Page 1.1
VERY HIGH DENSITY MULTIPLEXER MODULE 40-611A
pickering SECTION 1 - TECHNICAL SPECIFICATION
SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
PXI Very High Density Multiplexer 40-611A
ISSUE 1.0 FEB 2019
Supported by eBIRST
eBIRST switching system test tools simplify fault-nding by quickly
testing the system and graphically identifying the faulty relay.
For more information go to: pickeringtest.com/ebirst
• Highest Density 2A Multiplexers in PXI
• Available as a 158-Channel 1-Pole or a
79-Channel 2-Pole Multiplexer
• Low Cost per Channel
• Maximum Current 2A Hot or Cold Switching
• Switch up to 300VDC/250VAC and up to 60W
Max Power
• VISA, IVI & Kernel Drivers Supplied for Windows
• Supported by PXI or LXI Chassis
• Supported by
eBIRST ™
• 3 Year Warranty
1
4
5
C
Isolation
Switch
158
2
3
40-611A-001 Multiplexer Module
(158-Channel 1-Pole)
40-611A-002 Multiplexer Module
(79-Channel 2-Pole)
1.1
2.1
C.1
79.1
Isolation
Switch
1.2
2.2
C.2
79.2
The 40-611A Very High Density multiplexer module is available
in 158-Channel 1-Pole or 79-Channel 2-Pole congurations. It
uses high quality electro-mechanical signal relays allowing the
switching of current up to 2A and voltage up to 300VDC/250VAC.
The module is suitable for signal routing in high channel count
ATE and data acquisition systems. Connections are made via a
front panel 160-pin DIN 41612 connector.
The 40-611A can be operated as a conventional multiplexer
with break-before-make action when a new channel is selected.
Alternatively, the 40-611A-002 can be supplied as a variant that
allow multiple channels to be simultaneously selected.
Note: Multiple channel selection is not available for the 40-611A-
001 multiplexer.
Model 40-611A channel selection congurations have been
revised from model 40-611. The 40-611A defaults to single
channel selection with the 40-611A-002 multiple channel selection
variant dened by use of a sufx.
It should be noted that the isolation relays operate automatically
when a multiplexer channel is energized.
Larger multiplexers may be constructed by daisy chaining the
common signals from multiple modules (see example diagram
overleaf). Built in automatic isolation switching connects only the
currently active multiplexer to the analogue common, this minimizes
capacitive loading and leakage currents in large multiplexer systems.
Automatic isolation switching only applies to single channel selection
mode, for versions with multi channel selection, the isolation relays
are controlled separately from the channel relays. To prolong contact
life of the isolation relays it is strongly advised that they are cold
switched.

Page 1.2 VERY HIGH DENSITY MULTIPLEXER MODULE 40-611A
pickering
SECTION 1 - TECHNICAL SPECIFICATION
Very High Density MUX – 40-611A
pickeringtest.com
Overview
1
3
4
C
Isolation
Switch
158
2
40-611-001
158-Channel
1-Pole MUX
#1
Channel 1
Channel 2
Channel 3
Channel 4
Channel 158
1
3
4
C
Isolation
Switch
158
2
40-611-001
158-Channel
1-Pole MUX
#2
Channel 159
Channel 160
Channel 161
Channel 162
Channel 316
1
3
4
C
Isolation
Switch
158
2
40-611-001
158-Channel
1-Pole MUX
#3
Channel 317
Channel 318
Channel 319
Channel 320
Channel 474
Common
Three 40-611A-001 Modules Can Be Daisy-Chained
to Create a 474-Channel 1-Pole Multiplexer
