National Instruments RMX-410 Series User manual

RMX-4101

USER MANUAL
This Manual Covers Models:
RMX-4101 RMX-4102 RMX-4104
Rackmount Programmable DC Power Supplies
200W/400W/800W
Built-in USB, RS-232, RS-485, LAN Interface
RMX-410x
NATIONAL
INSTRUMENTS

Worldwide Technical Support and Product Information
ni.com
Worldwide Offices
Visit ni.com/niglobal to access the branch office websites, which provide up-to-date
contact information, support phone numbers, email addresses, and current events.
National Instruments Corporate Headquarters
11500 North Mopac Expressway Austin, Texas 78759-3504 USA Tel: [phone]
For further support information, refer to the NI Services appendix. To comment on NI
documentation, refer to the NI website at ni.com/info and enter the Info Code feedback.
© 2017-2018 National Instruments. All rights reserved.

Table of Contents
CHAPTER 1: GENERAL INFORMATION 13
1.1 User Manual Content ................................................................................................................. 13
1.2 Introduction................................................................................................................................... 13
1.2.1 General Description ......................................................................................................... 13
1.2.3 Features and Options ...................................................................................................... 13
1.2.4 Multiple Output Power System .................................................................................... 14
1.2.6 Analog Voltage Programming and Monitoring ..................................................... 14
1.2.7 Parallel Operation ............................................................................................................. 14
1.2.8 Output Connections ........................................................................................................ 14
1.2.9 Cooling and Mechanical Construction ...................................................................... 14
1.3.1 General .................................................................................................................................. 15
1.3.2 Serial Link Cable ................................................................................................................ 15
1.3.3 Misc. Hardware .................................................................................................................. 15
1.3.4 AC Cables .............................................................................................................................. 15
1.3.5 Serial Port Cables ............................................................................................................... 15
CHAPTER 2: SPECIFICATIONS 16
2.1 RMX-4101 Series Specifications.............................................................................................. 17
2.2 RMX-4102 Series Specifications.............................................................................................. 21
2.3 RMX-4104 Series Specifications ............................................................................................. 25
2.4 RMX-410x Mechanical................................................................................................................28
2.4.1 Rackmount Dimensions................................................................................................... 29
CHAPTER 3: INSTALLATION 31
3.1 General ............................................................................................................................................ 31
3.2 Preparation for Use..................................................................................................................... 31
3.3 Initial Inspection .......................................................................................................................... 31
3.4 Rackmount..................................................................................................................................... 31
3.5 Location, Mounting and Cooling........................................................................................... 32
3.5.1 Power Supply Rear Support Bracket ........................................................................... 32
3.6 AC Source Requirements.......................................................................................................... 32
3.7 AC Input Power Connection .................................................................................................... 32
3.7.1 AC Input Connector ........................................................................................................... 32
3.7.2 AC Input Cord ...................................................................................................................... 33
3.8 Turn-On Checkout Procedure................................................................................................. 33
3.8.1 General................................................................................................................................... 33
3.8.2 Prior to Operation.............................................................................................................. 33
3.8.3 Constant Voltage Check..................................................................................................34
3.8.4 Constant Current Check ..................................................................................................34
3.8.5 OVP Check............................................................................................................................34
3.8.6 UVL Check ............................................................................................................................34
3.8.7 Foldback Check .................................................................................................................. 35
3.9 Connecting the Load..................................................................................................................35
3.9.1 Load Wiring ..........................................................................................................................35
3.9.2 Current Carrying Capacity ..............................................................................................35
3.9.3 Wire Termination................................................................................................................ 37
3.9.4 Noise and Impedance Effects........................................................................................ 37
3.9.5 Inductive Loads .................................................................................................................. 37
3.9.6 Making the Load Connections ...................................................................................... 37
3.9.7 Connecting Single Loads, Local Sensing (default).................................................39
3.9.8 Connecting Single Loads, Remote Sensing.............................................................. 39
3.9.9 Connecting Multiple Loads, Radial Distribution Method....................................40

