INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CGA 2.22, AND ANSI Z21.50 RESPECTIVELY FOR VENTED GAS FIREPLACES.
MILLIVOLT SYSTEM
INSTALLATION AND OPERATION INSTRUCTIONS FOR
VENTED GAS FIREPLACE - GB20
NATURAL GAS MODEL GB20-N
PROPANE GAS MODEL GB20-P
CERTIFIEDFORCANADA AND UNITEDSTATES USINGANSI / AGA/CGA METHODS
WARNING: If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• Ifyoucannotreachyourgassupplier,call
the fire department.
Installation and service must be performed by a qualified installer, service agency or the
gas supplier.

2
WS-415-137/05.15.00
TABLE of CONTENTS
PG 2-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5 VENTING
Vent Safety Switch
Venting Action Check
6 INSTALLATION
Gas Installation
Framing
7 FINISHING
Log Placement
Door, Hood, & Louvre Removal & Installation
PG8 OPTIONAL BLOWER INSTALLATION
9 OPTIONAL FAN INSTALLATION
OPTIONAL THERMOSTATIC SENSOR
10-11 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
11 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustment
12-13 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Accessories
14-15 TROUBLE SHOOTING GUIDE
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
WARNING
•Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should
stay away to avoid burns or clothing ignition. Supervise young children when they are in the same room as
thefireplace.
• Dueto hightemperatures,the fireplaceshouldbe locatedoutof trafficandaway fromfurnitureand draper-
ies.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the
fireplace and venting system are kept clean. The fireplace and its venting system should be inspected
beforeuse and atleastannually byaqualifiedservice person.Morefrequent cleaning mayberequired due
to excessive lint from carpeting, bedding material, etc. The fireplace area must be kept clear and free from
combustible materials, gasoline and other flammable vapours and liquids.
• Under no circumstances should this fireplace be modified.
• Thisfireplacemustnotbeconnectedtoachimney fluepipeservinga separatesolid fuelburningappliance.
• Donotusethis fireplaceif anyparthasbeen underwater.Immediatelycall aqualifiedservicetechnicianto
inspect the fireplace and to replace any part of the control system and any gas control which has been
underwater.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the glass
should be done by a licensed or qualified service person. Use only with a glass door certified with the
fireplace.
• Do not strike or slam shut the fireplace glass door.

