National Instruments NI PXIe-2526 User manual

PXIe-2526

DEVICE SPECIFICATIONS
NI PXIe-2526
1-wire 158 × 1 Multiplexer
This document lists specifications for the NI PXIe-2526 (NI 2526) multiplexer relay module.
All specifications are subject to change without notice. Visit ni.com/manuals for the most
current specifications.
............................................................................Topology 1-wire 158 × 1 Multiplexer,
2-wire 79 × 1 Multiplexer
Contents
About These Specifications...................................................................................................... 1
Input Characteristics................................................................................................................. 2
RF Performance Characteristics................................................................................................3
Dynamic Characteristics........................................................................................................... 3
Physical Characteristics............................................................................................................ 4
Environment..............................................................................................................................4
Operating Environment.....................................................................................................4
Storage Environment.........................................................................................................5
Shock and Vibration..................................................................................................................5
Diagrams................................................................................................................................... 5
Accessories................................................................................................................................7
Compliance and Certifications..................................................................................................8
Safety................................................................................................................................ 8
Electromagnetic Compatibility......................................................................................... 8
CE Compliance ................................................................................................................ 9
Online Product Certification............................................................................................. 9
Environmental Management............................................................................................. 9
About These Specifications
Specifications characterize the warranted performance of the instrument under the stated
operating conditions.
Typical Specifications are specifications met by the majority of the instrument under the stated
operating conditions and are tested at 23 °C ambient temperature. Typical specifications are
not warranted.
All voltages are specified in DC, ACpk, or a combination unless otherwise specified.

Caution The protection provided by the NI 2526 can be impaired if it is used in a
manner not described in this document.
Input Characteristics
Maximum switching voltage
....................................................................Channel-to-channel 150 V
....................................................................Channel-to-ground 150 V, CAT O
Note This module is rated for Measurement Category I. It is intended to carry
signal voltages no greater than 150 V. This module can withstand up to 800 V
impulse voltage. Do not use this module for connection to signals or for
measurements within Categories II, III, or IV. Do not connect to MAINS supply
circuits (for example, wall outlets) of 115 VAC or 230 VAC. Refer to the Read Me
First: Safety and Electromagnetic Compatibility document for more information
about measurement categories.
Measurement Categories CAT I and CAT O (Other) are equivalent and are for measurements
performed on circuits not directly connected to the electrical distribution system referred to as
MAINS voltage. This category is for measurement of voltages from specially protected
secondary circuits. Such voltage measurements include signal levels, special hardware,
limited-energy parts of hardware, circuits powered by regulated low-voltage sources, and
electronics.
Caution When hazardous voltages (>42.4 Vpk/60 VDC) are present on any
channel, safety low-voltage (≤42.4 Vpk/60 VDC) cannot be connected to any other
channel.
............................................................................Maximum switching power 60 W, 62.5 VA
Caution The switching power is limited by the maximum switching current, the
maximum voltage, and must not exceed 60 W, 62.5 VA.
............................................................................CH-COM DC isolation resistance >1 GΩ, typical at 25 °C
Maximum current
....................................................................Switching 2 A (per channel)
....................................................................Carry 2 A (per channel)
............................................................................Minimum switch load 20 mV/1 mA
Note The NI 2526 is not recommended for 2-wire resistance measurements.
2| ni.com | NI PXIe-2526 Specifications

Note Switching inductive loads (for example, motors and solenoids) can produce
high voltage transients in excess of the module’s rated voltage. Without additional
protection, these transients can interfere with module operation and impact relay life.
For more information about transient suppression, visit ni.com/info and enter the
Info Code relayflyback.
DC path resistance
....................................................................
Initial < 0.5 Ω
....................................................................End-of-life ≥ 1.5 Ω
DC path resistance is a combination of relay contact resistance and trace resistance. Measure
path resistance by combining the resistance of the high and low signal paths from one row to
one column. Contact resistance typically remains low for the life of a relay. At the end of relay
life, the contact resistance rises rapidly above ≥ 1.5 Ω.
............................................................................Thermal EMF <10 µV
RF Performance Characteristics
............................................................................Bandwidth (-3 dB, typical at 23 ºC)
50 Ω termination
≤10 MHz
Open channel isolation (typical at 23 ºC) 50 Ω
termination
....................................................................10 kHz ≥ 67 dB
....................................................................100 kHz ≥ 49 dB
....................................................................1 MHz ≥ 29 dB
Dynamic Characteristics
Relay operate time
....................................................................Typical 1 ms
....................................................................Maximum 3.1 ms
....................................................................Simultaneous drive limit 82 relays
Expected relay life
....................................................................Mechanical 1 × 108 cycles
Electrical
............................................................
≤30 mV, ≤10 mA resistive 2.5 × 106 cycles
............................................................30 V, 1 A 5 × 105 cycles
NI PXIe-2526 Specifications | © National Instruments | 3