3.9.10 Multiple Load Connection with Distribution Terminals.....................................40
3.9.11 Grounding Outputs......................................................................................................... 41
3.10 Local and Remote Sensing..................................................................................................... 41
3.10.1 Sense Wiring ...................................................................................................................... 41
3.10.2 Local Sensing..................................................................................................................... 42
3.10.3 Remote Sensing................................................................................................................ 42
3.10.4 J2 Sense Connector Technical Information............................................................ 43
3.11 Repackaging for Shipment..................................................................................................... 43
CHAPTER 4: FRONT/REAR PANEL CONTROLS AND CONNECTORS 44
4.1 Introduction...................................................................................................................................44
4.2 Front Panel Display and Controls .........................................................................................44
4.3 Rear Panel Connectors ..............................................................................................................46
4.3.1 J1 Connector Terminal and Function..........................................................................48
4.3.2 J3 Connector Terminal and Function .........................................................................49
4.4 Front Panel Display Messages.................................................................................................50
4.5 Navigating the Main Menu..................................................................................................... 51
4.5.1 Introduction......................................................................................................................... 51
4.5.2 Exiting the Main Menu..................................................................................................... 52
4.6 Navigating Communication Menu........................................................................................ 52
4.6.1 Introduction......................................................................................................................... 52
4.6.2 Exiting the Communication Menu .............................................................................. 53
4.7 Navigating the Protection Menu ........................................................................................... 53
4.7.1 Introduction ......................................................................................................................... 53
4.7.2 Exiting the Protection Menu.......................................................................................... 53
CHAPTER 5: LOCAL OPERATION 54
5.1 Introduction...................................................................................................................................54
5.2 Standard Operation....................................................................................................................54
5.2.1 Constant Voltage Mode and Voltage Setting..........................................................54
5.2.2 Constant Current Mode and Current Setting.......................................................... 54
5.2.3 Automatic Crossover ........................................................................................................ 55
5.2.4 Output On/Off Control .................................................................................................... 55
5.2.5 Safe Start and Auto-Restart Modes............................................................................. 55
5.2.6 Viewing Software Revision............................................................................................. 55
5.3 Alarms and Protective Functions...........................................................................................56
5.3.1 Introduction.........................................................................................................................56
5.3.2 Over Voltage Protection..................................................................................................56
5.3.2.1 Setting the OVP Level ...................................................................................................56
5.3.2.2 Resetting the OVP Circuit............................................................................................ 57
5.3.3 Under Voltage Protection and Under Voltage Limit ............................................ 57
5.3.3.1 Setting the UVP/UVL Mode and Level .................................................................... 57
5.3.3.2 Activated UVP Alarm..................................................................................................... 57
5.3.4 Foldback Protection ......................................................................................................... 57
5.3.4.1 Setting the Foldback Protection..............................................................................58
5.3.4.2 Activated FOLD Alarm.................................................................................................. 58
5.3.5 Protection Delay.................................................................................................................58
5.3.5.1 Setting the Protection Delay......................................................................................58
5.3.6 Over Temperature Protection ....................................................................................... 58
5.3.7 AC Fail Alarm........................................................................................................................ 58
5.4 Series Operation .......................................................................................................................... 59
5.4.1 Series Connection for Increased Output Voltage................................................... 59
5.4.2 Series Connection for Positive and Negative Output Voltage .......................... 60
5.4.3 Remote Programming in Series Operation..............................................................60

5.5 Parallel Operation........................................................................................................................ 61
5.5.1 Introduction......................................................................................................................... 61
5.5.2 Basic Parallel Operation................................................................................................... 61
5.5.2.1 Master Unit Set Up ......................................................................................................... 61
5.5.2.2 Slave Unit Set Up............................................................................................................ 62
5.5.2.3 Setting Over Voltage Protection............................................................................... 62
5.5.2.4 Setting Foldback Protection ......................................................................................62
5.5.2.5 Connection to Load....................................................................................................... 62
5.5.3 Advanced Parallel Operation.........................................................................................64
5.5.3.1 Master Unit Set Up .........................................................................................................64
5.5.3.2 Slave Unit Set Up............................................................................................................64
5.6 Daisy-Chain Connection ........................................................................................................... 65
5.7 Rear Panel (J3 Connector) Functions and Settings.......................................................... 65
5.7.1 External Shut Off Function..............................................................................................66
5.7.2 Interlock Function - Analog On/Off. (Enable/Disable) ..........................................66
5.7.3 Auxiliary Programmed Function Pin 1 and Pin 2.................................................... 67
5.7.4 Power Supply OK Signal................................................................................................... 68
5.8 Rear Panel (J1 Connector) Functions....................................................................................68
5.8.1 CV/CC Signal.........................................................................................................................68
5.9 Parameter Setting Memory ..................................................................................................... 69
5.9.1 Default Setting ....................................................................................................................69
5.9.2 Reset .......................................................................................................................................69
5.9.3 Last Setting Memory ........................................................................................................ 69
5.9.4 Save <1..4>............................................................................................................................ 70
5.9.5 Recall <1..4> .........................................................................................................................70
CHAPTER 6: REMOTE ANALOG PROGRAMMING 72
6.1 Introduction...................................................................................................................................72
6.2 Local/Remote Analog Control................................................................................................72
6.3 Local/Remote Analog Indication........................................................................................... 72
6.4 Remote Voltage Programming of Output Voltage and Current ................................ 73
6.5 Remote Resistor Programming of Output Voltage and Output Current ................ 74
6.6 Programming Monitoring of Output Voltage (V_MON) and Current (I_MON).... 75
CHAPTER 7: Serial RS232/RS485 and USB Interface 76
7.1 Introduction ................................................................................................................................... 76
7.2 Configuration................................................................................................................................ 76
7.2.1 Default Setting .................................................................................................................... 76
7.2.2 Address Setting................................................................................................................... 76
7.2.3 Communication Interface Selection .......................................................................... 76
7.2.4 Baud Rate Setting............................................................................................................... 77
7.2.5 Language Selection (RS232/RS485, USB) .................................................................. 77
7.2.6 Setting Unit in Remote, Local Lockout or Local Mode .........................................77
7.3 Rear Panel RS232/485 Connector...........................................................................................78
7.4 Connectig Power Supply To RS232 Or RS485 BUS...........................................................79
7.5 Rear Panel USB Connector........................................................................................................80
7.5.1 USB Getting Started...........................................................................................................80
7.6 Multi Power Supply Connection to RS232, RS485, LAN, or USB.................................. 80
7.7 GEN Protocol (GEN series communication language) .................................................... 81
7.7.1 Data Format .......................................................................................................................... 81
7.7.2 End of Message....................................................................................................................81
7.7.3 Command Repeat............................................................................................................... 81
7.7. 4 Che ck su m .............................................................................................................................. 81
7.7.5 Acknowledge ....................................................................................................................... 81