3
WS-415-137/05.15.00
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO9002 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen
who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test
station. The complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that
you, the customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your new NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON gas fireplace aregas fireplace are
gas fireplace aregas fireplace are
gas fireplace are
warranted against defects for as long as you own the fireplace. This covers: combustionwarranted against defects for as long as you own the fireplace. This covers: combustion
warranted against defects for as long as you own the fireplace. This covers: combustionwarranted against defects for as long as you own the fireplace. This covers: combustion
warranted against defects for as long as you own the fireplace. This covers: combustion
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glasschamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glasschamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
chamber, heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
(thermal breakage only), gold plated parts against tarnishing, porcelainized enamelled com-
ponents and aluminum extrusion trims.ponents and aluminum extrusion trims.
ponents and aluminum extrusion trims.ponents and aluminum extrusion trims.
ponents and aluminum extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
covered andcovered and
covered andcovered and
covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON will provide replacement parts free of charge during the first yearwill provide replacement parts free of charge during the first year
will provide replacement parts free of charge during the first yearwill provide replacement parts free of charge during the first year
will provide replacement parts free of charge during the first year
of the limited warranty.of the limited warranty.
of the limited warranty.of the limited warranty.
of the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. RepairLabour related to warranty repair is covered free of charge during the first year. Repair
Labour related to warranty repair is covered free of charge during the first year. Repair
work, however, requires the prior approval of an authorized company official. Labour costswork, however, requires the prior approval of an authorized company official. Labour costs
work, however, requires the prior approval of an authorized company official. Labour costswork, however, requires the prior approval of an authorized company official. Labour costs
work, however, requires the prior approval of an authorized company official. Labour costs
to the account ofto the account of
to the account ofto the account of
to the account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on a predetermined rate schedule and any repairare based on a predetermined rate schedule and any repair
are based on a predetermined rate schedule and any repairare based on a predetermined rate schedule and any repair
are based on a predetermined rate schedule and any repair
work must be done through an authorizedwork must be done through an authorized
work must be done through an authorizedwork must be done through an authorized
work must be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEONwarrants itsproducts against manufacturingdefects to theoriginal purchaseronly-- i.e.,the individual orlegal entity(registered customer)whosename appearson the
warrantyregistrationcard filed withNAPOLEON--provided thatthepurchasewasmade through anauthorizedNAPOLEON dealer andissubjecttothe following conditionsandlimitations:
Thisfactorywarranty is nontransferableandmaynot be extendedwhatsoeverbyanyof our representatives.
Thegas fireplace mustbeinstalled byalicenced, authorized servicetechnicianor contractor.Installationmust be doneinaccordance with theinstallationinstructions includedwiththe
productand alllocal and nationalbuilding and firecodes.
Thislimited warranty doesnotcoverdamages caused bymisuse,lackof maintenance, accident,alterations,abuseor neglectandpartsinstalled from othermanufacturerswillnullify this
warranty.
Thislimited warranty furtherdoesnotcover anyscratches,dents,corrosion or discolouringcausedby excessive heat,abrasiveand chemical cleanersnorchippingon porcelainenamel
parts,mechanical breakageofPHAZER™ logsandembers, noranyventing componentsusedin the installationof the fireplace.
NAPOLEONwarrants itsstainlesssteelburnersagainst defectsinworkmanshipandmaterial forlife,subjectto the followingconditions:Duringthe first 10yearsNAPOLEON will replace
or repair thedefective partsat ouroption free ofcharge. From10 yearsto life, NAPOLEONwill provide replacementburners at50%of thecurrent retail price.
Inthe first yearonly,thiswarranty extendstotherepair or replacementofwarranted parts whicharedefective in materialorworkmanship providedthattheproduct hasbeenoperatedin
accordancewith the operationinstructionsand undernormalconditions.
After the first year, with respect to thisPresident's Limited Lifetime Warranty,NAPOLEON may, at itsdiscretion,fully dischargeallobligations withrespectto this warrantybyrefunding
tothe originalwarrantedpurchaser the wholesaleprice of anywarrantedbut defectivepart(s).
Afterthe first year,NAPOLEON willnotbe responsible forinstallation,labour oranyother costs orexpensesrelated tothereinstallation of awarrantedpart, and suchexpensesare not
coveredbythiswarranty.
Notwithstandingany provisions containedinthis President's LimitedLifetimeWarranty, NAPOLEON’Sresponsibilityunder thiswarrantyisdefined asaboveandit shall notinany event
extendto any incidental,consequentialor indirectdamages.
Thiswarranty defines theobligationsandliability of NAPOLEONwithrespecttothe NAPOLEON gasfireplaceand any otherwarrantiesexpressed or impliedwithrespectto this product,
itscomponents oraccessoriesare excluded.
NAPOLEONneither assumes,norauthorizes any thirdpartyto assume, onitsbehalf, any otherliabilitieswith respect tothesale ofthisproduct. NAPOLEONwillnotbe responsible for:
over-firing,downdrafts, spillage causedbyenvironmental conditions suchasrooftops, buildings, nearbytrees,hills,mountains, inadequateventsor ventilation, excessiveventingconfigu-
rations,insufficient makeup air,or negative airpressureswhich may ormaynot becausedby mechanical systemssuchas exhaustfans,furnaces, clothesdryers,etc.
Anydamages tofireplace,combustion chamber,heatexchanger, brasstrimor othercomponent dueto water,weatherdamage, long periodsof dampness, condensation,damaging
chemicalsor cleanerswill not bethe responsibilityof NAPOLEON.
Thebill of saleorcopy willberequiredtogether withaserial number andamodel number whenmakingany warrantyclaimsfrom your authorizeddealer.The warranty registrationcard
mustbe returned withinfourteendays to registerthewarranty.
NAPOLEONreserves therightto have itsrepresentative inspect anyproduct or partthereofprior tohonouringany warrantyclaim.
ALLSPECIFICATIONS AND DESIGNSARE SUBJECTTOCHANGE WITHOUT PRIORNOTICE DUE TOON-GOING PRODUCTIMPROVEMENTS.NAPOLEON® ISAREGISTERED
TRADEMARKOFWOLFSTEEL LTD. PATENTS U.S.5.303.693.801-CAN.2.073.411,2.082.915.©WOLF STEEL LTD.

