property damage, personal injury or
death. Read and follow all warnings and instrucons in this manual prior to operang grill.
Safe Operang Pracces
 


 
 
 
 

 
 
 
 
 

 

 
 
 
 


 

 
 
 
 

 
 
 
 
 
 
 
 
 
 
  
 
 
 
 

 

 



4

Gas Cylinder



 
 
 




WARNING! Ensure that the hose is routed to maintain proper clearance to the underside of the unit.
Hoses that contact high temperature surfaces may melt and leak, causing a re.
Cylinder Connecon 
 Leak test all joints prior to using the barbecue. 

WARNING!
 
 
 
 

 
 

Gas Hose
 

 

 
 
 
 

5

Leak Tesng Instrucons
WARNING! A leak test must be performed annually and each me a cylinder is hooked up or if a part
of the gas system is replaced.
WARNING! Never use an open ame to check for gas leaks. Be certain no sparks or open ames are
in the area while you check for leaks. Sparks or open ames will result in a re or explosion, damage to
property, serious bodily injury, or death.
Leak tesng


Brush a half-and-half soluon of liquid soap and water onto all joints and connecons of the regulator,
hose, manifolds and valves.
Bubbles will indicate a gas leak. Either ghten the loose joint or have the part replaced with one recommended
by the Napoleon Customer Care department and have the grill inspected by a cered gas installer.
If the leak cannot be stopped, immediately shut o the gas supply, disconnect it, and have the grill inspected
by a cered gas installer or dealer. Do not use the grill unl the leak has been corrected.
Technical Data

       
          
        
         
         



 
 

   
   
 





 





6

Lights Le Burner
Side Burner
Right Burner
Centre Burner
Lighng Instrucons
O Posion
Rear Burner Infra Red Burner
WARNING! Open lid.
WARNING! Ensure all burner controls are in the o posion. Turn on the gas supply valve.






  







 














































WARNING! Do not use the rear burner (rosserie burner) with the main burners operang.

7

Operang The Grill
Inial Lighng


Main Burner Use







Your All Season Grill
Direct Cooking



Indirect Cooking




Side Burner Use (if equipped)


WARNING! Never grill food directly on the side burner grate. It is designed for use with pots and pans
only.
Infrared Main Burner Use (If Equipped)




CAUTION! Due to the intense heat the infrared burners provide, food le unaended over burners
will burn quickly. Keep the lid open when cooking with the infrared burners set to high. The intense heat
ensures adequate searing temperatures even with the lid open. This also allows observaon of the food to
prevent burning.
Rear Burner Use (If Equipped)












WARNING! Barbecue sauce and salt can be corrosive and will cause rapid deterioraon of the gas grill
components unless cleaned regularly. When nished cooking disassemble rosserie components, wash
thoroughly with warm soapy water and store indoors.

8

Infrared Heat















 







Infrared Grilling Chart
   




























 

 








   


 






 

 


   


9

Maintenance / Cleaning Instrucons
Note








WARNING! Always wear protecve gloves and safety glasses when cleaning your grill.
WARNING! Turn o the gas at the source and disconnect the unit before servicing. To avoid the pos sibility
of burns, maintenance should be done only when the grill is cool. A leak test must be performed annually
and whenever any component of the gas train is replaced or gas smell is present.
WARNING! Always wear protecve gloves and safety glasses when servicing your grill.
WARNING! To avoid the possibility of burns, maintenance should be done only when the grill is cool.
Avoid unprotected contact with hot surfaces. Ensure all burners are turned o. Clean grill in an area where
cleaning soluons will not harm decks, lawns, or paos. Do not use oven cleaner to clean any part of this
gas grill. Do not use a self-cleaning oven to clean cooking grids or any other parts of the gas grill. Barbecue
sauce and salt can be corrosive and will cause rapid deterioraon of the gas grill components unless
cleaned regularly.
Grids And Warming Rack


Control Panel



Cleaning Inside The Gas Grill



Drip Pan






Cleaning The Outer Grill Surface:  






WARNING! Hose: Check for abrasions, melng, cuts, and cracks in the hose. If any of these condions
exist, do not use the gas grill. Have the part replaced by your Napoleon Gas Grill dealer or qualied gas
installer.

10

Tube Burner

CAUTION! Beware of Spiders.
 







 




Reinstallaon

WARNING! When reinstalling the burner aer cleaning it is very important
that the valve/orice enters the burner tube before lighng your gas grill. If the
valve is not inside the burner tube a re or explosion could occur.
Protecon Of Infrared Burners



 






 
 
 








REPLACEMENT SCREEN N565-0002
Infrared Burners




11

Troubleshoong
Problem Possible Causes Soluon




































  





 



 






































12

KEEP YOUR RECEIPT AS PROOF OF PURCHASE TO VALIDATE YOUR WARRANTY.
Ordering Replacement Parts
Warranty Informaon




 




 
 
 
 



 
 
 
 

  
  
  
  
  

13

CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses
for your protecon. Although we make every eort to make the assembly process as problem free and
safe as possible, it is characterisc of fabricated steel parts that the edges and corners might be sharp and
could cause cuts if handled incorrectly.
Geng Started
 

 
 

 

 
 
If you have any quesons about assembly or grill operaon, or if there are damaged or missing parts please
call our Customer Care Department at 1-866-820-8686 between 9 AM and 5 PM (Eastern Standard Time).







TOOLS REQUIRED FOR ASSEMBLY (tools not included)

14

2. Caster/Bracket Installaon


1. Magnet and Bushing Installaon

2 X N430-0002
16 X N570-0073 (1/4-20 X 3/8”) 3/8”(10mm) 7/16”(11mm)
16 X N450-0027 (1/4-20)
2 X N105-0011
non relvolving caster- le side

15

4 x N570-0080 (#14 x 1/2”) 3/8”(10mm)
3. Le and Right Cart Panel Installaon



16

6 x N570-0080 (#14 x 1/2”) 3/8”(10mm)
4. Rear Cart Panel Installaon


5. Condiment Basket


6. Front Cabinet Support Installaon



7. Propane Tank Heat Shield Installaon


17

2 x N570-0080 (#14 x 1/2”)
3/8”(10mm)
8 x N570-0080 (#14 x 1/2”) 2 X N430-0002
6. Front Cabinet Support Installaon



3/8”(10mm)
7. Propane Tank Heat Shield Installaon


18

4 x N570-0073 (1/4-20 X 3/8”) 3/8”(10mm)
8. Grill Head Installaon
PROPANE ONLY 





Two people are required for this step.
Incorrect Assembly
Correct Assembly

19

3/8”(10mm)
2 x N570-0073 (1/4-20 X 3/8”)
9. Baery Pack / Rosserie Mount Installaon




20

3/8”(10mm)
10 x N570-0073 (1/4-20 X 3/8”)
Bend tabs on front of shelf up
with a at head screw driver,
insert screw through tab and
into end cap.
Tabs located on either side of ice bucket
must engage notches in side shelf.
10. Assembling End Caps to Side Shelf / Side Burner

11. Side Shelf Installaon


12. Side Burner Installaon