7.7.6 Backspace.............................................................................................................................. 81
7.7.7 Error Mess ages ..................................................................................................................... 81
7.8 GEN Command Set Description.............................................................................................. 82
7.8.1 General guides ....................................................................................................................82
7.8.2 Command Set Categories ...............................................................................................82
7.8.3 Identification Commands ...............................................................................................82
7.8.4 Initialization Commands................................................................................................. 83
7.8.5 Output Commands............................................................................................................ 83
7.8.6 Global Output Commands .............................................................................................85
7.8.7 Auxiliary Commands......................................................................................................... 87
7.8.8 Status Commands.............................................................................................................. 87
7.9 Serial Communication Test Set-Up........................................................................................88
7.10 SCPI Protocol................................................................................................................................ 88
7.10.1 Data Format........................................................................................................................88
7.10.2 End of Message.................................................................................................................88
7.10.3 End of Command ............................................................................................................. 88
7.10.4 Checksum............................................................................................................................ 89
7.10.5 SCPI Requirements........................................................................................................... 89
7.10.6 SCPI Command Hierarchy ............................................................................................. 89
7.10.7 Header..................................................................................................................................89
7.10.8 Data Formats......................................................................................................................90
7.10.9 Character Data...................................................................................................................90
7.10.10 Commands Notes...........................................................................................................90
7.11 SCPI Common Commands......................................................................................................90
7.12 SCPI Subsystem Commands...................................................................................................95
7.12.1 Output Subsystem ...........................................................................................................95
7.12.2 Instrument Subsystem ...................................................................................................98
7.12.3 Voltage Subsystem ..........................................................................................................98
7.12.4 Current Subsystem..........................................................................................................100
7.12.5 Measure Subsystem........................................................................................................101
7.12.6 DISPlay Subsystem..........................................................................................................102
7.12.7 INITiate Subsystem .........................................................................................................103
7.12.8 LIST Subsystem ................................................................................................................103
7.12.9 STATus Subsystem ...........................................................................................................105
7.12.10 SYSTem Subsystem.......................................................................................................107
7.12.11 TRIGger Subsystem .......................................................................................................108
7.12.12 WAVE Subsystem ...........................................................................................................109
7.12.13 Global Subsystem.......................................................................................................... 110
7.13 Command Summary................................................................................................................ 111
CHAPTER 8: ADVANCED FUNCTIONS 115
8.1 Introduction.................................................................................................................................. 115
8.2 FIX Mode........................................................................................................................................ 115
8.3 LIST Mode...................................................................................................................................... 116
8.4 WAVE Mode .................................................................................................................................. 117
8.5 Trigger ............................................................................................................................................ 118
8.5.1 Input Trigger ....................................................................................................................... 118
8.5.2 Output Trigger................................................................................................................... 119
8.6 Transient Waveform Example ................................................................................................ 119
8.6.1 Wave Programing ............................................................................................................. 119
8.6.2 Wave Execution via Communication PC .................................................................. 119
8.6.3 Wave Execution via Front Panel .................................................................................120
8.7 Additional Examples .................................................................................................................120
8.7.1 List Example......................................................................................................................... 120

8.7.2 Waveform Example .......................................................................................................... 120
CHAPTER 9: STATUS, FAULT AND SRQ REGISTERS 121
9.1 General ...........................................................................................................................................121
9.2 Power Supply Status Structure ..............................................................................................122
9.3 Condition Registers ...................................................................................................................122
9.3.1 Fault Register .....................................................................................................................122
9.3.2 Status Register ...................................................................................................................123
9.4 Conditional, Enable and Event Registers ...........................................................................123
9.4.1 Conditional Registers.......................................................................................................123
9.4.2 Event Registers...................................................................................................................123
9.4.3 Enable Register ..................................................................................................................123
9.5 Service Request ..........................................................................................................................123
9.6 Standard Event Status Group .................................................................................................124
9.6.1 Register Functions ............................................................................................................124
9.6.2 Register Commands.........................................................................................................124
CHAPTER 10: MAINTENANCE 125
10.1 Introduction................................................................................................................................125
10.2 Units Under Warranty.............................................................................................................125
10.3 Periodic Maintenance.............................................................................................................125
10.4 Adjustments and Calibration...............................................................................................125
10.5 Parts Replacement and Repairs ..........................................................................................125
10.6 Troubleshooting .......................................................................................................................125
10.7 Fuse Rating .................................................................................................................................126
USER MANUAL INDEX 128