4
WS-415-137/05.15.00
GENERAL INSTRUCTIONS
THIS GAS FIREPLACE SHOULD BE INSTALLED AND
SERVICED BY A QUALIFIED INSTALLER to conform with
local codes. In absence of local codes, install the GB20 to
the current National Fuel Gas Code, ANSI Z223.1, or the
current CAN/CGA B149, Installation Codes.
The fireplace and its individual shutoff valve must be dis-
connected from the gas supply piping system during any
pressure testing of that system at test pressures in ex-
cess of 1/2 psig (3.5 kPa). The fireplace must be isolated
from the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the
gas supply piping system at test pressures equal to or
less than 1/2 psig (3.5 kPa).
When the fireplace is installed directly on carpeting, vinyl
tile or other combustible material other than wood floor-
ing, the fireplace shall be installed on a metal or wood
panel extending the full width and depth.
If the optional fan or blower is installed, the junction box
must be electrically connected and grounded in accord-
ance with local codes. In the absence of local codes, use
the current CSA C22.1 CANADIAN ELECTRICAL CODE in
Canada or the ANSI/NFPA 70-1996 NATIONAL ELECTRI-
CAL CODE in the United States.
GENERAL INFORMATION
FORYOUR SATISFACTION, THIS FIREPLACE HASBEEN
TEST-FIRED TO ASSURE ITS OPERATION AND QUAL-
ITY! Maximum input for the GB20 is 17,000 BTU/h for natu-
ral gas and propane. When the fireplace is installed at
elevations above 4,500ft, and in the absense of specific
recommendations from the local authority having jurisdic-
tion, the certified high altitude input rating shall be reduced
at the rate of 4% for each additional 1,000ft.
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. Manifold pressure under flow conditions is 3.5
inches water column for natural gas and 10 inches water
column for propane.
FIGURE1
This fireplace is approved for bedroom and bed-sitting room
installation.
Noexternal electricity(110voltsor24volts)isrequired
for the gas system operation. Expansion / contraction
noIses during heating up and cooling down cycles are
normal and are to be expected.
CARE OF GLASS, AND PLATED PARTS
Do not use abrasive cleaners to clean plated parts. Buff
lightly with a clean dry cloth. The GB20 is factory equipped
with 3/16" thick tempered glass. Use only replacement glass
available from your Napoleon dealer.
Do not substitute materials.
Clean the glass after the first 10 hours of operation with a
recommended gas fireplace glass cleaner. Thereafter
clean as required.
Do not clean glass when hot!
If the glass is not kept clean permanent discolouration
and / or blemishes may result.
Use only accessories designed for and
listed with your specific fireplace.
Provide adequate ventilation and combustion air.
Provide adequate accessibility clearance for serv-
icing and operating the fireplace. Never obstruct
the front opening of the fireplace.
Objects placed in front of the fireplace must be
kept a minimum of 48" away from the front face of
the unit.
For safe and proper operation of the fireplace fol-
low the venting & operating instructions exactly.
Provide a means for visually checking the vent
connection to the fireplace after the fireplace is
installed.
The fireplace must be installed against finished
walls. Do not install against a vapour barrier or
exposed insulation.

5
WS-415-137/05.15.00
The GB20 is a vented appliance and must be connected to
a chimney in accordance with the current installation
codes. In absence of local codes, install to the current
National Fuel Gas Code, ANSI Z223.1, or the current
CAN/CGA B149, Installation Codes. This model can be
common-vented.
A minimum four inch diameter (4"ø) B-vent or class A vent
is required. Secure the B-vent to the exhaust collar on the
stove top with 3 screws. In cold climates, the use of a B-
vent and an insulated chase is recommended.
VENT SAFETY SWITCH
This thermally activated switch, located in front of the draft
hood, senses an increase in temperature and acts as a
safety shut-off (A). It shuts down the gas to the main burner
in the event of a severe downdraft of air or a blocked or
disconnected chimney flue. If the flue is blocked or has no
"draw", the safety switch will automatically shut off the sup-
ply of gas within 10 minutes.
Tampering with the safety switch can result in
carbon monoxide poisoning and possible death.
The one wire running from the vent safety switch is at-
tached to terminal 1 of the valve (See 'B' below). The other
wire ( laying loose in the valve control area) may be at-
tached to a wall switch or thermostat.
VENTING ACTION CHECK
A test for correct venting action must be made before
the installed unit can be left with the customer.
Follow the procedure below:
1. Close all doors and windows in the room / start ex-
haust fans in the home / turn the fireplace blower off (if so
equipped).
2. Set controls to "high" and light the unit.
3. Wait 5 minutes. Light a match and hold to the front of
the draft draft hood. FIGURE 4.
VENTING
FIGURES4
L
O
O
T
P
I
L
I
H
N
F
L
O
T
O
P
I
F
O
FIGURE2
FIGURE3
Venting action is satis-
factory, if smoke and
flames are drawn into the
draft hood.
Ventingactionisunsatisfac-
tory, if the smoke spills back,
and the flame splays out-
ward. If venting action is un-
satisfactory, turn off the unit,
wait 10 minutes and try again.
If the smoke is still not drawn
intothedrafthood,turntheunit
off and check for vent block-
age or restriction. If neces-
sary, consult with a qualified
inspector. Until the draft prob-
lem is corrected, the safety
switch will continue to cycle
the main burner on and off.
This spillage monitoring system must not be ad-
justed or disabled.
In the event that the spillage monitoring system
or any of its parts are exchanged, only original
manufacturer'spartsmaybeused.
B
A

