INSTALLATION GUIDE
NI WSN-3291 Outdoor IP Enclosure
For NI WSN-32xx Series Devices
This installation guide describes how to install and use the National Instruments WSN-3291 outdoor IP
enclosure. The NI WSN-3291 outdoor IP enclosure is an accessory that provides NI WSN-32xx devices
with a minimum ingress protection (IP) rating of IP65 against dust and water in harsh outdoor or
industrial environments. For more information about IP ratings, refer to the Understanding IP Ratings
section. For the NI WNS-32xx device specifications, refer to the device user guides available at
ni.com/manuals.
Figure 1 shows the NI WSN-3291 outdoor IP enclosure components.
Figure 1. NI WSN-3291 Outdoor IP Enclosure Components
Note You need a #1 flat and a #2 Phillips screwdriver to install the NI WSN-3291.
The NI WSN-3291 kit includes the following items:
• NI WSN-3291
• Two M16 gland shells
• Two gland inserts, standard size
• Two gland inserts, reduced size
• Two gland plugs
• Two lock nuts
• 2.4 GHz antenna
• IP Boot
•IPSleeve
• Antenna wire connector
1 IP Sleeve
2 Antenna
3 Antenna Wire Connector
4LockNuts
5 Gland Inserts, Reduced
6 Gland Plugs
7 Gland Inserts, Standard
8 Gland Shells
9 IP Boot
345
876
1 2
9

NI WSN-3291 Outdoor IP Enclosure Installation Guide 2 ni.com
Dimensions
Figure 2 shows the NI WSN-3291 dimensions.
Figure 2. NI WSN-3291 Dimensions
Mounting the NI WSN-3291
Figure 3 shows the NI WSN-3291 mounting hole dimensions, which are molded on the enclosure
back surface for convenience. NI recommends mounting the NI WSN-3291 before installing the
NI WSN-32xx device and attaching the internal and external cables.
Tip Attach the cover after mounting the NI WSN-3291 and installing the NI WSN-32xx device,
as shown in Figure 9.
120 mm
(4.724 in.)
91.13mm
(3.588 in.)
20.96 mm
(0.825 in.)
220 mm
(8.661 in.)
79 mm
(3.118in.)
60 mm
(2.362 in.)

©National Instruments Corporation 3 NI WSN-3291 Outdoor IP Enclosure Installation Guide
Figure 3. NI WSN-3291 Mounting Hole Dimensions and Locations
Setting Up and Installing the NI WSN-3291
Complete the following steps to set up and install the NI WSN-3291:
Step 1: Unpack and Inspect the Kit Contents
Remove the device from the package and inspect the device and kit contents. Contact NI if the device
appears damaged. Do not install a damaged device or use kit contents that appear damaged.
Step 2: Unscrew and Detach the NI WSN-3291 Cover
The cover of the NI WSN-3291 is equipped with captive screws. Use a #2 Phillips screwdriver to remove
the cover.
Step 3: Connect Antenna Wire Connector
The NI WSN-3291 ships with an internal antenna cable to connect the NI WSN-32xx device to the IP
rated antenna connector on the inside of the NI WSN-3291.
3.228in.
(82 mm.)
8.031 in.
(204 mm.)
4X Ø .248in.
(6.3mm)

NI WSN-3291 Outdoor IP Enclosure Installation Guide 4 ni.com
Step 4: Install the NI WSN-32xx Device
Complete the following steps to install the NI WSN-32xx device into the NI WSN-3291:
1. Ensure the mounting tabs are aligned with the NI WSN-32xx device keyholes. Slide the
NI WSN-32xx device onto the mounting tabs of the NI WSN-3291 outdoor IP enclosure,
as shown in Figure 4.
Figure 4. Installing the NI WSN-32xx Device
Figure 5. Connecting Internal Cables
2. Secure the NI WSN-32xx device by rotating the retention bracket and fastening the screw on the
retention bracket while referring to Figure 5.
1 Retention Bracket 2 Retention Bracket Screw
1
2