8
NATIONAL
INSTRUMENTS
Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits for electromagnetic
compatibility (EMC) stated in the product specifications. These requirements and limits provide
reasonable protection against harmful interference when the product is operated in the intended
operational electromagnetic environment.
This product is intended for use in industrial locations. However, harmful interference may occur
in some installations, when the product is connected to a peripheral device or test object, or if
the product is used in residential or commercial areas. To minimize interference with radio and
television reception and prevent unacceptable performance degradation, install and use this
product in strict accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved by National
Instruments could void your authority to operate it under your local regulatory rules.
Safety
This product is designed to meet the requirements of the following standards of safety for
test and measurement equipment:
* IEC 61010-1, EN 61010-1
* UL 61010-1, CSA 61010-1
Note: For UL and other safety certifications, refer to the product label or the Online
Product Certification section.
Electromagnetic Compatibility
This product meets the requirements of the following EMC standards for electrical equipment
for measurement, control, and laboratory use:
* EN 61326-1 (IEC 61326-1): Class A emissions; Basic immunity
* EN 55011 (CISPR 11): Group 1, Class A emissions
* EN 55022 (CISPR 22): Class A emissions
* EN 55024 (CISPR 24): Immunity
* AS/NZS CISPR 11: Group 1, Class A emissions
* AS/NZS CISPR 22: Class A emissions
* FCC 47 CFR Part 15B: Class A emissions
* ICES-001: Class A emissions
Note: In the United States (per FCC 47 CFR), Class A equipment is intended for use in commercial,
light-industrial, and heavy-industrial locations. In Europe, Canada, Australia and New Zealand
(per CISPR 11) Class A equipment is intended for use only in heavy-industrial locations.
Note: Group 1 equipment (per CISPR 11) is any industrial, scientific, or medical equipment that
does not intentionally generate radio frequency energy for the treatment of material or inspection/
analysis purposes.
Note: For EMC declarations and certifications, and additional information, refer to the Online
Product Certification section.

9
NATIONAL
INSTRUMENTS
CE Compliance
This product meets the essential requirements of applicable European Directives as follows:
* 2014/35/EC; Low-Voltage Directive (safety)
* 2014/30/EU; Electromagnetic Compatibility Directive (EMC)
Online Product Certification
Refer to the product Declaration of Conformity (DoC) for additional regulatory compliance
information. To obtain product certifications and the DoC for this product, visit ni.com/
certification, search by model number or product line, and click the appropriate link in the
Certification column.
Environmental Management
NI is committed to designing and manufacturing products in an environmentally responsible
manner. NI recognizes that eliminating certain hazardous substances from our products is beneficial
to the environment and to NI customers.
For additional environmental information, refer to the NI and the Environment Web page at
ni.com/environment.This page contains the environmental regulations and directives with which
NI complies, as well as other environmental information not included in this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers: At the end of the product life cycle, all products must be sent to a WEEE recycling
center. For more information aboutWEEE recycling centers, National InstrumentsWEEE initiatives,
and compliance withWEEE Directive 2002/96/EC onWaste and Electronic Equipment, visit ni.com/
environment/weee.

10
NATIONAL
INSTRUMENTS
CAUTION:
RMX-410x
series units are not authorized for use as critical component in nuclear control systems,
life support systems or equipment for use in hazardous environments without the express written
approval of the National Instruments.
OVERVOLTAGE CATEGORY AND ENVIRONMENTAL CONDITIONS
The RMX-410x series units have been evaluated to Overvoltage category II.
The RMX-410x series units are intended for use in the following operation conditions:
* Indoor use
* Pollution degree 2
* Max. operational altitude: 3000m above sea level
* Ambient temperature: 0°C-50°C.
GROUNDING
RMX-410X series units are Class I product.To minimize electrical shock hazard, the RMX-410xseries
units must be connected to an electrical ground. The instruments must be connected to the AC
power supply mains through a standard certified three-wire power cable, with the ground wire
firmly connected to an electrical ground (safety ground) at the power outlet. Any interruption of
the protective ground conductor or disconnection of the protective earth terminal will cause a
potential shock hazard that might cause personal injury.
LIVE CIRCUITS
Operating personnel must not remove the RMX-410x series unit cover.
No internal adjustment or component replacement is allowed by non-NI qualified service personnel.
Never replace components with power cable connected. To avoid injuries, always disconnect
power, discharge circuits and remove external voltage sources before touching components.

11
NATIONAL
INSTRUMENTS
PARTS SUBSTITUTIONS & MODIFICATIONS
Parts substitutions and modifications are by authorized NI service personnel only. For repairs or
modifications, the instrument must be returned to NI service facility.
AC INPUT
Do not connect RMX-410x series unit to mains supply exceeding the input voltage and frequency
rating. The input voltage and frequency rating is: 100-240V~, 50/60Hz. For safety reasons, the
mains supply voltage fluctuations should not exceed +/-10% of nominal voltage.
ENERGY HAZARD
The main output of RMX-410x series units is capable of providing hazardous energy. Due to
hazardous energy level the output and connections therefore must not be user accessible.
Manufacturer's final equipment must provide protection to service personnel against inadvertent
contact with output bus bars.
FUSE
Internal fuse is sized for fault protection and if a fuse was opened it would indicate that service is
required. Fuse replacement should be made by qualified technical personnel.
Refer to maintenance instructions in Chapter 10 for fuse ratings.
WARNING:
There is electric shock hazard when the power supply output is adjusted above 60VDC
Ensure that there is no possibility to touch simultaneously one of the output pins and earth (including
the power supply’s metal enclosure) nor to touch simultaneously one of the output pins and metal
parts of any external products supplied by the power supply when the output is adjusted above 60VDC.
Note: The protection provided by the RMX-410x can be impaired if it is used in a manner not
described in this document.