6
WS-415-137/05.15.00
Bend out the four nailing
tabs, attached on either side
of the fireplace and secure to
the 2x4 framing. The tabs will
facilitate the installation of ei-
ther a ½" or a 3/4" finished wall
thicknesss. The nailing tabs
must not be removed.
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system. Objects placed in front of the fireplace
should be kept a minimum of 48" away from the front face.
Combustible mantle clearance can vary according to the
mantle depth. FIGURES 11. Use the graph to help evaluate
the clearance needed.
GAS INSTALLATION
Proceed once the vent installation is complete.
1. Move the fireplace into position and secure using the
nailing tabs and/or secure to the floor through the ¼"ø holes
located at either end of the base.
2. Route a 3/8" N.P.T. black iron gas line, 1/2" type-L
copper tubing or equivalent to the fireplace.
3. For ease of accessibility, an optional remote wall
switch or millivolt thermostat may be installed in a conven-
ient location. Route 2-strand (solid core) millivolt wire
through the electrical hole located at the bottom left side of
the unit. The recommended maximum lead length de-
pends on wire size:
WIRESIZE MAX. LENGTH
14gauge 100 feet
16gauge 60 feet
18gauge 40 feet
Attach the one lead to terminal 3 (located on the gas valve)
and the other lead to the vent safety switch wire ( located
loose in the valve compartment). See FIGURE 3.
Do not connect either the wall switch, thermo-
stat or gas valve to electricity (110 volts).
4. Install rigid black pipe, 1/2" type-L copper tubing or, if
local codes permit, a 3/8" flex connector and shutoff valve
to the gas line and the fireplace gas valve. Seal and tighten
securely. An adapter fitting is required between the gas
valve and the coppertubing or flex connector. DO NOT KINK
FLEXIBLECONNECTOR.FIGURE6.
5. Check for gas leaks by brushing on a soap and water
solution.
Do not use open flame.
Purge all gas lines with the glass door of the fire-
place open. Assure that a continuous gas flow is
at the burner before closing the door.
FRAMING
It is best to frame
your fireplace after
it is positioned
and the vent sys-
tem is installed.
Use 2x4's and
frame to local
building codes.
FIGURE7-9.
To install the fireplace face flush with the finished wall,
position the framework to accomodate the thickness of the
finished wall.
FIGURE6
P
I
P
I
L
O
T
3
12
N
O
L
O
T
H
I
L
O
F
F
O
FIGURE5
FIGURES11
FIGURE10
FIGURES7
FIGURE9
FIGURE8

7
WS-415-137/05.15.00
LOG PLACEMENT
PHAZERTM logs exclusive to Napoleon Fireplaces, pro-
vide a unique and realistic glowing effect that is different in
every installation.
1. Place the front log, as shown, centered along the
inside front edge of the burner tray.
2. Place the back log onto the log support bracket, lo-
cated on the rear wall of the combustion chamber, push-
ing it as close to the firebox wall as possible.
3. Set the two smaller logs into the pockets and grooves
of the front and back logs, respectively.
POSITIONINGTHE LOGSIMPROPERLY WILLCAUSE
FLAMEIMPINGEMENTANDCARBONING.
Log colours may vary. During the initial use of the fireplace,
the colours will become more uniform as colour pigments
burn in during the heat activated curing process.
FIGURES12
DOOR, HOOD, AND OPTIONAL
LOUVRE REMOVAL & INSTALLATION
DOOR OPENING AND CLOSING: Open the valve control
door. Release the top and bottom door latches, located at
the right side of the door.
TO INSTALL THE HOOD: Insert the top flange of the hood
into the four clips located along the top of the unit as shown.
If the clips are inadevertently bent causing the hood to fit
loosely, a set screw may be used to secure the hood. The
slot, on the centre of the hood, lines up with the pilot hole in
the frame for this application.
THE OPTIONAL LOWER LOUVRE ASSEMBLY attaches
with 2 screws at each hinge. Optional brass door trim, and
webbed door facia are also available at your local Napo-
leon dealer.
FINISHING
2
1
3
LOWER LOUVRES
(VALVECONTROL
DOOR)
FIGURE15
HOOD
FIGURE14
FIGURE13 DOORHINGE
HOOD
CLIP
FLANGE

8
WS-415-137/05.15.00
Attach the connectors from the black and white wires to the
thermodisc and secure the thermodisc bracket to the secur-
ing stud at the bottom left of the unit using a lock washer and
wing nut. Ensure that the thermodisc touches the firebox
wall.
Attach the connectors from the black and red wires to the
blower.
Attach and secure the variable speed switch using the nut
provided. Plug the harness cord into the receptacle.
The wire harness provided in this kit is a universal
harness. When installed, ensure that any excess
wire is contained, preventing it from making con-
tact with moving or hot objects.
Because the blower is thermally activated, when
turned on, it will automatically start approximately
15 minutes after lighting the fireplace and will run
for approximately 30-45 minutes after the fireplace
has been turned off. Use of the fan increases the
output of heat.
Drywall dust will penetrate into the blower bear-
ings causing irreparable damage. Care must be
taken to prevent drywall dust from coming into
contact with the blower or its compartment. Any
damage resulting from this condition is not cov-
ered by the warranty policy.
INSTALLATION TO BE DONE BY A QUALIFIED INSTALLER
and must be electrically connected and grounded in accord-
ance with local codes. In the absence of local codes, use the
current CSA C22.1 CANADIAN ELECTRICAL CODE in Canada or the
ANSI/NFPA70-1996 NATIONAL ELECTRICAL CODE intheUnitedStates.
The three slots allow ease of adjustment of the blower. For
a quiet running blower, do not allow the assembly to sit on
the firebox base.
Slide the vibration reducing pad (A) into the clip and onto
the threaded stud (B) at the other end, piercing a hole into
the pad. The blower must be able to be positioned entirely
onto the pad.
Tilt the blower onto its side. Slide it past the controls and
into the clip (C). Secure to the threaded stud using the lock
washer and wing nut provided. Ensure that the blower
does not touch the fireplace base or the firebox.
red
white
black
RECEPTACLE /
THERMODISC
GROUND
SCREW
JUNCTIONBOX
ADJUSTMENT
SLOTS
FIGURE16
FIGURE17
FIGURE18 FIGURE19
FIGURE21
FIGURE20
OPTIONAL BLOWER INSTALLATION
C
A
B