©National Instruments Corporation 5 NI WSN-3291 Outdoor IP Enclosure Installation Guide
Step 5: Install the Antenna
Refer to Figure 6 to install the antenna assembly.
Figure 6. Antenna Assembly Installation
On the outside of the enclosure, place the IP boot onto the external antenna connector with the smaller
diameter hole out. Screw the antenna onto the external antenna connector until it bottoms out. Slide the
IP sleeve down the antenna and over the IP boot until the IP sleeve touches the enclosure.
Step 6: Attach External Cables and Assemble Glands
The NI WSN-3291 ships with two different insert sizes to use with the included gland shells. The larger
insert can accept cables with a diameter from 4–8 mm, while the smaller insert can accommodate cables
from 2–6 mm.
1 IP Boot
2Enclosure
3 External Antenna Connector
4 Antenna
5 IP Sleeve
2
3
4
5
1

NI WSN-3291 Outdoor IP Enclosure Installation Guide 6 ni.com
An accessory kit of inserts, called the NI WSN-3293 (NI Part Number 195738-01), for additional wiring
options is available at ni.com. Table 1 shows the insert sizes.
Once the cable(s) and corresponding inserts are selected, complete the following steps to assemble the
cable glands:
1. Assemble the selected inserts into the gland shell as shown in Figure 7.
Figure 7. Assembling Insert into Gland Shell
2. Insert the cable into cable gland, then insert the gland into the NI WSN-3291 enclosure cutout.
3. Loosely thread the included lock nut onto the gland shell as shown in Figure 8.
Figure 8. Cable Installation
Table 1. NI WSN-3292 Insert Sizes
Number of Holes Wire Size
23 mm
41.7 mm
61.4 mm
10 1.4 mm
Solid Plug*—
*The solid plug can be frozen and drilled to any size and configuration needed.
1 Outer Compression Nut 2LockNut
2
1

©National Instruments Corporation 7 NI WSN-3291 Outdoor IP Enclosure Installation Guide
4. Attach the wires to the 18 position I/O connector or the two-position power connector. Refer to the
NI WSN-32xx device user guides for more information.
5. Tighten the lock nut to approximately 3.75 N · m (33.2 lb · in.) ensuring that the O-ring is pressed
flat against the enclosure wall. Tighten the outer compression nut to approximately 2.50 N · m
(22.1 lb · in.) to seal the cable.
Step 7: Attach the Cover
The cover of the NI WSN-3291 is equipped with captive screws. Use a #2 Phillips screwdriver to install
the cover as shown in Figure 9.
Figure 9. Attaching the NI WSN-3291 Cover
Environmental
Caution The NI WSN-3291 is intended for outdoor use in most environments, but does have the
following limitation. Placing the NI WSN-3291 in direct sunlight causes the internal temperature to
rise above the outdoor ambient. NI recommends accounting for this limitation when using the
NI WSN-3291.

NI WSN-3291 Outdoor IP Enclosure Installation Guide 8 ni.com
Understanding IP Ratings
Proper use and installation of an NI WSN-32xx device in an NI WSN-3291 outdoor IP enclosure
provides a minimum IP rating of IP65 from harsh outdoor and industrial environments. An IP rating
of IP65 protects against entry by dust particles and low pressure water jets.
The two-digit ingress protection (IP) rating is defined by the IEC 60529 standard and specifies the
degree to which the enclosures protect against the intrusion of solid particles (represented by the
first number) and water (represented by the second number).
Table 2 lists the degree of protection.
Environmental Management
NI is committed to designing and manufacturing products in an environmentally responsible manner.
NI recognizes that eliminating certain hazardous substances from our products is beneficial to the
environment and to NI customers.
For additional environmental information, refer to the NI and the Environment Web page at
ni.com/environment. This page contains the environmental regulations and directives with
which NI complies, as well as other environmental information not included in this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the product life cycle, all products must be sent to a WEEE recycling
center. For more information about WEEE recycling centers, National Instruments WEEE initiatives,
and compliance with WEEE Directive 2002/96/EC on Waste and Electronic Equipment,
visit ni.com/environment/weee.
Table 2. IP Ratings
First Number (Protection Against Solid Objects) Second Number (Protection Against Water)
0No protection 0No protection
1Protects against objects greater than 50 mm 1Protects against vertically dripping water
2Protects against objects greater than 12.5 mm 2Protects against direct sprays up to 15° from vertical
3Protects against objects greater than 2.5 mm 3Protects against direct sprays up to 60° from vertical
4Protects against objects greater than 1 mm 4Protects against direct sprays from all angles
5Dust-protected (no harmful deposit) 5Protects against low pressure water jets
6Dust-tight 6Protects against high pressure water jets
— — 7 Immersible in water up to 1 m
— — 8 Immersible in water beyond 1 m