12
NATIONAL
INSTRUMENTS
SYMBOLS
Caution, risk of danger. Instruction manual symbol. The instrument will be marked
with this symbol when it is necessary for the user to refer to the instruction manual.
Indicates ground terminal.
Protective Conductor Terminal.
ON (Supply).
OFF (Supply).
Standby (Supply) .
Direct current (DC).
Alternate current (AC).
Denotes hazard. An attention to a procedure is called. Not following the procedure
correctly could result in personal injury. A WARNING sign should not be skipped and
all indicated conditions must be fully understood and met.
Denotes hazard. An attention to a procedure is called. Not following the procedure
correctly could result in damage to the equipment.
WARNING:
There is a potential shock hazard when using a power supply with an output voltage greater than
60VDC. Do not turn ON power supply when output voltage is above 60VDC without output bus-bars
and output connectors protection assembled. Turn OFF power supply or disconnect power supply
from AC mains before making or changing any rear panel connection.

13
NATIONAL
INSTRUMENTS
CHAPTER 1: GENERAL INFORMATION
1.1 User Manual Content
This user's manual contains the operating instructions, installation instructions and specifications
of the RMX-410x Series 200W, 400W, and 800W power supply series. The instructions refer to the
standard power supplies, including the built-in USB and RS232/485 serial communication. For
information related to operation with the LAN, refer to User Manual for power supply LAN.
1.2 Introduction
1.2.1 General Description
RMX-410x Series power supplies are wide output range, high performance switching power supplies.
The RMX-410x Series is power factor corrected and operates from worldwide AC voltage range
continuously. Output voltage and current are continuously displayed and LED indicators show
the complete operating status of the power supply. The Front Panel controls allow the user to set
the output parameters, the protection levels (Over-Voltage protection, Under-Voltage protection
and Foldback) and preview the settings. The rear panel includes the necessary connectors to
control and monitor the power supply operation by remote analog signals or by the built-in serial
communication USB, LAN, and RS232/485.
1.2.2 Models Covered by this Manual
Model Voltage range (V) Current range (A) Model Voltage range (V) Current range (A)
RMX-4101 0-20 0-10 RMX-4101 0-60 0-3.5
RMX-4102 0-20 0-20 RMX-4102 0-60 0-7
RMX-4104 0-20 0-40 RMX-4104 0-60 0-14
RMX-4101 0-36 0-6 RMX-4101 0-100 0-2
RMX-4102 0-36 0-12 RMX-4102 0-100 0-4
RMX-4104 0-36 0-24 RMX-4104 0-100 0-8
1.2.3 Features and Options
• Constant Voltage / Constant Current with automatic crossover.
• Active Power Factor correction.
• Universal Input Voltage 85-265Vac, continuous operation.
• Embedded Microprocessor Controller.
• Built in USB & RS232/485 Interface.
• Voltage & Current high resolution adjustment by digital Encoders.
• High resolution 16 bit ADCs & DACs.
• Software Calibration (no internal trimmers / potentiometers).
• Last Setting Memory.
• Independent Remote ON/OFF (Opto-Isolated) and Remote Enable/Disable.
• Parallel operation (Master/Slave) with Active current sharing.
• Remote sensing to compensate for voltage drop of power leads.
• External Analog Programming and Monitoring (0-5V or 0-10V, user selectable).
• Cooling fan speed control for low noise and extended fan life.
• LAN interface (SCPI compatible).

14
NATIONAL
INSTRUMENTS
1.2.4 Multiple Output Power System
The RMX-410x Series power supplies series can be configured into a programmable power system
of up to 31 units using the built-in LAN, USB or RS232/RS485 communication port in the power
supply and the RS485 linking cable provided with each power supply.
In a LAN system, each power supply can be controlled using the LAN controller (installed).
1.2.5 Control via the USB or RS232/485 Communication Ports
The following parameters can be programmed via the serial communication port:
•Output voltage setting.
•Output current setting.
•Output voltage measurement.
•Output current measurement.
•Output on/off control.
•Foldback protection setting.
•Over-voltage protection setting and readback.
•Under-Voltage protection setting and readback.
•Under-Voltage limit setting and read back.
•Power-supply start up mode (last setting or safe mode).
1.2.6 Analog Voltage Programming and Monitoring
Analog inputs and outputs are provided at the rear panel for analog control of the power supply.
The output voltage and the current limit can be programmed by analog voltage or by resistor,
and can be monitored by analog voltage. The power supply output can be remotely set to On
or Off and analog signals monitor the proper operation of the power supply and the mode of
operation (CV/CC).
1.2.7 Parallel Operation
Up to six RMX-410x Series power supplies of the same output voltage and current rating can be
paralleled in master-slave configuration with automatic current sharing to increase available power.
1.2.8 Output Connections
Output connections are made to rear panel bus-bars. Either the positive or negative terminal
may be grounded or the output may be floated. The power supplies shall not float outputs more
than +/- 100VDC above / below chassis ground. Contact factory for assistance with higher float
voltage applications.
Local or remote sense may be used. In remote sense, the voltage drop on the load wires should
be minimized. Refer to the specifications for the maximum voltage drop value.
1.2.9 Cooling and Mechanical Construction
The RMX-410x Series is cooled by an internal fan. At installation, care must be taken to allow
free air flow into the power supply via the front panel, and out of the power supply via the rear
panel.The RMX-410x Series power supply is a compact and lightweight unit which allows for easy
installation and gives a space saving solution for customer applications.