9
WS-415-137/05.15.00
Attach and secure the sensor assembly bracket to the se-
curing stud located next to the receptacle/junction box at
the bottom left of the unit using the lock washer and wing
nut. Ensure that the thermodisc touches the firebox wall.
Plug the power cord back into the receptacle.
When installed, ensure that any excess wire is contained,
preventing it from making contact with moving or hot ob-
jects.
Slide the fan assembly past the controls and and into the
clip. Secure using the lock washer and nut provided.
Attach the connectors from the black and white wires to the
thermodisc and secure the thermodisc bracket to the se-
curing stud at the bottom left of the unit using a lock washer
and wing nut. Ensure that the thermodisc touches the fire-
box wall.
ELECTRICAL INSTALLATION TO BE DONE BY A QUALI-
FIED INSTALLER and must be connected and grounded
in accordance with local codes. In the absence of local
codes,usethe current CSA C22.1 CANADIAN ELECTRICAL CODE in
Canada or the ANSI/NFPA 70-1996 NATIONAL ELECTRICAL CODE
in the United States.
The wire harness provided in this kit is a universal har-
ness. When installed, ensure that any excess wire is con-
tained, preventing it from making contact with moving or
hot objects.
Position the vibration reducing pad into the clip and onto
the threaded stud at the other end, piercing a hole into the
pad. The fan assembly must be able to be positioned en-
tirely onto the pad.
RECEPTACLE /
JUNCTION BOX
OPTIONAL THERMOSTATIC
SENSOR
SLOTS
OPEN ENDED
BRACKET
VARIABLE SPEED/
PIEZO IGNITOR
JUNCTION BOX
THERMODISC
SENSOR ASSEMBLY
BRACKET
RECEPTACLE /
FIGURE23
FIGURE22
FIGURE24
FIGURE25
OPTIONAL FAN INSTALLATION
THERMOSTATIC SENSOR CONTROL
This optional kit is meant to be used only in conjunction
with the GD65 Fan Kit, shown above, which may be or-
dered from your Wolf Steel / Napoleon dealer.
With the thermostatic sensor option, the fan, when turned
on, becomes thermally activated, and will automatically run
approximately 10 minutes after the fireplace has been lit
and for approximately 30-45 minutes after the fireplace has
been turned off.
Use of the fan increases the output of heat.
Unplug the power cord from the receptacle. Connect all
wires as shown.

10
WS-415-137/05.15.00
WHAT TODOIF YOU SMELLGAS:
• Turn off all gas to the fireplace.
• Open windows.
• Do not try to light any appliance.
• Do not touch any electric switch; do
not use any phone in your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire de-
partment.
P
I
N
O
L
O
T
F
F
O
GAS KNOB
FLAME
ADJUSTMENT
KNOB
O
T
P
I
L
L
O
I
H
T
P
I
L
O
N
O
F
F
O
PILOT
ON/OFF
KNOB
OPERATION / MAINTENANCE
FORYOURSAFETYREADBEFORELIGHTING:
A. This fireplace is equipped with a pilot which must be lit
by hand while following these instructions exactly.
B. Before operating smell all around the fireplace area for
gas and next to the floor because some gas is heavier
than air and will settle on the floor.
C. Use only your hand to turn the gas control knob. Never
use tools. If the knob will not turn by hand, do not try to
repair it. Call a qualified service technician. Force or at-
tempted repair may result in a fire or explosion.
D. Do not use this fireplace if any part has been under
water. Immediately call a qualified service technician to
inspect the fireplace and replace any part of the control
system and any gas control which has been under water.
LIGHTINGINSTRUCTIONS
WARNING: The gas valve has an interlock device which
will not allow the pilot burner to be lit until the thermocou-
ple has cooled. Allow approximately 60 seconds for the
thermocouple to cool.
When lighting and re-lighting, the gas knob cannot be turned
from pilot to off unless the knob is depressed slightly.
1. Stop! Read the above safety information on this label.
2. Turn off all electric power to the fireplace.
3. Turn the gas knob clockwise to off.
4. Wait five (5) minutes to clear out any gas. If you smell
gas including near the floor. Stop! Follow "B" in the above
safety information on this label. If you don't smell gas go
the next step.
5. Turn gas knob counter-clockwise to pilot.
6. Depress slightly and hold gas knob while lighting the
pilot with the push button ignitor. Keep knob depressed
for one minute, then release. If pilot does not continue to
burn, repeat steps 3 through 5.
7. With pilot lit, depress and turn gas knob counter-clock-
wise to on.
8. If equipped with remote on-off switch/thermostat, main
burner may not come on when you turn valve to on.
Remote switch must be in the on position to ignite burner.
9. Turn on all electric power to the fireplace.
TOTURNOFFGAS
1. Turn off all electric power to the fireplace if service is to
be performed. 2. Push in gas control knob slightly and turn clock-
wise to off. Do not force.
OPERATING INSTRUCTIONS
When lit for the first time, the fireplace will emit a slight
odour for a few hours. This is a normal temporary condi-
tion caused by the curing of the logs and the "burn-in" of
internal paints and lubricants used in the manufacturing
process and will not occur again.
After extended periods of non-operation such as following
a vacation or a warm weather season, the fireplace may
emit a slight odour for a few hours. This is caused by dust
particles in the heat exchanger burning off. In both cases,
open a window to sufficiently ventilate the room.
Purge all gas lines with the glass door of the fireplace
removed. Assure that a continuous gas flow is at the
burnerbeforeinstalling the door.