............................................................30 V, 2 A 1 × 105 cycles
............................................................60 VDC, 1 ADC resistive 1 × 105 cycles
Note Relays are field replaceable. Refer to the NI Switches Help at ni.com/
manuals for more information about replacing a failed relay.
Physical Characteristics
............................................................................Relay type Electromechanical, non-latching
............................................................................Relay contact material Palladium-ruthenium, gold covered
............................................................................Front panel connector 160 DIN 41612, 160 positions, male
Power requirement
PXI Express
............................................................12 V 21 W
............................................................3.3 V 3.4 W
............................................................................
Dimensions (L × W × H) 3U, one slot, PXI/cPCI module, PXI Express
compatible 21.6 cm × 2.0 cm × 13.0 cm
(8.5 in. × 0.8 in. × 5.1 in.)
............................................................................Weight 230 g (8.1 oz)
Environment
............................................................................Maximum altitude 2,000 m (800 mbar) (at 25 °C ambient
temperature)
............................................................................Pollution Degree 2
Indoor use only.
Operating Environment
............................................................................Ambient temperature range 0 °C to 55 °C (Tested in accordance with
IEC 60068-2-1 and IEC 60068-2-2. Meets
MIL-PRF-28800F Class 3 low temperature
limit and MIL-PRF-28800F Class 2 high
temperature limit.)
............................................................................
Relative humidity range 10% to 90%, noncondensing (Tested in
accordance with IEC 60068-2-56.)
4| ni.com | NI PXIe-2526 Specifications

Storage Environment
............................................................................
Ambient temperature range -40 °C to 71 °C (Tested in accordance
with IEC 60068-2-1 and IEC 60068-2-2. Meets
MIL-PRF-28800F Class 3 limits.)
............................................................................Relative humidity range 5% to 95%, noncondensing (Tested in
accordance with IEC 60068-2-56.)
Shock and Vibration
............................................................................Operating shock 30 g peak, half-sine, 11 ms pulse (Tested in
accordance with IEC 60068-2-27. Meets
MIL-PRF-28800F Class 2 limits.)
Random vibration
....................................................................Operating 5 Hz to 500 Hz, 0.3 grms
....................................................................Nonoperating 5 Hz to 500 Hz, 2.4 grms (Tested in accordance
with IEC 60068-2-64. Nonoperating test
profile exceeds the requirements of
MIL-PRF-28800F, Class 3.)
Diagrams
The following figure shows the NI 2526 power-on state.
Figure 1. NI 2526 Power-On State
k0
CH 0+
CH 0–
CH 1+
CH 1–
COM –
COM +
CH 78+
CH 78–
k1 kcomlo1w
kcomhi
kcomlo
k78
The following figures show the NI 2526 connector pinouts.
NI PXIe-2526 Specifications | © National Instruments | 5