15
NATIONAL
INSTRUMENTS
CAUTION:
Observe all torque guidelines within this manual. Over torque may damage unit or accessories.
Such damage is not covered under manufacturers warranty.
1.3 Accessories
1.3.1 General
Accessories are delivered with the power supply or separately upon ordering,The list below shows
the possible accessories and ordering numbers.
1.3.2 Serial Link Cable
Serial link cable, for linking power supplies by RS485 communication is provided with the power
supply.
Cable description: 0.5m length, shielded, RJ-45 type plugs, 8 contacts (P/N: 786188-01).
1.3.3 Misc. Hardware
• Bus bars protection
• Connector protection
• Connector housing IPD1-06-D-K(SAMTEC)
• Connector housing IPD1-04-D-K(SAMTEC)
• Connector housing IPD1-02-D-K(SAMTEC)
• Contact pins P/N: CC79R-2024-01-L(SAMTEC)
• Rackmount kit for RMX-410x 2U DC power supplies, holds six supplies. P/N: 786186-01
• Blank panel for RMX-410x rackmount kit. P/N: 786187-01
1.3.4 AC Cables
AC cables are not provided with the power supply. If an AC cable is required, it should be ordered
according to the following:
Part no. Description
786204-1R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 1.5M North America
786204-2R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 2.5M North America
786206-1R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 1.5M Europe
786206-2R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 2.5M Europe
786205-1R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 1.5M Korea
786205-2R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 2.5M Korea
786207-1R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 1.5M China
786207-2R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 2.5M China
786208-1R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 1.5M Japan
786208-2R5 POWER CORD, AC, IEC C15 to C14, 100-240V, 2.5M Japan
786209-02 POWER CORD, AC, IEC C15 to NEMA 5-15P, 13A, 2.5m
786212-02 POWER CORD, AC, IEC C15 to Euro, 240V, 2.5m
786213-02 POWER CORD, AC, IEC C15 to UK, 240V, 2.5m
786211-02 POWER CORD, AC, IEC C15 to Korea, 240V, 2.5m
786214-02 POWER CORD, AC, IEC C15 to China, 240V, 2.5m
786210-02 POWER CORD, AC, IEC C15 to Japan, 110V, 2.5m
1.3.5 Serial Port Cables
If a serial port cable is required, it should be ordered according to the description in section 7.2
* USB cables are not provided with the power supply.

16
NATIONAL INSTRUMENTS
2.1 RMX-4101 Series Specifications
RMX-4101
MODEL N/A 20-10 36-6 60-3.5 100-2
1. Rated output voltage(*1) V 20 36 60 100
2. Rated output current (*2) A 10 6 3.5 2
3. Rated output power W 200 216 210 200
CONSTANT VOLTAGE MODE 20-10 36-6 60-3.5 100-2
1. Max. Line regulation (*6) --- 0.01% of rated output voltage+2mV
2. Max. Load regulation (*7) --- 0.01% of rated output voltage+2mV
3. Ripple and noise (p-p, 20MHz) (*8) mV 50 50 50 80
4. Ripple r.m.s. 5Hz~1MHz mV 6 6 7 8
5. Temperature coefficient PPM/°C 30PPM/°C from rated output voltage, following 30 minutes warm-up.
6. Temperature stability --- 0.02% of rated Vout over 8hrs. interval following 30 minutes warm-up. Constant line, load & temp.
7. Warm-up drift --- Less than 0.05% of rated output voltage+2mV over 30 minutes following power on.
8. Remote sense compensation/wire V 1 2 3 5
9. Up-prog. Response time, 0~Vomax.(*9) mS 30 30 50 50
10. Down-prog. response time: Full load (*9)
mS
25 30 40 50
Time delay (*17) 250 320 380 1200
No load (*10) (*15)(*17) 65 85 100 250
No load (*10) (*16)(*17) 200 290 310 1100
11. Transient response time mS
Time for output voltage to recover within 0.5% of its rated output for a load change 10~90% of rated output current.
Output set-point: 10~100%, Local sense
Less than 1mS, for models up to and including 100V
12. Hold-up time (*19) --- 16mSec Typical.
1. Max. Line regulation (*6) --- 0.01% of rated output current+2mA
2. Max. Load regulation (*11) --- 0.01% of rated output current+5mA
3. Load regulation thermal drift --- Less than 0.05% of rated output current over 30 minutes following load change.
4. Ripple r.m.s. 5Hz~1MHz mA 15 8 4 3
5. Temperature coefficient PPM/°C 100PPM/°C from rated output current, following 30 minutes warm-up.
6. Temperature stability --- 0.05% of rated Iout over 8hrs. interval following 30 minutes warm-up. Constant line, load & temperature.
7. Warm-up drift --- Less than +/-0.1% of rated output current over 30 minutes following power on.
PROTECTIVE FUNCTIONS 20-10 36-6 60-3.5 100-2
1. Foldback protection --- Output shut-down when power supply change mode from CV to CC or CC to CV. User presetable.
Reset by AC input recycle in autostart mode or by OUTPUT button or by rear panel ENABLE, or by communication port.
2. Over-voltage protection (OVP) --- Inverter Shut down method. Reset by AC input recycle in autostart mode or by OUTPUT button or by rear panel ENABLE, or by
communication port.
3. Over -voltage trip point V 1~24 2~40 5~66 5~110
4. Output under voltage limit (UVL) --- Preset by front panel or communication port. Prevents from adjusting Vout below limit. Does not affect in analog programming.
5. Output under voltage protection (UVP) --- Output shut-down when power supply output voltage goes below UVP programming. User presetable.
Reset by AC input recycle in autostart mode or by OUTPUT button or by rear panel ENABLE, or by communication port.
6. Over temperature protection --- User selectable, latched or non latched.
CHAPTER 2: SPECIFICATIONS