11
WS-415-137/05.15.00
VENTURI ADJUSTMENT
Both fireplace models have air shutters that have been
factory set open according to the chart below:
Closing the air shutter will cause a more yellow flame, but
can lead to carboning. Opening the air shutter will cause a
more blue flame, but can cause flame lifting from the burner
ports. The flame may not appear yellow immediately; al-
low 15 to 30 minutes for the final flame colour to be estab-
lished.
AIRSHUTTER ADJUSTMENTMUST ONLYBEDONE BYA
QUALIFIEDGASINSTALLER!
3. Check to see that all burner ports are burning. Clean out
any of the ports which may not be burning or are not burn-
ing properly.
4. Check to see that the pilot flame is large enough to
engulf the thermocouple and thermopile and reaches to-
ward the burner with the third jet.
5. Replace the cleaned logs.
6. Check to see that the main burner ignites completely on
all openings when the gas knob for the burner is turned
on. A 5 to 10 second total light-up period is satisfactory. If
ignition takes longer, consult your Napoleon dealer / dis-
tributor.
7. Check that the gasketing on the sides, top and bottom of
the door is not broken or missing. Replace if necessary.
FLAME MUST ENVELOP
UPPER 3/8" TO 1/2" OF
THERMOCOUPLE &
THERMOPILE
PILOT
THERMOPILE BURNER
ELECTRODE
THERMO-
COUPLE
P
I
P
I
PILOT SCREW
L
O
T
N
O
L
O
T
H
I
L
O
F
F
O
FIGURE26
FIGURE27
FIGURE28
ADJUSTMENTS
MAINTENANCE Turn off the gas and electrical
power before servicing the fireplace.
CAUTION: Label all wires prior to disconnection when serv-
icing controls. Wiring errors can cause improper and dan-
gerous operation. Verify proper operation after servicing.
This fireplace and its venting system should be inspected
before use and at least annually by a qualified service per-
son. The fireplace area must be kept clear and free of com-
bustible materials, gasoline or other flammable vapours
and liquids. The flow of combustion and ventilation air must
not be obstructed.
1. In order to properly clean the burner and pilot assembly,
remove the logs to expose both assemblies.
2. Keep the control compartment, logs, burner, air shutter
opening and the area surrounding the logs clean by vacu-
uming or brushing, at least once a year.
PILOT BURNER ADJUSTMENT
Adjust the pilot screw to provide properly sized flame. Turn
in a clockwise direction to reduce the gas flow.
MODELGB20
NG 1/8"
LP 1/8"