Figure 2. NI 2526 1-Wire Pinout
B32
A32
C32
D32
E32
C31
D31
E31
C30
D30
E30
C29
D29
E29
C28
D28
E28
C27
D27
E27
C26
D26
E26
C25
D25
E25
C23
D23
E23
C22
D22
E22
C19
D19
E19
C18
D18
E18
C17
D17
E17
B31
A31
A30
B30
B29
A29
B28
A28
B27
A27
B26
A26
B25
A25
B24
A24
A23
B23
B22
A22
B20
A20
B19
A19
B18
A18
B17
A17
B21
A21
C24
D24
E24
C21
D21
E21
C20
D20
E20
C16
D16
E16 CH 123
C15
D15
E15 CH 44
CH 42
CH 43
C13
D13
E13 CH 49
CH 47
CH 48
C11
D11
E11 CH 54
CH 52
CH 53
C10
D10
E10 CH 138
CH 136
CH 137
C9
D9
E9 CH 59
CH 57
CH 58
C8
D8
E8 CH 143
CH 141
CH 142
D7
E7
C7
CH 64
CH 62
CH 63
E6
C6
D6 CH 148
CH 146
CH 147
C5
D5
E5 CH 69
CH 67
CH 68
C4
D4
E4 CH 153
CH 151
CH 152
C3
D3
E3 CH 74
CH 72
CH 73
C2
D2
E2 COM
CH 156
CH 157
C1
D1
E1 Reserved
CH 77
CH 78
B16
A16
B15
A15
B14
A14
B13
A13
B12
A12
B11
A11
B10
A10
B9
A9
B8
A8
B7
A7
B6
A6
B5
A5
B4
A4
B3
A3
B2
A2
B1
A1
C14
D14
E14 CH 128
CH 126
CH 127
C12
D12
E12 CH 133
CH 131
CH 132
C16 CH 121
CH 122
A17 CH 121
CH 122
CH 83
CH 81
CH 82
CH 4
CH 2
CH 3
CH 88
CH 86
CH 87
CH 9
CH 7
CH 8
CH 93
CH 91
CH 92
CH 14
CH 12
CH 13
CH 98
CH 96
CH 97
CH 19
CH 17
CH 18
CH 24
CH 22
CH 23
CH 108
CH 106
CH 107
CH 34
CH 32
CH 33
CH 118
CH 116
CH 117
CH 39
CH 37
CH 38
CH 103
CH 101
CH 102
CH 29
CH 27
CH 28
CH 113
CH 111
CH 112
CH 120
CH 120
CH 119
CH 41
CH 40
CH 125
CH 124
CH 46
CH 45
CH 130
CH 129
CH 51
CH 50
CH 135
CH 134
CH 56
CH 55
CH 140
CH 139
CH 61
CH 60
CH 145
CH 144
CH 66
CH 65
CH 150
CH 149
CH 71
CH 70
CH 155
CH 154
CH 76
CH 75
CH35
CH 16
CH 15
CH 100
CH 99
CH 21
CH 20
CH 105
CH 104
CH 110
CH 109
CH 31
CH 30
CH 115
CH 114
CH 35
CH 36
CH 26
CH 25
CH 80
CH 79
CH 1
CH 0
CH 85
CH 84
CH 6
CH 90
CH 89
CH 11
CH 10
CH 95
CH 94
CH 5
6| ni.com | NI PXIe-2526 Specifications

Figure 3. NI 2526 2-Wire Pinout
CH 1–
CH 0–
B32
A32
C32
D32
E32
C31
D31
E31
C30
D30
E30
C29
D29
E29
C28
D28
E28
C27
D27
E27
C26
D26
E26
C25
D25
E25
C23
D23
E23
C22
D22
E22
C19
D19
E19
C18
D18
E18
C17
D17
E17
CH 1+
CH 0+
B31
A31
CH 6–
CH 5– A30
B30
CH 6+
CH 5+
B29
A29
CH 11–
CH 10–
B28
A28
CH 11+
CH 10+
B27
A27
CH 16–
CH 15–
B26
A26
CH 16+
CH 15+
B25
A25
CH 21–
CH 20–
B24
A24
CH 21+
CH 20+ A23
B23
CH 26–
CH 25–
B22
A22
CH 31–
CH 30–
B20
A20
CH 31+
CH 30+
B19
A19
CH 36–
CH 41–
CH 35–
B18
A18
CH 35+
CH 36+ B17
A17
CH 26+
CH 25+
B21
A21
C24
D24
E24
C21
D21
E21
C20
D20
E20
C16
D16
E16 CH 44–
C15
D15
E15 CH 44+
CH 42+
CH 43+
C13
D13
E13 CH 49+
CH 47+
CH 48+
C11
D11
E11 CH 54+
CH 52+
CH 53+
C10
D10
E10 CH 59–
CH 57–
CH 58–
C9
D9
E9 CH 59+
CH 57+
CH 58+
C8
D8
E8 CH 64–
CH 62–
CH 63–
D7
E7
C7
CH 64+
CH 62+
CH 63+
E6
C6
D6 CH 69–
CH 67–
CH 68–
C5
D5
E5 CH 69+
CH 67+
CH 68+
C4
D4
E4 CH 74–
CH 72–
CH 73–
C3
D3
E3 CH 74+
CH 72+
CH 73+
C2
D2
E2 COM +
CH 77–
CH 78–
C1
D1
E1 COM –
CH 77+
CH 78+
CH 41–
CH 40–
B16
A16
CH 41+
CH 40+
B15
A15
CH 46–
CH 45–
B14
A14
CH 46+
CH 45+
B13
A13
CH 51–
CH 50–
B12
A12
CH 51+
CH 50+
B11
A11
CH 56–
CH 55–
B10
A10
CH 56+
CH 55+
B9
A9
CH 61–
CH 60–
B8
A8
CH 61+
CH 60+
B7
A7
CH 66–
CH 65–
B6
A6
CH 66+
CH 65+
B5
A5
CH 71–
CH 70–
B4
A4
CH 71+
CH 70+
B3
A3
CH 76–
CH 75–
B2
A2
CH 76+
CH 75+
B1
A1
C14
D14
E14 CH 49–
CH 47–
CH 48–
C12
D12
E12 CH 54–
CH 52–
CH 53–
C16 CH 42–
CH 43–
A17 CH 42–
CH 43–
CH 4–
CH 2–
CH 3–
CH 4+
CH 2+
CH 3+
CH 9–
CH 7–
CH 8–
CH 9+
CH 7+
CH 8+
CH 14–
CH 12–
CH 13–
CH 14+
CH 12+
CH 13+
CH 19–
CH 17–
CH 18–
CH 19+
CH 17+
CH 18+
CH 24+
CH 22+
CH 23+
CH 29–
CH 27–
CH 28–
CH 34+
CH 32+
CH 33+
CH 39–
CH 37–
CH 38–
CH 39+
CH 37+
CH 38+
CH 24–
CH 22–
CH 23–
CH 29+
CH 27+
CH 28+
CH 34–
CH 32–
CH 33–
CH35+
Accessories
Table 1. NI Accessories for the NI 2526
Accessory Part Number
DIN160 to 50-pin D-SUB switch cable, 1 m 782417-03
DIN160 to DIN160 switch cable, 1 m 782417-02
NI PXIe-2526 Specifications | © National Instruments | 7