17
NATIONAL INSTRUMENTS
ANALOG PROGRAMMING AND MONITORING
1. Vout voltage programming --- 0~100%, 0~5V or 0~10V, user selectable. Accuracy and linearity: +/-0.5% of rated Vout.
2. Iout voltage programming (*13) --- 0~100%, 0~5V or 0~10V, user selectable. Accuracy and linearity: +/-1% of rated Iout.
3. Vout resistor programming --- 0~100%, 0~5/10Kohm full scale, user selectable. Accuracy and linearity: +/-1% of rated Vout.
4. Iout resistor programming (*13) --- 0~100%, 0~5/10Kohm full scale, user selectable. Accuracy and linearity: +/-1.5% of rated Iout.
5. Shut Off (SO) control --- By electrical Voltage: 0~0.6V/4~15V or dry contact, user selectable logic.
6. Output current monitor (*13) --- 0~5V or 0~10V, user selectable. Accuracy: +/-1%.
7. Output voltage monitor --- 0~5V or 0~10V, user selectable. Accuracy: +/-1%.
8. Power supply OK signal --- 4~5V-OK, 0V-Fail. 500ohm series resistance.
9. Parallel operation (*20) --- Possible, up to 6 units in master/slave mode with single wire current balance connection.
10. Series operation --- 2 identical units (with external diodes).
11. CV/CC indicator --- Open collector. CC mode: On, CV mode: Off. Maximum voltage: 30V, maximum sink current: 10mA
12. Interlock (ILC) control ---
Enables/Disables the PS output by dry contact (Short: On, Open: Off, Source current: less than 0.5mA). Ena/Dis is activated by front panel.
13. Local/Remote mode Control --- By electrical signal or Open/Short: 0~0.6V or short: Remote, 2~15V or open: Local
14. Local/Remote mode Indicator --- Open collector (shunted by 36V zener). On (0~0.6V, 10mA sink current max.)-Remote. Off-Local (30V max.).
15.Trigger out --- Maximum low level output =0.8V, Minimum high level output =3.8V, Maximum high level output =5V,
Maximum source current =16mA, pulse =20μs Typical.
16.Trigger in --- Maximum low level input =1.2V, Minimum high level input =3.5V, Maximum high level input =5V, Maximum sink current
=16mA, positive edge, trigger: tw =10μs minimum, Tr/Tf =1μs maximum.
17. Programmed signal 1 --- Open collector, maximum voltage 25V,maximum sink current 100mA. (Shunted by 27V zener)
18. Programmed signal 2 --- Open collector, maximum voltage 25V,maximum sink current 100mA. (Shunted by 27V zener)
FRONT PANEL
1. Control functions
--- Multiple options with 2 Encoders
--- Vout/Iout manual adjust
--- OVP/UVL/UVP manual adjust
--- Protection Functions - OVP, UVL,UVP, Foldback, OCP, INT, SO
--- Communication Functions - Selection of LAN,RS232,RS485,USB
--- Communication Functions - Selection of Baud Rate, Address
--- Analog Control Functions - Selection Voltage/resistive programming, 5V/10V, 5K/10K programming
--- Analog Control Functions - Selection of Voltage/Current Monitoring 5V/10V, Output ON/OFF, Front Panel Lock.
2. Display --- Vout: 4 digits, accuracy: 0.5% of rated output voltage+/-1 count.
--- Iout: 4 digits, accuracy: 0.5% of rated output current+/-1 count.
3. Indications --- GREEN LEDs: FINE, MENU, PREV, PROT, REM, OUTPUT, CV, CC
--- RED LED: PROT (OVP, UVP, OTP, FOLD, AC FAIL).
4. Function buttons --- FINE, MENU, PREV, PROT, REM, OUTPUT
PROGRAMMING AND READBACK (RS232/485,USB, LAN)
1. Vout programming accuracy --- 0.05% of rated output voltage
2. Iout programming accuracy (*13) --- 0.1% of actual +0.1% of rated output current
3. Vout programming resolution --- 0.012% of full scale
4. Iout programming resolution --- 0.012% of full scale
5. Vout readback accuracy --- 0.05% of rated output voltage
6. Iout readback accuracy (*13) --- 0.1% of actual +0.3% of rated output current
7. Vout readback resolution --- 0.012% of full scale
8. Iout readback resolution --- 0.012% of full scale

18
NATIONAL INSTRUMENTS
RMX-4101 Series Specifications
RMX-4101
INPUT CHARACTERISTICS 20-10 36-6 60-3.5 100-2
1. Input voltage/freq. (*3) --- 85~265Vac continuous, 47~63Hz, single phase
2. Maximum Input current 100/200VAC (*4) (*18) --- 2.62/1.29 2.76/1.37 2.69/1.33 2.55/1.26
3. Power Factor (Typ) --- >0.99 at 100Vac, >0.98 at 200Vac,100% load
4. Efficiency (Typ) 100/200VAC (*4) (*18) % 77/79 79/80.5 79/80.5 79/81
5. Inrush current 100/200VAC (*5) --- Less than 15A/30A
ENVIRONMENTAL CONDITIONS
1. Operating temperature --- 0~50°C, 100% load.
2. Storage temperature --- -20~85°C
3. Operating humidity % 20~90% RH (no condensation).
4. Storage humidity % 10~95% RH (no condensation).
5. Altitude --- Maximum 3000m. Derate ambient temp above 2000m.
Operating: Maximum ambient temperature, From 2000m up to 3000m Ambient temperature 40°C.
SAFETY/EMC
1. Applicable standards: Safety ---
UL61010-1, EN61010-1, IEC61010-1. Design to meet UL60950-1, EN60950-1
10V≤Vout≤60V: Output,J1,J2,J3,J4,USB,LAN,IEEE/ISOLATED Analog are Non Hazardous
Vout=100V:Output,J1,J2 are Hazardous J3,J4,USB, IEEE/ISOLATED Analog ,LAN are Non Hazardous
EMC --- IEC/EN61326-1 (Built to meet EN55022/EN55024)
2. Withstand voltage ---
10≤Vout≤36V models: Input-Output&J1,J2,J3,J4,USB,LAN/IEEE/ISOLATED ANALOG: 4242VDC/1min; Input-Ground: 2828VDC/1min.
Output&J1,J2,J3,J4,USB,LAN/IEEE/ISOLATED ANALOG-Ground: 707VDC/1min.
60V,100V models: Input-Output&J1,J2: 4242VDC/1min; Input-J3,J4,USB,LAN/IEEE/ISOLATED Analog: 4242VDC/1min; Input-Ground: 2828VDC/1min.
Output&J1,J2- J3,J4,USB,LAN/IEEE/ISOLATED ANALOG :1910VDC/1min; Output&J1,J2-Ground: 1380VDC/1min.
J3, J4, USB/LAN/IEEE/ISOLATED ANALOG - Ground: 707VDC/1min;
3. Insulation resistance --- More than 100Mohm at 25°C, 70%RH.
4. Conducted emission --- IEC/EN61326-1 Industrial Location - B, FCC part 15-B, VCCI-B
5. Radiated emission --- IEC/EN61326-1 Industrial Location - A, FCC part 15-A, VCCI-A
MECHANICAL
1. Cooling --- Forced air cooling by internal fan.
2. Weight STANDARD Kg Less than 1.9Kg.
3. Dimensions (WxHxD) STANDARD mm H: 83, W: 70, D: 350 (excluding bus bars, handles…). (Refer to Outline drawing).

19
NATIONAL INSTRUMENTS
NOTES:
*1: Minimum voltage is guaranteed to maximum 0.1% of rated output voltage.
*2: Minimum current is guaranteed to maximum 0.2% of rated output current.
*3: For cases where conformance to various safety standards (UL, IEC, etc…) is required, to be described as 100-240Vac (50/60Hz).
*4: Ta=25°C with rated output power.
*5: Not including EMI filter inrush current, less than 0.2mSec at cold start Ta=25°C
*6: At 85~132Vac or 170~265VAC, constant load.
*7: From No-Load to Full-Load, constant input voltage. Measured at the sensing point in Remote Sense.
*8: Measured with JEITA RC-9131A (1:1) probe.
*9: From 10% to 90% or 90% to 10% of Rated Output Voltage, with rated resistive load.
*10: From 90% to 10% of Rated Output Voltage.
*11: For load voltage change, equal to the unit voltage rating, constant input voltage.
*13: The Constant Current programming, readback and monitoring accuracy do not include the warm-up and Load regulation thermal drift.
*14: Measured with JEITA RC-9131A (1:1) probe.
*15: For cases where the time interval between each down programming is longer than Td (time delay).
*16: For cases where the time interval between each down programming is shorter than Td (time delay).
*17: Td typical Minimum time between consecutive down programming cycles.
*18: PS with Lan and models decrease efficiency by 0.5% and increase input current by 0.5%.
*19: At rated output power.
*20: For Parallel operation more than 2 units 5% of total output current is requierd.