12
WS-415-137/05.15.00
ORDERING REPLACEMENT PARTS
Contact your dealer or the factory for questions concerning
prices and policies on replacement parts. Normally all parts
can be ordered through your Napoleon dealer or distribu-
tor. When ordering replacement parts always give the fol-
lowing information:
1. MODEL &SERIAL NUMBER OF FIREPLACE
2. INSTALLATION DATE OF FIREPLACE
3. PART NUMBER
4. DESCRIPTION OF PART
5. FINISH
REPLACEMENT PARTS FORFOR
FORFOR
FOR WW
WW
WARRANTYARRANTY
ARRANTYARRANTY
ARRANTY
REPLAREPLA
REPLAREPLA
REPLACEMENTCEMENT
CEMENTCEMENT
CEMENT
PP
PP
PARAR
ARAR
ARTSTS
TSTS
TS,,
,,
, AA
AA
A PHOPHO
PHOPHO
PHOTT
TT
TOCOPYOCOPY
OCOPYOCOPY
OCOPY OFOF
OFOF
OF THETHE
THETHE
THE
ORIGINALORIGINAL
ORIGINALORIGINAL
ORIGINAL
INVOICEINVOICE
INVOICEINVOICE
INVOICE WILLWILL
WILLWILL
WILL BEBE
BEBE
BE REQUIREDREQUIRED
REQUIREDREQUIRED
REQUIRED TOTO
TOTO
TO
HONOURHONOUR
HONOURHONOUR
HONOUR
THETHE
THETHE
THE CLAIMCLAIM
CLAIMCLAIM
CLAIM..
..
.
REPLACEMENT COMPONENTS:
PART NO. DESCRIPTION
WS-357-01 PIEZO IGNITER
WS-680-04 THERMOPILE
WS-680-05 THERMOCOUPLE
WS-100-053 BURNER TUBE
WS-100-38 NATURAL GAS PILOT ASSEMBLY
WS-100-39 PROPANE GAS PILOT ASSEMBLY
GB-335.014 HOOD
WS-660-07 SAFETY SWITCH
WS-660-05 ON/OFF TOGGLE SWITCH
WS-455-23 #51 NATURAL GAS PILOT ORIFICE
WS-455-24 #30 PROPANE GAS PILOT ORIFICE
WS-725-25 NATURAL GAS VALVE
WS-725-26 PROPANE GAS VALVE
WS-750-09 IGNITER WIRE
WS-385-45 NAPOLEONLOGO
GD660 STANDARD WALL SWITCH & 20FT OF WIRE
GB-225.065 BLACK DOOR FRAME
GB-010.568 GLASSc/wGASKET
GB-010.552 BLACK DOOR C/W GLASS
WS-455-048 #47 NATURAL GAS ORIFICE
WS-455-047 #56 PROPANE GAS ORIFICE
GD-135.057 BACK LOG
GD-135.028 FRONT LOG
DS-135.040 RIGHT LOG
GD-135.039 LEFT LOG
GL619 LOG SET ASSEMBLY
GL-619
GB-335.014
WS-660-07
REPLACEMENTS
GB-225.065 /
GB-010.552
GB-010.568
T
O
L
I
P
H
I
O
L
T
O
L
I
P
O
N
O
F
F

13
WS-415-137/05.15.00
WS690-1
GD-361.16
GD43-1AB/PB/SS
GD36
GD65
GB101-PB
GD3AB/PB/SS
GZ550-1KT
GD235-K
ACCESSORIES:
PART NO. DESCRIPTION
GD3AB 3" TRIM KIT - ANTIQUE BRASS
GD3PB 3" TRIM KIT - POLISHED BRASS
GD3SS 3" TRIM KIT - STAINLESS STEEL
GD43-1AB 4" - 3D TRIM KIT - ANTIQUE BRASS
GD43-1PB 4" - 3D TRIM KIT - POLISHED BRASS
GD43-1SS 4" - 3D TRIM KIT - STAINLESS STEEL
GB101-PB DOOR TRIM - POLISHED BRASS
WS690-1 MILLIVOLTTHERMOSTAT
WS660-2 HAND HELD WIRELESS REMOTE SWITCH
WS-660-010 REMOTE CONTROL - ADVANTAGE
WS-660-011 REMOTE CONTROL - ADVANTAGE PLUS
GZ550-1KT BLOWER KIT
GD65 FAN KIT
GD36 THERMOSTATIC SENSORCONTROL KIT FOR USE WITH GD65 ONLY
WS500-33 VARIABLE SPEED SWITCH WALL MOUNTING PLATE
GD235-K WEBBED DOOR
GLLK LOWER LOUVRE ASSEMBLY - BLACK
GLLAB LOWER LOUVRE ASSEMBLY - ANTIQUE BRASS
GLLPB LOWER LOUVRE ASSEMBLY - POLISHED BRASS
GLLSS LOWER LOUVRE ASSEMBLY - STAINLESS STEEL
MBP METAL BRICK PANEL SET
GLLK / GLLAB / GLLPB / GLLSS
MBP