Table 1. NI Accessories for the NI 2526 (Continued)
Accessory Part Number
DIN160 to bare wire switch cable, 1 m 782417-01
Relay replacement kit for IME02TS Relays 782461-10
Compliance and Certifications
Safety
This product is designed to meet the requirements of the following electrical equipment safety
standards for measurement, control, and laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA 61010-1
Note For UL and other safety certifications, refer to the product label or the Online
Product Certification section.
Electromagnetic Compatibility
This product meets the requirements of the following EMC standards for electrical equipment
for measurement, control, and laboratory use:
• EN 61326-1 (IEC 61326-1): Class A emissions; Basic immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• EN 55022 (CISPR 22): Class A emissions
• EN 55024 (CISPR 24): Immunity
• AS/NZS CISPR 11: Group 1, Class A emissions
• AS/NZS CISPR 22: Class A emissions
• FCC 47 CFR Part 15B: Class A emissions
• ICES-001: Class A emissions
Note In the United States (per FCC 47 CFR), Class A equipment is intended for
use in commercial, light-industrial, and heavy-industrial locations. In Europe,
Canada, Australia, and New Zealand (per CISPR 11), Class A equipment is intended
for use only in heavy-industrial locations.
Note Group 1 equipment (per CISPR 11) is any industrial, scientific, or medical
equipment that does not intentionally generate radio frequency energy for the
treatment of material or inspection/analysis purposes.
Note For EMC declarations, certifications, and additional information, refer to the
Online Product Certification section.
8| ni.com | NI PXIe-2526 Specifications

CE Compliance
This product meets the essential requirements of applicable European Directives, as follows:
• 2006/95/EC; Low-Voltage Directive (safety)
• 2014/30/EU; Electromagnetic Compatibility Directive (EMC)
Online Product Certification
Refer to the product Declaration of Conformity (DoC) for additional regulatory compliance
information. To obtain product certifications and the DoC for this product, visit ni.com/
certification, search by model number or product line, and click the appropriate link in the
Certification column.
Environmental Management
NI is committed to designing and manufacturing products in an environmentally responsible
manner. NI recognizes that eliminating certain hazardous substances from our products is
beneficial to the environment and to NI customers.
For additional environmental information, refer to the Minimize Our Environmental Impact
web page at ni.com/environment. This page contains the environmental regulations and
directives with which NI complies, as well as other environmental information not included in
this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the product life cycle, all NI products must be
disposed of according to local laws and regulations. For more information about
how to recycle NI products in your region, visit ni.com/environment/weee.
电子信息产品污染控制管理办法（中国 RoHS）
中国客户 National Instruments 符合中国电子信息产品中限制使用某些有害物
质指令(RoHS)。关于 National Instruments 中国 RoHS 合规性信息，请登录
ni.com/environment/rohs_china。(For information about China RoHS
compliance, go to ni.com/environment/rohs_china.)
NI PXIe-2526 Specifications | © National Instruments | 9

Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for information on National Instruments trademarks.
Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents
covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the
patents.txt file on your media, or the National Instruments Patent Notice at ni.com/patents. You can find information about
end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer to the Export
Compliance Information at ni.com/legal/export-compliance for the National Instruments global trade compliance policy and
how to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES
AS TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS.
U.S. Government Customers: The data contained in this manual was developed at private expense and is subject to the
applicable limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.
© 2014 National Instruments. All rights reserved.
376206A-01 Dec14