14
WS-415-137/05.15.00
TROUBLE SHOOTING GUIDE
B EFORE ATTEMPTING TO TROUBLESHOOT , PURGE YOUR UNIT AND INITIALLY LIGHT THE PILOT AND THE MAIN BURNER WITH THE GLASS DOOR
REMOVED
.
TEST SOLUTIONSYMPTOM PROBLEM
PILOT
THERMOPILE BURNER
ELECTRODE
THERMO-
COUPLE
Pilot will not light. - check if pilot can be lit by a match
- check that the wire is connected to the push button ignitor.
- check if the push button ignitor needs tightening.
- replace the wire if the wire insulation is broken or frayed.
- replace the electrode if the ceramic insulator is cracked or broken.
- replace the push button ignitor.
No spark at pilot burner
- fill the tank.Out of propane gas
Spark gap is incorrect - spark gap should be 0.150" to 0.175" (5/32" to 11/64" approx.) from
the electrode tip and the pilot burner. To ensure proper electrode
location, tighten securing nut (finger tight plus 1/4 turn).
No gas at the pilot burner - check that the manual valve is turned on.
- check the pilot orifice for blockage.
- replace the valve.
- call the gas distributor.
Main burner goes
out; pilot goes out. Refer to "MAIN BURNER GOES OUT; PILOT STAYS ON"
Faulty thermocouple. - replace.
Main burner goes
out; pilot stays on. Pilot flame is not large enough or not engulfing the
thermopile
- turn up pilot flame.
- replace pilot assembly.
Thermopile shorting - clean thermopile connection to the valve. Reconnect.
- replace thermopile / valve.
Remote wall switch wire is
too long; too much resist-
ance in the system.
- shorten wire to correct length or wire gauge.
Faulty thermostat or switch. - replace.
Vent safety switch has
opened. - Vent has become blocked or disconnected. Correct.
Pilot goes out when
the gas knob is re-
leased.
The gas valve has
an interlock device
whichwill notallow
the pilot burner to
be lit until the ther-
mocouple has
cooled. Allow ap-
proximately 60
seconds for the
thermocouple to
cool.
System is not correctly
purged. - purge the gas line with the glass door open.
Out of propane gas. - fill the tank.
Pilot flame is not large
enough - turn up the pilot flame.
- gently twist the pilot head to improve the flame pattern around the
thermocouple.
Pilot flame is not engulfing
the thermocouple.
Thermocouple shorting /
faulty. - loosen and tighten thermocouple. - clean thermocouple and valve connection.
- replace thermocouple.
- replace valve.
Faultyvalve. - replace.
Pilot burning; no
gas to main
burner; gas knob
is on 'HI'; wall
switch / thermostat
is on.
Themostat or switch is de-
fective. - connect a jumper wire across the wall switch terminals; if main
burner lights, replace switch / thermostat.
Mainburnerorificeisplugged. - remove stoppage in orifice.
Faultyvalve. - replace.
Wall switch wiring is defec-
tive. - disconnect switch wires & connect a jumper wire across terminals
1 & 3; if the main burner lights, check the wires for defects and / or
replace wires.

15
WS-415-137/05.15.00
White / grey film
forms. Sulphur from fuel is being deposited on glass, logs or
combustion chamber sur-
faces.
- clean the glass with a recommended gas fireplace glass cleaner.
DO NOT CLEAN GLASS WHEN HOT.
If deposits are not cleaned off regularly, the glass may become
permanently marked.
TEST SOLUTION
PROBLEMSYMPTOM
Pilot goes out
while standing;
Main burner is in
'OFF' position.
Gas piping is undersized. - turn on all gas appliances and see if pilot flame flutters, dimin-
ishes or extinguishes, especially when main burner ignites. Monitor
appliance supply working pressure.
- check if supply piping size is to code. Correct all undersized piping.
Flames are con-
sistently too large
or too small.
Carboning occurs.
- check pressure readings:
Inlet pressure can be checked by turning screw (A) counter-clock-
wise 2 or 3 turns and then placing pressure gauge tubing over the
test point. Gauge should read 7" (minimum 4.5") water column for
natural gas or 13" (11" minimum) water column for propane. Check
that main burner is operating on "HI".
Outlet pressure can be checked the same as above using screw
(B). Gauge should read 3.5" water column for natural gas or 10"
water column for propane. Check that main burner is operating on
"HI".
AFTER TAKING PRESSURE READINGS, BE SURE TO TURN
SCREWSCLOCKWISEFIRMLYTORESEAL.DONOTOVERTORQUE.
Leak test with a soap and water solution.
Unit is over-fired or under-
fired.
P
I
AB
P
I
L
O
T
N
O
L
O
T
H
I
L
O
F
F
O
Remote wall
switch is in "OFF"
position; main
burner comes on
when gas knob is
turned to "ON" po-
sition.
Wall switch is mounted up-
side down - reverse.
Faultyvalve. - replace.
- replace.Remote wall switch is
grounding.
- check for ground (short); repair ground or replace wire.Remote wall switch wire is
grounding.
Carbon is being
deposited on
glass, logs or com-
bustion chamber
surfaces. Flame is impinging on the
logs or combustion cham-
ber.
- check that the logs are correctly positioned.
- open air shutter to increase the primary air.
- check the input rate: check the manifold pressure and orifice size
as specified by the rating plate values.
- check to ensure proper venting action
Air shutter has become
blocked - ensure air shutter opening is free of lint or other obstructions.
Exhaust fumes
smelled in room,
headaches.
Fireplace is spilling. - check for chimney blockage
- check that chimney is installed to building code.
- room is in negative pressure; increase fresh air supply.
Main burner flame
is a blue, lazy,
transparent flame.
Not enough combustion air - room is in negative pressure; increase fresh air supply

16
WS-415-137/ 05.15.00
Wolf Steel Fireplace Service History
Thisfireplacemust be serviced annually dependingonusage.
Date ServiceTechnician
Name ServicePerformed Special ConcernsDealerName

17
WS-415-137/05.15.00
NOTES:
